Product
Data
38TXA (60 Hz)
Air Conditioner
with Puron
®
(R-410A)
Sizes 024 thru 060
Copyright 1999 Carrier Corporation Form 38TXA-4PD
Carrier’s WeatherMaker 38TXA with
Puron® provides a completely unique
collection of features which cannot be
matched by any other family of
equipment. The 38TXA family has been
designed as the first air conditioning
system utilizing Carrier’s unique Puron®
refrigerant. The environmentally sound
refrigerant allows you to make a
responsible decision in the protection of
the earth’s ozone layer. Carrier’s
WeatherMaker systems with Puron® are
certified by the independent Green Seal
organization.These systems also meet the
Energy Star® guidelines for energy
efficiency.
FEATURES/BENEFITS
WeatherArmor III System is a three
component system—The casing steel is
galvanized and coated with a layer of zinc
phosphate. A modified polyester powder
coating is then applied and baked on,
providing each unit with a hard, smooth
finish that will last for many years.
All screws on the cabinet exterior are
SermaGuard coated for a long lasting,
rust-resistant, quality appearance.
The coil is protected with an enhanced
coil guard. With spacing of 3/8 in. and
construction of coated 12 gage wire, the
guard helps to protect from inclement
weather (hail), vandalism, and incidental
damage.
Puron® Environmentally Sound
Refrigerant — Is Carrier’s exclusive
refrigerant designed to help protect the
environment. Puron® is an HFC
refrigerant which does not contain
chlorine that can harm the ozone layer.
The most important advantage of Puron®
refrigerantisthatithasnotbeenbannedin
future air conditioning systems as the
traditional refrigerant R-22 has been.
Puron® refrigerant is in service in
thousands of systems providing highly
reliable, environmentally sound
performance.
High Efficiency Performance — Is
delivered through a combination of
features including Carrier’s Puron®
refrigerant, unique scroll compressor, and
advancedheattransfersurfaces.Efficiency
ratings are 13 SEER (Seasonal Energy
EfficiencyRatio) with enhanced ratings of
upto14SEER.Sophisticatedheat transfer

2
Model number nomenclature
38TXA 024 3 0 1
Deluxe 13 SEER Split-System
Air Conditioner Packaging
Series
Nominal Capacity
024 — 24,000 Btuh 042 — 42,000 Btuh
030 — 30,000 Btuh 048 — 48,000 Btuh
036 — 36,000 Btuh 060 — 60,000 Btuh
Electrical
3 — 208/230-1
surfaces utilized in Carrier’s 38TXA
design allow heat to easily be transferred
to the outdoor air and requires less energy.
The unique scroll compressor found in the
38TXA design performs quietly and adds
to the overall efficiency of the system.
Finally Carrier’s unique Puron®
refrigerant operates more efficiently than
ordinary R-22 refrigerant found in other
systems. The efficiency levels provided by
the 38TXA provide end users with lower
costs of operation than traditional air
conditioning systems.
AssuredFutureService — Byutilizing
the environmentally sound refrigerant,
Puron®, 38TXA models will remain
serviceablewell intothefuture.TheClean
Air Act of 1990 has placed a cap on
production of most other refrigerants
which has scheduled reductions
beginning in 2004. The resulting cap in
production ultimately results in a
complete ban on many other refrigerants
innewequipment by theyear2010.These
changes, required by federal law, mean
the supply of other refrigerants may be
limited in the near future making Puron®
the correct choice when considering long
term serviceability.
Highly Reliable Performance — Is
delivered through the superior design of
the system and componentry. The
reliability of the 38TXA models has been
proven to provide the lowest incidence of
warranty service of any product in the
Carrier family in its past 3 years of
service. Long term reliability is assured
through the use of both high and low
pressureswitcheswhichwill not allowthe
system to operate in the event of a
significant change in operating pressure.
In doing this, the system is protected from
damage if an unusual condition arises.
Finally, Carrier includes a special liquid
line filter drier designed to trap moisture
and contaminants which could otherwise
shorten the life of the system.
Carrier’s Silencer System — Is one of
the most sought after features of the
38TXA family. Extremely low operating
sound is the result of special attention to
the air moving through the outdoor unit, a
specially designed sound enclosure
surrounding the compressor, and an
exclusive laminated plate beneath the
compressor to eliminate sound
transmission to the rest of the system.
Application Versatility — Carrier’s
systemsutilizing Puron®refrigerant have
the same application guidelines as other
systems.Applications which include long
line sets (50 to 175 ft) or applications
whichrequire the systemto operateat low
outdoor temperatures (below 55°F) are
approved under Carrier’s standard
guidelines.
Carrier Coils and Fan Coils to
Complete the System — Carrier
specially designs both the outdoor
product and indoor coil products to
operate with assured reliability and
performance.A wide range of indoor coil
options are listed in the ratings section of
this publication.
SpecialProtectiveDevices — Highand
low pressure switches and internal
protection in the compressor including
temperature and current sensing
overloads prevent operation under
potentially damaging circumstances. A
special liquid line filter drier designed to
trap nearly 4 times the volume of
contaminants of standard driers provides
superiorprotectionfrommoisturetrapped
in the system.
Electrical Range — 208/230 volt,
single phase only.
WideRangeofSizes — Availableinsix
sizes 2, 2-1/2, 3, 3-1/2, 4 and 5 tons.
Totally Enclosed Fan Motor —
Protected from adverse weather
conditions.
Unit Design — Enhanced copper and
aluminum heat transfer surfaces with
vertical air discharge to direct air up and
away from the area.
External Service Valves — Both
servicevalvesarebackseatingtypevalves
which are externally located. These
uniquevalves allowservice technicians to
evacuate or charge the system in less time
than standard service valves.
Easy Serviceability — Removal of one
panel provides access to both electrical
and refrigerant carrying components
simplifying installation and service.
AgencyApprovals — 38TXA models
are listed with UL, c-UL,ARI, CEC, and
CSA-EEV. Special endorsements have
also been awarded these products by
Green Seal an independent organization
monitoring environmental concerns and
Energy Star® which recognizes energy
efficient products.
Limited Warranty — A standard one
year warranty on parts with extended
warranty coverage on the compressor for
atotalof10years.Optionalwarrantiesare
available through your Carrier distributor.
M
A
N
U
F
A
C
T
U
R
E
R
C
E
R
T
I
F
I
E
D
T
O
A
R
I
A
S
C
O
M
P
L
Y
I
N
G
W
I
T
H
A
R
I
S
T
A
N
D
A
R
D
2
1
0
U
N
I
T
A
R
Y
A
I
R
C
O
N
D
I
T
I
O
N
I
N
G
E
Q
U
I
P
M
E
N
T
CERTIFICATION APPLIES ONLY WHEN THE
COMPLETE SYSTEM IS LISTED WITH ARI. REGISTERED QUALITY SYSTEM
As an ENERGY STAR® partner, Carrier Corporation
has determined that this product meets the ENERGY
STAR® guidelines for energy efficiency.
This product meets Green Seal criteria for
manufacturing, energy efficiency, sound levels,
and packaging.It contains no CFCs or HCFCs.

3
Physical data
* For tubing sets greater than 50 ft, consult Residential Split System Long-Line Application Guideline and Service Manual.
NOTE: See unit Installation Instructions for proper installation.
ACCURATER
®
PISTON CHART
* Piston listed is for any approved non-capillary tube coil combination. Piston is
shipped with outdoor unit and must be installed in approved indoor coil.
CHARGING SUBCOOLING (TXV-TYPE EXPANSION DEVICE * )
* Must be a Puron® (R-410A) approved hard shutoffTXV.
UNIT SIZE-SERIES 024-30 030-30 036-30 042-30 048-30 060-31
OperatingWeight (Lb)
220 213 243 253 301 337
COMPRESSOR
Copeland Manufacturer
Type
Scroll
REFRIGERANT Puron® (R-410A)
Control AccuRater® (Bypass Type)
Charge (Lb) 6.00 6.00 6.88 8.75 10.13 12.00
COND FAN Propeller Type, Direct Drive
Air Discharge Vertical
Air Qty (CFM) 2400 2400 2800 2800 3300 3300
Motor HP 1/8 1/8 1/5 1/5 1/4 1/4
Motor RPM 825 825 825 825 1100 1100
COND COIL Copper Tube, Aluminum Plate Fin
Face Area (Sq ft) 15.2 12.2 15.2 18.2 18.2 18.2
Fins per In. 25 25 25 25 20 20
Rows 111122
Circuits 222355
VALVE CONNECT. (In. ID) Sweat
Vapor 5/8 3/4
3/4
7/8 7/8 7/8
Liquid 3/8
REFRIGERANTTUBES* (In. OD)
Vapor (0–50 FtTube Length)
5/8 3/4
3/4
7/8
7/8 1-1/8
Vapor (Max Diameter for Long-
Line Applications)
7/8
7/8 7/8 1-1/8
1-1/8 1-1/8
Liquid (0–50 FtTube Length) 3/8
Liquid (For Long-Line
Applications)
3/8
UNIT SIZE-SERIES PISTON* IDENTIFICATION NO.
024-30 61
030-30 63
036-30 70
042-30 73
048-30 78
060-31 96
UNIT SIZE-SERIES REQUIRED SUBCOOLING (°F)
024-30 13
030-30 12
036-30 11
042-30 12
048-30 11
060-31 12

4
Accessories
* Fan motor with ball bearings required.
† See low-ambient controller Installation Instructions for application.
‡ Do not use hard shutoff TXV with Liquid-Line Solenoid Valve.
Accessory usage guideline
* ForTubing line sets greater than 50 ft, refer to Residential Split System Long-Line Application Guideline and Service Manual.
† Only when low-pressure switch is used.
‡ Required for Low-Ambient Controller (full modulation feature) and MotorMaster® Control only.
ORDERING NO. DESCRIPTION
KAATD0101TDR
Time-Delay Relay — All Sizes
KSALA0301410 Low-Ambient Pressure Switch — All Sizes
P251-0083 (RCD) Low-Ambient Controller — All Sizes
32LT660004* (RCD) MotorMaster® Control — All Sizes
KAAFT0101AAA† Evaporator Freeze Thermostat — All Sizes
KAAWS0201AAA† Winter Start Control — All Sizes
KSACY0101AAA Cycle Protector — All Sizes
KSAHS1501AAA Start Assist — Capacitor and Relay — Sizes 024–042
KSAHS1601AAA Start Assist — Capacitor and Relay — Sizes 048, 060
KAACS0201PTC Start Assist — PTC — All Sizes
KAACH1201AAA Crankcase Heater — Sizes 024–042
Standard Crankcase Heater — Sizes 048, 060
KSATX0201HSZ‡ Thermostatic Expansion Valve (Hard Shutoff) — Sizes 024, 030
KSATX0301HSZ‡ Thermostatic Expansion Valve (Hard Shutoff) — Sizes 036, 042
KSATX0401HSZ‡ Thermostatic Expansion Valve (Hard Shutoff) — Size 048
KSATX0501HSZ‡ Thermostatic Expansion Valve (Hard Shutoff) — Size 060
KSAPX0101PIS Piston Body — All Sizes
HC38GE230 (RCD) Ball Bearing Fan Motor — Sizes 024–042
HC40GE230 (RCD) Ball Bearing Fan Motor — Sizes 048, 060
KH45LG140 (RCD) Filter Drier (Suction Line) — Sizes 024–036
KH45LG141 (RCD) Filter Drier (Suction Line) — Sizes 042–060
KAALS0201LLS Liquid-Line Solenoid Valve — Sizes 024–048
Standard Liquid-Line Solenoid Valve — Size 060
KSASF0101AAA Support Feet — All Sizes
KAACF0201MED Coastal Filter — All Sizes
THERMOSTAT/SUBBASE PKG DESCRIPTION
TSTATCCNAC01-B
Thermostat — Auto Changeover, Non-Programmable, °F/°C, 1-Stage Heat, 1-Stage Cool
TSTATCCPAC01-B Thermostat — Auto Changeover, 7-Day Programmable, °F/°C, 1-Stage Heat, 1-Stage Cool
TSTATCCPRH01-B Thermidistat™ Control — ProgrammableThermostat with Humidity Control
TSTATCCBAC01
Builder’s Thermostat — Manual Changeover, Non-Programmable, °F/°C, 1 Stage Heat, 1-Stage
Cool
TSTATXXSEN01-B Outdoor Air Temperature Sensor
TSTATXXNBP01 Backplate for Non-Programmable Thermostat
TSTATXXPBP01 Backplate for Programmable Thermostat
TSTATXXBBP01 Backplate for Builder’sThermostat
TSTATXXCNV10 Thermostat Conversion Kit (4 to 5 wire) — 10 Pack
ACCESSORY
REQUIRED FOR
LOW-AMBIENT
APPLICATIONS
(Below 55°F)
REQUIRED FOR
LONG-LINE
APPLICATIONS*
(Over 50 Ft)
REQUIRED FOR
SEA COAST
APPLICATIONS
(Within 2 Miles)
Crankcase Heater
Yes Yes No
Evaporator FreezeThermostat Yes No No
Winter Start Control Yes† No No
Accumulator No No No
Compressor Start Assist
Capacitor and Relay
Yes Yes No
Low-Ambient Controller,
MotorMaster® Control,
or
Low-Ambient Pressure Switch
Yes No No
Wind Baffle See Low-Ambient Instructions No No
Coastal Filter No No Yes
Support Feet Recommended No Recommended
Liquid-Line SolenoidValve
or
Hard ShutoffTXV
No
See Long-Line
Application
Guideline No
Ball Bearing Fan Motor Yes‡ No No

5
Accessory description and usage (Listed alphabetically)
1. Ball Bearing Fan Motor
A fan motor with ball bearings which permits speed reduction while maintaining bearing lubrication.
SUGGESTED USE: Required on all units where Low-Ambient Controller (full modulation feature) or MotorMaster® Control has been added.
2. Coastal Filter
A mesh screen inserted under the top cover and inside the base pan to protect the condenser coil from corrosive atmosphere without restricting airflow.
SUGGESTED USE: In geographic areas where salt damage could occur.
In areas with high pollution levels.
3. Compressor Start Assist—Capacitor and Relay
Start capacitor and start relay which gives ‘‘hard’’boost to compressor motor at each start-up.
SUGGESTED USE: Installations where interconnecting tube length exceeds 50 ft.
Installations where outdoor design temperature exceeds 105°F (40.6°C).
Installations where Liquid-Line Solenoid Valve has been added.
4. Compressor Start Assist—PTC
Solid-state electrical device which gives a ‘‘soft’’ boost to compressor at each start-up.
SUGGESTED USE: Installations with marginal power supply.
5. Crankcase Heater
An electric resistance heater which mounts to the base of the compressor to keep the lubricant warm during off cycles. Improves compressor lubrication on restart and
minimizes chance of refrigerant slugging. May or may not include a thermostat control.
SUGGESTED USE: When interconnecting tube length exceeds 50 ft.
When unit will be operated below 55°F (12.8°C) outdoor air temperature. Use with Low-Ambient Controller.
All commercial installations.
6. Cycle Protector
Solid-state timing device which prevents compressor rapid recycling. Control provides an approximate 5-minute delay after power to the compressor has been interrupted
for any reason, including normal room thermostat cycling.
SUGGESTED USE: Installations in areas where power interruptions are frequent.
Where user is likely to “play” with the room thermostat.
All commercial installations.
Installations where interconnecting tube length exceeds 50 ft.
High-rise applications.
7. Evaporator FreezeThermostat
An SPST temperature actuated switch which stops unit operation when evaporator reaches freeze-up conditions.
SUGGESTED USE: All units where Winter Start Control has been added.
8. Filter Drier (Suction Line)
A device for removing contaminants from refrigerant circulating in an air conditioner: 1 direction flow.
SUGGESTED USE: All split-system air conditioners.
9. Liquid-Line SolenoidValve (LSV)
An electrically operated shutoff valve to be installed at the outdoor or indoor unit (depending on tubing configuration) and which stops and starts refrigerant liquid flow
in response to compressor operation. Maintains a column of refrigerant liquid ready for action at next compressor operation cycle.
NOTE: Compressor Start Assist — Capacitor and Relay must also be used. Do not use with hard shutoff TXV.
SUGGESTED USE: For improved system performance in air conditioners for certain combinations of indoor and outdoor units Refer toARI Unitary Directory.
In certain long-line applications. Refer to Residential Split SystemApplication Guideline and Service Manual.
10. Low-Ambient Controller
Head pressure controller is a cycle control device activated by a temperature sensor mounted on a header tube of the outdoor coil. It is designed to cycle the outdoor fan
motor in order to maintain condensing temperature within normal operating limits (approximately 100°F high and 60°F low). The control will maintain working head
pressure at low-ambient temperatures down to 0°F when properly installed.
SUGGESTED USE: Cooling operation at outdoor temperatures below 55°F (12.8°C).
11. Low-Ambient Pressure Switch
A long life pressure switch which is mounted to outdoor unit service valve. It is designed to cycle the outdoor fan motor in order to maintain head pressure within normal
operating limits (approximately 200 psig to 365 psig). The control will maintain working head pressure at low-ambient temperatures down to 0°F when properly
installed.
SUGGESTED USE: Cooling operation at outdoor temperatures below 55°F (12.8°C).
12. MotorMaster® Control
A fan speed control device activated by a temperature sensor. Designed to control condenser fan motor speed in response to the saturated, condensing temperature during
operation in cooling mode only. For outdoor temperatures down to –20°F, it maintains condensing temperature at 100°F ± 10°F.
SUGGESTED USE: Cooling operation at outdoor temperatures below 55°F.
All commercial installations.
13. Outdoor AirTemperature Sensor
A device that allows the temperature at a remote location (outdoors) to be displayed at the thermostat.
SUGGESTED USE: All corporate programmable thermostats.
14. Piston Body
This piston body is to be used as a replacement for the FK4C Fan Coil R-22 thermostatic expansion valve when used with Puron® (R-410A) air conditioner units.
Use piston and piston ring shipped with outdoor unit for installations under 50 ft.
SUGGESTED USE: All Puron® (R-410A) air conditioner installations matched with FK4C Fan Coils.
15. Support Feet
Four stick-on plastic feet which raise the unit 4 in. above the mounting pad. This allows sand, dirt, and other debris to be flushed from the unit base minimizing corrosion.
SUGGESTED USE: For improved sound ratings.
Coastal installations.
Windy areas or where debris is normally circulating.
Rooftop installations.
16. Thermostatic ExpansionValve (TXV) Kit
A modulating flow control valve which meters refrigerant liquid flow rate into the evaporator in response to the superheat of the refrigerant gas leaving the evaporator. Kit
includes valve, adapter tubes, and external equalizer tube. Hard shutoff type valves are available.
SUGGESTED USE: For improved system performance in cooling mode for certain combinations of indoor and outdoor units. Refer toARI Unitary Directory.
Required for use on all zoning systems.
17. Time-Delay Relay
An SPST delay relay which briefly continues operation of the indoor blower motor to provide additional cooling after the compressor cycles off.
SUGGESTED USE: For improved efficiency ratings for certain combinations of indoor and outdoor units. Refer toARI Unitary Directory.
Required for use on all zoning systems.
18. Winter Start Control
An SPST delay relay which bypasses the low-pressure switch for approximately 3 minutes to permit start-up for cooling operation under low-load conditions.
SUGGESTED USE: All air conditioners where Low-Ambient Controller has been added.

6
Electrical data
* Permissible limits of the voltage range at which unit will operate satisfactorily.
† If wire is applied at ambient greater than 30°C (86°F), consult Table 310-16 of the NEC (ANSI/NFPA 70).The ampacity of nonmetallic-sheathed
cable (NM), trade name ROMEX, shall be that of 60°C (140°F) conductors, per the NEC (ANSI/NFPA 70) Article 336-26. If other than uncoated
(non-plated), 60 or 75°C (140 or 167°F) insulation, copper wire (solid wire for 10 AWG and smaller, stranded wire for larger than 10 AWG) is used,
consult applicable tables of the NEC (ANSI/NFPA 70).
‡ Length shown is as measured 1 way along wire path between unit and service panel for voltage drop not to exceed 2%.
** Time-delay fuse.
FLA — Full Load Amps
LRA — Locked Rotor Arms
MCA — Minimum Circuit Amps
RLA — Rated Load Amps
NOTE: Control circuit is 24-v on all units and requires external power source. Copper wire must be used from service disconnect to unit. All motors/
compressors contain internal overload protection.
SOUND POWER (dBA)
UNIT SIZE-
SERIES V/PH OPERVOLTS* COMPR FAN
FLA MCA
60°C
MIN
WIRE
SIZE†
75°C
MIN
WIRE
SIZE†
60°C
MAX
LENGTH
(Ft)‡
75°C
MAX
LENGTH
(Ft)‡
MAX
FUSE**
OR CKT
BKR AMPSMax Min LRA RLA
024-30
208/230/1 253 187
61.0 13.5 0.8 17.6 14 14 44 42 25
030-30 72.5 14.7 0.8 19.2 14 14 41 39 30
036-30 83.0 15.4 1.1 20.2 12 12 62 59 30
042-30 105.0 18.6 1.1 24.4 10 10 80 76 40
048-30 109.0 20.5 1.4 27.0 10 10 73 70 40
060-31 158.0 27.6 1.4 35.9 8 8 85 80 60
UNIT SIZE-SERIES SOUND LEVEL
024-30 70
030-30 71
036-30 71
042-30 74
048-30 76
060-31 78

7
Dimensions
2 1/2
"
1 9/16
"
AIR DISCHARGE
4 3/16
"
3/8IN.
DIA.
LIQUID LINE CONN
1 3/4
"
FIELD POWER SUPPLY CONN 7/8IN.
DIA HOLE WITH
11/8IN. DIA KNOCKOUT AND 1 3/8IN. DIA KNOCKOUT

10 1/2
"
FG
N
A
FIELD CONTROL SUPPLY CONN 7/8IN.
DIA HOLE

AIR DISCHARGE
AIR DISCHARGE AIR IN
AIR IN
AIR IN
HDIA VAPOR LINE CONN
3/8IN. DIA TIEDOWN
KNOCKOUTS (2) PLACES IN BASEPAN B
1 1/4
"
M
ACCESS
PANEL
L
K
C
D
E
J
C
L
1.Allow 30 in.
clearance to service side of unit, 48 in. above unit, 6 in.
on one side, 12 in. on remaining side, and 24 in. between units for proper airflow. Minimum outdoor operating ambient in cooling mode is 55°F (unless low ambient control is used) max 125°F.2. Series designation is the 13th position of the unit model number.3. Center of gravity .4.
NOTES:
A97084
DIMENSIONS (IN.)
UNIT
SIZE SERIES
UNIT DIMENSIONS MINIMUM
MOUNTING
PAD
DIMENSIONSABCDEFGHJKLMN
024 30 33-13/16 30 34-15/16 4 9-3/4 21-1/2 27-7/8 5/8 8-3/16 17 19-3/4 15-3/4 2-15/16 26 x 32 030 30 27-13/16 30 34-15/16 4 9-3/4 15-1/2 21-7/8 3/4 8-3/16 18-1/2 19-3/4 13 2-15/16 26 x 32 036 30 33-13/16 30 34-15/16 4 9-3/4 21-1/2 27-7/8 3/4 8-3/16 17 19-3/4 15-3/4 2-15/16 26 x 32 042 30 39-13/16 30 34-15/16 4 9-3/4 27-1/2 33-7/8 7/8 8-3/16 17-3/4 19 17-3/4 2-15/16 26 x 32 048 30 39-13/16 30 34-15/16 4 9-3/4 27-1/2 33-7/8 7/8 8-3/16 16-3/4 19-1/2 17-1/4 2-15/16 26 x 32 060 31 39-13/16 30 34-15/16 4 9-3/4 27-1/2 33-7/8 7/8 8-3/16 16-1/2 19 16-3/4 2-15/16 26 x 32

8
Combination ratings
See notes on pg. 16.
UNIT
SIZE-SERIES INDOOR UNIT TOT. CAP. BTUH
FACTORY-
SUPPLIED
ENHANCE-
MENT
SEER
EER
Standard
Rating
Carrier Gas Furnace
or Accessory
TDR† Accessory TXV‡
024-30
CC5A/CD5AA030* 24,000 NONE — 13.00 13.00 11.10
CC5A/CD5AA024 24,000 NONE — 12.50 12.50 11.20
CC5A/CD5AW024 24,000 NONE — 12.50 12.50 11.10
CC5A/CD5AW030 24,000 NONE — 13.00 13.00 11.20
CE3AA024 24,000 NONE — 12.50 12.50 11.25
CE3AA030 24,000 NONE — 13.00 13.00 11.35
CF5AA024 24,000 NONE — 12.50 12.50 11.20
CJ5A/CK5A/CK5BA024 24,000 NONE — 12.50 12.50 11.20
CJ5A/CK5A/CK5BA030 24,000 NONE — 13.00 13.00 11.35
CJ5A/CK5A/CK5BW024 24,000 NONE — 12.50 12.50 11.20
CJ5A/CK5A/CK5BW030 24,000 NONE — 13.00 13.00 11.35
CK3BA024 24,000 NONE — 12.50 12.50 11.20
CK3BA030 24,000 NONE — 13.00 13.00 11.35
F(A,B)4AN(F,C)024 24,000 TDR 12.50 — 12.50 11.30
F(A,B)4AN(F,C)030 24,000 TDR 13.00 — 13.00 11.40
FF1(B,C,D)NA024 24,000 TDR 12.50 — 12.50 11.30
FF1(B,C,D)NA030 24,000 TDR 13.00 — 13.00 11.50
FG3AAA024 24,000 NONE — 12.00 12.00 11.00
FK4CNF002+Puron® (R-410A) TXV** 26,000 TDR 14.00 — — 12.40
FK4CNF003+Puron® (R-410A) TXV** 26,000 TDR 14.00 — — 12.60
FK4CNF003+61 Piston†† 25,600 TDR 14.00 — — 12.95
FV4ANF002 26,000 TDR & TXV 14.00 — — 12.40
FV4ANF003 26,000 TDR & TXV 14.00 — — 12.60
FX4ANF030 24,000 TDR & TXV 12.50 — — 11.00
COILS + 58MVP040-14VARIABLE SPEED FURNACE
CC5A/CD5AA024 24,000 TDR 13.50 — 13.50 11.95
CC5A/CD5AA030 24,000 TDR 14.00 — 14.00 12.25
CC5A/CD5AW024 24,000 TDR 13.50 — 13.50 11.95
CC5A/CD5AW030 24,000 TDR 14.00 — 14.00 12.25
CE3AA024 24,000 TDR 13.50 — 13.50 12.05
CE3AA030 24,000 TDR 14.00 — 14.00 12.30
CJ5A/CK5A/CK5BW030 24,000 TDR 14.00 — 14.00 12.20
CK3BA024 24,000 TDR 13.50 — 13.50 12.00
CK3BA030 24,000 TDR 14.00 — 14.00 12.20
COILS + 58MVP060-14VARIABLE SPEED FURNACE
CC5A/CD5AA024 24,000 TDR 13.50 — 13.50 11.90
CC5A/CD5AA030 24,000 TDR 14.00 — 14.00 12.15
CC5A/CD5AW024 24,000 TDR 13.50 — 13.50 11.90
CC5A/CD5AW030 24,000 TDR 14.00 — 14.00 12.15
CE3AA024 24,000 TDR 13.50 — 13.50 12.00
CE3AA030 24,000 TDR 14.00 — 14.00 12.25
CJ5A/CK5A/CK5BW024 24,000 TDR 13.50 — 13.50 12.00
CJ5A/CK5A/CK5BW030 24,000 TDR 14.00 — 14.00 12.20
CK3BA024 24,000 TDR 13.50 — 13.50 12.00
CK3BA030 24,000 TDR 14.00 — 14.00 12.20
COILS + 58MVP080-14VARIABLE SPEED FURNACE
CC5A/CD5AA024 24,000 TDR 13.50 — 13.50 12.05
CC5A/CD5AA030 24,000 TDR 14.00 — 14.00 12.30
CC5A/CD5AW024 24,000 TDR 13.50 — 13.50 12.05
CC5A/CD5AW030 24,000 TDR 14.00 — 14.00 12.30
CE3AA024 24,000 TDR 13.50 — 13.50 12.15
CE3AA030 24,000 TDR 14.00 — 14.00 12.40
CJ5A/CK5A/CK5BW024 24,000 TDR 13.50 — 13.50 12.25
CJ5A/CK5A/CK5BW030 24,000 TDR 14.00 — 14.00 12.45
CK3BA024 24,000 TDR 13.50 — 13.50 12.25
CK3BA030 24,000 TDR 14.00 — 14.00 12.45
COILS + 58U(H,X)V060-12VARIABLE SPEED FURNACE
CC5A/CD5AA024 24,000 TDR 13.50 — 13.50 11.95
CC5A/CD5AA030 24,000 TDR 14.00 — 14.00 12.15
CC5A/CD5AW024 24,000 TDR 13.50 — 13.50 11.95
CC5A/CD5AW030 24,000 TDR 14.00 — 14.00 12.15
CE3AA024 24,000 TDR 13.50 — 13.50 12.05
CE3AA030 24,000 TDR 14.00 — 14.00 12.05
CJ5A/CK5A/CK5BA024 24,000 TDR 13.50 — 13.50 12.15
CJ5A/CK5A/CK5BA030 24,000 TDR 14.00 — 14.00 12.35
CJ5A/CK5A/CK5BW030 24,000 TDR 14.00 — 14.00 12.35
CK3BA024 24,000 TDR 13.50 — 13.50 12.15
CK3BA030 24,000 TDR 14.00 — 14.00 12.35
030-30
CC5A/CD5AA036* 29,000 NONE — 13.00 13.00 10.85
CC5A/CD5AA030 28,000 NONE — 12.50 12.50 11.20
CC5A/CD5AW030 28,000 NONE — 12.50 12.50 10.85
CD5A/CD5BW036 29,000 NONE — 13.00 13.00 11.20
CE3AA030 28,000 NONE — 12.50 12.50 11.00
CE3AA036 28,400 NONE — 12.50 12.50 11.10
CF5AA036 28,400 NONE — 12.50 12.50 11.15
CJ5A/CK5A/CK5BA030 28,000 NONE — 12.50 12.50 10.95
CJ5A/CK5A/CK5BA036 29,000 NONE — 13.00 13.00 11.25
CJ5A/CK5A/CK5BN036 27,000 NONE — 13.00 13.00 11.25
CJ5A/CK5A/CK5BW030 28,000 NONE — 12.50 12.50 10.95
CJ5A/CK5A/CK5BW036 29,000 NONE — 13.00 13.00 11.25
CK3BA030 28,000 NONE — 12.50 12.50 10.95
CK3BA036 29,000 NONE — 13.00 13.00 11.25

9
Combination ratings continued
See notes on pg. 14.
UNIT
SIZE-SERIES INDOOR UNIT TOT. CAP. BTUH
FACTORY-
SUPPLIED
ENHANCE-
MENT
SEER
EER
Standard
Rating
Carrier Gas Furnace
or Accessory
TDR† Accessory TXV‡
030-30
F(A,B)4ANF030 28,600 TDR 12.50 — 12.50 11.10
F(A,B)4ANF036 29,000 TDR 12.50 — 12.50 10.95
FF1(A,B)NA030 28,600 TDR 12.50 — 12.50 11.05
FG3AAA036 28,400 NONE — 12.50 12.50 11.00
FK4CNF001+Puron® (R-410A) TXV** 29,000 TDR 13.00 — — 11.95
FK4CNF001+63 Piston†† 28,600 TDR 13.00 — — 12.10
FK4CNF002+Puron® (R-410A) TXV** 29,000 TDR 13.50 — — 12.05
FK4CNF003+Puron® (R-410A) TXV** 29,600 TDR 14.00 — — 12.40
FK4CNF003+63 Piston†† 29,000 TDR 14.00 — — 12.55
FV4ANF002 29,000 TDR & TXV 13.50 — — 12.05
FV4ANF003 29,600 TDR & TXV 14.00 — — 12.40
FX4ANF030 28,600 TDR & TXV 12.50 — — 11.00
FX4ANF036 29,000 TDR & TXV 12.50 — — 10.95
COILS + 58MVP040-14VARIABLE SPEED FURNACE
CC5A/CD5AA030 28,400 TDR 13.20 — 13.20 11.55
CC5A/CD5AA036 29,600 TDR 13.50 — 13.50 11.90
CC5A/CD5AW030 28,400 TDR 13.20 — 13.20 11.55
CC5A/CD5AW036 29,600 TDR 13.50 — 13.50 11.90
CE3AA030 29,000 TDR 13.50 — 13.50 11.70
CE3AA036 29,200 TDR 13.50 — 13.50 11.75
CJ5A/CK5A/CK5BW030 28,400 TDR 13.00 — 13.00 11.45
CJ5A/CK5A/CK5BW036 29,600 TDR 13.50 — 13.50 11.95
CK3BA030 28,400 TDR 13.00 — 13.00 11.45
CK3BA036 29,600 TDR 13.50 — 13.50 11.95
COILS + 58MVP060-14VARIABLE SPEED FURNACE
CC5A/CD5AA030 28,400 TDR 13.20 — 13.20 11.50
CC5A/CD5AA036 29,600 TDR 13.50 — 13.50 11.90
CC5A/CD5AW030 28,400 TDR 13.20 — 13.20 11.50
CC5A/CD5AW036 29,600 TDR 13.50 — 13.50 11.90
CE3AA030 29,000 TDR 13.20 — 13.20 11.65
CE3AA036 29,200 TDR 13.50 — 13.50 11.75
CJ5A/CK5A/CK5BA036 29,600 TDR 13.50 — 13.50 11.95
CJ5A/CK5A/CK5BW030 28,400 TDR 13.20 — 13.20 11.45
CK3BA030 28,400 TDR 13.20 — 13.20 11.45
CK3BA036 29,600 TDR 13.50 — 13.50 11.95
COILS + 58MVP080-14VARIABLE SPEED FURNACE
CC5A/CD5AA030 28,600 TDR 13.50 — 13.50 11.65
CC5A/CD5AA036 29,600 TDR 14.00 — 14.00 12.10
CC5A/CD5AW030 28,600 TDR 13.50 — 13.50 11.65
CC5A/CD5AW036 29,600 TDR 14.00 — 14.00 12.10
CE3AA030 29,000 TDR 13.50 — 13.50 11.80
CE3AA036 29,200 TDR 13.50 — 13.50 11.90
CJ5A/CK5A/CK5BW030 28,600 TDR 13.20 — 13.20 11.55
CJ5A/CK5A/CK5BW036 29,600 TDR 14.00 — 14.00 12.10
CK3BA030 28,600 TDR 13.20 — 13.20 11.55
CK3BA036 29,600 TDR 14.00 — 14.00 12.10
COILS + 58U(H,X)V060-12VARIABLE SPEED FURNACE
CC5A/CD5AA030 28,000 TDR 13.50 — 13.50 11.65
CC5A/CD5AA036 29,000 TDR 14.00 — 14.00 12.05
CC5A/CD5AW030 28,000 TDR 13.50 — 13.50 11.65
CC5A/CD5AW036 29,000 TDR 14.00 — 14.00 12.05
CE3AA030 28,400 TDR 13.50 — 13.50 11.80
CE3AA036 28,600 TDR 13.50 — 13.50 11.85
CJ5A/CK5A/CK5BA030 28,000 TDR 13.50 — 13.50 11.70
CJ5A/CK5A/CK5BA036 29,000 TDR 14.00 — 14.00 12.20
CJ5A/CK5A/CK5BN036 27,000 TDR 14.00 — 14.00 12.00
CJ5A/CK5A/CK5BW030 28,000 TDR 13.50 — 13.50 11.70
CK3BA030 28,000 TDR 13.50 — 13.50 11.70
CK3BA036 29,000 TDR 14.00 — 14.00 12.20
COILS + 58U(H,X)V080-16VARIABLE SPEED FURNACE
CC5A/CD5AA030 28,000 TDR 13.50 — 13.50 11.85
CC5A/CD5AA036 29,200 TDR 14.00 — 14.00 12.25
CC5A/CD5AW030 28,000 TDR 13.50 — 13.50 11.85
CC5A/CD5AW036 29,200 TDR 14.00 — 14.00 12.25
CE3AA030 28,600 TDR 13.50 — 13.50 12.00
CE3AA036 28,800 TDR 13.50 — 13.50 12.05
CJ5A/CK5A/CK5BW030 28,000 TDR 13.50 — 13.50 11.90
CJ5A/CK5A/CK5BW036 29,000 TDR 14.00 — 14.00 12.40
CK3BA030 28,000 TDR 13.50 — 13.50 11.90
CK3BA036 29,000 TDR 14.00 — 14.00 12.40
036-30
CC5A/CD5AA042* 35,000 NONE — 13.00 13.00 11.20
CC5A/CD5AA036 35,000 NONE — 13.00 13.00 11.20
CC5A/CD5AW042 35,000 NONE — 12.50 12.50 11.10
CD5AW036 35,000 NONE — 13.00 13.00 11.20
CE3AA036 35,000 NONE — 12.50 12.50 11.05
CE3AA042 35,000 NONE — 13.00 13.00 11.30
CF5AA036 35,000 NONE — 13.00 13.00 11.15
CJ5A/CK5A/CK5BA036 35,000 NONE — 13.00 13.00 11.20
CJ5A/CK5A/CK5BA042 35,000 NONE — 13.00 13.00 11.20
CJ5A/CK5A/CK5BN042 34,000 NONE — 13.00 13.00 11.20
CJ5A/CK5A/CK5BW036 35,000 NONE — 13.00 13.00 11.20
CK3BA036 35,000 NONE — 13.00 13.00 11.20
CK3BA042 35,000 NONE — 13.00 13.00 11.20
F(A,B)4AN(F,B)042 35,000 TDR 13.00 — 13.00 11.25

10
Combination ratings continued
See notes on pg. 14.
UNIT
SIZE-SERIES INDOOR UNIT TOT. CAP. BTUH
FACTORY-
SUPPLIED
ENHANCE-
MENT
SEER
EER
Standard
Rating
Carrier Gas Furnace
or Accessory
TDR† Accessory TXV‡
036-30
F(A,B)4ANF036 35,000 TDR 12.50 — 12.50 11.15
FG3AAA036 35,000 NONE — 12.20 12.20 10.95
FK4CNF002+Puron® (R-410A) TXV** 35,000 TDR 13.00 — — 11.75
FK4CNF003+Puron® (R-410A) TXV** 35,000 TDR 13.50 — — 12.05
FK4CNF005+Puron® (R-410A) TXV** 36,000 TDR 14.00 — — 12.20
FK4CNF005+70 Piston†† 35,000 TDR 14.00 — — 12.35
FV4ANF002 35,000 TDR & TXV 13.00 — — 11.75
FV4ANF003 35,000 TDR & TXV 13.50 — — 12.05
FV4ANF005 36,000 TDR & TXV 14.00 — — 12.20
FX4ANF036 34,000 TDR & TXV 12.25 — — 11.00
FX4ANF042 35,000 TDR & TXV 13.00 — — 11.25
COILS + 58MVP040-14VARIABLE SPEED FURNACE
CC5A/CD5AW042 35,000 TDR 13.00 — 13.00 11.45
CC5A/CD5AA036 35,000 TDR 13.20 — 13.20 11.60
CC5A/CD5AA042 35,000 TDR 13.20 — 13.20 11.50
CE3AA036 35,000 TDR 13.00 — 13.00 11.35
CE3AA042 35,000 TDR 13.20 — 13.20 11.60
CJ5A/CK5A/CK5BA042 35,000 TDR 13.00 — 13.00 11.45
CJ5A/CK5A/CK5BW036 35,000 TDR 13.00 — 13.00 11.45
CK3BA036 35,000 TDR 13.00 — 13.00 11.45
CK3BA042 35,000 TDR 13.00 — 13.00 11.45
COILS + 58MVP060-14VARIABLE SPEED FURNACE
CC5A/CD5AA036 35,000 TDR 13.20 — 13.20 11.45
CC5A/CD5AA042 35,000 TDR 13.20 — 13.20 11.60
CC5A/CD5AW042 35,000 TDR 13.00 — 13.00 11.50
CD5AW036 35,000 TDR 13.20 — 13.20 11.45
CE3AA036 35,000 TDR 13.00 — 13.00 11.35
CE3AA042 35,000 TDR 13.20 — 13.20 11.60
CJ5A/CK5A/CK5BA036 35,000 TDR 13.00 — 13.00 11.50
CJ5A/CK5A/CK5BN042 34,000 TDR 13.00 — 13.00 11.50
CK3BA036 35,000 TDR 13.00 — 13.00 11.50
CK3BA042 35,000 TDR 13.20 — 13.20 11.60
COILS + 58MVP080-14VARIABLE SPEED FURNACE
CC5A/CD5AA036 35,000 TDR 13.20 — 13.20 11.65
CC5A/CD5AA042 35,000 TDR 13.50 — 13.50 11.85
CC5A/CD5AW042 35,000 TDR 13.50 — 13.50 11.75
CD5AW036 35,000 TDR 13.20 — 13.20 11.65
CE3AA036 35,000 TDR 13.00 — 13.00 11.55
CE3AA042 35,000 TDR 13.50 — 13.50 11.85
CJ5A/CK5A/CK5BA042 35,000 TDR 13.50 — 13.50 11.75
CJ5A/CK5A/CK5BW036 35,000 TDR 13.20 — 13.20 11.60
CK3BA036 35,000 TDR 13.20 — 13.20 11.60
CK3BA042 35,000 TDR 13.50 — 13.50 11.75
COILS + 58MVP080-20VARIABLE SPEED FURNACE
CC5A/CD5AA036 35,000 TDR 13.50 — 13.50 11.75
CC5A/CD5AA042 35,000 TDR 13.50 — 13.50 11.90
CC5A/CD5AW042 35,000 TDR 13.50 — 13.50 11.85
CD5AW036 35,000 TDR 13.50 — 13.50 11.75
CE3AA036 35,000 TDR 13.00 — 13.00 11.60
CE3AA042 35,000 TDR 13.50 — 13.50 11.90
CJ5A/CK5A/CK5BA042 35,000 TDR 13.00 — 13.00 11.60
CJ5A/CK5A/CK5BW036 35,000 TDR 13.00 — 13.00 11.45
CK3BA036 35,000 TDR 13.00 — 13.00 11.45
CK3BA042 35,000 TDR 13.00 — 13.00 11.60
COILS + 58MVP100-20VARIABLE SPEED FURNACE
CC5A/CD5AA036 35,000 TDR 13.50 — 13.50 11.75
CC5A/CD5AA042 35,000 TDR 13.50 — 13.50 11.90
CC5A/CD5AW042 35,000 TDR 13.50 — 13.50 11.85
CD5AW036 35,000 TDR 13.50 — 13.50 11.75
CE3AA036 35,000 TDR 13.00 — 13.00 11.60
CE3AA042 35,000 TDR 13.50 — 13.50 11.90
CJ5A/CK5A/CK5BA042 35,000 TDR 13.50 — 13.50 12.00
CJ5A/CK5A/CK5BW036 35,000 TDR 13.50 — 13.50 11.80
CK3BA036 35,000 TDR 13.50 — 13.50 11.80
CK3BA042 35,000 TDR 13.50 — 13.50 12.00
COILS + 58MVP120-20VARIABLE SPEED FURNACE
CC5A/CD5AA036 35,000 TDR 13.50 — 13.50 11.75
CC5A/CD5AA042 35,000 TDR 13.50 — 13.50 11.90
CC5A/CD5AW042 35,000 TDR 13.50 — 13.50 11.85
CD5AW036 35,000 TDR 13.50 — 13.50 11.75
CE3AA036 35,000 TDR 13.00 — 13.00 11.60
CE3AA042 35,000 TDR 13.50 — 13.50 11.90
CJ5A/CK5A/CK5BA042 35,000 TDR 13.50 — 13.50 12.00
CJ5A/CK5A/CK5BW036 35,000 TDR 13.50 — 13.50 11.85
CK3BA036 35,000 TDR 13.50 — 13.50 11.85
CK3BA042 35,000 TDR 13.50 — 13.50 12.00
COILS + 58U(H,X)V060-12VARIABLE SPEED FURNACE
CC5A/CD5AA036 35,000 TDR 13.50 — 13.50 11.70
CC5A/CD5AA042 35,000 TDR 13.50 — 13.50 11.85
CC5A/CD5AW042 35,000 TDR 13.50 — 13.50 11.75

11
Combination ratings continued
See notes on pg. 14.
UNIT
SIZE-SERIES INDOOR UNIT TOT. CAP. BTUH
FACTORY-
SUPPLIED
ENHANCE-
MENT
SEER
EER
Standard
Rating
Carrier Gas Furnace
or Accessory
TDR† Accessory TXV‡
036-30
CD5AW036 35,000 TDR 13.50 — 13.50 11.70
CE3AA036 35,000 TDR 13.20 — 13.20 11.60
CE3AA042 35,000 TDR 13.50 — 13.50 11.85
CJ5A/CK5A/CK5BA036 35,000 TDR 13.50 — 13.50 11.80
CK3BA036 35,000 TDR 13.50 — 13.50 11.80
CK3BA042 35,000 TDR 13.50 — 13.50 11.85
COILS + 58U(H,X)V080-16VARIABLE SPEED FURNACE
CC5A/CD5AA036 35,000 TDR 13.50 — 13.50 11.95
CC5A/CD5AA042 35,000 TDR 14.00 — 14.00 12.10
CC5A/CD5AW042 35,000 TDR 13.50 — 13.50 12.05
CD5A/CD5BW036 35,000 TDR 13.50 — 13.50 11.95
CE3AA036 35,000 TDR 13.50 — 13.50 11.85
CE3AA042 35,000 TDR 14.00 — 14.00 12.15
CJ5A/CK5A/CK5BA042 35,000 TDR 13.50 — 13.50 12.05
CJ5A/CK5A/CK5BW036 35,000 TDR 13.50 — 13.50 12.00
CK3BA036 35,000 TDR 13.50 — 13.50 12.00
CK3BA042 35,000 TDR 13.50 — 13.50 12.05
COILS + 58U(H,X)V100-20VARIABLE SPEED FURNACE
CC5A/CD5AA036 35,000 TDR 14.00 — 14.00 12.15
CC5A/CD5AA042 35,000 TDR 14.00 — 14.00 12.25
CC5A/CD5AW042 35,000 TDR 14.00 — 14.00 12.15
CD5A/CD5BW036 35,000 TDR 14.00 — 14.00 12.15
CE3AA036 35,000 TDR 13.50 — 13.50 12.05
CE3AA042 35,000 TDR 14.00 — 14.00 12.30
CJ5A/CK5A/CK5BA042 35,000 TDR 14.00 — 14.00 12.35
CJ5A/CK5A/CK5BW036 35,000 TDR 14.00 — 14.00 12.25
CK3BA036 35,000 TDR 14.00 — 14.00 12.25
CK3BA042 35,000 TDR 14.00 — 14.00 12.35
COILS + 58U(H,X)V120-20VARIABLE SPEED FURNACE
CC5A/CD5AA036 35,000 TDR 13.50 — 13.50 12.00
CC5A/CD5AA042 35,000 TDR 14.00 — 14.00 12.15
CC5A/CD5AW042 35,000 TDR 13.50 — 13.50 12.05
CD5AW036 35,000 TDR 13.50 — 13.50 12.00
CE3AA036 35,000 TDR 13.50 — 13.50 11.90
CE3AA042 35,000 TDR 14.00 — 14.00 12.15
CJ5A/CK5A/CK5BA042 35,000 TDR 14.00 — 14.00 12.25
CJ5A/CK5A/CK5BW036 35,000 TDR 13.50 — 13.50 12.15
CK3BA036 35,000 TDR 13.50 — 13.50 12.15
CK3BA042 35,000 TDR 14.00 — 14.00 12.25
042-30
CD5AA048* 40,500 NONE — 13.00 13.00 11.20
CC5A/CD5AA042 40,500 NONE — 13.00 13.00 11.15
CC5A/CD5AC048 40,000 NONE — 12.50 12.50 11.10
CC5A/CD5AW042 40,000 NONE — 12.50 12.50 11.00
CC5A/CD5AW048 40,500 NONE — 13.00 13.00 11.20
CE3AA042 41,000 NONE — 13.00 13.00 11.25
CE3AA048 41,000 NONE — 13.00 13.00 11.30
CF5AA048 40,500 NONE — 12.50 12.50 11.20
CJ5A/CK5A/CK5BA042 40,500 NONE — 13.00 13.00 11.20
CJ5A/CK5A/CK5BA048 40,500 NONE — 13.00 13.00 11.30
CJ5A/CK5A/CK5BN042 39,500 NONE — 12.50 12.50 11.20
CJ5A/CK5A/CK5BN048 39,500 NONE — 12.50 12.50 11.30
CJ5A/CK5A/CK5BW048 40,500 NONE — 13.00 13.00 11.30
CK3BA042 40,500 NONE — 13.00 13.00 11.20
CK3BA048 40,500 NONE — 13.00 13.00 11.30
F(A,B)4AN(F,B)042 40,500 TDR 12.50 — 12.50 11.20
F(A,B)4AN(F,B)048 41,000 TDR 13.00 — 13.00 11.40
FG3AAA048 40,000 NONE — 12.50 12.50 11.20
FK4CNB006+Puron® (R-410A) TXV** 41,500 TDR 14.00 — — 12.90
FK4CNB006+73 Piston†† 41,000 TDR 14.00 — — 13.00
FK4CNF003+Puron® (R-410A) TXV** 39,500 TDR 13.00 — — 11.95
FK4CNF005+Puron® (R-410A) TXV** 41,000 TDR 13.50 — — 12.50
FV4ANB006 41,500 TDR & TXV 14.00 — — 12.90
FV4ANF003 39,500 TDR & TXV 13.00 — — 11.95
FV4ANF005 41,000 TDR & TXV 13.50 — — 12.50
FX4ANF042 40,000 TDR & TXV 12.50 — — 11.20
FX4ANF048 40,500 TDR & TXV 12.50 — — 11.20
COILS + 58MVP040-14VARIABLE SPEED FURNACE
CC5A/CD5AA042 40,500 TDR 12.80 — 12.80 11.05
CC5A/CD5AC048 40,000 TDR 12.50 — 12.50 11.10
CC5A/CD5AW042 40,000 TDR 12.50 — 12.50 11.00
CC5A/CD5AW048 40,500 TDR 13.00 — 13.00 11.30
CD5AA048 40,500 TDR 13.00 — 13.00 11.30
CE3AA042 40,000 TDR 13.00 — 13.00 11.15
CE3AA048 40,000 TDR 13.00 — 13.00 11.20
COILS + 58MVP060-14VARIABLE SPEED FURNACE
CC5A/CD5AA042 40,500 TDR 12.80 — 12.80 11.10
CC5A/CD5AC048 40,000 TDR 12.50 — 12.50 11.15
CC5A/CD5AW042 40,000 TDR 12.50 — 12.50 11.05
CC5A/CD5AW048 40,000 TDR 13.00 — 13.00 11.35
CD5AA048 40,000 TDR 13.00 — 13.00 11.35
CE3AA042 40,500 TDR 13.00 — 13.00 11.20
CE3AA048 40,500 TDR 13.00 — 13.00 11.25

12
Combination ratings continued
UNIT
SIZE-SERIES INDOOR UNIT TOT. CAP. BTUH
FACTORY-
SUPPLIED
ENHANCE-
MENT
SEER
EER
Standard
Rating
Carrier Gas Furnace
or Accessory
TDR† Accessory TXV‡
042-30
COILS + 58MVP080-14VARIABLE SPEED FURNACE
CC5A/CD5AA042 40,500 TDR 13.00 — 13.00 11.40
CC5A/CD5AC048 40,000 TDR 13.00 — 13.00 11.45
CC5A/CD5AW042 40,000 TDR 13.00 — 13.00 11.30
CC5A/CD5AW048 40,500 TDR 13.20 — 13.20 11.60
CD5AA048 40,500 TDR 13.50 — 13.50 11.60
CE3AA042 41,000 TDR 13.00 — 13.00 11.50
CE3AA048 41,000 TDR 13.20 — 13.20 11.55
CJ5A/CK5A/CK5BA042 40,500 TDR 13.00 — 13.00 11.30
CJ5A/CK5A/CK5BA048 40,500 TDR 13.20 — 13.20 11.55
CK3BA042 40,500 TDR 13.00 — 13.00 11.30
CK3BA048 40,500 TDR 13.20 — 13.20 11.55
COILS + 58MVP080-20VARIABLE SPEED FURNACE
CC5A/CD5AA042 40,500 TDR 13.20 — 13.20 11.50
CC5A/CD5AC048 40,000 TDR 13.20 — 13.20 11.55
CC5A/CD5AW042 40,000 TDR 13.00 — 13.00 11.40
CC5A/CD5AW048 40,500 TDR 13.50 — 13.50 11.75
CC5AA048 40,500 TDR 13.50 — 13.50 11.75
CE3AA042 41,000 TDR 13.20 — 13.20 11.60
CE3AA048 41,000 TDR 13.50 — 13.50 11.65
COILS + 58MVP100-20VARIABLE SPEED FURNACE
CC5A/CD5AA042 40,500 TDR 13.20 — 13.20 11.50
CC5A/CD5AC048 40,000 TDR 13.20 — 13.20 11.55
CC5A/CD5AW042 40,000 TDR 13.00 — 13.00 11.40
CDC5A/CD5AW048 40,500 TDR 13.50 — 13.50 11.75
CC5AA048 40,500 TDR 13.50 — 13.50 11.75
CE3AA042 41,000 TDR 13.20 — 13.20 11.60
CE3AA048 41,000 TDR 13.50 — 13.50 11.65
CJ5A/CK5A/CK5BA042 40,500 TDR 13.00 — 13.00 11.55
CJ5A/CK5A/CK5BW048 40,500 TDR 13.50 — 13.50 11.80
CK3BA042 40,500 TDR 13.00 — 13.00 11.55
CK3BA048 40,500 TDR 13.50 — 13.50 11.80
COILS + 58MVP120-20VARIABLE SPEED FURNACE
CC5A/CD5AA042 40,500 TDR 13.20 — 13.20 11.50
CC5A/CD5AC048 40,000 TDR 13.20 — 13.20 11.55
CC5A/CD5AW042 40,000 TDR 13.00 — 13.00 11.40
CC5A/CD5AW048 40,500 TDR 13.50 — 13.50 11.75
CD5AA048 40,500 TDR 13.50 — 13.50 11.75
CE3AA042 41,000 TDR 13.20 — 13.20 11.60
CE3AA048 41,000 TDR 13.50 — 13.50 11.65
CJ5A/CK5A/CK5BA042 40,500 TDR 13.00 — 13.00 11.65
CJ5A/CK5A/CK5BW048 40,500 TDR 13.50 — 13.50 11.85
CK3BA042 40,500 TDR 13.00 — 13.00 11.65
CK3BA048 40,500 TDR 13.50 — 13.50 11.85
COILS + 58U(H,X)V080-16VARIABLE SPEED FURNACE
CC5A/CD5AA042 40,000 TDR 13.50 — 13.50 11.80
CC5A/CD5AC048 39,500 TDR 13.00 — 13.00 11.80
CC5A/CD5AW042 40,000 TDR 13.00 — 13.00 11.70
CC5A/CD5AW048 40,500 TDR 13.50 — 13.50 12.00
CD5AA048 40,500 TDR 14.00 — 14.00 12.00
CE3AA042 40,500 TDR 13.50 — 13.50 11.90
CE3AA048 41,000 TDR 13.50 — 13.50 11.95
CJ5A/CK5A/CK5BA042 40,000 TDR 13.50 — 13.50 11.85
CJ5A/CK5A/CK5BA048 40,500 TDR 14.00 — 14.00 12.00
CK3BA042 40,000 TDR 13.50 — 13.50 11.85
CK3BA048 40,500 TDR 14.00 — 14.00 12.00
COILS + 58U(H,X)V100-20VARIABLE SPEED FURNACE
CC5A/CD5AA042 40,500 TDR 13.50 — 13.50 12.05
CC5A/CD5AC048 40,000 TDR 13.50 — 13.50 12.05
CC5A/CD5AW042 40,000 TDR 13.50 — 13.50 12.00
CC5A/CD5AW048 40,500 TDR 14.00 — 14.00 12.25
CD5AA048 40,500 TDR 14.00 — 14.00 12.25
CE3AA042 41,000 TDR 14.00 — 14.00 12.15
CE3AA048 41,000 TDR 14.00 — 14.00 12.20
CJ5A/CK5A/CK5BA042 40,500 TDR 13.50 — 13.50 12.15
CJ5A/CK5A/CK5BW048 40,500 TDR 14.00 — 14.00 12.30
CK3BA042 40,500 TDR 13.50 — 13.50 12.15
CK3BA048 40,500 TDR 14.00 — 14.00 12.30
COILS + 58U(H,X)V120-20VARIABLE SPEED FURNACE
CC5A/CD5AA042 40,500 TDR 13.50 — 13.50 11.90
CC5A/CD5AC048 39,500 TDR 13.50 — 13.50 11.85
CC5A/CD5AW042 40,000 TDR 13.50 — 13.50 11.80
CC5A/CD5AW048 40,500 TDR 13.50 — 13.50 12.05
CD5AA048 40,500 TDR 13.50 — 13.50 12.05
CE3AA042 40,500 TDR 13.50 — 13.50 12.00
CE3AA048 41,000 TDR 13.50 — 13.50 12.05
CJ5A/CK5A/CK5BA042 40,500 TDR 13.50 — 13.50 12.15
CJ5A/CK5A/CK5BW048 40,500 TDR 13.50 — 13.50 12.20
CK3BA042 40,500 TDR 13.50 — 13.50 12.15
CK3BA048 40,500 TDR 13.50 — 13.50 12.20
048-30 CC5A/CD5AA060* 46,500 NONE — 13.00 13.00 11.50
CC5A/CD5AC048 45,000 NONE — 12.50 12.50 11.35
CC5A/CD5AW048 46,000 NONE — 13.00 13.00 11.50
See notes on pg. 14.

13
Combination ratings continued
See notes on pg. 14.
UNIT
SIZE-SERIES INDOOR UNIT TOT. CAP. BTUH
FACTORY-
SUPPLIED
ENHANCE-
MENT
SEER
EER
Standard
Rating
Carrier Gas Furnace
or Accessory
TDR† Accessory TXV‡
048-30
CC5A/CD5AW060 47,000 NONE — 13.00 13.00 11.80
CD5AA048 46,000 NONE — 13.00 13.00 11.50
CE3AA048 46,500 NONE — 13.00 13.00 11.65
CE3AA060 47,000 NONE — 13.00 13.00 11.85
CF5AA048 46,000 NONE — 12.50 12.50 11.55
CJ5A/CK5A/CK5BA048 46,000 NONE — 13.00 13.00 11.55
CJ5A/CK5A/CK5BA060 46,500 NONE — 13.00 13.00 11.65
CJ5A/CK5A/CK5BN048 44,000 NONE — 12.50 12.50 11.30
CJ5A/CK5A/CK5BN060 45,500 NONE — 13.00 13.00 11.90
CJ5A/CK5A/CK5BW048 46,000 NONE — 13.00 13.00 11.55
CJ5A/CK5A/CK5BX060 47,000 NONE — 13.00 13.00 11.90
CK3BA048 46,000 NONE — 13.00 13.00 11.55
CK3BA060 46,500 NONE — 13.00 13.00 11.65
F(A,B)4AN(F,B)048 46,000 TDR 12.20 — 12.20 11.50
F(A,B)4AN(F,B)060 47,000 TDR 12.50 — 12.50 11.55
FB4ANB070 47,500 TDR 13.00 — 13.00 12.00
FG3AAA048 46,000 NONE — 12.20 12.20 11.50
FG3AAA060 46,500 NONE — 12.50 12.50 11.65
FK4CNB006+Puron® (R-410A) TXV** 47,500 TDR 14.00 — — 13.15
FK4CNB006+78 Piston†† 47,000 TDR 14.00 — — 13.15
FV4ANB006 47,500 TDR & TXV 14.00 — — 13.15
FX4ANB060 47,000 TDR & TXV 12.50 — — 11.50
FX4ANF048 46,000 TDR & TXV 12.20 — — 11.50
COILS + 58MVP080-20VARIABLE SPEED FURNACE
CC5A/CD5AA060 46,500 TDR 13.00 — 13.00 11.55
CC5A/CD5AC048 45,000 TDR 12.50 — 12.50 11.20
CC5A/CD5AW048 46,000 TDR 13.00 — 13.00 11.50
CC5A/CD5AW060 47,000 TDR 13.50 — 13.50 12.00
CD5AA048 46,000 TDR 13.00 — 13.00 11.50
CE3AA048 46,500 TDR 13.00 — 13.00 11.55
CE3AA060 47,000 TDR 13.20 — 13.20 11.95
COILS + 58MVP100-20VARIABLE SPEED FURNACE
CC5A/CD5AA060 46,500 TDR 13.00 — 13.00 11.55
CC5A/CD5AC048 45,000 TDR 12.50 — 12.50 11.20
CC5A/CD5AW048 46,000 TDR 13.00 — 13.00 11.50
CC5A/CD5AW060 47,000 TDR 13.50 — 13.50 12.00
CD5AA048 46,000 TDR 13.00 — 13.00 11.50
CE3AA048 46,500 TDR 13.00 — 13.00 11.55
CE3AA060 47,000 TDR 13.20 — 13.20 11.95
CJ5A/CK5A/CK5BA060 46,500 TDR 13.00 — 13.00 11.70
CJ5A/CK5A/CK5BN060 45,500 TDR 13.00 — 13.00 11.95
CJ5A/CK5A/CK5BX060 47,500 TDR 13.50 — 13.50 12.05
CK3BA060 46,500 TDR 13.00 — 13.00 11.70
COILS + 58MVP120-20VARIABLE SPEED FURNACE
CC5A/CD5AA060 46,500 TDR 13.00 — 13.00 11.55
CC5A/CD5AC048 45,000 TDR 12.50 — 12.50 11.20
CC5A/CD5AW048 46,000 TDR 13.00 — 13.00 11.50
CC5A/CD5AW060 47,000 TDR 13.50 — 13.50 12.00
CD5AA048 46,000 TDR 13.00 — 13.00 11.50
CE3AA048 46,500 TDR 13.00 — 13.00 11.55
CE3AA060 47,000 TDR 13.20 — 13.20 11.95
CJ5A/CK5A/CK5BA060 46,500 TDR 13.00 — 13.00 11.80
CJ5A/CK5A/CK5BW048 46,000 TDR 13.00 — 13.00 11.60
CJ5A/CK5A/CK5BX060 47,500 TDR 13.50 — 13.50 12.15
CK3BA048 46,000 TDR 13.00 — 13.00 11.60
CK3BA060 46,500 TDR 13.00 — 13.00 11.80
COILS + 58U(H,X)V080-16VARIABLE SPEED FURNACE
CC5A/CD5AA060 45,500 TDR 13.50 — 13.50 12.15
CC5A/CD5AC048 45,000 TDR 13.00 — 13.00 11.95
CC5A/CD5AW048 46,500 TDR 13.50 — 13.50 12.15
CC5A/CD5AW060 47,000 TDR 14.00 — 14.00 12.50
CD5AA048 46,000 TDR 13.50 — 13.50 12.15
CE3AA048 46,500 TDR 13.50 — 13.50 12.20
CE3AA060 47,000 TDR 14.00 — 14.00 12.50
CJ5A/CK5A/CK5BA048 46,000 TDR 13.20 — 13.20 11.85
CK3BA048 46,000 TDR 13.20 — 13.20 11.85
CK3BA060 46,500 TDR 13.20 — 13.20 12.00
COILS + 58U(H,X)V100-20VARIABLE SPEED FURNACE
CC5A/CD5AA060 45,500 TDR 13.50 — 13.50 12.15
CC5A/CD5AC048 45,000 TDR 13.00 — 13.00 11.95
CC5A/CD5AW048 46,000 TDR 13.50 — 13.50 12.15
CC5A/CD5AW060 47,000 TDR 14.00 — 14.00 12.50
CD5AA048 46,000 TDR 13.50 — 13.50 12.15
CE3AA048 46,500 TDR 13.50 — 13.50 12.20
CE3AA060 47,000 TDR 14.00 — 14.00 12.50
CJ5A/CK5A/CK5BA060 46,500 TDR 13.50 — 13.50 12.60
CJ5A/CK5A/CK5BW048 46,000 TDR 13.50 — 13.50 12.40
CJ5A/CK5A/CK5BX060 47,500 TDR 14.00 — 14.00 12.90
CK3BA048 46,000 TDR 13.50 — 13.50 12.40
CK3BA060 46,500 TDR 13.50 — 13.50 12.60
COILS + 58U(H,X)V120-20VARIABLE SPEED FURNACE
CC5A/CD5AA060 45,500 TDR 13.50 — 13.50 12.15
CC5A/CD5AC048 45,000 TDR 13.00 — 13.00 11.95
CC5A/CD5AW048 46,000 TDR 13.50 — 13.50 12.15

14
Combination ratings continued
* Tested combination
† In most cases, only 1 method should be used to achieveTDR function. Using more than 1 method in a system may cause degradation in perfor-
mance.Use either the accessory Time-Delay Relay KAATD0101TDR or a furnace equipped with TDR. All Carrier furnaces are equipped with
TDR except for the 58GFA.
‡ Based on computer simulation.TXV must be Puron® compatible and hard shutoff type.
** Ratings shown are with FK4C R-22 TXV replaced with Puron® TXV.
†† Ratings shown are with FK4C R-22 TXV replaced with Piston Body Kit and piston shipped with outdoor unit.
EER — Energy Efficiency Ratio
LLS — Liquid-Line Solenoid
SEER — Seasonal Energy Efficiency Ratio
TDR — Time-Delay Relay
TXV — Thermostatic Expansion Valve
NOTES: 1. Ratings are net values reflecting the effects of circulating fan motor heat. Supplemental electric heat is not included.
2. Tested outdoor/indoor combinations have been tested in accordance with DOE test procedures for central air conditioners. Ratings for
other combinations are determined under DOE computer simulation procedures.
3. Determine actual CFM values obtainable for your system by referring to fan performance data in fan coil or furnace coil literature.
4. Do not apply with capillary tube coils as performance and reliability are significantly affected.
UNIT
SIZE-SERIES INDOOR UNIT TOT. CAP. BTUH
FACTORY-
SUPPLIED
ENHANCE-
MENT
SEER
EER
Standard
Rating
CarrierGasFurnace
or Accessory
TDR† Accessory TXV‡
048-30
CC5A/CD5AW060 47,000 TDR 14.00 — 14.00 12.50
CD5AA048 46,000 TDR 13.50 — 13.50 12.15
CE3AA048 46,500 TDR 13.50 — 13.50 12.20
CE3AA060 47,000 TDR 14.00 — 14.00 12.50
CJ5A/CK5A/CK5BA060 46,500 TDR 13.50 — 13.50 12.45
CJ5A/CK5A/CK5BW048 46,000 TDR 13.50 — 13.50 12.25
CJ5A/CK5A/CK5BX060 47,500 TDR 14.00 — 14.00 12.75
CK3BA048 46,000 TDR 13.50 — 13.50 12.25
CK3BA060 46,500 TDR 13.50 — 13.50 12.45
060-31
CJ5A/CK5A/CK5BX060* 59,000 LLS — 13.00 — 11.10
CJ5A/CK5A/CK5BA060 58,000 LLS — 12.50 — 10.95
CK3BA060 58,000 LLS — 12.50 — 10.95
F(A,B)4AN(F,B,C)060 58,000 LLS & TDR 12.20 — — 10.60
FG3AAA060 57,000 LLS — 12.20 — 10.80
FK4CNB006+Puron® (R-410A)TXV** 59,000 LLS & TDR 13.25 — — 11.55
FK4CNB006+96 Piston†† 59,000 LLS &TDR 13.25 — — 11.55
FV4ANB006 58,000 LLS, TDR, & TXV 13.25 — — 11.55
FX4ANB060 58,000 LLS, TDR, & TXV 12.50 — — 10.95
COILS + 58MVP100-20VARIABLE SPEED FURNACE
CJ5A/CK5A/CK5BA060 57,000 LLS & TDR 12.50 — — 11.00
CJ5A/CK5A/CK5BX060 58,000 LLS & TDR 13.00 — — 11.25
CK3BA060 57,000 LLS & TDR 12.50 — — 11.00
COILS + 58MVP120-20VARIABLE SPEED FURNACE
CJ5A/CK5A/CK5BA060 57,000 LLS & TDR 12.75 — — 11.05
CJ5A/CK5A/CK5BX060 58,000 LLS & TDR 13.00 — — 11.30
CK3BA060 57,000 LLS & TDR 12.75 — — 11.05
COILS + 58U(H,X)V100-20VARIABLE SPEED FURNACE
CJ5A/CK5A/CK5BA060 57,500 LLS & TDR 13.00 — — 11.20
CJ5A/CK5A/CK5BX060 58,500 LLS & TDR 13.25 — — 11.50
CK3BA060 57,500 LLS & TDR 13.00 — — 11.20
COILS + 58U(H,X)V120-20VARIABLE SPEED FURNACE
CJ5A/CK5A/CK5BA060 57,500 LLS & TDR 12.75 — — 11.05
CJ5A/CK5A/CK5BX060 58,500 LLS & TDR 13.00 — — 11.35
CK3BA060 57,500 LLS & TDR 12.75 — — 11.05

15
Detailed cooling capacities*
See notes on pg. 24.
EVAP
AIR CONDENSER ENTERING AIRTEMPERATURES °F 75 85 95 105 115 125
CFM EWB
Capacity
MBtuh† Total
Sys
KW**
Capacity
MBtuh† Total
Sys
KW**
Capacity
MBtuh† Total
Sys
KW**
Capacity
MBtuh† Total
Sys
KW**
Capacity
MBtuh† Total
Sys
KW**
Capacity
MBtuh† Total
Sys
KW**Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡
38TXA024-30 Outdoor Section With CC5A/CD5AA030 Indoor Section
650
72 27.3 12.9 1.47 26.5 12.6 1.64 25.5 12.3 1.83 24.4 11.8 2.03 23.1 11.4 2.26 21.6 10.8 2.50
67 25.7 16.3 1.47 24.7 16.0 1.63 23.6 15.4 1.82 22.3 14.9 2.02 21.0 14.4 2.23 18.8 13.5 2.46
63†† 22.9 15.5 1.45 21.4 14.8 1.61 20.0 14.2 1.79 18.7 13.6 1.98 17.3 13.0 2.19 15.7 12.3 2.42
62 22.2 18.8 1.45 20.7 18.0 1.61 19.2 17.3 1.78 17.7 16.6 1.97 16.3 15.9 2.18 15.0 15.0 2.41
57 20.0 20.0 1.44 18.9 18.9 1.59 17.6 17.6 1.77 17.0 17.0 1.96 16.2 16.2 2.18 15.3 15.3 2.41
750
72 27.7 13.3 1.50 26.9 13.0 1.67 25.9 12.7 1.86 24.8 12.3 2.06 23.4 11.8 2.28 22.0 11.3 2.53
67 26.1 17.0 1.49 25.2 16.8 1.66 24.0 16.2 1.85 22.8 15.8 2.05 21.5 15.3 2.27 19.1 14.4 2.50
63†† 24.5 16.9 1.49 23.0 16.2 1.65 21.6 15.6 1.83 20.2 15.0 2.03 18.8 14.3 2.24 17.2 13.7 2.47
62 23.2 20.3 1.48 21.7 19.6 1.64 20.1 18.8 1.82 18.8 18.1 2.01 17.4 17.3 2.22 16.3 16.3 2.46
57 21.1 21.1 1.47 20.0 20.0 1.63 19.4 19.4 1.81 18.6 18.6 2.01 17.8 17.8 2.23 16.8 16.8 2.46
850
72 27.8 13.5 1.53 27.1 13.3 1.70 26.3 13.1 1.89 25.2 12.8 2.09 23.7 12.3 2.32 22.2 11.8 2.56
67 26.6 17.8 1.53 25.4 17.3 1.69 24.3 17.0 1.88 23.2 16.7 2.08 21.8 16.2 2.30 20.0 15.5 2.54
63†† 25.2 17.8 1.52 24.0 17.3 1.69 22.8 16.8 1.87 21.6 16.3 2.07 19.9 15.6 2.28 17.6 14.6 2.51
62 24.3 21.9 1.52 22.5 21.0 1.68 21.1 20.2 1.85 19.7 19.5 2.05 18.4 18.4 2.27 17.5 17.5 2.51
57 22.7 22.7 1.51 21.6 21.6 1.67 20.9 20.9 1.85 20.0 20.0 2.05 19.2 19.2 2.27 17.5 17.5 2.51
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section Size Cooling Indoor Section Size Cooling Capacity Power Capacity Power
CC5A/CD5AA 024 1.00 1.00 COILS + 58MVP060-14VARIABLE SPEED FURNACE
030 1.00 1.00 CC5A/CD5AA 024 1.00 0.96
CC5A/CD5AW 024 1.00 1.00 030 1.00 0.95
030 1.00 1.00 CC5A/CD5AW 024 1.00 0.96
CE3AA 024 1.00 1.00 030 1.00 0.95
030 1.00 1.00 CE3AA 024 1.00 0.96
CF5AA 024 1.00 1.00 030 1.00 0.95
CJ5A/CK5A/CK5BA 024 1.00 1.00 CJ5A/CK5A/CK5BW 024 1.00 0.95
030 1.00 1.00 030 1.00 0.95
CJ5A/CK5A/CK5BW 024 1.00 1.00 CK3BA 024 1.00 0.95
030 1.00 1.00 030 1.00 0.95
CK3BA 024 1.00 1.00 COILS + 58MVP080-14 VARIABLE SPEED FURNACE
030 1.00 1.00 CC5A/CD5AA 024 1.00 0.95
F(A,B)4AN(F,C) 024 1.00 1.00 030 1.00 0.94
030 1.00 1.00 CC5A/CD5AW 024 1.00 0.95
FF1(B,C,D)NA 024 1.00 1.00 030 1.00 0.94
030 1.00 1.00 CE3AA 024 1.00 0.95
FG3AAA 024 1.00 1.00 030 1.00 0.94
FK4CNF 002‡‡ 1.08 0.96 CJ5A/CK5A/CK5BW 024 1.00 0.94
003‡‡ 1.17 0.95 030 1.00 0.94
003*** 1.08 0.92 CK3BA 024 1.00 0.94
FV4ANF 002 1.08 0.96 030 1.00 0.94
003 1.08 0.95 COILS + 58U(H,X)V060-12 VARIABLE SPEED FURNACE
FX4ANF 030 1.00 1.03 CC5A/CD5AA 024 1.00 0.93
COILS + 58MVP040-14VARIABLE SPEED FURNACE 030 1.00 0.93
CC5A/CD5AA 024 1.00 0.95 CC5A/CD5AW 024 1.00 0.93
030 1.00 0.94 030 1.00 0.93
CC5A/CD5AW 024 1.00 0.95 CE3AA 024 1.00 0.94
030 1.00 0.94 030 1.00 0.93
CE3AA 024 1.00 0.96 CJ5A/CK5A/CK5BA 024 1.00 0.93
030 1.00 0.95 030 1.00 0.93
CJ5A/CK5A/CK5BW 030 1.00 0.95 CJ5A/CK5A/CK5BW 030 1.00 0.93
CK3BA 024 1.00 0.95 CK3BA 024 1.00 0.93
030 1.00 0.95 030 1.00 0.93

16
Detailed cooling capacities* continued
See notes on pg. 24.
EVAP
AIR CONDENSER ENTERING AIRTEMPERATURES °F 75 85 95 105 115 125
CFM EWB
Capacity
MBtuh† Total
Sys
KW**
Capacity
MBtuh† Total
Sys
KW**
Capacity
MBtuh† Total
Sys
KW**
Capacity
MBtuh† Total
Sys
KW**
Capacity
MBtuh† Total
Sys
KW**
Capacity
MBtuh† Total
Sys
KW**Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡
38TXA030-30 Outdoor Section With CC5A/CD5AA036 Indoor Section
1875
72 33.4 16.3 1.80 32.2 15.9 1.99 31.1 15.6 2.21 29.7 15.2 2.46 27.9 14.5 2.73 26.0 13.9 3.05
67 31.4 21.2 1.79 30.0 20.7 1.97 28.6 20.1 2.19 27.0 19.6 2.43 24.5 18.6 2.69 21.7 17.5 2.97
63†† 29.4 20.9 1.77 27.8 20.2 1.96 25.1 19.0 2.15 22.3 17.8 2.37 20.4 17.0 2.63 18.2 16.1 2.91
62 28.6 25.7 1.77 26.6 24.7 1.95 24.5 23.6 2.15 22.3 22.3 2.37 20.5 20.5 2.63 19.4 19.4 2.93
57 26.6 26.6 1.75 25.1 25.1 1.93 23.6 23.6 2.14 21.9 21.9 2.37 20.8 20.8 2.63 19.6 19.6 2.93
1000
72 33.9 16.9 1.85 32.7 16.5 2.04 31.6 16.3 2.26 30.0 15.8 2.50 28.2 15.2 2.78 26.3 14.7 3.10
67 31.9 22.3 1.83 30.5 21.8 2.02 29.0 21.3 2.23 27.4 20.8 2.47 25.2 20.0 2.74 22.3 18.9 3.02
63†† 30.0 22.1 1.82 28.5 21.5 2.00 25.8 20.3 2.20 23.1 19.2 2.42 21.1 18.3 2.68 18.9 17.4 2.96
62 29.4 27.5 1.81 27.2 26.4 1.99 25.1 25.1 2.19 23.3 23.3 2.43 22.3 22.3 2.69 20.3 20.3 2.99
57 27.9 27.9 1.80 26.4 26.4 1.99 24.7 24.7 2.19 23.7 23.7 2.43 22.6 22.6 2.70 20.4 20.4 2.99
1125
72 34.2 17.4 1.89 33.0 17.1 2.08 31.7 16.7 2.30 30.1 16.3 2.54 28.5 15.9 2.82 26.5 15.4 3.15
67 32.2 23.3 1.87 30.8 22.9 2.06 29.3 22.4 2.27 27.7 22.0 2.51 25.7 21.3 2.78 22.7 20.2 3.07
63†† 30.3 23.1 1.86 29.0 22.7 2.05 26.3 21.6 2.25 24.1 20.6 2.47 21.8 19.6 2.73 19.6 18.7 3.01
62 29.9 29.0 1.86 28.1 27.9 2.04 26.6 26.6 2.25 25.1 25.1 2.49 23.8 23.8 2.75 21.2 21.2 3.04
57 29.5 29.5 1.85 28.2 28.2 2.04 26.6 26.6 2.25 25.3 25.3 2.49 23.5 23.5 2.75 21.1 21.1 3.04
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section Size Cooling Indoor Section Size Cooling Capacity Power Capacity Power
CC5A/CD5AA 030 0.97 0.99 CC5A/CD5AW 030 0.98 0.95
036 1.00 1.00 036 1.02 0.95
CC5A/CD5AW 030 0.97 0.99 CE3AA 030 1.00 0.95
CD5AW 036 1.00 1.00 036 1.01 0.95
CE3AA 030 0.97 1.00 CJ5A/CK5A/CK5BW 030 0.98 0.95
036 0.98 1.00 036 1.02 0.95
CF5AA 036 0.98 1.00 CK3BA 030 0.98 0.95
CJ5A/CK5A/CK5BA 030 0.97 0.99 036 1.02 0.95
036 1.00 0.99 COILS + 58MVP060-14VARIABLE SPEED FURNACE
CJ5A/CK5A/CK5BN 036 0.93 0.99 CC5A/CD5AA 030 0.98 0.95
CJ5A/CK5A/CK5BW 030 0.97 0.99 036 1.02 0.95
036 1.00 0.99 CC5A/CD5AW 030 0.98 0.95
CK3BA 030 0.97 0.99 036 1.02 0.95
036 1.00 0.99 CE3AA 030 1.00 0.95
F(A,B)4ANF 030 0.99 0.99 036 1.01 0.95
036 1.00 1.01 CJ5A/CK5A/CK5BA 036 1.02 0.95
FF1(A,B)NA 030 0.99 1.00 CJ5A/CK5A/CK5BW 030 0.98 0.95
FG3AAA 036 0.98 1.00 CK3BA 030 0.98 0.95
FK4CNF 001‡‡ 1.00 0.94 036 1.02 0.95
001*** 0.99 0.92 COILS + 58MVP080-14VARIABLE SPEED FURNACE
002‡‡ 1.00 0.94 CC5A/CD5AA 030 0.99 0.94
003‡‡ 1.02 0.92 036 1.02 0.94
003*** 1.00 0.90 CC5A/CD5AW 030 0.99 0.94
FV4ANF 002 1.00 0.94 036 1.02 0.94
003 1.02 0.92 CE3AA 030 1.00 0.94
FX4ANF 030 0.99 0.99 036 1.01 0.94
036 1.00 1.02 CJ5A/CK5A/CK5BW 030 0.99 0.95
COILS + 58MVP040-14VARIABLE SPEED FURNACE 036 1.02 0.94
CC5A/CD5AA 030 0.98 0.95 CK3BA 030 0.99 0.95
036 1.02 0.95 036 1.02 0.94

17
Detailed cooling capacities* continued
See notes on pg. 24.
EVAP
AIR CONDENSER ENTERING AIRTEMPERATURES °F 75 85 95 105 115 125
CFM EWB
Capacity
MBtuh† Total
Sys
KW**
Capacity
MBtuh† Total
Sys
KW**
Capacity
MBtuh† Total
Sys
KW**
Capacity
MBtuh† Total
Sys
KW**
Capacity
MBtuh† Total
Sys
KW**
Capacity
MBtuh† Total
Sys
KW**Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡
38TXA030-30 Outdoor Section With CC5A/CD5AA036 Indoor Section continued
1875
72 33.4 16.3 1.80 32.2 15.9 1.99 31.1 15.6 2.21 29.7 15.2 2.46 27.9 14.5 2.73 26.0 13.9 3.05
67 31.4 21.2 1.79 30.0 20.7 1.97 28.6 20.1 2.19 27.0 19.6 2.43 24.5 18.6 2.69 21.7 17.5 2.97
63†† 29.4 20.9 1.77 27.8 20.2 1.96 25.1 19.0 2.15 22.3 17.8 2.37 20.4 17.0 2.63 18.2 16.1 2.91
62 28.6 25.7 1.77 26.6 24.7 1.95 24.5 23.6 2.15 22.3 22.3 2.37 20.5 20.5 2.63 19.4 19.4 2.93
57 26.6 26.6 1.75 25.1 25.1 1.93 23.6 23.6 2.14 21.9 21.9 2.37 20.8 20.8 2.63 19.6 19.6 2.93
1000
72 33.9 16.9 1.85 32.7 16.5 2.04 31.6 16.3 2.26 30.0 15.8 2.50 28.2 15.2 2.78 26.3 14.7 3.10
67 31.9 22.3 1.83 30.5 21.8 2.02 29.0 21.3 2.23 27.4 20.8 2.47 25.2 20.0 2.74 22.3 18.9 3.02
63†† 30.0 22.1 1.82 28.5 21.5 2.00 25.8 20.3 2.20 23.1 19.2 2.42 21.1 18.3 2.68 18.9 17.4 2.96
62 29.4 27.5 1.81 27.2 26.4 1.99 25.1 25.1 2.19 23.3 23.3 2.43 22.3 22.3 2.69 20.3 20.3 2.99
57 27.9 27.9 1.80 26.4 26.4 1.99 24.7 24.7 2.19 23.7 23.7 2.43 22.6 22.6 2.70 20.4 20.4 2.99
1125
72 34.2 17.4 1.89 33.0 17.1 2.08 31.7 16.7 2.30 30.1 16.3 2.54 28.5 15.9 2.82 26.5 15.4 3.15
67 32.2 23.3 1.87 30.8 22.9 2.06 29.3 22.4 2.27 27.7 22.0 2.51 25.7 21.3 2.78 22.7 20.2 3.07
63†† 30.3 23.1 1.86 29.0 22.7 2.05 26.3 21.6 2.25 24.1 20.6 2.47 21.8 19.6 2.73 19.6 18.7 3.01
62 29.9 29.0 1.86 28.1 27.9 2.04 26.6 26.6 2.25 25.1 25.1 2.49 23.8 23.8 2.75 21.2 21.2 3.04
57 29.5 29.5 1.85 28.2 28.2 2.04 26.6 26.6 2.25 25.3 25.3 2.49 23.5 23.5 2.75 21.1 21.1 3.04
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section Size Cooling Indoor Section Size Cooling Capacity Power Capacity Power
COILS + 58U(H,X)V060-12VARIABLE SPEED FURNACE COILS + 58U(H,X)V080-16VARIABLE SPEED FURNACE
CC5A/CD5AA 030 0.97 0.93 CC5A/CD5AA 030 0.97 0.91
036 1.00 0.93 036 1.01 0.91
CC5A/CD5AW 030 0.97 0.93 CC5A/CD5AW 030 0.97 0.91
036 1.00 0.93 036 1.01 0.91
CE3AA 030 0.98 0.93 CE3AA 030 0.99 0.92
036 0.99 0.93 036 0.99 0.92
CJ5A/CK5A/CK5BA 030 0.97 0.92 CJ5A/CK5A/CK5BW 030 0.97 0.91
036 1.00 0.92 036 1.00 0.91
CJ5A/CK5A/CK5BN 036 0.93 0.93 CK3BA 030 0.97 0.91
CJ5A/CK5A/CK5BW 030 0.97 0.92 036 1.00 0.91
CK3BA 030 0.97 0.92 — — —
036 1.00 0.92

18
Detailed cooling capacities* continued
See notes on pg. 24.
EVAP
AIR CONDENSER ENTERING AIRTEMPERATURES °F 75 85 95 105 115 125
CFM EWB
Capacity
MBtuh† Total
Sys
KW**
Capacity
MBtuh† Total
Sys
KW**
Capacity
MBtuh† Total
Sys
KW**
Capacity
MBtuh† Total
Sys
KW**
Capacity
MBtuh† Total
Sys
KW**
Capacity
MBtuh† Total
Sys
KW**Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡
38TXA036-30 Outdoor Section With CC5A/CD5AA042 Indoor Section
1050
72 40.4 19.6 2.15 39.0 19.2 2.40 37.4 18.6 2.66 35.6 18.0 2.96 33.4 17.3 3.28 30.9 16.4 3.64
67 38.0 25.3 2.14 36.4 24.8 2.38 34.6 24.1 2.65 32.5 23.3 2.94 30.4 22.4 3.24 26.5 20.9 3.57
63†† 34.9 24.6 2.12 32.5 23.6 2.35 30.1 22.5 2.60 27.5 21.4 2.87 24.9 20.3 3.17 22.3 19.2 3.50
62 33.9 30.2 2.12 31.6 29.1 2.34 29.2 27.9 2.59 26.7 26.5 2.86 24.5 24.5 3.17 23.2 23.2 3.51
57 31.3 31.3 2.09 29.5 29.5 2.32 27.5 27.5 2.57 26.4 26.4 2.86 25.1 25.1 3.17 23.6 23.6 3.51
1200
72 41.0 20.3 2.20 39.7 19.9 2.45 38.1 19.4 2.72 36.2 18.9 3.02 33.9 18.1 3.34 31.4 17.3 3.70
67 38.5 26.5 2.19 37.0 26.1 2.43 35.0 25.3 2.69 33.1 24.7 2.99 30.9 23.9 3.30 26.9 22.4 3.62
63†† 36.1 26.3 2.18 33.6 25.2 2.41 31.1 24.1 2.66 28.3 23.0 2.93 26.0 22.0 3.24 23.3 20.9 3.56
62 34.8 32.4 2.17 32.4 31.2 2.39 30.0 29.7 2.65 27.9 27.9 2.93 26.8 26.8 3.25 24.6 24.6 3.58
57 32.7 32.7 2.15 31.0 31.0 2.38 29.9 29.9 2.64 28.7 28.7 2.94 27.3 27.3 3.25 24.8 24.8 3.58
1350
72 41.4 20.9 2.25 40.2 20.6 2.50 38.2 19.9 2.76 36.4 19.4 3.06 34.2 18.8 3.38 31.7 18.2 3.75
67 39.0 27.8 2.24 37.4 27.3 2.48 35.5 26.7 2.74 33.5 26.1 3.03 31.2 25.4 3.35 27.2 23.8 3.68
63†† 36.9 27.8 2.23 34.5 26.8 2.46 31.9 25.7 2.71 29.4 24.6 2.99 26.9 23.6 3.30 24.2 22.4 3.62
62 35.8 34.5 2.22 33.2 32.9 2.45 31.1 31.1 2.70 30.0 30.0 3.00 28.6 28.6 3.32 25.8 25.8 3.65
57 34.8 34.8 2.22 33.3 33.3 2.45 32.0 32.0 2.72 30.7 30.7 3.01 28.3 28.3 3.32 25.9 25.9 3.65
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section Size Cooling Indoor Section Size Cooling Capacity Power Capacity Power
CC5A/CD5AA 036 1.00 1.00 COILS + 58MVP060-14VARIABLE SPEED FURNACE
042 1.00 1.00 CC5A/CD5AA 036 1.00 0.98
CC5A/CD5AW 042 1.00 1.00 042 1.00 0.97
CD5AW 036 1.00 1.00 CC5A/CD5AW 042 1.00 0.97
CE3AA 036 1.00 1.00 CD5AW 036 1.00 0.98
042 1.00 1.00 CE3AA 036 1.00 0.98
CF5AA 036 1.00 1.00 042 1.00 0.98
CJ5A/CK5A/CK5BA 036 1.00 1.00 CJ5A/CK5A/CK5BA 036 1.00 0.98
042 1.00 1.00 CJ5A/CK5A/CK5BN 042 0.97 0.98
CJ5A/CK5A/CK5BN 042 0.97 1.00 CK3BA 036 1.00 0.98
CJ5A/CK5A/CK5BW 036 1.00 1.00 042 1.00 0.97
CK3BA 036 1.00 1.00 COILS + 58MVP080-14 VARIABLE SPEED FURNACE
042 1.00 1.00 CC5A/CD5AA 036 1.00 0.97
F(A,B)4ANF 036 1.00 1.00 042 1.00 0.96
F(A,B)4AN(F,B) 042 1.00 1.00 CC5A/CD5AW 042 1.00 0.96
FG3AAA 036 1.00 1.00 CD5AW 036 1.00 0.97
FK4CNF 002‡‡ 1.00 0.94 CE3AA 036 1.00 0.97
003‡‡ 1.00 0.93 042 1.00 0.96
005‡‡ 1.03 0.96 CJ5A/CK5A/CK5BA 042 1.00 0.96
005*** 1.00 0.91 CJ5A/CK5A/CK5BW 036 1.00 0.97
FV4ANF 002 1.00 0.94 CK3BA 036 1.00 0.97
003 1.00 0.93 042 1.00 0.96
005 1.03 0.96 COILS + 58MVP080-20VARIABLE SPEED FURNACE
FX4ANF 036 0.97 1.00 CC5A/CD5AA 036 1.00 0.96
042 1.00 1.00 042 1.00 0.95
COILS + 58MVP040-14VARIABLE SPEED FURNACE CC5A/CD5AW 042 1.00 0.95
CC5A/CD5AA 036 1.00 0.98 CD5AW 036 1.00 0.96
042 1.00 0.97 CE3AA 036 1.00 0.96
CC5A/CD5AW 042 1.00 0.97 042 1.00 0.96
CE3AA 036 1.00 0.98 CJ5A/CK5A/CK5BA 042 1.00 0.97
042 1.00 0.98 CJ5A/CK5A/CK5BW 036 1.00 0.98
CJ5A/CK5A/CK5BA 042 1.00 0.98 CK3BA 036 1.00 0.98
CJ5A/CK5A/CK5BW 036 1.00 0.98 042 1.00 0.97
CK3BA 036 1.00 0.98 — — —
042 1.00 0.98

19
Detailed cooling capacities* continued
See notes on pg. 24.
EVAP
AIR CONDENSER ENTERING AIRTEMPERATURES °F 75 85 95 105 115 125
CFM EWB
Capacity
MBtuh† Total
Sys
KW**
Capacity
MBtuh† Total
Sys
KW**
Capacity
MBtuh† Total
Sys
KW**
Capacity
MBtuh† Total
Sys
KW**
Capacity
MBtuh† Total
Sys
KW**
Capacity
MBtuh† Total
Sys
KW**Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡
38TXA036-30 Outdoor Section With CC5A/CD5AA042 Indoor Section continued
1050
72 40.4 19.6 2.15 39.0 19.2 2.40 37.4 18.6 2.66 35.6 18.0 2.96 33.4 17.3 3.28 30.9 16.4 3.64
67 38.0 25.3 2.14 36.4 24.8 2.38 34.6 24.1 2.65 32.5 23.3 2.94 30.4 22.4 3.24 26.5 20.9 3.57
63†† 34.9 24.6 2.12 32.5 23.6 2.35 30.1 22.5 2.60 27.5 21.4 2.87 24.9 20.3 3.17 22.3 19.2 3.50
62 33.9 30.2 2.12 31.6 29.1 2.34 29.2 27.9 2.59 26.7 26.5 2.86 24.5 24.5 3.17 23.2 23.2 3.51
57 31.3 31.3 2.09 29.5 29.5 2.32 27.5 27.5 2.57 26.4 26.4 2.86 25.1 25.1 3.17 23.6 23.6 3.51
1200
72 41.0 20.3 2.20 39.7 19.9 2.45 38.1 19.4 2.72 36.2 18.9 3.02 33.9 18.1 3.34 31.4 17.3 3.70
67 38.5 26.5 2.19 37.0 26.1 2.43 35.0 25.3 2.69 33.1 24.7 2.99 30.9 23.9 3.30 26.9 22.4 3.62
63†† 36.1 26.3 2.18 33.6 25.2 2.41 31.1 24.1 2.66 28.3 23.0 2.93 26.0 22.0 3.24 23.3 20.9 3.56
62 34.8 32.4 2.17 32.4 31.2 2.39 30.0 29.7 2.65 27.9 27.9 2.93 26.8 26.8 3.25 24.6 24.6 3.58
57 32.7 32.7 2.15 31.0 31.0 2.38 29.9 29.9 2.64 28.7 28.7 2.94 27.3 27.3 3.25 24.8 24.8 3.58
1350
72 41.4 20.9 2.25 40.2 20.6 2.50 38.2 19.9 2.76 36.4 19.4 3.06 34.2 18.8 3.38 31.7 18.2 3.75
67 39.0 27.8 2.24 37.4 27.3 2.48 35.5 26.7 2.74 33.5 26.1 3.03 31.2 25.4 3.35 27.2 23.8 3.68
63†† 36.9 27.8 2.23 34.5 26.8 2.46 31.9 25.7 2.71 29.4 24.6 2.99 26.9 23.6 3.30 24.2 22.4 3.62
62 35.8 34.5 2.22 33.2 32.9 2.45 31.1 31.1 2.70 30.0 30.0 3.00 28.6 28.6 3.32 25.8 25.8 3.65
57 34.8 34.8 2.22 33.3 33.3 2.45 32.0 32.0 2.72 30.7 30.7 3.01 28.3 28.3 3.32 25.9 25.9 3.65
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section Size Cooling Indoor Section Size Cooling Capacity Power Capacity Power
COILS + 58MVP100-20VARIABLE SPEED FURNACE COILS + 58U(H,X)V080-16VARIABLE SPEED FURNACE
CC5A/CD5AA 036 1.00 0.96 CC5A/CD5AA 036 1.00 0.93
042 1.00 0.95 042 1.00 0.92
CC5A/CD5AW 042 1.00 0.95 CC5A/CD5AW 042 1.00 0.92
CD5AW 036 1.00 0.96 CD5AW 036 1.00 0.93
CE3AA 036 1.00 0.96 CE3AA 036 1.00 0.93
042 1.00 0.96 042 1.00 0.93
CJ5A/CK5A/CK5BA 042 1.00 0.95 CJ5A/CK5A/CK5BA 042 1.00 0.93
CJ5A/CK5A/CK5BW 036 1.00 0.96 CJ5A/CK5A/CK5BW 036 1.00 0.93
CK3BA 036 1.00 0.96 CK3BA 036 1.00 0.93
042 1.00 0.95 042 1.00 0.93
COILS + 58MVP120-20VARIABLE SPEED FURNACE COILS + 58U(H,X)V100-20VARIABLE SPEED FURNACE
CC5A/CD5AA 036 1.00 0.96 CC5A/CD5AA 036 1.00 0.92
042 1.00 0.95 042 1.00 0.92
CC5A/CD5AW 042 1.00 0.95 CD5AW 036 1.00 0.92
CD5AW 036 1.00 0.96 CE3AA 036 1.00 0.92
CE3AA 036 1.00 0.96 042 1.00 0.92
042 1.00 0.96 CJ5A/CK5A/CK5BA 042 1.00 0.91
CJ5A/CK5A/CK5BA 042 1.00 0.95 CJ5A/CK5A/CK5BW 036 1.00 0.92
CJ5A/CK5A/CK5BW 036 1.00 0.96 CK3BA 036 1.00 0.92
CK3BA 036 1.00 0.96 042 1.00 0.91
042 1.00 0.95 COILS + 58U(H,X)V120-20 VARIABLE SPEED FURNACE
COILS + 58U(H,X)V060-12VARIABLE SPEED FURNACE CC5A/CD5AA 036 1.00 0.93
CC5A/CD5AA 036 1.00 0.95 042 1.00 0.92
042 1.00 0.94 CC5A/CD5AW 042 1.00 0.92
CC5A/CD5AW 042 1.00 0.94 CD5AW 036 1.00 0.93
CD5AW 036 1.00 0.95 CE3AA 036 1.00 0.93
CE3AA 036 1.00 0.95 042 1.00 0.93
042 1.00 0.94 CJ5A/CK5A/CK5BA 042 1.00 0.92
CJ5A/CK5A/CK5BA 036 1.00 0.95 CJ5A/CK5A/CK5BW 036 1.00 0.92
CK3BA 036 1.00 0.95 CK3BA 036 1.00 0.92
042 1.00 0.94 042 1.00 0.92

20
Detailed cooling capacities* continued
See notes on pg. 24.
EVAP
AIR CONDENSER ENTERING AIRTEMPERATURES °F 75 85 95 105 115 125
CFM EWB
Capacity
MBtuh† Total
Sys
KW**
Capacity
MBtuh† Total
Sys
KW**
Capacity
MBtuh† Total
Sys
KW**
Capacity
MBtuh† Total
Sys
KW**
Capacity
MBtuh† Total
Sys
KW**
Capacity
MBtuh† Total
Sys
KW**Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡
38TXA042-30 Outdoor Section With CD5AA048 Indoor Section
1225
72 46.7 22.7 2.49 45.2 22.3 2.77 43.3 21.6 3.09 41.2 20.9 3.44 38.8 20.1 3.83 36.0 19.2 4.26
67 44.0 29.5 2.47 42.3 28.9 2.75 39.8 27.8 3.05 37.7 27.1 3.40 35.4 26.3 3.79 31.4 24.7 4.18
63†† 40.5 28.7 2.44 37.8 27.5 2.70 35.0 26.3 3.00 32.0 25.0 3.32 30.2 24.3 3.70 27.8 23.3 4.11
62 39.3 35.4 2.43 36.7 34.1 2.69 33.9 32.7 2.98 31.1 30.9 3.31 29.5 29.5 3.69 27.9 27.9 4.11
57 36.4 36.4 2.40 34.3 34.3 2.67 32.1 32.1 2.96 30.8 30.8 3.30 29.4 29.4 3.69 27.7 27.7 4.11
1400
72 47.1 23.3 2.55 45.8 23.0 2.83 43.9 22.5 3.15 41.8 21.8 3.51 39.3 21.1 3.90 36.5 20.2 4.33
67 44.3 30.5 2.52 42.7 30.2 2.81 40.5 29.4 3.12 38.4 28.8 3.47 35.9 27.9 3.85 31.7 26.4 4.25
63†† 42.1 30.7 2.51 39.3 29.5 2.78 36.4 28.3 3.07 33.6 27.1 3.40 31.8 26.3 3.79 27.9 24.7 4.18
62 40.5 37.9 2.50 37.8 36.5 2.76 35.0 34.8 3.06 32.7 32.7 3.39 31.2 31.2 3.78 29.5 29.5 4.21
57 38.1 38.1 2.48 36.2 36.2 2.74 35.0 35.0 3.05 33.6 33.6 3.40 32.2 32.2 3.79 29.3 29.3 4.20
1575
72 47.5 23.9 2.61 46.2 23.7 2.90 44.4 23.2 3.22 41.8 22.4 3.56 39.5 21.8 3.95 36.8 21.1 4.40
67 44.9 31.9 2.58 43.0 31.5 2.86 41.1 31.1 3.18 38.8 30.3 3.53 36.3 29.6 3.92 32.0 28.0 4.32
63†† 42.5 32.0 2.57 40.5 31.4 2.85 37.6 30.1 3.15 35.0 29.1 3.48 33.1 28.3 3.87 27.9 26.0 4.24
62 41.6 40.2 2.57 38.9 38.5 2.83 36.5 36.5 3.13 35.4 35.4 3.49 32.7 32.7 3.86 30.7 30.7 4.29
57 40.7 40.7 2.56 39.0 39.0 2.83 37.6 37.6 3.15 35.8 35.8 3.49 33.5 33.5 3.87 30.7 30.7 4.29
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section Size Cooling Indoor Section Size Cooling Capacity Power Capacity Power
CC5A/CD5AA 042 1.00 1.00 CD5AA 048 1.00 0.99
CC5A/CD5AC 048 0.99 1.00 CE3AA 042 0.99 1.01
CC5A/CD5AW 042 0.99 1.00 048 0.99 1.01
048 1.00 1.00 COILS + 58MVP060-14VARIABLE SPEED FURNACE
CD5AA 048 1.00 1.00 CC5A/CD5AA 042 1.00 1.00
CE3AA 042 1.01 1.00 CC5A/CD5AC 048 0.99 0.99
048 1.01 1.00 CC5A/CD5AW 042 0.99 1.00
CF5AA 048 1.00 1.00 048 0.99 0.99
CJ5A/CK5A/CK5BA 042 1.00 1.00 CD5AA 048 0.99 0.99
048 1.00 1.00 CE3AA 042 1.00 1.00
CJ5A/CK5A/CK5BN 042 0.98 1.00 048 1.00 1.01
048 0.98 1.00 COILS + 58MVP080-14VARIABLE SPEED FURNACE
CJ5A/CK5A/CK5BW 048 1.00 1.00 CC5A/CD5AA 042 1.00 0.98
CK3BA 042 1.00 1.00 CC5A/CD5AC 048 0.99 0.97
048 1.00 1.00 CC5A/CD5AW 042 0.99 0.98
F(A,B)4AN(F,B) 042 1.00 1.00 048 1.00 0.97
048 1.01 1.00 CD5AA 048 1.00 0.97
FG3AAA 048 0.99 1.00 CE3AA 042 1.01 0.98
FK4CNB 006‡‡ 1.02 0.90 048 1.01 0.99
006*** 1.01 0.92 CJ5A/CK5A/CK5BA 042 1.00 0.99
FK4CNF 003‡‡ 0.98 0.92 048 1.00 0.98
005‡‡ 1.01 0.91 CK3BA 042 1.00 0.99
FV4ANB 006 1.02 0.90 048 1.00 0.98
FV4ANF 003 0.98 0.92 COILS + 58MVP080-20VARIABLE SPEED FURNACE
005 1.01 0.91 CC5A/CD5AA 042 1.00 0.98
FX4ANF 042 0.99 1.00 CC5A/CD5AC 048 0.99 0.96
048 1.00 1.01 CC5A/CD5AW 042 0.99 0.98
COILS + 58MVP040-14VARIABLE SPEED FURNACE 048 1.00 0.96
CC5A/CD5AA 042 1.00 1.01 CC5AA 048 1.00 0.96
CC5A/CD5AC 048 0.99 0.99 CE3AA 042 1.01 0.98
CC5A/CD5AW 042 0.99 1.00 048 1.01 0.98
048 1.00 0.99 — — —
