Carson FY5 Destroyer User manual

ForYoungster5 from Carson Model Sport, is a brushless
truggy that speaks sheer brute force.
Robust technology sturdy alloy components and cool
looks guarantee plenty of action out there. The FY5 get
its power from the 1150watt 4S BL system.
The beefy electric drive makes light work of handling
and develops its own torgue throughoutthe rev range.
A range of set-up options allow the chassis to be adju-
sted for any terrain. The professional, interference-free
2,4GHz remote control included with the FY5, sits com-
fortably in your hand. The ready to run FY5 is supplied
with 2 LiPo power packs 11T.
FY5 Destroyer Line BL4S 2,4GHz RTR
Jegindøvej 21, DK- 8800 Viborg
[phone] - [email protected]
All brands available for Danish customers. For specic brands available in your country
please contact us.
Only whole sale, no sale to END users – Please contact your nearest Dealer.
Art.: 500409040
V.nr.: 450710
• 4WD
• RTR
• Motortype: Brushless11T
• Motor size: 4S Brushless 1500 kV
• Ballbearing: 4 Whells
• Servo: 22kg - metal gear
• Battery: 2 x 7,4V 3200mAh LiPo power
• Speed: 70km/h
• Scale: 1:5
• Length: 680mm
• Width: 415mm
• Not incl: Charger & 8xAA batt.(radio)
• Ballbearing: 4 Whells
• Tires: Off Road
• Rims: Black plastic
• Suspension: Adjustable
• Shock absorbers: Oil lled 4 alum.
• Remote control: 2,4GHz Reex-X LCD
• Anodized aluparts
• Spareparts: available
ma am

CARSON FY5 Destroyerline Brushless 50 040 9040
DBetriebsanleitung Seite 2 - 15
GInstruction Manual Page 16 - 29

29CARSON FY5 Destroyerline Brushless 50 040 9040
GB
l. Troubleshooting
Problem Cause Correction
Model doesn’t move Transmitter or chassis power switch is not ”ON“ Switch power on receiver or transmitter
Polarity or battery type is wrong Check polarity and type of battery
Batteries have run down Change batteries or charge them
Loss of control Batteries have run down Change batteries or charge them
Antenna is missing or not attached properly Attach receiver antenna and/or transmitter antenna
screw tight
R/C model using same band (frequency) is nearby Run model in different area or change crystal
Doesn’t run straight Steering trim is not adjusted correctly Make adjustment
Front and rear wheel nuts are too lose Tighten wheel nuts
Doesn’t stop Throttle trim is not adjusted correctly Make adjustment
Doesn‘t reverse Throttle trim is not adjusted correctly Make adjustment
Wrong action Control properly
Running too slowly Batteries have run down Change batteries or charge them
Motor has lost power Change to spare motor
Rear wheel nuts are too loose Tighten wheel nuts
Dust or foreign objects are inside gears Turn the power switch ”OFF“ and clean out gears

30 CARSON FY5 Destroyerline Brushless 50 040 9040
Montage
Explosionszeichnung • Exploded View
50 040 5380
50 040 5380
50 040 5380
50 040 5380
50 040 5380
50 040 5380
50 040 5380
50 040 5380
50 040 5380
50 040 5280
50 040 5381
50 040 5369
50 040
50 040 5
3
50 040 5392
50 090 6139
50 040 5382
50 040 5382
50 040 5368
50 040 5381
50 040 5381
50 040 5381
50 040 5381
50 040 5380
50 040 5380
50 040 5381
50 040 5381
50 040 5381
50 040 5381
50 040 5381
50 040 5381
50 040 5381
50 040 5384
50 040 5383
50 040 5386
50 040 5386
50 040 5386
50 040 5386
50 040 5386
50 090 0101
50 040 5368
50 040 5369
50 040 5370
50 040 5370
50 040 5373
50 0
4
50 040 5272
50 040 5272
50 040 5315
50 040 5379
50
0
50 040 5256
50 040 5257
50 040 52
6
50 040 5258
50 040 5276
50 040 5
2
50 040 5275
50 040 5289
50 040 5377
50 0405377
5
50 040 5260
50 04
0
50 040 5267
50
50 040 5280
50 040 5268
50 040 5378
50 040 5326

31CARSON FY5 Destroyerline Brushless 50 040 9040
Montage
50 040 5380
50 040 5380
50 040 5380
50 040 5369
50 040 5383
50 040 5380
50 040 5380
50 040 5380
50 040 5380
50 040 5380
50 040 5380
50 040 5380
50 040 5380
50 040 5380
50 040 5380
50 040 5383
50 040 5383 50 040 5328
50 040 5380 50 040 5369
0
040 5380 50 040 5328
50 040 5333
4
0 5338
50 040 5338
50 040 5338
50 040 5392
50 040 5392
50 040 5392
50 090 6138
50 040 5387
50 040 5389
50 040 5391
50 080 0073
50 040 5393
50 040 5382
50 040 5382
50 040 5382
50 040 5382
3
86
50 040 5376
50 040 5376
5
370
500405371
500405371
50 040 5373
50 040 5319
50 040 5373
50 040 5375
50 040 5375
50 040 5378
50 040 5378
50 040 5272
50 040 5272
50 040 5326
50 040 5319
50 040 5374
50 040 5379
50 040 5385
50 040 5257
50 040 5269
0
5269
50 040 5258
50 040 5273
50 040 5273
50 040 5275
50 040 5275
50 040 5276
0
40 5276
50 040 5276
50 040 5275
50 040 5279
50 040 5279
50 040 5260
50 040 5260
50 040 5260
500405267
0 040 5267
50 040 5267
50 040 5280
50 040 5280
50 040 5280
50 040 5280
50 040 5280
50 090 0101
50 090 0101
50 040 5289
50 040 5378
500405273
50 040 5326
50 040 5319
6
50 040 5378
50 040 5326

32 CARSON FY5 Destroyerline Brushless 50 040 9040
Montage
N° Bezeichnung Description
50 040 5256 Frontrammer Frontbumper
50 040 5257 Querlenkerhalter 2 Stück Suspension arm mount 2 pcs
50 040 5258 Querlenkerhalter oben vorne/hinten Upper suspension arm mount fr/rear
50 040 5260 Radachse mit Pin 2 Stück Axle w/pin 2 pcs
50 040 5267 Querlenkerstifte vorne kurz 4 Stück/ 4 Stück lang Front suspension arm pin short 4 pcs
suspension arm pin long 4 pcs
50 040 5268 Chassis-Front Front chassis
50 040 5269 Unterer Querlenkerhalterblock V/H Lower suspension mount block fr/rr
50 040 5273 Radträger hinten L/R Hub rear carrier
50 040 5275 4x Querlenker Pin hinten 4x Rear suspension arm pin
50 040 5276 Schrauben, Muttern, Beilagscheiben Screws, nuts, washers
50 040 5279 Diffmitnehmer Diff. outdrive
50 040 5280 Kugellagerset 8 Stück Ball bearing 8 pcs
50 040 5284 Differenzialgehäuse Diff gear box
50 040 5289 Dämpferbrücke Shocktower
50 040 5315 Abdeckung vorne Upper deck front
50 040 5319 Mitteldifferenzial komplett Center diff unit complete
50 040 5325 Differenzial Zahnrad-Set Driven gear bevel set
50 040 5326 Differenzial v/h komplett Diff gearbox unit f/r complete
50 040 5328 Empfänger-Box Receiver-case
50 040 5333 Oberdeckhalterung v/h Front rear upper deck mount
50 040 5338 Akkuhalterungs-Set Battery base/cover

33CARSON FY5 Destroyerline Brushless 50 040 9040
Montage
N° Bezeichnung Description
50 040 5368 Chassis-Platte FY5 Chassis plate
50 040 5369 Querlenker oben 2 Stück FY5 Upper suspension mount front 2 pcs
50 040 5370 Querlenker unten vorne 2 Stück FY5 Lower suspension mount front 2 pcs
50 040 5371 Querlenker unten hinten 2 Stück FY5 Lower suspension mount rear 2 pcs
50 040 5372 Antriebswellen 2 Stück FY5 Driver shaft 2 pcs
50 040 5373 Lenkgestängeset FY5 Steering linkage
50 040 5374 Motorritzel FY5 Motor gear
50 040 5375 Mittelantriebswellen v/h FY5 Centre driving shaft f/r
50 040 5376 Oberdeck-Set FY5 Upper deck set
50 040 5377 Achsschenkel-Set vorne 2 Stück FY5 C carrier front/rear 2 pcs
50 040 5378 Stoßdämpferset v/h 2 Stück FY5 Shock absorber front/rear 2 pcs
50 040 5379 Lenkhebel-Set 2 Stück FY5 Steering horn set 2 pcs
50 040 5380 Linsenkopfschrauben Set FY5 B-head cross screws
50 040 5381 Senkkopfschrauben Set FY5 Flat cross screw set
50 040 5382 Stabilisatorset FY5 Anti roll bar set
50 040 5383 Schrauben-Set MIX FY5 Screw set mix
50 040 5384 Servosaver-Set FY5 Servo saver set
50 040 5385 Diffmitnehmer FY5 Diff. outdrive
50 040 5386 Lenkservohalterung + Karosseriehalter FY5 Steering servo mount + body holder
50 040 5387 Differenzial-Einheit FY5 Differential unit
50 040 5388 Motorhalter FY5 Motor mount
50 040 5389 Motorkühler + Lüfter FY5 Motor heat sink + cooling fan
50 040 5390 Hauptzahnrad 49 Z. FY5 Main gear 49 T
50 040 5391 Chassis hinten FY5 Rear chassis
50 040 5392 Radmitnehmer-Set 2 Stück Rim hub set 2 pcs
50 040 5393 Spoilerhalter FY5 Wing mount
50 080 0073 Karosserie + Spoiler FY5 Body + wing
50 090 6138 Brushlessmotor KV1500 FY5 Brushless motor KV1500
50 090 6139 Brushlessregler FY5 ESP
50 090 0101 Reifenset FY5 2 Stück Wheel set 2 pcs

34 CARSON FY5 Destroyerline Brushless 50 040 9040
Ersatzteile
Ersatzteile
Spare Parts
50 040 5257 2x Querlenkerhalterung
2x Suspension arm mount
50 040 5260 2x Achse
2x Axle
50 040 5256 Rammer vorne
Front bumper
50 040 5276 M12 Nuss
Nut M12
50 040 5279 Differenzialzapfen Set
Diff. outdrive set, M4 x 4 mm
50 40 5273 Nabenhalterung hinten
Hub rear carrier
50 040 5275 4x Querlenker Pin hinten
4x Rear suspension arm pin
3 x 34.5 mm
50 040 5268 Stoßfänger vorne
Front damper
50 040 5267 Querlenker Pin 4x lang, 4x kurz
Front susp. arm pin 4x l., 4x short
50 040 5269 Unterer Querlenker v + h
Lower susp. mount block f + r
50 040 5280 8x Kugellager
8x Ball bearings
50 040 5284 Differenzialgehäuse
Diff gear box
50 040 5289 Dämpferbrücke
Shocktower
50 040 5258 Querlenkerhalterung oben v + h
Upper suspension mount f + r
50 040 5315 Abdeckung vorne
Upper deck front
50 040 5319 Zentraldifferenzial komplett
Centre differential unit complete
50 040 5325 Antriebs- + Diff-Zahnräder
Driving + diff gear set

35CARSON FY5 Destroyerline Brushless 50 040 9040
Ersatzteile
Ersatzteile • Spare Parts
50 040 5374 Motorritzel mit Madenschraube
Motor gear with grub screw
50 040 5370 2x Querlenker vorne unten
2x Front lower suspension arm
50 040 5371 2x Querlenker unten hinten
2x Rear lower suspension arm
50 040 5375 Mittelantriebswellen vorne/hi
Centre drive shaft front/rear
50 040 5368 Chassis
Chassis
50 040 5369 2x Querlenker oben
2x Suspension arm unit left/r
50 040 5376 Oberdeck-Set
Upper deck front/rear
50 040 5372 2x Antriebswelle l + r
2x Transverse drive shaft l + r
50 040 5373 Lenkgestängeset
Steering link unit
50 040 5326 Differenzial v/h komplett
Diff gear box unit f/r complete
50 040 5333 Oberdeckhalterung v + h
Upper deck mount front + rear
50 040 5338 Akkubox und Abdeckung
Battery base and cover
50 040 5328 Empfängerbox
Receiver case
50 040 5377 C-Halterung vorne + hinten
C-carrier front + rear

36 CARSON FY5 Destroyerline Brushless 50 040 9040
Ersatzteile • Spare Parts
Ersatzteile
50 040 5384 Servosaver Set
Servo saver unit
50 040 5388 Motorhalter
Motor mount
50 040 5379 Achsschenkel links/rechts
Knuckle arm left/right
50 040 5382 Stabilisatorset
Anti roll bar set
50 040 5383 Schraubenset Mix
Mix screw set
50 040 5389 Motorkühler + Lüfter
Motor heat sink + cooling fan
50 040 5385 Diffmitnehmer
Diff outdrive
50 040 5386
Lenkservo- + Karosseriehalterung
Steering servo + body mount
50 040 5387 Differenzialeinheit
Diff unit
50 040 5378 2x Stoßdämpferset vorne/hinten
2x Shock absorber set front/rear
50 040 5380 Linsenkopfschraubenset
B-head hex screw set
50 040 5381 Senkkopfschrauben Set
Flat hex screw set
50 040 5390 Hauptzahnrad 49 Z
Main gear 49 T
50 040 5391 Chassis hinten
Rear chassis

37CARSON FY5 Destroyerline Brushless 50 040 9040
Ersatzteile • Spare Parts
Ersatzteile
50 090 6138 Brushless Motor
Brushless motor
50 040 5393 Spoilerhalter
Wing mount
50 080 0073 Spoiler + Karosserie
Wing + body
50 090 0101 2x Reifenset FY5
2x Wheel set FY5
50 040 5392 2x Radmitnehmer mit Pin
2x Rim hub with pin
50 090 6139 Brushless Regler 80 A
Brushless ESC 80 A

www.carson-modelsport.com
For Germany:
Service-Hotline:
Mo - Do 8.00 – 17.00 Uhr
Fr 8.00 – 14.30 Uhr
01805–73 33 00
14 ct/min
CARSON-MODEL SPORT
Werkstraße 1 • D-90765 Fürth • Germany
CARSON-MODEL SPORT
Abt. Service
Mittlere Motsch 9
96515 Sonneberg
