Case IH PUMA CVX 150 Operator's manual

PUMA CVX
QUICK INSTRUCTION
This booklet gives a brief overview of
the most important controls of the
Case IH Puma CVX
The quick instruction is not a substitute for the operator´s manual !
To operate the vehicle follow the
instructions in the operator´s manual !
Note: this quick instruction also includes optional
equipment that is not included in the basic version.
150, 165, 175
185, 200, 220, 240

2
FIRST STEPS
To start using the tractor:
1. Set Shuttle Lever in Parking Position !
To start the engine set shuttle lever
in parking position (press lever down,
then forward).
2. Ensure that Multicontroller
(MC) is fully pulled back !
Only start the engine with
the MC in full backward
position.
3. Adjust the Split Hand Throttle –
Eco-DriveTM !
Acceleration only possible if right
hand lever is set above the left one.
minimum
engine speed
maximum
engine speed
1
2
1
2
POWER ECO Constant
Engine Speed
TRANSPORT
Engine Droop
PTO

3
4. Depress Clutch Pedal !
In order to start the engine the clutch pedal
must be depressed.
5. Choose the right speed range!
3 speed ranges (target speeds) each in forward
and reverse are available.
The target speed in each speed range can be
adjusted between 0,03 and 43 or 52 km/h with
the scroll wheel on MC.
Change between speed ranges with buttons on MC.
6. Start driving!
Select driving direction with shuttle lever.
Ground speed can be changed either by
moving MC or using foot operated speed pedal.
Both MC and foot pedal are always active –
simply choose your driving preference
and change between operating
modes whenever you want.
Foot pedal fully down or MC
fully forward = target speed.
FIRST STEPS

4
SELECTION OF DRIVING SPEED:
Both Multicontroller and driving foot pedal change the
ground speed when being moved.
Engine speed and transmission ratio are automatically
adjusted by the APM engine –transmission
management no operator effort required.
APM is always available at key on. 
ACCELERATION:
Your Puma CVX will increase the ground speed
proportionally to the rate you move the MC forward or
depress the driving pedal.
quick movement = quick acceleration.
DRIVING
soft speed reduction = long roll out distance
medium speed reduction = medium roll out d.
quick speed reduction = short roll out distance
Level 1 is default and always available at key-on (your dealer can
change this to “memorize level“ if desired).
Ground speed Active Hold Control System engaged!
52
DECELERATION:
Driving with foot pedal:
rate of speed reduction depends on
aggressivity level set with button on ICP.

5
DECELERATION:
Driving with Multicontroller:
•Pulling back MC fully backward quickly 
max. deceleration through engine and gearbox
(4WD engages) active hold control.
TRANSPORT OF HEAVY TRAILERS:
Keeping tractor/trailer combination stretched:
•Pulling back MC fully backward slowly / moderatly
speed reduction in accordance to set aggressivity
level active hold control.
If your tractor/trailer combination is instable,
the trailer brakes can be applied while the tractor
is still applying draw pull.
DRIVING
•Keep the MC-shuttle button pressed (forward) –
automatic engine speed reduction while braking
is deactivated and transmission remains frozen
in present ratio,
•by applying the service brake and accelerating
with MC or foot pedal the tractor/trailer
combination remains stretched (both tractor and
trailer brakes are active).
•Activation of this feature is shown in A-pillar
display.

6
CONTROL ELEMENTS
1
1. Shuttle Lever +
Parking Brake
2. A-Pillar Instrument
3. AFS 700 Monitor
4. Multicontroller
5. Eco-Drive™
(split hand throttle)
6. Remote Valve Operation
7. Intuitive Control Pannel (ICP)
8. Control Elements under
Armrest Cover
9. Power Take Off F + R on/off
10. PTO speed selection
6
7
8
9
10
4
2
3
5

7
SHUTTLE LEVER
(Forward F/ Reverse R)
Integrated Parking Brake P
(also activates trailer brakes!)
Neutral N
Shift
MULTICONTROLLER
Power Shuttle
Speed Range
(Cruise Control)
Remote Valve
Rear Hitch
up / down,
quick penetration,
stop Scroll Wheel
target speed
HMC & CERPM Button
head land management
constant engine speed
CONTROL ELEMENTS

8

1. Lowering throttle rear hitch.
2. Sensitivity draft control system.
3. Height limitation rear hitch.
4. Slip control value [%].
5. Remote valve configuration–
oil flow, timer. Push–turn logic.
6. Lift height limitation front hitch.
7. Lowering throttle front hitch,
(FHM only see page 15).
CONTROL ELEMENTS ON C-PILLAR
1. Hydraulic main switch
Up:Remote valves active
Center: Remotes, rear hitch locked
Down: Remotes + rear hitch active
2. High mounted road lights / LED stripes in bonnet
3. Heated front and rear screen
4. AccuGuide activation
5. ISOBUS class 3 activation / engagement
6. Electronic battery isolator
7. Diagnosis connector
8. 9 pin ISOBUS connector
CONTROLS UNDER LID OF ARMREST
1 2
3 4
5 6
7
8
CONTROL ELEMENTS

9
DISPLAY ON THE A-PILLAR
1 2 3
45 6
7 8 9
10 11 12
13 14 15
Engine coolant
temperature
Fuel level
Warning Light
Panel
Engine speed
Target speed
Transmission
status
Ground speed
AdBlue level
1. Change/Scroll 1
2. Raise
3. Change/Scroll 2
4. Program / Input of data
5. Lower
6. Reset
7. Engine oil / air pressure
8. Wheel slip
9. Front & rear PTO speed /
Lift height front & rear hitch
10. Performance data of the tractor
11. Driven distance
12. Area counter
13. Service interval / operating hours
14. Air condition
15. Remote valve settings
MULTI FUNCTION DISPLAY:
- configuration menu
- engine load [%]
-engine oil pressure [bar/%]
- engine oil temperature [°C]
- charge air temperature [°C]
- AdBlue temperature [°C]
- transmission oil pressure [bar]
- transmission oil temp. [°C]
- battery voltage [V]
- pneumatic air pressure [%]
- climate control settings
- slip value [%]
- work performance [ha]
- work performance [ha/h]
- fuel level [litres]
- fuel rate [l/h]
- remaining working time at
present fuel rate [h]
- distance counter [km]
- slow speed indicator [m/min]
- working time [h:min]
- PTO speed front / rear [rpm]
- lift height front / rear hitch [%]
- hydraulic remote valve settings

10
CONSTANT ENGINE SPEED
Press button 1 or 2 actual
engine speed is saved constant
speed function is activated.
Fine adjustment with arrow keys.
Toggle between stored speeds with
respective button on MC (page 7).
HMC
Headland Management Control
system:
- recording
- automatic or sequencial replay
AUTO PTO
see page 16
ECO FAN
engages cooling
package cleaning
function for 30 sec.
TRACTION MANAGEMENT
automatic or permanent
engagement of 4WD and diff-lock
HITCH RIDE CONTROL
shock absorption for heavy
equipment transported on
rear three point linkage
FRONT AXLE SUSPENSION
locks suspension below 12km/h,
keep button pressed for 3 sec. 
toggle between suspension
stiffness hard/medium/soft
ISOBUS III
confirmation for
ISOBUS class III
activation
INTUITIVE CONTROL PANEL
TOP LINK
LIFT ROD

11
1
3
2
SLIP CONTROL
activation
1
2
3
REAR HITCH
Working depth (lowest position)
Percentage draft- / position
control
Sensitive UP/DOWN (ideal for
implement connection) plus
operation indicator lights
INTUITIVE CONTROL PANEL
1
2
3
MANUAL TRANSMISSION MODE
APM off ground speed (transmission
ratio) adjusted with Multicontroller,
engine speed with foot pedal.
CVT MODE
deceleration rate
(see page 4)
ACCU-GUIDE
activation of
guidance system
HYDRAULIC STATUS
indicator lights for de-activated
remote valves and rear hitch
1
3
2
FRONT HITCH
Working position 
operated with hitch
buttons & Shift on MC
Sensitive UP/DOWN (pg. 15)
1
3
1
3
JOYSTICK
operation of front or
rear remote valves
AUTO PTO
(see page 16)

12
REMOTE VALVES
2
3
1. Rear mounted remote 1 respectively –
if fitted - remote 5 is activated on
Multicontroller. Any remote with option
configurable remote valve operation.
2. Paddle levers on armrest control up
to 4 remote valves in a proportional
way (default for operation of rear
mounted valves). Positions:
- float control,
- retract (lower),
- neutral.
- extend (raise).
3. Operation of up to 4 remotes with the
proportional joystick (default for mid
mounted valves).
Remote 1 forward/reverse
Remote 2 left/right
Remote 3 forward/reverse +
Remote 4 left/right +
4. Control of rear and mid mounted
remotes can be swopped between
joystick and paddle levers.
5. Activation button for:
- oil motor mode (paddle lever in float),
- timer function
OPERATION:
1
4
5
short timer activated
long timer recording activated
N
~

13
REMOTE VALVES
CONNECTION:
Connecting a single acting cylinder:
hydraulic hose coupled to raising port
To extend cylinder  paddle lever in
raise position (fully backwards)
To retract (lower) cylinder paddle
lever in float position (fully forward)
Connecting a double acting cylinder:
hydraulic pressure hose coupled to
raising port,
hydraulic return hose coupled to
lowering port .
To extend cylinder  paddle lever in
raise position (fully backwards)
To retract (lower) cylinder paddle lever
in lowering position (one step forward).
Connecting an oil motor:
pressure hose in raising port, return hose
in lower ing port (respectviely to free flow
return coupling / case drain).
Engage oil motor mode (p. 12).
shut off oil motor in float position !
POWER BEYOND
For direct oil supply to implements capable
of controlling oil pump pressure and flow
rate a POWER BEYOND plate is available
for all models.
R hydraulic oil return
P hydraulic pressure line
LS load sensing (power demand)
detection line.
N.B.
Raise port has improved
sealing against internal
leakage !
Connect implements that
must remain lifted here !
lowering
1
2
3
4
5
1
2
3
4
5
raising
R
P
LS
Puma
150-175 CVX
Puma
185-240 CVX

14
FRONT HYDRAULIC & PTO
COMPONENTS:
single or double acting mode
for front hydraulic power lift* external control
FHPL
front PTO
front couplers
front hydraulic power lift on/off*
FHPL cooler
* models 185 –240 only

15
FRONT HITCH MANAGEMENT
5
1
4
6
3
2

1. Connect front implement with
sensitve raise / lower buttons.
2. Adjust maximum lift height.
3. Adjust lowering throttle
 in off position FHM is locked.
the front hitch can now be
operated with the joystick.
4. Set working position of implement.
5. Operate front hitch with up/down
buttons plus shift button on MC.
Shift + up hitch raises to
height set with 2.
Shift + down hitch lowers to work
position set with 4.
Engaging AUTO FLOAT mode:
Keep shift + down pressed for 3 seconds.
every time front hitch is lowered it will
go down to set work position and
then into FLOAT.
Disengaging AUTO FLOAT mode:
Keep shift + up pressed for 3 sec.
6. Turn on front auto PTO operation
if required (see page 16).
WORKING WITH FHM:

16
SPEED SELECTION
Puma 150 –175 CVX:
3 PTO speeds available. Options:
540 / 540E / 1.000
540E / 1.000 / 1.000E
Engine speeds:
- 540 @ 1.969 rpm
- 540E @ 1.546 / 1.592 rpm /
- 1.000 @ 1.886 rpm
- 1.000 E @ 1.621 rpm
Puma 185 –240 CVX
2 or 4 PTO speeds available. Options:
540E / 1.000 or 1.000 / 1.000E
540E / 540E / 1.000 / 1.000E
Engine speeds:
- 540 @ 1.950 / 1.931 rpm /
- 540E @ 1.569/ 1.598 rpm /
- 1.000 @ 1.893 / 1.912 rpm /
- 1.000 E @ 1.700 / 1.583 rpm /
POWER TAKE OFF
AUTO PTO:
1. Set lifting height values for
rear and front hitch, at which
PTO shall switch off and on in
AFS Pro 700 monitor.
2. Activate AUTO PTO switch
on ICP while PTO is on.
Note: Auto PTO disengages when leaving the tractor.
2
1
2
1
2
1
2
1
2
1
2
1
2
1
2
PTO brake release
PTO speed selector
ground speed PTO
Fender mounted PTO switch: < 5 sec. PTO on/off
> 5 sec. permanent on
PTO speed selector
PTO engage front/rear
1
PTO brake release

17
AFS PRO 700 MONITOR
AVAILABLE FUNCTIONS:
general setup, adjustments
status info icons
HMC I status bar
configurable info field
6 configurable
work screens
software status,
GPS, RDI, VT,…
USB data
transfer
virtual terminal
via ISOBUS
advanced
HMC II
remote valve
configuration
data
storage
wizard, alarm,
calculator
tractor, imple-
ment settings
Accu
Guide
& area

18
All Puma CVX tractors are equipped with a system that enables
recording and playback of repeated actions on the headland HMC.
HMC status and functions are displayed in AFS Pro monitor.
RECORDING A SEQUENCE:
1. Choose if you want to record sequence (field out) or (field in)
time or distance based 
2. Start recording by pressing HMC step switch on MC or simply start
working with your first vehicle function. Pressing the HMC step
switch while recording inserts a PAUSE.
3. When headland manouver is completed  short saves sequence.
The following actions or functions may, depending on tractor specification,
be included in the sequence:
Lock / unlock front suspension. Raise / lower front and/or rear three point hitch. Operate
electronic remote valves. Hydraulically adjust the top link and/or right-hand lift rod.
Transmission operation. Engage and disengage front and/or rear PTO. Engage the
constant engine speed management. Engage AutoGuidance. Run Eco Fan operation.
short = record standby  long toggle between
 short toggle between
to confirm your choice  long .
HEADLAND MANAGEMENT CONTROL

19
REPLAY OF A SEQUENCE:
1. Choose if you want to replay sequence (field out) or (field in)
with time or distance based recorded values.
You can also replay sequences A and B in alternating order or
2. Start AUTOMATIC REPLAY of all recorded functions
of a sequence by pressing HMC step switch.
Pressing the HMC step switch during replay sets the
system into PAUSE mode.
3. MANUAL REPLAY the programme will pause after
each step is completed. Depress the step switch to
replay the next step.
HEADLAND MANAGEMENT CONTROL
short = replay standby  long toggle
 short toggle between
to confirm your choice  long .

20
HMC II
As an option the Puma CVX can be equipped with a state of th art
end of row system that is operated on the AFS monitor HMC II.
Depending on the tractor configuration there are different HMC II
functions storeable.
To work with the system choose the icon HMC on the home screen.
RECORDING A SEQUENCE :
Recording during active work:
1. choose if you want to have the actions recorded
depending on the distance you drive or the time
that elapses until you carry out an action.
2. pressing “record START“ immediately
triggers recording.
No separate activation
or settings necessary.
3. the 1st action executed is always stored with
0 seconds / 0 meters delay.
This means, when the playback mode is started
(see section “Replay“) the action is executed
immediately.
If a delayed start is wanted a time / distance value
can be inserted once the whole sequence is
recorded.
There are two different modes available to record
a sequence record the functions during active
work in the field or record while parking by keying
in functions on the AFS monitor.
