SERVICE MANUAL
ELECTRONIC CASH REGISTER
(without price)
QT-6000
(EX-820)
AUG. 2004
QT-6000
Ver. 3 : Mar. 2010

CONTENTS
QT-6000 PAGE
1. SPECIFICATIONS........................................................................................ 1
2. INITIALIZATION........................................................................................... 5
3. DISASSEMBLY............................................................................................ 9
4. ASSEMBLY................................................................................................ 15
5. OPTION INSTALLATION........................................................................... 21
6. IN LINE / OUT LINE ................................................................................... 27
7. DIAGNOSTIC OPERATION....................................................................... 29
8. CIRCUIT EXPLANATIONS ........................................................................ 51
9. ERROR CODE LIST................................................................................... 79
10. IC DATA ..................................................................................................... 91
11. PCB LAYOUT .......................................................................................... 103
12. CIRCUIT DIAGRAMS............................................................................... 106
13. PARTS LIST............................................................................................. 125
To prevent malfunctions caused by the weak batteries, charge the memory
protection batteries for over 12-hours before installation or after a long-time
vacation (over 30 days).
•Before installation, initialize the terminal and leave it turn on over 12-hours.
•After a long-time vacation, initialize the terminal and restore the program data if
the terminal is in malfunction, and leave it turn on over 12-hours.
•Over 48-hours charging makes the batteries fully charged.

— 1 —
1. SPECIFICATIONS
1-1. Electrical Specifications
1-2. Environmental specifications
1-3. Main LSI specifications
• CPU Name HD6417751RF240 (SH-4)
Number of control bit 32 bits
• I/O controller Name UPD78F4216AGC8EUDA01
Number of control bit 16 bits
• Gate array Name UPD65945GJ-P16-JEU
• SDRAM Name EDS2532AABH-75L
Capacity 256 Mbits
• Flash ROM Name MBM29QM12DH
Capacity 128 Mbits
• Display controller Name SM712GX020000-AA
• ADPCM speech LSI Name MSM9841GS-2K
• Ethernet controller Name LAN91C113-NE (10/100BASE TX)
• PCMCIA controller Name R5C485-LQFP144
• Operating temperature 0 °C ~ 40 °C
• Operating humidity 20 % ~ 85 %
• Storage temperature -20 °C ~ 65 °C
• Storage humidity 10 % ~ 85 %
120V 220V 230V 240V
• Power consumption <AC input current at Adaptor>
In operation 1.1A 1.1A 1.1A 1.1A
Display off 0.25A 0.15A 0.14A 0.13A
<DC input current at QT-6000>
In operation 0.9A 0.9A 0.9A 0.9A
Display off 0.5A 0.5A 0.5A 0.5A
• Memory protection Back-up battery NiMH (nickel-metal-hydride)
HHR-21HL3G1B (USA only)
HHR-21HL3G1C (Except USA)
Back-up period 30 days (25 °C)
Battery life Replace the battery every 5 years.
Recharge time 24 hours (full charge)
• Clock & Calendar Accuracy Within ±40 sec. Per month (25 °C)
Auto calendar Effective until 2099 A.D.

— 2 —
1-5. I/O Ports
COM port (D sub 9pin) x 6
LAN port (Ethernet 10BASE-T/100BASE-TX) x 1
PC CARD slot x 1
CF CARD slot x 1
Drawer port x 2
External speaker jack x 1 (ø3.5 mono)
External microphone jack x 1 (ø3.5 mono)
• LCD Display Name NL8060BC31-27
Size 12.1 inch SVGA TFT panel
Resolution 800 x 600
Interface CMOS 6 bits
Colors 262,144 colors
• Touch Panel Name N010-0550-T711
Size 12.1 inch
• Panel brightness control 1 x VR controller
• Speaker 0.5 watt x 1
• Microphone Mini electret condenser microphone "EM100TW-ER"
• Power supply External adaptor "ADP820AA"
• Cleck key Magnetic ibutton prove "94-J-04"
1-4. Devices specifications
Card slot cover
PC CARD slot, CF CARD slot
DC IN
PC/MODEM SCANNER DISPLAY
DRW1 DRW2
COM1
COM4
COM2
COM5
COM3
COM6
SPK
MIC
LAN1
VOL
COM1 COM4 COM2 COM5 COM3 COM6
From the AC adaptor
Inline (10/100Base-T)
Drawer 2
Drawer 1
Ext. microphone
Ext. speaker

— 3 —
DEVICE NAME MODEL NOTE
• Magnet i-Button QT-6011DLS
• Display set for customer QT-6060D Connect to Com 3
• Display cable for customer QT-6061CB
(for mounting to the base)
• Display 5-meter cable for customer QT-6062CB
• Slip printer SP-1300 Connect to Com 2, 3 or 4
• Slip printer cable PRT-CB-8C Length 1.5m
• Remote printer UP-250 Connect to Com 2, 3, 4, 5 or 6
• Remote printer UP-350 Connect to Com 2, 3, 4, 5 or 6
• Remote printer SA-3015 Connect to Com 2, 3, 4, 5 or 6
• Remote printer UP-360 Connect to Com 2, 3, 4, 5 or 6
• Printer cable PRT-CB-8A Length 3m
• Printer cable PRT-CB-8B Length 5m
• Power unit for External Printer PS-180 EPSON MODEL
• Handy scnner HHS-15 Com2 port only
• MCR QT-6046MCR
• Drawer cable QT-6031CB Length 3m
• PC cable PRL-CB-2 Com1 port only
1-6. Option List
CASIO sales options
1-7. Drawer
Type Drawer Name Specification USA Other
Countries
M DL-2785 D-20BC-B84M-15* X
M DL-2786 D-20BC-B84SM-15* X
M DL-2920 D-20BC-B87M-15* X
M DL-2921 D-20BC-B87SM-15* X
M DL-2425 D-20BC-B55SM-15* X
M DL-2525 D-20BC-B64SM-15* X
L DL-3616 D-11BH-B65SS-9* X X
L DL-3617 D-11BH-B65S-9* X
DEVICE NAME MAKER MODEL NOTE
• Slip printer/ AC adaptor AD31-U or E U: 100V / E: 200V
• Remote printer EPSON TM-T88 lll Connect to Com 2, 3, 4, 5 or 6
• Remote printer EPSON TM-U220 Connect to Com 2, 3, 4, 5 or 6
• Power cord for power unit EPSON AC-170
• Laser scanner PSC QuickScan6000 Com2 port only
• Handy scnner PSC HS1250 Com2 port only
• CF Memory card Sandisk SDCFB-xx-505
• Modem U.S.Robotics 56k FAX
• ISDN TA DEVOLO MICROLINK ISDN
• HUB NETGEAR DS104, DS108
• Wireless LAN card NETGEAR WG551
• Access Point NETGEAR WG602
• External speaker ELECOM MS-76CH
• External microphone ELECOM MS-STM55
• For external speaker / microphone Ohm Electric AP-2633
Stereo-monaural conversion plug
Local purchase options

—4 —
CAUTION
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type
recommended by the manufacturer.
Dispose of used batteries according
to the manufacture’s instructions.
VORSICHT !
Explosionsgefahr bei unsachgemäßem Austausch der
Batterie.
Ersatz nur durch denselben oder einen vom
Hersteller empfohlenen gleichwertigen Typ.
Entsorgung gebrauchter Batterien nach
Angaben des Herstellers.
ADVARSEL !
Lithiumbatteri - Eksplosionsfare ved fejlagtig hándtering.
Udskiftning má kun ske med batteri
af samme fabrikat og type.
Levér det brugte batteri tilbage til leverandØren.
1-8. Duration of Life
Panel of TFT LCD 50,000 hours
Back Light of TFT LCD 43,000 hours
Touch Panel (number of touch times) 10 million times
LCD of customer display (option) 20,000 hours
Back light of customer display (option) 20,000 hours
Head of MCR 300,000 times (in a clean office room)
■ Installing Precautions
When installing QT-6000, attach the ferrite core to the QT-6000 side. Wind the AC
adaptor cable around the ferrite core two times.
The ferrite core is packed with QT-6000.

— 5 —
2. INITIALIZATION
2-1. MACHINE INITIALIZATION
2-1-1. How to initialize the terminal
Preparation:
1. All peripheral devices and terminals of this cluster should be turned off.
2. Connect all of the peripheral devices (such as printer, display etc.) to terminal.
3. Connect all terminals by inline.
Operation:
4. Turn on all peripheral devices of a terminal.
5. Turn on this terminal with pressing the initialze switch and release.
Init Sw
INIT
Copyright(C)2004
CASIO COMPUTER CO.,LTD. C
All rights reserved.
ROM VER xxxxxx xxxx
789
CREATE xxxx-xx-xx xx:xx
QT-6000 Version x.xx 456
APL VER. xxxxxx xxxx
123
0
OK
6. After releasing the key, enter “20000”(U.S.), “10000”(other area: English), “40000”(other area:
German), “50000”(other area: French), “60000”(other area: Spanish) and press the OK key.
ID & IP ADDRESS
Terminal ID ENTER ID
DHCP USE
OK?
——— Terminal ID: 1 - 32
——— If you do not use DHCP server, select “NO”, and you have
to enter IP address of this terminal.
——— Press <YES> to continue.
* The terminal ID of the DHCP server must be “1”.
* TheIP addressof eachterminal shouldbe theunique numberfrom 192.168.0. 0to 192.168.255.255.

—6 —
——— Enter date if it is wrong.
——— Enter time if it is wrong.
——— Within 12 characters
——— Master / Backup master / Satellite / Self master
——— Enter cluster No. “1”~ “9”, if using check cluster system.
——— No printer / UP-350 / UP-360 / SA-3015 / UP-250 for R
/
J or Order printer.
——— No printer / SA-3015 / SP-1300
——— Press <YES> to continue.
Date 01-10-10
Time 12:34 00
ID Character MC #01
Check System Master
Check cluster ID 0
R/J/Order Printer1 No
R/J/Order Printer2 No
R/J/Order Printer3 No
Slip Printer No
OK? YES
——— Select, if no need to download any data.
——— Select to download a program data from CF card.
——— Select to download a program data from other teminal.
INIT 10-10-01 12:34 000001
AUTO PGM
1.No Restore /Receive
2.PGM Restore (CF Card)
3.PGM Receive (Inline)
——— All Data (including totalizer) / All PGM (program only)
——— Select the machine to send the data.
INIT 10-10-01 12:34 000001
Receive Data All PGM
PGM Receive from MC #05
OK? YES
Restore from CF card.
Insert the CF card into the slot and select the appropriate file and press the <YES> key.
Program receive from other terminal.
2-1-2. How to initialize the terminal (add / replace one terminal)
Preparation:
1. All peripheral devices and terminals of this cluster should be turned off.
2. Connect all of the peripheral devices (such as printer, display etc.) to this terminal.
3. Connect the added / replaced terminal to inline.
Operation:
Follow the steps shown on the page 5 to 6.

— 7 —
2-1-3. How to flag clear the terminal (or INIT2)
Preparation:
1. All peripheral devices and this terminal should be turned off.
2. Check the connection of all peripheral devices (such as printer, display etc.) of this terminal.
3. Check the connection of this terminal to inline.
Operation:
4. Turn on all peripheral devices of this terminal.
5. Turn on this terminal with pressing the <DISP ON/OFF> key.
6. Press <OK> key.
FC
Copyright(C)2004
CASIO COMPUTER CO.,LTD.
All rights reserved.
ROM VER xxxxxx xxxx
CREATE xxxx-xx-xx xx:xx
QT-6000 Version x.xx
APL VER. xxxxxx xxxx
OK
7. Select “1. Flag Clear”and press <YES> key to flag clear.
or select “2.Init2”and press <YES> key and enter “8888888888”and <YES> key to Init 2.
2-2. SYSTEM INITIALIZATION
In this chapter shows how to install QT-6000 systems and peripherals.
2-2-1. How to load IPL (Initial Program Loading)
Normally, IPL is not necessary since the terminal has efficient programmable options to
meet your circumstances.
In some cases, you need to change the application program to meet your requirements, the
IPL is necessary to download the application program to the terminal.
To load IPL, there are two methods:
1) From PC to a terminal via RS-232C
2) From CF card to a terminal

— 8 —
2-2-2. IPL Operation
INITIAL PROGRAM LOAD
COM PORT
MODEM
CF CARD
IN LINE PORT
INITIAL PROGRAM LOAD
115200 bps
57600 bps
56000 bps
38400 bps
19200 bps
9600 bps
4800 bps
2400 bps
INITIAL PROGRAM LOAD
START IPL
Date 00-00-00
Time 12:34 00
ID Character MC #01
Check System Master
Check Cluster ID 0
R / J / Order Printer1 UP-350
R / J / Order Printer2 UP-350
Slip Printer SP-1300
OK? Yes
0 .00
4. If you choose COM port or IN LINE port, select baud rate of the
IPL source device and press the <YES> key.
5. Press the <YES> key to proceed, in case of downloading via
inline, automatic ID definition is made by this timing. So press
the <YES> key terminal by terminal.
6. After finishing IPL, machine initialization is necessary.
1. Turn on this terminal with pressing the initialze switch and
release.
2. Enter “44449999”and press “OK”key.
If you select “CF card”, insert the CF card into the slot before
this step.
3. Select the appropriate method to loading IPL data and press
the <YES> key.
(using COM PORT)

— 9 —
3. DISASSEMBLY
■ QT-6000
1. Separate the main unit and the stand.
2. Remove one screw and the cover.
3. Remove two screws and the cover.
4. Remove ten screws.
5. Remove one screw and the lid of the software key.
6. Remove the wiring for the DRAWER (a cable and an earth).
Screws
Screw × 10

— 10 —
7. Open the CARD SLOT COVER.
8. Remove each screw, and then the PC CARD and the COVER for the CF CARD.
9. Release the hook and remove the REAR CASE.
Be careful with the REAR CASE when removing it since there is a wiring which connects to the speaker.
10.Remove the connector for the speaker.
11. Remove four screws and the iron plate.
12.Remove three screws.
13.Remove four connectors, one FPC and the IO unit.
FPC Connectors
Screw × 4 Screw × 3
CARD SLOT COVER
Screws

— 11 —
14. Remove the connector for the battery and the battery. 15.Remove four connectors.
15.Remove twelve screws and the metal bracket.
Connectors × 4
FPC
16.Remove three connectors and one FPC.
Screw × 3Screw × 3Screw × 3
Screw × 3
Connectors × 3

— 12 —
17.Remove six screws, one connector, one FPC, three bosses, and then remove the main PCB.
FPC
Connectors
boss
Screw × 6
18.Remove 14 screws and then the LCD unit.
19.Remove two screws, one connector and the inverter PCB.
20.Remove four screws and the LCD.
Screw × 14
Screw × 2Connectors
Screw × 4
The touch panel is fixed by double-sided tape.

— 13 —
■ QT-6060D
1. Remove four screws.
2. Release the connector and remove the IO PCB.
3. Remove four screws and separate the unit as shown below.
Screw × 4Connector
Screw × 4
4. Remove the cap.
5. Remove four screws under both packing.
Screw × 2Screw × 2

— 14 —
6. Release the hook and remove the REAR CASE.
7. Remove five screws, connector and the HINGE.
8. Remove seven screws and separate the LCD Unit.
Screw × 5
Screw × 7

— 15 —
4. ASSEMBLY
■ QT-6000
1. Place the LCD UNIT in the frame and fix it with four screws.
2. Connect the connector and fix the inverter PCB with two screws.
Screw × 2
3. Fix the LCD UNIT to the FRONT CASE with 14 screws.
Fix the screws from above the earth plate.
Bind the wirings for the inverter.
4. Fix the main PCB with six screws and three bosses.
FPC
Connector
Boss × 3
Screw × 6

— 16 —
5. Connect one PFC and three connector.
6. Fix the iron plate with twelve screws.
Terminal side
7. Connect four connectors.
Screw × 3Screw × 3Screw × 3
Screw × 3
15.Remove four connectors.
Connectors × 4
Connectors × 3

— 17 —
8. Connect the connector for the battery and assemble the battery.
9. Assemble the IO Unit and fix it with three screws.
Connect four connectors and one FPC.
FPC
Screw × 3
10.Fix the iron plate with four screws.
Screw × 4
Connectors

— 18 —
11. Connect the connector for the speaker and assemble the REAR CASE.
Hook the REAR CASE and fix it with ten screws.
12.Fix the PC CARD and the CF CARD COVER.
Fix the backup battery cover with one screw.
Connect the DRAWER wiring (a cable and an earth).
13.Fix the case with two screws.
Screw × 10
14.Fix the IP PORT COVER and the stand.
CARD SLOT COVER
Screws
