Casio SE-C3500 User manual

User's Manual
SE-C3500
Electronic Cash Register
(M size drawer)

E-2
Introduction
Thank you very much for purchasing this CASIO electronic cash register. START-UP is QUICK and
EASY!
For the basic settings of your cash register, please see “Quick Start Guide”.
Original Carton/Package
If for any reason, this product is to be returned to the store where purchased, it must be packed in the
original carton/package.
Location
Locate the Cash register on a at, stable surface, away from heaters or areas exposed to direct sunlight,
humidity or dust.
Power Supply
Your cash register is designed to operate on standard household current (120 V, 220 V, 230 V, 240 V;
50/60 Hz). Do not overload the outlet by plugging in too many appliances.
Cleaning
Clean the cash register exterior with a soft cloth which has been moistened with a solution of a mild neu-
tral detergent and water, and wrung out. Be sure that the cloth is thoroughly wrung out to avoid damage
to the printer. Never use paint thinner, benzene, or other volatile solvents.
The mains plug on this equipment must be used to disconnect mains power. Please ensure that the
socket outlet is installed near the equipment and shall be easily accessible.
Trademark
SD and SDHC Logos are trademarks of SD-3C,LLC.

E-3
To use the cash register safely ..............................................................................................E-4
To use the cash register’s basic function .............................................................................E-9
Getting started................................................................................................................................ E-10
Getting to know your cash register .............................................................................................. E-15
How to read the printouts .............................................................................................................. E-23
How to use your cash register ......................................................................................................E-24
Before opening your store.............................................................................................................E-25
Registering items in departments ................................................................................................E-26
Basic setups and registrations .....................................................................................................E-30
Other registrations .........................................................................................................................E-38
Daily sales reports..........................................................................................................................E-48
Advanced programmings and registrations....................................................................... E-51
Advanced registrations..................................................................................................................E-52
Character settings .......................................................................................................................... E-72
Advanced programmings ..............................................................................................................E-81
Programming functions of departments and PLUs in a lump ...................................................E-94
Programming functions of departments and PLUs individually ...............................................E-97
Printing programmed data........................................................................................................... E-113
Printing various sales reports..................................................................................................... E-119
Using an SD card .......................................................................................................................... E-127
Before you consider it as a problem .......................................................................................... E-130
Specications ............................................................................................................................... E-134

E-4
To use the cash register safely
• Congratulations upon your selection of this CASIO product. Be sure to read the following safety precau-
tions before using it for the rst time. After reading this guide, keep it close at hand for easy reference.
• Please pay due attention to the following symbols to help you use the product safely and properly and
to avoid any personal injury or damage to the product.
*Danger If this symbol is ignored and the product consequently misused, it can result in seri-
ous personal injury and/or death.
*Warning If this symbol is ignored and the product consequently misused, it may result in
serious personal injury and/or death.
*Caution If this symbol is ignored and the product consequently misused, it may result in
personal injury and/or property damage.
• The gures in this manual have the following meanings.
’This symbol means be careful = a warning.
The example at left is a warning about an electrical shock.
!This symbol indicates something you must not do = prohibited action. The example at left
means never disassemble the product.
$This symbol indicates something you must do = an instruction.
The example at left indicates you should unplug the product from the outlet. Please note that
instructions that are difcult to express by a gure are indicated by +.
*Danger
If liquid that leaked from a battery gets in your eye, on your skin or clothes, deal with it immedi-
ately as follows.
-1. Immediately rinse it off with lots of water.
2. Immediately get medical treatment.
Failing to act may result in a rash or loss of sight.
*Warning
Handling the register
$• Should the register malfunction, start to emit smoke or a strange odor, or otherwise
behave abnormally, immediately shut down the power and unplug the AC plug from the
power outlet. Continued use creates the danger of re and electric shock. Contact CASIO
service representative.
-
-
!
• Do not place containers of liquids near the register and do not allow any foreign matter
to get into it. Should water or other foreign matter get into the register, immediately shut
down the power and unplug the AC plug from the power outlet. Continued use creates the
danger of short circuit, re and electric shock. Contact CASIO service representative.
• Should you drop the register and damage it, immediately shut down the power and unplug
the AC plug from the power outlet. Continued use creates the danger of short circuit, re
and electric shock.
• Attempting to repair the register yourself is extremely dangerous. Contact CASIO service
representative.
• Never try to take the register apart or modify it in any way. High-voltage components
inside the register create the danger of re and electric shock. Contact CASIO service
representative for all repair and maintenance.

E-5
To use the cash register safely
*Warning
Power plug and AC outlet
+
+
+
-
• Use only a proper AC electric outlet. Use of an outlet with a different voltage from the
rating creates the danger of malfunction, re, and electric shock. Overloading an electric
outlet creates the danger of overheating and re.
• Make sure the power plug is inserted as far as it will go. Loose plugs create the danger of
electric shock, overheating, and re.
• Do not use the register if the plug is damaged. Never connect to a power outlet that is
loose.
• Use a dry cloth to periodically wipe off any dust built up on the prongs of the plug. Humid-
ity can cause poor insulation and create the danger of electric shock and re if dust stays
on the prongs.
• Do not allow the power cord or plug to become damaged, and never try to modify them in
any way. Continued use of a damaged power cord can cause deterioration of the insula-
tion, exposure of internal wiring, and short circuit, which creates the danger of electric
shock and re.
• Contact CASIO service representative whenever the power cord or plug requires repair or
maintenance.
*Caution
-• Do not place the register on an unstable or uneven surface. Doing so can cause the
register - especially when the drawer is open - to fall, creating the danger of malfunction,
re, and electric shock.
Do not place the register in the following areas.
+• Areas where the register will be subject to large amounts of humidity or dust, or directly
exposed to hot or cold air.
• Areas exposed to direct sunlight, in a close motor vehicle, or any other area subject to
very high temperatures.
The above conditions can cause malfunction, which creates the danger of re.
+• Do not overlay bend the power cord, do not allow it to be caught between desks or other
furniture, and never place heavy objects on top of the power cord. Doing so can cause
short circuit or breaking of the power cord, creating the danger of re and electric shock.
+• Be sure to grasp the plug when unplugging the power cord from the wall outlet. Pulling on
the cord can damage it, break the wiring, or cause short, creating the danger of re and
electric shock.
-• Never touch the plug while your hands are wet. Doing so creates the danger of electric
shock. Pulling on the cord can damage it, break the wiring, or cause short, creating the
danger of re and electric shock.
-• At least once a year, unplug the power plug and use a dry cloth or vacuum cleaner to clear
dust from the area around the prongs of the power plug.
Never use detergent to clean the power cord, especially power plug.
+• Keep small parts out of the reach of small children to make sure it is not swallowed ac-
cidentally.

E-6
To use the cash register’s basic function
*Caution
Only use the specied batteries.
-• Do not disassemble, modify or short-circuit them.
• Do not put them in re or water or heat them.
• Do not mix new and old batteries or different types of batteries.
• Orient the terminals +- correctly.
• Remove the batteries if the system will not be used for a long time.
• After batteries are spent, dispose of them as per local regulations.
• Do not try to recharge dry cell batteries.
Disposing of batteries:
-• Make sure that you dispose of used batteries in accordance with the rules and regulations
in your local area.

E-7
To use the cash register’s basic function
When the cash drawer does not open!
In case of power failure or the machine is in malfunction,
the cash drawer does not open automatically. Even in
these cases, you can open the cash drawer by pulling
drawer release lever (see below).
Important: The drawer will not open, if it is locked with a
drawer lock key.
Drawer release lever

E-8
Manufacturer:CASIO COMPUTER CO., LTD.
6-2, Hon-machi 1-chome, Shibuya-ku, Tokyo 151-8543, Japan
Responsible within the European Union:CASIO EUROPE GmbH
CASIO-Platz 1, 22848 Norderstedt, Germany
Please keep all information for future reference.
The declaration of conformity may be consulted at http://world.casio.com/
This mark applies in EU countries
only.
The main plug on this equipment must be used to disconnect mains power.
Please ensure that the socket outlet is installed near the equipment and shall be easily
accessible.
WARNING
THIS IS A CLASS A PRODUCT. IN A DOMESTIC ENVIRONMENT THIS PRODUCT
MAY CAUSE RADIO INTERFERENCE IN WHICH CASE THE USER MAY BE RE-
QUIRED TO TAKE ADEQUATE MEASURES.
This product is also designed for IT power
distribution system with phase-to-phase
voltage 230 V.
Laite on liitettävä suojamaadoituskostkettimilla vaurstettuun pistorasiaan
Apparatet må tilkoples jordet stikkontakt
Apparaten skall anslutas till jordat nätuttag.
FCC WARNING: Changes or modifications not expressly approved by
the party responsible for compliance could void the user’s authority to operate
the equipment.
WARNING: This equipment has been tested and found to comply with the limits for
a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in accordance with the instruction
manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in which case
the user will be required to correct the interference at his own expense.
GUIDELINES LAID DOWN BY FCC RULES FOR USE OF THE UNIT IN THE U.S.A.
(Not applicable to other areas)
To use the cash register’s basic function

E-9
Basic function
To use the cash register’s basic function
Getting started........................................................................................................... E-10
Loading memory protection batteries ............................................................................ E-10
Installing paper roll ........................................................................................................... E-11
Setting date, time, and tax table ...................................................................................... E-13
To set Australian GST ....................................................................................................... E-14
Getting to know your cash register ..........................................................................E-15
General guide .................................................................................................................... E-15
To adjust the main display ............................................................................................... E-16
To set the customer display ............................................................................................. E-16
To set the menu sheet....................................................................................................... E-17
Display................................................................................................................................ E-18
Keyboard............................................................................................................................ E-19
How to read the printouts......................................................................................... E-23
How to use your cash register ................................................................................. E-24
Before opening your store........................................................................................ E-25
Checking the time and date ............................................................................................. E-25
Preparing bills and coins for change .............................................................................. E-25
Registering items in departments ........................................................................... E-26
Basic setups and registrations ................................................................................ E-30
To program basic settings ............................................................................................... E-30
Programming departments .............................................................................................. E-32
Registering departments’ preset data ............................................................................E-33
Programming PLUs...........................................................................................................E-34
Registering PLUs’ preset data .........................................................................................E-35
Other registrations .................................................................................................... E-38
Discount.............................................................................................................................E-38
Reduction...........................................................................................................................E-39
Registering various payment methods...........................................................................E-40
Registering returned goods .............................................................................................E-42
Registrations without transactions.................................................................................E-44
Corrections ........................................................................................................................E-45
Daily sales reports ....................................................................................................E-48
Print out of daily sales report ..........................................................................................E-49

E-10
To use the cash register’s basic function
Getting started
This chapter shows how to setup the cash register and get it ready to operate.
Loading memory protection batteries
Important: These batteries protect information stored in your cash register’s memory when there is a
power failure or when you unplug the cash register. Be sure to install these batteries rst.
1Remove the printer cover.
2Remove the battery compartment cover.
3Note the (+) and (–) markings in the battery compartment. Load a set of
two new “AA” type manganese batteries so that their plus (+) and minus
(–) ends are facing as indicated by the markings.
4Replace the battery compartment cover and the printer cover.
Warning
• No battery is included in the accessories.
• Never try to recharge the batteries.
• Do not expose batteries to direct heat, let them become shorted or try to take them apart.
• Keep batteries out of the reach of small children. If your child should swallow a battery, consult a physi-
cian immediately.
• There is a risk of explosion if the batteries are replaced with improper type.
• Dispose of used batteries according to the instructions.

E-11
Basic function
To use the cash register’s basic function
Installing paper roll
Caution (in handling the thermal paper)
• Never touch the printer head and the platen.
• Unpack the thermal paper just before your use.
• Avoid heat and direct sunlight.
• Avoid dusty and humid places for storage.
• Do not scratch the paper.
• Do not keep the printed paper under the following circumstances:
• High humidity and temperature/direct sunlight/contact with glue, thinner or a rubber eraser.
To install receipt paper
1Remove the printer cover.
2Open the platen arm of the receipt printer (on the left) by lifting it up.
3Ensuring the paper is being fed from the bottom of the roll, lower the roll
into the space behind the printer.
4Put the leading end of the paper over the printer.
5Close the platen arm slowly until it locks securely.
6Replace the printer cover, passing the leading end of the paper through
the cutter slot. Tear off the excess paper.

E-12
To use the cash register’s basic function
To install journal paper
1By the same procedure of setting receipt paper, set journal paper on
the journal printer.
2Using jkey, feed the paper about 20 cm.
3Remove the paper guide of the take-up reel.
4Slide the leading end of the paper into the groove on the spindle of the
take-up reel and wind it onto the reel two or three turns.
5Replace the paper guide of the take-up reel.
6Place the take-up reel into place behind the printer, above the roll
paper.
7Press the jkey to take up any slack in the paper.
8Replace the printer cover.

E-13
Basic function
To use the cash register’s basic function
Setting date, time, and tax table
1Plug in the power socket into a wall outlet.
Be sure to check the rating plate on the side of the
cash register to make sure that its voltage matches
that of the power supply in your area.
2As soon as the power socket is plugged in, the dis-
play shows the language selection display. Choose
language and country by using ?or >keys then
press Fkey.
3Display changes to date and time setting display. Mov-
ing the input area (reversed area) by ?or >keys,
input date, month, year and time from ten key pad.
Input the time by 24 - hour system. For example, 1356
for 1:56 pm. After then press Fkey. For Austra-
lian model, the setting is completed by this step To set
Australian GST, please see the next section.
4 Display then changes to tax table setting screen. Us-
ing ten key pad, input tax rates. You can set four kinds
of tax rates.
5Press Fkey.
Now your cash register is ready to operate basic regis-
trations.

E-14
To use the cash register’s basic function
To set Australian GST
The following operation programs the cash register Australian GST (the Goods
and Service Tax) setting. It is not necessary to program this setting for other
countries than Australia.
Step Operation
1Turn the Mode switch to X position.
2Enter the setting code “01012001” and press okey.
(Pressing okey again cancels the setting.)
01012001o
3Press Fkey. Now your cash register complies with
Australian GST. The printer prints “GST system was
changed”.
F
By setting Australian GST system;
• Australian special rounding system is programmed.
• Tax symbol (*) will be printed on receipts or journals.
• Taxable amount will not be printed.
• “GST INCLUDED” will be printed on receipts or journals for tax 1.
• “TAXABLE AMT” will be printed on receipts or journals for taxable 1 amount.
• “$” will be printed as the monetary symbol.
• “MOF” will be printed on receipts.
• Ten percent tax rate, add-in tax, and rounding off are programmed in tax table 1. No setting in other tax
tables.
• Other taxable amount and tax amount than TX1 (tax 1) and TA1 (taxable 1) will not be printed on sales
reports.
• The lowest signicant digit is restricted to 0 or 5 for cash sales, received on account, paid out, and
money declaration amounts.
• Total line is printed even in direct (cash) sale.

E-15
Basic function
To use the cash register’s basic function
Getting to know your cash register
General guide
1
2
3
45
6
7
8
9
10
1Drawer 6 Customer display
2 SD card slot cover 7 Main display
3Printer cover 8Mode switch
4Receipt printer 9Com port connector cover
5Journal printer 10 Drawer lock
Mode switch
Use the mode keys to change the position of the mode switch and select the mode you want to use.
PGM (Programming)
This position is for setting your cash register to suit the needs of your
store.
RF (Refund)
Use this position to correct registered items.
OFF
The cash register turns off in this position.
REG (Register)
This position is for normal transactions.
X (Read)
This is the position used for issuing daily sales totals report without clear-
ing the data.
Z (Reset)
This position is for issuing reports of daily totals with clearing the accumu-
lated totals.
X2/Z2 (Periodic sale read/reset)
Used to obtain periodic sales reports without resetting total data.

E-16
To use the cash register’s basic function
Mode keys
There are two types of mode keys: the program key (marked “PGM”) and the operator key (marked
“OP”). The program key can be used to set the mode switch to any position, while the operator key can
select the REG and OFF position.
PGM
OP
PGM RF OFF REG X Z X2/Z2
OP key - - ¡ ¡ ---
PGM key ¡¡¡¡¡¡¡
Drawer The drawer opens automatically whenever you nalize a registration and
whenever you issue a read or reset report. The drawer will not open if it is
locked with the drawer key.
Drawer key Use this key to lock and unlock the drawer.
Magnetic plate Use this plate for tacking the notes received from customer.
To adjust the main display
1 Put in ngers in the ditch of the main display and tilt it
to the angle you can see clearly.
To set the customer display
1Lift the customer display until it stops.
2Rotate the display so that customers can see it.

E-17
Basic function
To use the cash register’s basic function
To set the menu sheet
1Pull the sheet cover up and remove the old menu
sheet.
2Put the new menu sheet and replace the sheet cover.

E-18
To use the cash register’s basic function
Display
Main display
During a registration
CLERK001 REG 000011
1 PLU001 •1.00
3 DEPT001 •6.00
SUBTOTAL •7.00
QT 4 6.00
1
2
3
4
After nalization
CLERK001 REG 000011
1 PLU001 •1.00
3 DEPT001 •6.00
TL •7.00
CASH •10.00
CG •3.00
CG •3.00
QT 4
•
10.00
5
9
6
7
8
1 Clerk Number or name/Mode/Consecutive No. 5 Total amount
2Registered item Quantity/Category/Price 6Paid by/Tendered amount
3Subtotal amount 7Change
4 Total quantity/Price of the last item 8 Change
9Total quantity/Tendered amount
Customer display
0123456'89
DELICATESSEN

E-19
Basic function
To use the cash register’s basic function
Keyboard
GUEST/
POST
RECEIPT
7 8 9
4 5 6
1 2 3
0 00 .PLU
RF
#/NS
C
—
%–
RECEIPT
ON/OFF
↓
HELP
SUBTOTAL
CA/AMT
TEND
RA PO
CHK
SIGN
OFF
TAX
PGM
X/DATE/
TIME
CLK #
↑
PRICE
MENU
SHIFT
ERR.CORR
CANCEL
NB NEW
/OLD
8
7
6
5
4
3
2
1
16
15
14
13
12
11
10
9
24
23
22
21
20
19
18
17
32
31
30
29
28
27
26
25
40
39
38
37
36
35
34
33
48
47
46
45
44
43
42
41
56
55
54
53
52
51
50
49
64
63
62
61
60
59
58
57
72
71
70
69
68
67
66
65
VAT
RECEIPT
FEED
JOURNAL
FEED
1
7
12 13
14
19
20
21
22
23
2
15 16
17
3
4
6
5
9
10
11
29
26
8
24
25
27
28 30
18
1fHold this key down to feed receipt paper from the printer.
2jHold this key down to feed journal paper from the printer.
3NNon-add key: Use this key to print reference number (to identify a personal check,
credit card, etc.) during a transaction. Use this function after a numeral entry.
No sale key: Use this key to open the drawer without any registration.
4eUse this key to correct registration errors or to cancel a transactions.
5RUse this key to input refunded amounts or to void preceding inputs.
6mUse this key to input reduction values.
7CUse this key to clear an entry that has not yet been registered.
8pUse this key to register discounts.
9VUse this key for printing breakdown of VAT.
10 09'^Use these keys to input numbers.
11 @Use this key to shift at PLU keys to 1st to 3rd menu.
12 ~Use this key to set the tax status and tax table.
13 /Use this key to look up the procedures to set date/time, tax table etc.
14 oUse this key to input a clerk number.
15
SIGN
OFF
Use this key to sign clerk off the register.
16 gUse this key to issue guest or post-nalization receipts..

E-20
17 QUse this key to switch issuing receipts on and off.
18 RA Use this key following a numeric entry to register money received for non-sale trans-
actions.
19 ]Use this key following a numeric entry to register money paid out from the drawer.
20 SUse this key for adding the latest registered total amount to the previous balance to
obtain a new balance.
21 ZUse this key in a check tracking system to input check numbers in order to open new
checks and to reopen exsisting checks.
22 ?Use this key to move the cursor on the display up.
23 XUse this key to input a quantity for a multiplication. Between transactions, pressing this
key displays the current time and date.
24 kUse this key to register a check tendering.
25 >Use this key to move the cursor on the display down.
26 :Use this key to register unit prices for a PLU (subdepartment).
27 oUse this key to display and print the current subtotal (including tax) amount.
28 +Use this key to input PLU (subdepartment) numbers.
29 FUse this key to register a cash sale.
30 1to 72 Use these keys to register items to departments.
