Casio 3230 User manual

Operation Guide 3230/3232
E-9
To switch the backlight function on and off
In the Timekeeping Mode, hold down Efor about two seconds to switch the backlight
function on and off. When you switch the backlight function on, an indicator appears
on the display as shown.
Backlight function on indicator
The backlight function indicator remains on the display in all modes until you switchx
the backlight function off.
The above operation controls operation of the backlight function only. It does notx
affect operation of audible tones and signals.
E-8
About the backlight
When you switch the backlight function on, the backlight of the watch flashes
whenever alarm (page E-10), countdown timer or hourly time signal is sounding.
PressingxDin any mode illuminates the display, regardless of the backlight’s on/
off setting.
The backlight of this watch employs an electro-luminescent (EL) light, which loses itsx
illuminating power after very long term use.
Frequent use of the backlight shortens the battery life.x
The watch will emit an audible sound whenever the display is illuminated. This isx
caused by a transistor that vibrates when the EL panel lights up. It does not indicate
malfunction of the watch.
The illumination provided by the backlight may be hard to see when viewed underx
direct sunlight.
The backlight automatically stops illuminating whenever an alarm sounds.x
E-7
While any other digits (besides seconds) are selected (flashing), press4. Eto
increase the number. Holding down Echanges the number at high speed.
xTo switch between the 12-hour and 24-hour formats, press
D
while some
digits are flashing.
After you set the time and date, press5. Ato return to the Timekeeping Mode.
The day of the week is automatically set in accordance with the date.x
The date can be set within the range of January 1, 2000 to December 31, 2099.x
If you do not operate any button for a few minutes while a selection is flashing, thex
flashing stops and the watch goes back to the Timekeeping Mode automatically.
E-6
Timekeeping
To set the time and date
Press1. Awhile in the Timekeeping Mode. The seconds
digits flash on the display because they are selected.
Press2. Cto change the selection in the following
sequence.
Minutes
Seconds
Year
Hour
MonthDay
While the seconds digits are selected (flashing), press3.
Eto reset the seconds to “00”. If you press Ewhile the
seconds count is in the range of 30 to 59, the seconds
are reset to “00” and 1 is added to the minutes. If the
seconds count is in the range of 00 to 29, the minutes
count is unchanged.
Day of week
Month
Day
Hour : Minutes Seconds
PM indicator
E-5
PressxCto change from mode to mode. After you perform an operation in any
mode, pressing Creturns to the Timekeeping.
PressxDin any mode to illuminate the display. Illumination turns off about two
seconds after you release D.
Stopwatch
Countdown Timer
E-4
General Guide
All of the illustrations in this manual show Module 3230.x
Timekeeping Alarm
Press C.
E-3
Procedure Lookup
The following is a handy reference list of all the operational procedures contained in
this manual.
To set the time and date ......................................................................................... E-6
To switch the backlight function on and off ......................................................... E-9
To set the alarm time............................................................................................. E-12
To stop the alarm .................................................................................................. E-13
To switch an alarm and Hourly Time Signal on and off..................................... E-13
To set the countdown time ................................................................................... E-14
To use the countdown timer................................................................................. E-15
To switch auto repeat timing on and off ............................................................. E-16
To measure elapsed time...................................................................................... E-17
To record split times ............................................................................................ E-18
To time first and second place finishes .............................................................. E-18
E-2
Contents
General Guide.......................................................................................................... E-4
Timekeeping............................................................................................................. E-6
Alarm ...................................................................................................................... E-10
Countdown Timer.................................................................................................. E-14
Stopwatch .............................................................................................................. E-17
Specifications ........................................................................................................ E-19
E-1
About This Manual
Depending on the model of your watch, display text appears either as dark figuresx
on a light background or light figures on a dark background. All sample displays in
this manual are shown using dark figures on a light background.
Button operations are indicated using the letters shown in the illustration.x
[Module 3230] [Module 3232]
MA1010-EA

Operation Guide 3230/3232
E-19
Specifications
Accuracy at normal temperature: ±15 seconds a month
Timekeeping: Hour, minutes, seconds, pm (P), month, day, the day of the week
Time system: Switchable between 12-hour and 24-hour formats
Calendar system: Auto-calendar pre-programmed from the year 2000 to 2099
Alarm: Multi-function alarm, hourly time signal
Countdown Timer
Measuring unit: 1 second
Input range: from 1 second to 24 hours
Other: Auto-repeat function
Stopwatch
Measuring units: 1/100 second (for the first 60 minutes)
1 second (after 60 minutes)
Measuring capacity: 23 hours, 59 minutes, 59 seconds
Measuring modes: Elapsed time, split time and two finishes
Illumination: EL (electro-luminescent) backlight
E-18
To record split times
Press1. Eto start the stopwatch.
Press2. Bto display the timing up to that point. Stopwatch timing continues
internally.
Press3. Bto clear the split time and to continue time measurement on the display.
You can repeat steps 2 and 3 as many times as you want.x
Press4. Eto stop the time measurement.
Press5. Bto clear the stopwatch to all zeros.
To time first and second place finishes
Press1. Eto start the stopwatch.
Press2. Bwhen the first finisher crosses the line, and record the time.
Press3. Ewhen the second finisher crosses the line.
Press4. Bto display the finishing time of the second finisher.
Press5. Bagain to clear the stopwatch to all zeros.
E-17
Stopwatch
The Stopwatch Mode lets you measure elapsed time, split
times, and two finishes. The range of the stopwatch is
23 hours, 59 minutes, 59 seconds.
To measure elapsed time
Press1. Eto start the stopwatch.
Press2. Eto stop the stopwatch.
You can resume the measurement operation byx
pressing Eagain.
Press3. Bto clear the stopwatch to all zeros.
For the first 60 minutes, the display shows minutes,x
seconds, and 1/100 second. After 60 minutes, the display
format changes to show hours, minutes, and seconds.
Mode indicator
Current time
Minutes
Seconds
1/100 second
E-16
To switch auto repeat timing on and off
Press1. Awhile in the Countdown Timer Mode. The
hours digit flashes on the display because it is selected.
Press2. Dto switch auto repeat on and off.
Press3. Ato return to the Countdown Timer Mode.
When the end of the countdown is reached whilex
auto repeat is on, the alarm sounds, but the starting
countdown time is reset and countdown timing starts
again automatically whenever the countdown reaches
zero. You can stop timing by pressing E, and manually
reset to the starting countdown time by pressing A.
Auto repeat on indicator
E-15
After you set the countdown time, press4. Ato return to the Countdown Timer
Mode.
If you do not operate any button for a few minutes while a selection is flashing,x
the flashing stops and the watch goes back to the Countdown Timer Mode
automatically.
To use the countdown timer
Press1. Ewhile in the Countdown Timer Mode to start the countdown timer.
Press2. Eagain to stop the countdown timer.
You can continue countdown timer operation by pressingxE.
Stop the timer and then press3. Auntil the countdown time is reset to its starting
value.
When the end of the countdown is reached and auto repeat timing is off, the alarmx
sounds for 10 seconds or until you stop the alarm by pressing any button.
Countdown timing stops, and the countdown time is automatically reset to its starting
value after the alarm stops.
E-14
Countdown Timer
The countdown timer can be set within a range of 1 second
to 24 hours. When the countdown reaches zero, an alarm
sounds for 10 seconds or until you press any button.
To set the countdown time
Press1. Awhile in the Countdown Timer Mode. The
hours digit flashes on the display because it is selected.
Press2. Cto change the selection in the following
sequence.
Seconds
Hours Minutes
Press3. Eto increase the selected number. Holding down Echanges the number
at high speed.
To set the starting value of the countdown time to 24 hours, setx0:00'00.
Mode indicator
Current time
Hours : Minutes Seconds
E-13
To stop the alarm
Press any button to stop the alarm after it starts to sound.
To switch an alarm and Hourly Time Signal on and off
Press Ewhile in the Alarm Mode to change the status of an alarm (see “Alarm
Types” on page E-10) and Hourly Time Signal in the following sequence.
Both ON Both OFF Alarm Only Hourly Time
Signal only
Alarm on indicator
Hourly time signal on indicator
E-12
To set the alarm time
Press1. Awhile in the Alarm Mode until the hour digits start to flash on the display.
The hour digits flash because they are selected.
At this time the alarm is automatically switched on.x
Press2. Cto change the selection in the following sequence.
MonthHour Minutes Day
Press3. Eto increase the selected digits. Holding down Echanges the number at
high speed.
The format (12-hour and 24-hour) of the alarm time matches the format you selectx
for normal timekeeping.
When setting the alarm time using the 12-hour format, take care to set the timex
correctly as morning or afternoon.
After you set the alarm time, press4. Ato return to the Alarm Mode.
If you do not operate any button for a few minutes while a selection is flashing, thex
flashing stops and the watch goes back to the Alarm Mode automatically.
E-11
To set a date alarmx
Set the month, day, hour and minutes for the alarm time. This type of setting causes
the alarm to sound at the specific time, on the specific date you set.
xTo set a 1-month alarm
Set the month, hour and minutes for the alarm time. Set “– –” for the day (see step 3
under “To set the alarm time”). This type of setting causes the alarm to sound every
day at the time you set, only during the month you set.
xTo set a monthly alarm
Set the day, hour and minutes for the alarm time. Set “–” for the month (see step 3
under “To set the alarm time”). This type of setting causes the alarm to sound every
month at the time you set, on the day you set.
E-10
Alarm
You can set an alarm with hour, minutes, month, and day.
When the alarm is on, the alarm sounds for 20 seconds
at the preset time. When the Hourly Time Signal is on, the
watch beeps every hour on the hour.
Alarm Types
The types of alarm you get depends on the information
you set.
To set a daily alarmx
Set the hour and minutes for the alarm time. Set “–” for the
month and “– –” for the day (see step 3 under “To set the
alarm time”). This type of setting causes the alarm to sound
every day at the time you set.
Mode indicator
Month
Day
Hour : Minutes
Hourly time signal on
indicator
Alarm on indicator

Operation Guide 3230/3232
E-20
Battery: One lithium battery (Type: CR2016)
Approximately 2 years on type CR2016 (assuming backlight operation
3.5 sec./day and alarm operation 20 sec./day)
Note: Frequent use of the backlight shortens the battery life noted above.
