Casio 3499 User manual

User’s Guide 3499
E-7
CBA
Compass Mode Barometer/
Thermometer Mode
Altimeter Mode
Determines north and can be used to
check a bearing.
Point 12 o’clock at your destination,
press C.
Destination
North
xRe-start
Bearing
N: North
E: East
W: West
S: South
Direction
angle 315°
0°
Direction angle
to bearing
B
C
A
B
Barometric
pressure graph
Temperature
Barometric
pressure
Altitude Graph
(Changes in altitude.)
Altitude
xRe-start
C
A
E-6
Using the Watch
Navigating Between the Timekeeping, Compass, Barometer/Thermometer and
Altimeter Modes
xTo return directly to the Timekeeping Mode from any other mode, hold down Dfor at least two
seconds.
xTo enter the Compass, Barometer/Thermometer or Altimeter Mode from any mode not shown in the
diagram below, first return to the Timekeeping Mode.
Timekeeping Mode
xFace illumination
D
E-5E-4
Charging the Watch
Remove the watch from your wrist and place it in a brightly lit area.
xThe watch may become hot when exposed to light for charging. Take care to avoid burn injury.
xAvoid charging in locations where it is very hot.
Power Saving
xLeaving the watch in a dark locations for about one hour between the hours of 10 p.m. and 6 a.m. will
cause PS to flash on the display. All functions will continue operation.
xLeaving the watch in a dark location for about one week will cause PS to remain on the display without
flashing. Only the timekeeping function will continue operation.
Battery Alerts
When battery power goes low, a warning message (LOW or CHG) appears on the display and
certain functions become disabled. When a warning message appears, charge the watch as soon
as possible.
E-3
Contents
Charging the Watch.......................................................................................................................E-4
Using the Watch ............................................................................................................................E-6
Navigating Between the Timekeeping, Compass, Barometer/
Thermometer and Altimeter Modes............................................................................................. E-6
Navigating to Other Modes......................................................................................................... E-8
Changing the Current Time and Date Settings..........................................................................E-10
Mode Settings .............................................................................................................................E-12
Specifications..............................................................................................................................E-13
Operating Precautions ................................................................................................................E-17
User Maintenance .......................................................................................................................E-24
E-2
Important!
xKeep the watch’s face exposed to light as much as possible (page E-4).
xThis manual provides a brief overview of your watch.
Important Altimeter and Compass Information!
xThe Altimeter Mode displays relative altitude based on barometric pressure readings. Readings taken
at different times at the same location may produce different values due to changes in pressure. The
value displayed by the watch may be different from the actual elevation and/or sea level elevation of
your location.
xWhen using the Altimeter Mode for mountain climbing or other activities, it is highly recommended that
you check a map, local altitude indications, or some other source for your current correct altitude, and
that you regularly calibrate the Altimeter Mode.
xWhen using the watch compass for serious trekking or climbing always take along another compass
to confirm readings. If watch readings are different from the other compass, perform bidirectional
calibration of the watch compass.
xDirection readings and calibration will not be possible if the watch is near a permanent magnet
(magnetic accessory, etc.), metal objects, high-voltage wires, aerial wires, or electrical appliances (TV,
computer, cellphone, etc.)
xCalibration: Operation Guide available at the CASIO website.
E-1
ENGLISH
Congratulations upon your selection of this CASIO watch.
For details about how to use this watch and for
troubleshooting information, go to the website
below.
https://world.casio.com/manual/wat/
To ensure that this watch provides you with
the years of service for which it is designed,
carefully read and follow the instructions
in this manual, especially the information
under “Operating Precautions” and “User
Maintenance”.
Be sure to keep all user documentation handy
for future reference.
Important!
xThis manual provides a brief overview of your
watch.
xIf you are going to a location where Internet
access is not available, download the
Operation Guide PDF from the website below
to a device that you will be taking along with
you.
Note that CASIO COMPUTER CO., LTD. assumes no responsibility for any damage or loss
suffered by you or any third party arising through the use of your watch or its malfunction.
MA2011-EA © 2021 CASIO COMPUTER CO., LTD.

User’s Guide 3499
E-15
Temperature Sensor Precision:
±2°C (±3.6°F) in range of –10°C to 60°C (14.0°F to 140.0°F)
Sunrise/sunset:
Sunrise/sunset time display; selectable date
Stopwatch:
Measuring unit: 1/10 second
Measuring capacity: 999:59' 59.9"
Measuring accuracy: ±0.0006%
Measuring modes: Elapsed time, split time, two finishes
Countdown Timer:
Measuring unit: 1 second
Countdown range: 24 hours
Setting unit: 1 minute
Alarms: 5 Daily alarms (with one snooze alarm); Hourly time signal
World Time: 48 cities (31 time zones)
Other: Daylight Saving Time/Standard Time
Illumination: LED light; Selectable illumination duration (approximately 1.5 seconds or 3 seconds);
Auto Light Switch (Full Auto Light operates only in the dark)
Other: Battery power indicator; Power Saving; Low-temperature resistance (–10°C/14°F); Button
operation tone on/off
E-14
Altimeter:
Measurement range: –700 to 10,000 m (or –2,300 to 32,800 ft.) without reference altitude
Display range: –10,000 to 10,000 m (or –32,800 to 32,800 ft.)
Negative values can be caused by readings produced based on a reference altitude or due to
atmospheric conditions.
Display unit: 1 m (or 5 ft.)
Current Altitude Data: Every second for the first 3 minutes, followed by every 5 seconds for
approximately 1 hour (0'05); every second for the first 3 minutes, followed
by every 2 minutes for approximately 12 hours (2'00)
Altitude Memory Data:
Manually saved records: 30 (altitude, date, time)
Auto saved values: One set of high altitude and its reading date and time, low altitude and its
reading date and time, total ascent and its save start date and time, total
descent and its save start date and time
Trek log data: High altitude, low altitude, cumulative ascent, cumulative descent for up to 14
treks
Other: Reference altitude setting; Altitude differential; Altitude auto measurement interval (0'05 or
2'00)
Bearing Sensor Precision:
Direction: Within ±10°
Values are guaranteed for a temperature range of –10°C to 60°C (14°F to 140°F).
North pointer: Within ±2 digital segments
Pressure Sensor Precision:
Measurement accuracy: Within ±3 hPa (0.1 inHg) (Altimeter accuracy: Within ±75m (246 ft.))
xValues are guaranteed for a temperature range of –10°C to 40°C (14°F to 104°F).
xPrecision is lessened by strong impact to either the watch or the sensor, and by temperature
extremes.
E-13
Specifications
Accuracy at normal temperature: ±15 seconds a month
Timekeeping: Hour, minute, second, p.m. (P), year, month, day, day of the week
Time format: 12-hour and 24-hour
Calendar system: Full Auto-calendar pre-programmed from the year 2000 to 2099
Other: Three display formats (day of the week/day screen, month/day screen, barometric pressure
graph screen); Home City code (can be assigned one of 48 city codes); Standard Time /
Daylight Saving Time (summer time)
Year display on setting screen only.
Digital Compass: 60 seconds continuous reading; 16 directions; Angle value 0° to 359°; Four
direction pointers; Calibration (bidirectional); Magnetic declination correction;
Bearing Memory
Barometer:
Measurement and display range:
260 to 1,100 hPa (or 7.65 to 32.45 inHg)
Display unit: 1 hPa (or 0.05 inHg)
Reading timing: Daily from midnight, at two-hour intervals (12 times per day); Every five seconds
in the Barometer/Thermometer Mode
Other: Calibration; Manual reading (button operation); Barometric pressure graph; Barometric
pressure differential pointer; Barometric pressure change indicator
Thermometer:
Measurement and display range: –10.0 to 60.0°C (or 14.0 to 140.0°F)
Display unit: 0.1°C (or 0.2°F)
Reading timing: Every five seconds in the Barometer/Thermometer Mode
Other: Calibration; Manual reading (button operation)
E-12
Mode Settings
For full details about timer, alarm, World Time City summer time, and other settings, and about
calibrating measurements (direction, altitude, barometric pressure, temperature), refer to the
Operation Guide available at the CASIO website.
E-11
Screen To do this: Do this:
Reset the second to 00
(If the current seconds count is between 30 and 59,
one is added to the minute count).
Press A.
Change the hour or minute
Use A(+) and C(–).
Change the year, month, or day
4. After all of the settings are the way you want, press Etwice to exit the setting screen.
E-10
Changing the Current Time and Date Settings
1. In the Timekeeping Mode, hold down Efor at least two seconds. Keep Edepressed until the
city code and city name starts to scroll.
2. Press Dto move the flashing in the sequence shown below to select the other settings.
City Code DST Year
Thermometer/Barometer/
Altitude display unit
12/24-Hour
Format Second Hour Minute
MonthDay
Button Operation
Tone
Illumination
Duration
Power
Saving
3. When the timekeeping setting you want to change is flashing, use Aand/or Cto change it as
described below.
Screen To do this: Do this:
Change the city code Use A(East) and C(West).
Toggle between Daylight Saving Time (ON) and
Standard Time (OFF). Press A.
Toggle between 12-hour (12H) and 24-hour (24H)
timekeeping. Press A.
E-9
Data Recall Mode Stopwatch Mode
Alarm Mode Timer Mode
Last displayed record
xScroll
xScroll
xSelect data type Minutes Seconds
1/10 second
Hours
xSplit
xReset
xStart
xStop
xReset
xStart
xStop
Minutes Seconds
xScroll
xScroll
xOn/Off
D
D
D D
E-8
Navigating to Other Modes
Timekeeping Mode Sunrise/Sunset Mode
World Time Mode
Month, day
xSelect screen
Barometric pressure
graph
Day of the week, day
xScroll
xScroll
Sunset time Sunrise time
Home City time
World Time City
time
World Time City
code
xScroll
xScroll
D D
D

User’s Guide 3499
L-3
City Code City UTC Offset/
GMT Differential
DEL Delhi +5.5
KTM Kathmandu +5.75
DAC Dhaka +6
RGN Yangon +6.5
BKK Bangkok +7
SIN Singapore
+8
HKG Hong Kong
BJS Beijing
TPE Taipei
SEL Seoul +9
TYO Tokyo
ADL Adelaide +9.5
GUM Guam +10
SYD Sydney
NOU Noumea +11
WLG Wellington +12
xBased on data as of July 2020.
xIf the city or area you want is not included in the
above table, set the Home City to a city code
that is in the same time zone as the location you
want to select.
xFor details about the Home City, World Time City
and summer time settings, refer the Operation
Guide available at the CASIO website.
L-2
City Code Table
City Code City UTC Offset/
GMT Differential
PPG Pago Pago –11
HNL Honolulu –10
ANC Anchorage –9
YVR Vancouver –8
LAX Los Angeles
YEA Edmonton –7
DEN Denver
MEX Mexico City –6
CHI Chicago
NYC New York –5
SCL Santiago –4
YHZ Halifax
YYT St. Johns –3.5
RIO Rio De Janeiro –3
FEN Fernando de
Noronha –2
RAI Praia –1
City Code City UTC Offset/
GMT Differential
UTC
0LIS Lisbon
LON London
MAD Madrid
+1
PAR Paris
ROM Rome
BER Berlin
STO Stockholm
ATH Athens
+2CAI Cairo
JRS Jerusalem
MOW Moscow +3
JED Jeddah
THR Tehran +3.5
DXB Dubai +4
KBL Kabul +4.5
KHI Karachi +5
L-1
City Code Table
E-16
Power Supply: Solar panel and one rechargeable battery
Approximate battery operating time: 8 months (from full charge to Level 4) under the following
conditions:
xLight: 1.5 seconds/day
xBeeper: 10 seconds/day
xDirection readings: 20 times/month
xClimbs: Once (approximately 1 hour of altitude readings)/month
xBarometric pressure change indicator readings: Approximately 24 hours/month
xBarometric pressure graph: Readings every 2 hours
xDisplay: 18 hours/day
Frequent use of illumination runs down the battery. Particular care is required when using the auto
light switch.
Specifications are subject to change without notice.
