Casio 5200 User manual

Operation Guide 5222
E-9
Hour : Minutes
Day of the Week
and Day
Hour : Minutes Seconds
Seconds
DD
Day
Day of week PM indicator
D
E-8
Timekeeping
This watch features separate digital and analog timekeeping. The procedures for
setting the digital time (page E-11) and analog time (page E-16) are different.
In the Timekeeping Mode, you can pressxDto change the display format as shown
below.
E-7
Alarm Mode Stopwatch Mode Countdown Timer
Mode
E-6
General Guide
PressxCto change from mode to mode.
In any mode (except when a setting screen is on the display), pressxBto illuminate
the display.
Timekeeping Mode World Time Mode
Press C.
E-5
To configure the countdown timer ...................................................................... E-28
To use the countdown timer................................................................................. E-29
To turn on illumination.......................................................................................... E-30
To turn the button operation tone on or of ......................................................... E-32
E-4
To set the digital time and date............................................................................ E-11
To toggle the Timekeeping Mode digital time
between DST and Standard Time..................................................................... E-15
To adjust the analog time ..................................................................................... E-16
To view the time in another city........................................................................... E-18
To toggle a city code time between Standard Time
and Daylight Saving Time ................................................................................. E-19
To set an alarm time.............................................................................................. E-21
To test the alarm.................................................................................................... E-22
To turn the alarm and the hourly time signal on and off ................................... E-23
To measure times with the stopwatch................................................................. E-26
Procedure Lookup
The following is a handy reference list of all the operational procedures contained in
this manual.
E-3
Contents
General Guide.......................................................................................................... E-6
Timekeeping............................................................................................................. E-8
Analog Time Setting.............................................................................................. E-16
World Time............................................................................................................. E-18
Alarm ...................................................................................................................... E-20
Stopwatch .............................................................................................................. E-25
Countdown Timer.................................................................................................. E-27
Illumination ............................................................................................................ E-30
Reference ............................................................................................................... E-31
Specifications ........................................................................................................ E-35
E-2
E-1
About This Manual
Depending on the model of your watch, its display mayx
have dark figures on a light background or light figures on
a dark background. All samples in this manual show dark
figures on a light background.
Button operations are indicated using the letters shownx
in the illustration.
For the sake of simplicity, the sample displays in thisx
manual do not show the analog hands of the watch.
Each section of this manual provides you with thex
information you need to perform operations in each
mode. Further details and technical information can be
found in the “Reference” section.
MA1101-EA

Operation Guide 5222
E-19
To toggle a city code time between Standard Time and Daylight Saving Time
In the World Time Mode, use1. Dto display the city code
whose Standard Time/Daylight Saving Time setting you
want to change.
Hold down2. Afor about one second to toggle between
Daylight Saving Time (DST indicator displayed) and
Standard Time (DST indicator not displayed).
The DST indicator is on the display whenever you displayx
a city code for which Daylight Saving Time is turned on.
Note that the DST/Standard Time setting affects onlyx
the currently displayed city code. Other city codes are
not affected.
You will not be able to change the DST/Standard Time setting of the city codex
currently selected as your Home City.
Note that you cannot switch between Standard Time and Daylight Saving Time whilex
is selected as the city code.
DST indicator
E-18
World Time
World Time digitally displays the current time in 48 cities
(29 time zones) around the world.
All of the operations in this section are performed inx
the World Time Mode, which you enter by pressing C
(page E-6).
To view the time in another city
In the World Time Mode, press Dto scroll eastwardly
through city codes.
For full information about city codes, see the “City Codex
Table” at the back of this manual.
If the current time shown for a city is wrong, it probablyx
means there is a problem with your Timekeeping
Mode time and/or Home City code settings. Go to
the Timekeeping Mode and make the necessary
adjustments.
City code
Current time for the
selected city code
E-17
If you need to advance the analog time setting a long way, hold downxDuntil
the time starts advancing at high speed, and then press B. This locks the
high-speed hand movement, so you can release the button. High-speed hand
movement continues until you press any button. It will also stop automatically
after the time advances 12 hours or if an alarm (daily alarm, Hourly Time Signal,
or countdown beeper) starts to sound.
Press3. Ato exit the setting screen.
The watch will automatically adjust the minute hand slightly to match its internalx
second count when you exit the setting screen.
E-16
Analog Time Setting
Perform the procedure below when the time indicated by the analog hands does not
match the time of the digital display.
To adjust the analog time
In the Timekeeping Mode, hold down1. Dfor about three
seconds until the lower right display first shows H-SET
and then the current digital time starts to flash. This is
the analog hand adjustment mode.
Press2. Dto advance the analog time setting by
20 seconds.
Holding downxDadvances the analog time setting at
high speed.
E-15
To toggle the Timekeeping Mode digital time between DST and Standard Time
In the Timekeeping Mode, hold down1. Auntil the
seconds start to flash, which indicates the setting
screen.
Press2. Conce to display the DST setting screen.
Press3. Dto toggle between Daylight Saving Time
(displayed) and Standard Time ( displayed).
Press4. Ato exit the setting screen.
The DST indicator appears on the Timekeeping Modex
screen to indicate that Daylight Saving Time is turned on.
DST indicator
E-14
Press5. Ato exit the setting screen.
Resetting the seconds only (without changing the DST, Home City code, hour, orx
minute setting) causes the analog minute hand setting to be adjusted automatically.
See “Digital Time Daylight Saving Time (DST) Setting” below for details about thex
DST setting.
The 12-hour/24-hour timekeeping format you select in the Timekeeping Mode isx
applied in all modes.
Digital Time Daylight Saving Time (DST) Setting
Daylight Saving Time (summer time) advances the digital time setting by one hour
from Standard Time. Remember that not all countries or even local areas use Daylight
Saving Time.
E-13
When the setting you want to change is flashing, use4. Band Dto change it as
described below.
Screen To do this: Do this:
Reset the seconds to Press D.
Toggle between Daylight Saving Time ( )
and Standard Time ( ) Press D.
Change the Home City code Use D(east) and B(west).
Change the hour or minutes Use D(+) and B(–).
Toggle between 12-hour ( ) and 24-hour
( ) timekeeping Press D.
Change the year Use D(+) and B(–).
Change the month or day
E-12
Press3. Cto move the flashing in the sequence shown below to select the other
settings.
Seconds DST Home City Code Hour Minutes
12/24-Hour FormatYearMonthDay
E-11
To set the digital time and date
In the Timekeeping Mode, hold down1. Auntil the
seconds start to flash, which indicates the setting
screen.
Press2. Ctwice to move the flashing to the Home City
code setting (page E-12), and then use Band Dto
select the code you want.
Make sure you select your Home City code beforex
changing any other setting.
For full information on city codes, see the “City Codex
Table” at the back of this manual.
E-10
Digital Time and Date
Use the Timekeeping Mode to set and view a digital display of the current time and
date. When setting the digital time, you can also configure settings for summer time
(Daylight Saving Time or DST), your Home City code (the code for the city where you
normally use the watch), the 12/24-hour format.
This watch is preset with a number of city codes, each of which represents the timex
zone where that city is located. When setting the digital time, it is important that you
select the correct city code for your Home City. If your location is not included in the
preset city codes, select the preset city code that is in the same time zone as your
location.
Note that all of the times for the World Time Mode city codes (page E-18) arex
displayed in accordance with the digital time and date settings you configure in the
Timekeeping Mode.
After you correctly set your Home City time and date, you can set the watch up forx
timekeeping with a different city code simply by changing the Home City code in the
Timekeeping Mode.

Operation Guide 5222
E-29
To use the countdown timer
Press Dwhile in the Countdown Timer Mode to start the
countdown timer.
When the end of the countdown is reached, the alarmx
sounds for 10 seconds or until you stop it by pressing any
button. The countdown time is reset to its starting value
automatically after the alarm stops.
The countdown timer operation continues even if you exitx
the Countdown Timer Mode.
PressxDwhile a countdown operation is in progress to
pause it. Press Dagain to resume the countdown.
To completely stop a countdown operation, first pausex
it (by pressing D), and then press A. This returns the
countdown time to its starting value.
E-28
To configure the countdown timer
While the countdown start time is on the display in the1.
Countdown Timer Mode, hold down Auntil the current
countdown start time starts to flash, which indicates the
setting screen.
If the countdown start time is not displayed, use thex
procedure under “To use the countdown timer” (page
E-29) to display it.
When the setting you want to change is flashing, use2. B
and Dto change it.
Setting Screen Button Operation
Start Time
Use D(+) and B(–) to change the setting.
• You can set a start time in the range of 1 minute to
60 minutes in 1-minute increments.
Press3. Ato exit the setting screen.
E-27
Countdown Timer
The countdown timer can be set within a range of
one minute to 60 minutes. An alarm sounds when the
countdown reaches zero.
All of the operations in this section are performed in thex
Countdown Timer Mode, which you enter by pressing C
(page E-7).
Seconds
Minutes
E-26
To measure times with the stopwatch
Elapsed Time
D D D D A
Start Stop Re-start Stop Clear
Split Time
D A A D A
Start Split
(SPL indicator
displayed)
Split release Stop Clear
Two Finishes
D A D A A
Start Split
First runner
finishes. Display
time of first
runner.
Stop
Second runner
finishes.
Split release
Display time of
second runner.
Clear
E-25
Stopwatch
The stopwatch lets you measure elapsed time, split times,
and two finishes.
The display range of the stopwatch is 59 minutes,x
59 seconds.
The stopwatch continues to run, restarting from zero afterx
it reaches its limit, until you stop it.
The stopwatch measurement operation continues even ifx
you exit the Stopwatch Mode.
Exiting the Stopwatch Mode while a split time is frozenx
on the display clears the split time and returns to elapsed
time measurement.
All of the operations in this section are performed in thex
Stopwatch Mode, which you enter by pressing C(page
E-7).
SPL indicator
Seconds
Minutes
E-24
Alarm On
Signal On
Alarm Off
Signal Off
Alarm On
Signal Off
Alarm Off
Signal On
The alarm on indicator and hourly time signal on indicator are shown in all modes.x
The alarm on indicator flashes while the alarm is sounding.x
E-23
To turn the alarm and the hourly time signal on and off
In the Alarm Mode, you can use1. Dto cycle through the
available alarm and hourly time signal combinations as
shown below.
Hourly time signal
on indicator
Alarm on indicator
E-22
Alarm Operation
The alarm sounds at the preset time for about 20 seconds, regardless of the mode
the watch is in.
Alarm and Hourly Time Signal operations are performed in accordance with thex
Timekeeping Mode digital time.
To stop the alarm tone after it starts to sound, press any button.x
To test the alarm
In the Alarm Mode, hold down Dto sound the alarm.
E-21
To set an alarm time
In the Alarm Mode, hold down1. Auntil the hour setting
of the alarm time starts to flash, which indicates the
setting screen.
This operation automatically turns on the alarm.x
Press2. Cto move the flashing between the hour and
minute settings.
While a setting is flashing, use3. D(+) and B(–) to
change it.
When setting the alarm time using the 12-hour format, take care to set the timex
correctly as a.m. (no indicator) or p.m. (Pindicator).
Press4. Ato exit the setting screen.
E-20
Alarm
You can set one Daily Alarm. When the alarm is turned on,
the alarm tone sounds when the alarm time is reached.
You can turn on an Hourly Time Signal that causes the
watch to beep twice every hour on the hour.
PressingxDcycles through the available alarm and
hourly time signal combinations (page E-23).
All of the operations in this section are performed in thex
Alarm Mode, which you enter by pressing C(page E-7).
Alarm time
(Hour : Minutes)
Hourly time signal
on indicator
Alarm on indicator

Operation Guide 5222
L-3
City
Code City UTC Offset/ GMT Differential
THR Tehran +3.5
DXB Dubai +4
KBL Kabul +4.5
KHI Karachi +5
DEL Delhi +5.5
DAC Dhaka +6
RGN Yangon +6.5
BKK Bangkok +7
SIN Singapore
+8
HKG Hong Kong
BJS Beijing
TPE Taipei
SEL Seoul +9
TYO Tokyo
ADL Adelaide +9.5
City
Code City UTC Offset/ GMT Differential
GUM Guam +10
SYD Sydney
NOU Noumea +11
WLG Wellington +12
xBased on data as of July 2010.
xThe rules governing global times
(UTC offset and GMT differential) and
summer time are determined by each
individual country.
L-2
City
Code City UTC Offset/ GMT Differential
PPG Pago Pago –11
HNL Honolulu –10
ANC Anchorage –9
YVR Vancouver –8
LAX Los Angeles
YEA Edmonton –7
DEN Denver
MEX Mexico City –6
CHI Chicago
MIA Miami
–5YTO Toronto
NYC New York
SCL Santiago –4
YHZ Halifax
YYT St. Johns –3.5
City
Code City UTC Offset/ GMT Differential
RIO Rio De Janeiro –3
RAI Praia –1
UTC
0LIS Lisbon
LON London
MAD Madrid
+1
PAR Paris
ROM Rome
BER Berlin
STO Stockholm
ATH Athens
+2CAI Cairo
JRS Jerusalem
MOW Moscow +3
JED Jeddah
City Code Table
L-1
City Code Table
E-36
Countdown Timer
Measuring unit: 1 second
Countdown range: 60 minutes
Input range: 1 minute to 60 minutes (1-minute increments)
Illumination: LED (light-emitting diode)
Battery: Two silver oxide batteries (Type: SR726W)
Approximately 2 years on type SR726W (assuming alarm operation 20 seconds
and one illumination operation per day)
E-35
Specifications
Accuracy at normal temperature: ±30 seconds a month
Digital Timekeeping: Hour, minutes, seconds, p.m. (P), day, day of the week
Time format: 12-hour and 24-hour
Calendar system: Full Auto-calendar pre-programmed from the year 2000 to 2099
Other: 3 screen formats (Day of the Week and Day, Hour: Minutes, Seconds);
Home City code (can be assigned one of 48 city codes); Daylight Saving
Time (summer time)/Standard Time
Analog Timekeeping: Hour, minutes (hand moves every 20 seconds)
World Time: 48 cities (29 time zones)
Other: Daylight Saving Time/Standard Time
Alarm: One daily alarm; Hourly Time Signal
Stopwatch
Measuring unit: 1 second
Measuring capacity: 59'59"
Measuring modes: Elapsed time, split time, two finishes
E-34
World Time
All World Time Mode times are calculated from the current Home City time in thex
Timekeeping Mode using UTC time differential values.
The UTC differential is a value that indicates the time difference between ax
reference point in Greenwich, England and the time zone where a city is located.
The letters “UTC” is the abbreviation for “Coordinated Universal Time”, which is thex
world-wide scientific standard of timekeeping. It is based upon carefully maintained
atomic (cesium) clocks that keep time accurately to within microseconds. Leap
seconds are added or subtracted as necessary to keep UTC in sync with the Earth’s
rotation.
E-33
Timekeeping
Resetting the seconds to 00 while the current count is in the range of 30 tox
59 causes the minutes to be increased by 1. In the range of 00 to 29, the seconds
are reset to 00 without changing the minutes.
With the 12-hour format, thexPindicator appears on the display for times in the
range of noon to 11:59 p.m. and no indicator appears for times in the range of
midnight to 11:59 a.m.
With the 24-hour format, times are displayed in the range of 0:00 to 23:59, withoutx
any indicator.
The year can be set in the range of 2000 to 2099.x
The watch’s built-in full automatic calendar makes allowances for different monthx
lengths and leap years. Once you set the date, there should be no reason to change
it except after you have the watch’s batteries replaced.
The day of the week is displayed automatically in accordance with the date (year,x
month, and day) settings.
E-32
To turn the button operation tone on or off
In any Mode (except a setting mode), hold down Cfor about three seconds to toggle
the button operation tone on or off.
The tone off indicator is displayed in all modes when the tone is turned off.x
Auto Return Feature
If you leave a screen with flashing digits on the display for two or three minutes
without performing any operation, the watch automatically exits the setting screen.
Scrolling
The Band Dbuttons are used in various modes and setting screens to scroll
through data on the display. In most cases, holding down these buttons during a scroll
operation scrolls through the data at high speed.
Initial Screens
When you enter the World Time, the data you were viewing when you last exited the
mode appears first.
E-31
Reference
This section contains more detailed and technical information about watch operation.
It also contains important precautions and notes about the various features and
functions of this watch.
Button Operation Tone
The button operation tone sounds any time you press one
of the watch’s buttons. You can turn the button operation
tone on and off as desired.
Even if you turn off the button operation tone, the alarm,x
the Hourly Time Signal, and the countdown alarm all
operate normally.
Button operation tone
off indicator
E-30
Illumination
An LED (light-emitting diode) illuminates the display for
easy reading in the dark.
Illumination Precautions
The illumination provided by the light may be hard to see when viewed under directx
sunlight.
Illumination automatically turns off whenever an alarm sounds.x
Frequent use of illumination runs down the batteries.x
To turn on illumination
In any mode (except when a setting screen is on the display), press Bto turn on
illumination.
