User’s Guide 5603 (OC)
E-7
Timekeeping (Current Time and Day Adjustment)
● Timekeeping is kept accurate using information provided by a time calibration signal and by
communication with a mobile phone.
xTime calibration signals can be received using Auto Receive or Manual Receive (page E-11).
xTo set the current time and day, normally use the procedure under “Time Calibration Signal Auto
Receive” (page E-12).
xFor information about how to adjust time using a phone, refer to the Operation Guide available at
the website below.
https://world.casio.com/manual/wat/
xIf you are in an area where a time calibration signal cannot be received or if you cannot connect
with a phone for some reason, adjust time and date settings manually (page E-16).
Important!
xFor the watch to be able to receive a time calibration signal, its Home City setting must be one where
time calibration signal reception is normally supported (pages E-14 and L-2).
xIf you feel that the current time and/or day indicator are not in the correct positions, you can adjust
their alignment. For details, see the Operation Guide available at the CASIO website.
xTime calibration signal reception is normally possible in the areas below.
Japan, China, North America, Europe
For details, see the Operation Guide available at the CASIO website.
E-6
Charge Level Indication
xPushing the crown back in after pulling it out will cause the current charge level to be indicated
momentarily.
M: Good (medium)
H: Good (high)
L: Insufficient (low)
Battery Alerts
xLow Battery
Second hand jumps every two seconds (Low Battery Alert).
xDead Battery
All hands stopped.
E-5
Charging the Watch
xWhen you are not wearing the watch, leave it where its face (solar panel) is
exposed to bright light for charging.
xTo help ensure stable operation, expose the face of the watch to about a half
day of direct sunlight each month to charge it.
xWhile wearing the watch, take care so your sleeve does not block its face
(solar panel) from light. Charging efficiency may be reduced if the face (solar
panel) is blocked from light, even partially.
Caution
xThe case of the watch may become extremely hot when charging. Guard against burn injury.
Power Saving
xLeaving the watch in a dark location for about one hour between 10:00 p.m. and 5:50 a.m. will cause
the second hand to stop.
xLeaving the watch in a dark location for about one week will cause all hands to stop.
E-4
Contents
Features .............................................................................................................................................. E-2
Charging the Watch............................................................................................................................ E-5
Timekeeping (Current Time and Day Adjustment) ............................................................................. E-7
Mode Reference Guide....................................................................................................................... E-8
Using the Watch in a Medical Facility or Aircraft .......................................................................... E-10
Timekeeping (Based on a Time Calibration Signal) ......................................................................... E-11
Appropriate Signal Reception Location (Time Calibration Signal).................................................. E-11
Time Calibration Signal Auto Receive.......................................................................................... E-12
Time Calibration Signal Manual Receive...................................................................................... E-13
City (Time Zone) Setting ................................................................................................................... E-14
Home City (Time Zone) Setting ................................................................................................... E-14
World Time City (Time Zone) Setting........................................................................................... E-15
Configuring Time and Date Settings Manually ................................................................................ E-16
Specifications ................................................................................................................................... E-17
Operating Precautions...................................................................................................................... E-19
User Maintenance............................................................................................................................. E-25
E-3
Bluetooth®is a registered trademark or trademark of Bluetooth SIG, Inc. of the United States.
This product has a Mobile Link function that lets it communicate with a Bluetooth®capable phone to
perform automatic time adjustment and other operations.
xThis product complies with or has received approval under radio laws in various countries and
geographic areas. Use of this product in an area where it does not conform to or where it has not
been approved under applicable radio laws may be punishable under local laws. For details, visit
https://world.casio.com/ce/BLE/.
xUse of this product inside of an aircraft is restricted by the aviation laws of each country. Be sure to
obey instructions provided by flight personnel concerning use of devices such as this product.
E-2
Features
Your watch provides you with the features and functions described below.
◆Solar powered operation........................................................................................Page E-5
The watch generates electrical power from sunlight and other types of light, and uses it to charge a
battery that powers operation.
◆Accurate timekeeping.............................................................................................Page E-7
Timekeeping is kept accurate using information provided by receipt of a time calibration signal and by
communication with a phone.
◆Current time in cities around the globe.................................................................Page E-8
View the current time in 27 cities (38 time zones) around the globe.
Simple swapping of World Time with your Home Time.
◆Stopwatch................................................................................................................Page E-8
The stopwatch measures elapsed time up to 24 hours in one-second increments.
E-1
ENGLISH
Congratulations upon your selection of this CASIO watch.
To ensure that this watch provides you with the
years of service for which it is designed, carefully
read and follow the instructions in this manual,
especially the information under “Operating
Precautions” and “User Maintenance”.
Be sure to keep all user documentation handy
for future reference.
xKeep the watch’s face exposed to light as
much as possible (page E-5).
Important!
xFor details about how to adjust the current
time zone, time, and day settings, see
“Timekeeping (Current Time and Day
Adjustment)” (page E-7).
Note that CASIO COMPUTER CO., LTD. assumes no responsibility for any damage or loss suffered
by you or any third party arising through the use of your watch or its malfunction.
For details about how to use this watch and for
troubleshooting information, go to the website
below.
https://world.casio.com/manual/wat/
MA1902-EA © 2019 CASIO COMPUTER CO., LTD.

User’s Guide 5603 (OC)
E-15
World Time City (Time Zone) Setting
Shows current World City time.
1. In the World Time Mode, pull the crown out to the first click.
xRotate the crown to move the second hand to the city or time zone whose date and time you want
to select.
City setting (–)
City setting (+)
30
E-14
City (Time Zone) Setting
Important!
xIn order to prevent loss of water resistance and damage due to impact, make sure that the crown is
fully pushed in to its normal position after operating it.
xOperation details: Operation Guide available at the CASIO website.
Home City (Time Zone) Setting
1. Pull the crown out to the second click.
xRotate the crown to move the second hand to the city or time zone you want to select.
30
City setting (–)
City setting (+)
E-13
Time Calibration Signal Manual Receive
1. Hold down Afor at least 0.5 seconds until the second hand moves
to R (RC). If the second hand is a position other than R (RC), keep B
depressed until it moves to R (RC).
xThis operation cannot be performed while the watch is paired with a
phone (page E-9).
2. Place the watch near a window.
xThe time setting will be adjusted automatically when a signal receive
operation is successful.
xCalibration signal reception normally takes anywhere from about two
to 10 minutes. It can take as long as 20 minutes.
xBest reception is in the middle of the night.
30
Second hand
E-12
Time Calibration Signal Auto Receive
● Leave the watch in a location that is appropriate for time calibration signal reception between
the hours of midnight and 5:00 a.m. See “Appropriate Signal Reception Location (Time
Calibration Signal)” (page E-11).
xThe second hand will point to R (RC) while time calibration signal reception is in progress.
xReception normally takes anywhere from about two to ten minutes, but it can take as long as
20minutes.
xWhen the receive operation is successful, the time and day settings will be adjusted automatically.
xYou can disable auto receive if you want. See “Using the Watch in a Medical Facility or Aircraft”
(page E-10).
E-11
Timekeeping (Based on a Time Calibration Signal)
Appropriate Signal Reception Location (Time Calibration Signal)
xKeep the watch away from metal and position it so its 12 o’clock side is
facing a window. Avoid moving the watch as much as possible and do
not perform any watch operations while a signal receive operation is in
progress.
● You may experience time calibration signal reception problems in
the areas described below.
-Among or near buildings
-While riding in a vehicle
-Near household appliances, office machines, mobile phones, etc.
-On a construction site, in an airport, or any other location where radio
wave interference occurs
-Near high-voltage lines
-In mountainous areas or behind a mountain
xAlways check the time setting on the day there should be a switch
between standard time and summer time (DST). If the setting is not
correct (due to signal reception failure), turn DST on or off manually as
required.
12 o’clock
E-10
Using the Watch in a Medical Facility or Aircraft
xDisable auto time adjustment whenever you are in a medical facility, and aircraft, in any other area
where radio wave reception and connection with a phone are prohibited or restricted.
xDisabling auto time adjustment disables time calibration signal auto receive and auto connection with
a phone.
xPress Bonce and then pull out the crown to the first click. The second hand will move to Y (YES)
(auto receive enabled) or N (NO) (auto receive disabled). To disable auto time adjustment, rotate the
crown to move the second hand to N (NO). To enable auto time adjustment, rotate the crown to
move the second hand to Y (YES). After the setting is the way you want, push the crown back in to its
normal position.
30
E-9
*1 The A-side of the dial indicates an a.m. time, while the P-side indicates a p.m. time.
*2 Indicates elapsed seconds during a stopwatch operation, and current time seconds while the
stopwatch is reset to zero.
*3 Points to ST while a stopwatch operation is in progress. Points to the current day of the week while
the stopwatch is reset to all zeros.
World Time Mode Button Operations
xTo check the current Home City (time zone) setting, press Aonce.
xTo swap your Home Time with the World Time, hold down Afor at least threeseconds.
xTo view the result of last time calibration by time signal reception or Mobile Link, press Bonce.
xIf the watch is not paired with a phone, you can perform the operations below.
-To adjust time with a time signal, hold down Bfor at least 0.5seconds.
-To pair with a phone, hold down Bfor at least 2.5 seconds.
xIf the watch is paired with a phone, you can perform the operations below.
-To adjust time using Mobile Link, hold down Bfor at least 0.5seconds.
-To connect with the phone, hold down Bfor at least 2.5seconds.
-To find the phone, hold down Bfor at least five seconds.
xFor details, refer to the Operation Guide available at the CASIO website.
https://world.casio.com/manual/wat/
E-8
Mode Reference Guide
xTo navigate between modes, press Awhile the crown is pulled out (to either the first or second
click). After selecting the mode you want, push the crown back in to its normal position. You can also
navigate between modes using Mobile Link.
World Time Mode Stopwatch Mode
30
World time
hour hand
World time
minute hand
Second hand
B
A
Hour hand 24-hour hand
Minute hand
Crown
Day of the week hand
Day
Indicator
World time
24-hour
hand *1
30
xStart
xStop
Seconds *2
xReset
xAfter reset, B
has the same
functions that it
has in the World
Time Mode.
Points to
ST *3
Hours
Minutes
Hours
(0 to 24)

User’s Guide 5603 (OC)
E-18
Hand position correction
Data Communication Specifications
Bluetooth®
Frequency Band: 2400MHz-2480MHz
Maximum Transmission: 0 dBm (1 mW)
Communication range: 2 meters max. (depends on environment)
Stopwatch:
Measuring unit: 1 second
Measuring capacity: 23 hours 59 minutes, 59 seconds (24 hours)
Measuring mode: Elapsed time
Other: Power Saving; Battery power indicator; Low battery alert; Auto Correction of Hand Home
Positions
Power Supply: Solar panel and one rechargeable battery
Approximately 5 months
Not exposed to light under the conditions below.
xAuto time adjustment: 4 times/day
xPower saving: 6 hours/day
Specifications are subject to change without notice.
E-17
Specifications
Accuracy at normal temperature: ±15 seconds a month (When receive of a calibration signal or
communication with a phone for time adjustment is not possible.)
Timekeeping : Hour, minutes, seconds, day, day of the week
Calendar system: Full Auto-calendar pre-programmed from the year 2000 to 2099
Other: Home City (Time Zone) and World Time City (Time Zone) can be assigned one of 38 time zones
(27 cities)* and Coordinated Universal Time; Daylight Saving Time (summer time)/Standard
Time auto switching
* Time zone data may be changed when the watch communicates with a phone.
Signal receive function: Auto receive, manual receive
Auto transmitter selection (for JJY, MSF/DCF77)
Receivable call signs: JJY (40 kHz/60 kHz), BPC (68.5 kHz), WWVB (60 kHz), MSF (60 kHz),
DCF77 (77.5 kHz)
Manual and auto standard time/summer time switching
Mobile Link Functions:
Auto Time Adjustment
Time setting automatically adjusted during a fixed time period.
One-touch Time Correction
Manual connection and time adjustment
Phone Finder
Watch operation sounds a tone on the connected phone.
Home City/World Time City swapping
Auto summer time switching
Automatic switching between standard time and summer time.
E-16
Configuring Time and Date Settings Manually
● Pull out the crown to the second click, hold down Bfor at least three seconds, and then
perform the operations below to adjust the time and date settings.
30
30
B
(Example: Setting to June 30, 2019)
B
Current time and date setting (+)
Current time and date setting (–)
(Month)(Day) (Year 1’s digit)
BB B
(Hour, minute)
(Year 10’s digit)
00
60
90 30
20
10
80 40
70 50
0
6
93
2
1
84
75
12
6
93
2
1
84
75
10
11
(At least 3 seconds)
xOperation details: Operation Guide available at the CASIO website.
https://world.casio.com/manual/wat/
L-3
City Code City UTC Offset/GMT
Differential
Radio wave to
be received
Summer Time Period
Summer Time Start Summer Time End
– – +8.75 –
None NoneTYO TOKYO* +9 JJY
– – +9.5
–
SYD SYDNEY +10 02:00, first Sunday in
October
03:00, first Sunday
in April
– – +10.5 None None
NOU NOUMEA +11
WLG WELLINGTON +12 02:00, last Sunday in
September
03:00, first Sunday
in April
– – +12.75
None None
TBU NUKUALOFA +13
CXI KIRITIMATI +14
BAR BAKER ISLAND –12
PPG PAGO PAGO –11
HNL HONOLULU –10
– – –9.5
ANC ANCHORAGE –9
02:00, second
Sunday in March
02:00, first Sunday in
November
LAX LOS ANGELES* –8
WWVBDEN DENVER* –7
CHI CHICAGO* –6
L-2
City (Time Zone) List
City Code City UTC Offset/GMT
Differential
Radio wave to
be received
Summer Time Period
Summer Time Start Summer Time End
UTC 0 None None
LON LONDON* 0
MSF/DCF77
01:00, last Sunday
in March
02:00, last Sunday in
October
PAR PARIS* +1 02:00, last Sunday
in March
03:00, last Sunday in
October
ATH ATHENS* +2 03:00, last Sunday
in March
04:00, last Sunday in
October
JED JEDDAH +3
–None None
– – +3.5
DXB DUBAI +4
– – +4.5
–– +5
DEL DELHI +5.5
– – +5.75
DAC DHAKA +6
– – +6.5
BKK BANGKOK +7
HKG HONG KONG* +8 BPC
L-1
City (Time Zone) List
L-4
City Code City UTC Offset/GMT
Differential
Radio wave to
be received
Summer Time Period
Summer Time Start Summer Time End
NYC NEW YORK* –5 WWVB 02:00, second
Sunday in March
02:00, first Sunday in
November
YHZ HALIFAX* –4
– – –3.5
–
None None
RIO RIO DE JANEIRO –3 0:00, first Sunday in
November
0:00, third Sunday
in February or 0:00,
fourth Sunday in
February
FEN F. DE NORONHA –2 None None
RAI PRAIA –1
* Cities where auto receive is normally supported.
xBased on data as of July 2018.
xFor details about city (time zone), and summer time settings, refer to the Operation Guide available at
the CASIO website.
https://world.casio.com/manual/wat/
