Castle Care-Tech Euro-MERiDIAN User manual

Page A1
You’ve Made the Right
Choice
Contents
Introduction A1-4
Using Euro-MERiDIAN with Code or Tag B1-5
Intelligent Setting B6-7
When Problems Arise C1-3
Setting Individual Area D1-3
Chime Facility E1
Omitting Zones E2-3
Keypad Personal Attack E4
Manager Menu F1-2
Omitting 24 hr Zones F3
Changing Date & Time F4
Change/Add Codes or Tags F5-10
Review History Log F11-12
SMS Phonebook F13
Walk Testing Detectors F14
Testing your Sounder F15
SMS Messaging System F16-17
Dial Out Menu F18
Allow Engineer Menu F19
Block Remote Set F20
Perform Anti-Code Reset F21
Service & Codeholder Records G1-2
Note the specification of Euro-MERiDIAN may vary
between models, and some facilities in the manual
may not be available. Check with your installer for full
details. This equipment may be used in systems
installed to a lower grade, which will be agreed with
your installation company.
© Castle Care-Tech 2005 (INSTRUCT-94) Issue 1

Page A2
You’ve Made the Right
Choice
Using your Euro-MERiDIAN Alarm
System just couldn’t be easier!
This is the Keypad from where
you control your Alarm System.
Note:
For your security, the keypad becomes
disabled for 90 seconds after 24 incorrect key-
presses, or after 6 attempts to present invalid
tags. It will subsequently be disabled again
after 7 further incorrect key-presses or after
another invalid tag is presented. Once a
correct code or tag has been registered, the
keypad is returned to normal operation.

Page A3
The MERiDIAN Keypad
The display gives you any
important messages. It will alert
you if you need to call your alarm
installation engineer.
The 10 digit numeric keypad is
where you use your PIN code.
The A B C D keys help simplify use,
and will illuminate to highlight
your choice of security cover, or
flash if there is a problem.
This is where you present your
Tag .
MAINS
FAIL
A
lert
A
larm
Tamper
Fault
Unset
MERiDIAN
TIME
:

Page A4
Warning Indications
A
lert
A
larm
Tamper
Fault
Unset
A
lert
A
larm
Tamper
Fault
Unset
A
lert
A
larm
Tamper
Fault
Unset
A
lert
A
larm
Tamper
Fault
Unset
A
lert
A
larm
Tamper
Fault
Unset
All setting points (Keypads or Tag
Readers) have lamps to clearly
indicate what is happening.
The ‘Alert’ lamp will flash if there is
information available to you. Enter
your code to see the information.
After a code has been entered, one of
the following lamps will light: Alarm,
tamper or fault. The relevant detail of
the problem will be shown on the
display. To clear the display, press the
‘Yes’ key (the display will clear
automatically after 3 minutes.)
The ‘Alarm’ lamp will flash after code
entry if an alarm occurs.
The ‘Tamper’ lamp will flash after
code entry if the wiring or
equipment is tampered with.
The ‘Fault’ lamp will light after code
entry to indicate if a technical fault
occurs.
The ‘Unset’ lamp will light for 5
seconds if the panel is completely
Unset (steady) or if some areas remain
Set (flashing). It will also light during
the setting procedure, going off once
set.

Page A5
Using Tags
Euro-MERiDIAN’s High Security
Proximity Tag (or Card) will set or
unset your Alarm system with the
minimum of fuss or complexity.
The Tag contains NO batteries and
is completely maintenance free.
Just touch the Tag to the logo to
use.
The Keypad will BEEP to
acknowledge the TAG.

Using the
Keypad with
your PIN
Code or

Page B1
Security Checks
Before you set your system:
You must ensure all doors and
windows are securely closed and
any pets or people are excluded
from areas protected by
movement sensors.
Close Windows
Close Doors
Exclude Pets & People

Page B2
Leaving the Building
If you are leaving the building, go
to Keypad and key in your PIN
code, or present your Tag.
Exit tone Starts
The appropriate area (ABCD) keys
will illuminate.
(If flexi-set is enabled you will be able to
choose which areas you set, see page D2)
Leave by agreed Exit Route
Close and Lock the Final Exit
Door
Finally, press the ‘Push to Set’
button (if fitted) that is mounted
externally by the final exit door.
Exit tone will cease
Euro-MERiDIAN is now SET
MERiDIAN
TIME
:
SETTING[009]
OFFICE
Exit Timer
If your exit is timed,
you will see the above
screen.
If you use a Push-to-Set
button, or final-door-
set, you will see the
screen below.
Leave via
desig route

Page B3
Faults when you Switch On
A
lert
A
larm
Tamper
Fault
Unset
If when you key in your PIN code
(or present your Tag) a warning
tone sounds and the fault lamp
comes on. The keypad display
will show the nature of the
problem.
An appropriate
A B C D key will
flash to indicate within which
area the fault exists.
The tone will cease after about
10 seconds.
Press the NO key
The system will remain unset, so
you can resolve the problem.
For example, you may have left a
door open, if so, close the door.
Now commence the setting
procedure again.
UNABLE TO SET
BACK
DOOR

Page B4
Faults when Leaving the
Building
If when you have closed the final
exit door (and pushed the ‘Push
to Set’ button if fitted ), the exit
tone continues to sound an
interrupted tone…
“beep – beep – beep – “
You have probably left a
protected door on the exit route
open.
Return to the keypad and note
the message on the display.
Stop the setting procedure with
your PIN code, or Tag.
Close the open door
Now commence the setting
procedure again (see B2).
EXIT VIA
HALLWAY

Page B5
Entering the Building
A
lert
A
larm
Tamper
Fault
Unset
To enter the building you must
use the agreed entry route and
go straight to the keypad.
Entry tone will be sounding
“beep – beep – beep –“
Key in your PIN code, or present
your Tag.
Entry tone will cease
To indicate that the system has
unset, the unset lamp will
illuminate for five seconds.
Euro-MERiDIAN is now UNSET
ENTRY [020]
TIME
ENTRY [010]
TIME
**

Page B6
Part-Setting the System
Intelligent Set (if programmed)
If you wish to set Euro -MERiDIAN
and stay in the building (eg set
the alarm at night), the Euro-
MERiDIAN’s intelligent operating
system will realise which level of
security you require and will set
only part of the system.
You will NOT need to press a
Push-to-Set button if you set
only part of a system.
If intelligent set is not installed
on your system, you may part set
the system as described on
Pages D1-D2.

Page B7
Staying in the Building
Intelligent Set
To Part Set Euro -MERiDIAN go to
the keypad and enter your PIN
code or present your Tag.
The appropriate A B C D keys will
illuminate
Exit tone will start
Leave the protected area and
retire to the un-protected area
(eg upstairs).
After a preset time the exit tone
will cease.
Euro-MERiDIAN is now Part Set

When
Problems
Arise, Just
Key in your
PIN Code or

Page C1
Silencing Alarms
If an Alarm tone sounds, the
Alert lamp will flash:
Just key in your PIN code or
Present your Tag.
The Alarm will stop sounding
The display will indicate the
problem.
Press the ‘YES’ Key
Euro-MERiDIAN will advise you on
any action that is needed. If the
‘Alert’ LED indication remains lit,
there is additional information
available. Enter your PIN or
present your Tag to view.
Alarm Silence
LOW VOLTS
Alarm Silence
LOW VOLTS

Page C2
Engineer Reset
When an alarm has been
cancelled and the Police have
been notified by the Alarm
Receiving Centre, you will see
the following screen when you
try to use the system:
It is usually necessary for an
engineer from your installation
company to check the
installation and reset the system
for further use.
But if you have caused the
alarm in error your Alarm
Receiving Centre or Alarm
Installation Company may permit
you to reset the system without
an engineer present.
You will be required to quote a
5-digit code by telephone (advise
them that the system is a Castle
Euro-MERiDIAN). You will then be
given a special code which will
reset the system for that one
occasion only.
This 5-digit code is displayed in
the ‘user menu’ – see page F21.
Active Faults
Restore Reqd
Engineer Reset
Required 21055

Page C3
Automatic Inhibit
Euro-MERiDIAN is designed to
automatically disable certain
functionality. The factory default
settings are as shown below:
Intruder
Alarm Signal
After 3* unconfirmed
alarms in the same area or 1
confirmed alarm.
Tamper
Alarm Signal
After 3* unconfirmed
alarms in the same area or 1
confirmed alarm.
Keypad After 23 keypresses without
entering a valid code, keys
are disabled for 90 seconds.
After reinstatement, this will
be repeated after each 7
keypresses until a valid code
is entered.
Tag Reader After 6 presentations of an
invalid tag, the reader will be
disabled for 90 seconds. After
reinstatement, this will be
repeated for each invalid tag
until a valid tag is used.
* This figure is programmable by the
installing company

Setting
Individual
Areas

Page D1
The A B C D Keys
Sometimes your security needs
will be a little more complex and
you will need to use the A B C D
keys.
Your Installer can also give
names to all four of the
A B C D
areas, so that you can easily
identify them.
For example:
A =Reception or A ll Set
B =Warehouse B edtime Set
C =Office C at in Lounge
D =Storeroom D og in Study
In addition, names can be given to
the whole system
‘ALL AREAS’
These will be displayed when
setting the system.
MERiDIAN
TIME
:
SETTING
RECEPTION
SETTING
ALL AREAS

Page D2
Codes with Flexi-Set
For greater flexibility in setting
parts of your system, you can
make a choice at the keypad.
Key in your PIN code or present
your Tag.
If you do not wish to set all the
areas assigned to your code/Tag,
simply select the areas you wish to
Set by pressing the relevant
A B C D key(s).
To change your mind, press the
relevant A B C D key(s) again.
Press the Yes key to accept
Setting areas will now be
displayed, with the corresponding
area keys being lit.
Euro -MERiDIAN will now Set the
selected areas.
SET AREAS
[ABCD]
SETTING
ALL AREAS
