CASTLE Meridian User manual

CARE TECH
CARE TECH
CARE TECH
CASTLE
CARE TECH
Welcome to
Welcome to
Security and
Peace of Mind
Intelligent Security & Fire Ltd

CARE TECH
CARE TECH
CARE TECH
CASTLE
CARE TECH
Contents
Introduction A1-3
Using Meridian with your PIN Code B1-7
Using Meridian with your Tag C1-8
When Pro lems Arise D1-2
Chime Facility E4
Continual Protection E6
Omitting Zones E8
Masked Detectors E9
Keypad Personal Attack E10
Changing or Adding Codes or Tags F4
Changing Date and Time F5
Reviewing Logs F6
Walk Testing Detectors F7
Testing your Sounder F8
Intelligent Security & Fire Ltd

✔
and/or
optional
optional
✔
CARE TECH
CARE TECH
CARE TECH
CASTLE
CARE TECH
THIS INFORMATION IS FOR
USE BY THE INSTALLER ONLY
To simplify operation for the user
and to avoid unnecessary
confusion, the Meridian User
Manual can e made up to
include only relevant information.
Select the modules you require
and insert into the inder supplied
Sections Content
Introduction A1-3
Using PIN Codes B1-7
(Select page B6 'Intelligent' or 'Without Intelligent Set)
Using Tags C1-8
(Select page C7 'Intelligent' or 'Without Intelligent Set)
When Pro lems Arise D1-2
Advanced Functions E1-10
Manager Menu F1-8
Intelligent Security & Fire Ltd

Using your Meridian Alarm System
just couldn't e easier!
This is the Keypad from where you
control your Alarm System.
A1
A1
You've Made the Right Choice
ag
Intelligent Security & Fire Ltd

The display gives you any
important messages.
The 12 digit numeric keypad is
where you use your PIN code.
The A B C D keys help
simplify use.
The 4 display lights show the
status of the protected areas
controlled y your Alarm.
This is where you use your Tag.
MAINS FAIL
MAINS FAIL
A1
A2
The Meridian Keypad
ag
Intelligent Security & Fire Ltd

Be ore you switch Meridian on
you must ensure all doors and
windows are securely closed and
any pets are excluded from areas
protected y movement sensors.
Close
Doors
Close
Windows
Exclude
Pets
A1
A3
Security Checks
Intelligent Security & Fire Ltd

Using the
Keypad
With Your
4 Digit
PIN Code
A1
B1
Intelligent Security & Fire Ltd

SETTING
ALL
MERIDIAN
TIME:
A1
B2
eaving the building
If you are leaving the uilding,
go to the Keypad and
key in your 4 digit PIN code.
Exit tone starts.
Leave y the agreed exit route.
Intelligent Security & Fire Ltd

Close and lock the inal exit door.
Finally, press the 'Push to Set'
utton (if fitted) that is mounted
externally y the final exit door.
Exit tone will cease.
Meridian is now set.
(If the exit tone continues with an
interrupted tone, you must re-enter
the uilding, note the message on
the display, and switch the alarm
off with your PIN Code.)
A1
B3
eaving the building
Intelligent Security & Fire Ltd

To enter the uilding you must
use the agreed entry route and
go straight to the Keypad.
Entry tone will e sounding.
"Beep - Beep - Beep - - - "
Key in your 4 digit PIN code.
Entry tone will cease.
Meridian is now UNSET.
MERIDIAN
TIME:
A1
B4
Entering the building
Intelligent Security & Fire Ltd

If you wish to set Meridian
and stay in the uilding.
(eg set the alarm at night)
Simply follow the same
procedure.
Meridian's intelligent operating
system will realise what you
require and set only part of the
system.
You will NOT need to press a
'Push-to-Set' utton when you set
only part o the system.
A1
B5
Part - Setting Meridian
Intelligent Security & Fire Ltd

MERIDIAN
TIME:
A1
B6
Staying in the building
Intelligent Setting
SETTING B
BEDTIME
To part set Meridian go to the
Keypad and key in your
4 digit PIN code.
Exit tone will start.
Leave the protected area and
retire to the unprotected area
(eg upstairs).
After a pre-set time the exit
tone will cease.
Meridian is now part set.
Intelligent Security & Fire Ltd

To part set Meridian go to the
Keypad and key in your
4 digit PIN code and press 'B'.
Exit tone will start.
Leave the protected area and
retire to the unprotected area
(eg upstairs).
After a pre-set time the exit tone
will cease.
Meridian is now part set.
MERIDIAN
TIME:
A1
B6
Without
Intelligent Setting
SETTING B
BEDTIME
Staying in the building
Intelligent Security & Fire Ltd

To unset Meridian
Go to the Keypad
Entry tone will e sounding
"Beep - Beep - Beep- - -"
Key in your 4 digit PIN code.
Entry tone will cease.
Meridian is now unset.
A1
B7
Unsetting Meridian
MERIDIAN
TIME:
Intelligent Security & Fire Ltd

ag
A1
C1
Using a
Proximity Tag
Intelligent Security & Fire Ltd

Meridian's High Security
Proximity Tag can e used to set
or unset your Alarm System with
the minimum of fuss or complexity.
The Tag contains NO atteries
and is completely maintenance
free.
Just touch the Tag to the logo
to use.
A1
C2
ag
Using Tag
Intelligent Security & Fire Ltd

SETTING
ALL
A1
C3
eaving the building
To set Meridian, simply touch
the Meridian Keypad as
shown with the Tag.
The Keypad will "Beep" to
acknowledge the Tag.
Exit tone starts.
Leave y the agreed exit route.
Intelligent Security & Fire Ltd

Close and lock the inal exit
door
Finally, press the 'Push to Set'
utton (if fitted) that is mounted
externally y the final exit door.
Exit tone will cease.
Meridian is now set.
C4
eaving the building
Intelligent Security & Fire Ltd

To enter the uilding you MUST
use the agreed entry route and
go straight to the Keypad.
Entry tone will e sounding
"Beep - Beep - Beep - - -".
Touch your Tag to the Keypad.
Entry tone will stop.
Meridian is now UNSET.
MERIDIAN
TIME:
A1
C5
Entering the building
Intelligent Security & Fire Ltd

If you wish to set Meridian
and stay in the uilding
(eg set the alarm at night)
Meridian's intelligent operating
system will realise what you
require and set only part of the
system.
You will NOT need to press a
'Push-to-Set' utton if you set
only part of the system.
A1
C6
Part - Setting Meridian
Intelligent Security & Fire Ltd
