Cateye STRADA CC-RD100N User manual

Click the button and follow the in-
structions.
CATEYE STRADA
CC-RD100N
Quick Start
START

Thank you for purchasing our cyclocomputer CATEYE STRADA.
This Quick Start Manual explains how to set up the computer and how to install the unit on
your bicycle.
Please set up the unit according to the specified procedure, then it will be ready for use as a
cyclocomputer.
Before use, read the instruction manual that comes with the product thoroughly
to the end to understand the functions of this unit, and to use it safely in a
correct manner.
Next

This PDF contains a movie file.
When you click on the movie screen, a message regarding security appears. Click the
“Trust in the text” or “Play” button to close the message.
Click the screen again to play the movie.
Next

CATEYE STRADA
Quick Start Manual Contents
Click the item you wish to view.
Return to Cover
Setting up the computer
How to install the speed sensor
How to install the bracket (movie)

Operation of buttons
Set up the computer by operating the buttons as follows.
Check the button position before you start setting up.
MODE
MENU
Back
Press the MENU button and the MODE
button on the back of the computer.
Next

CATEYE STRADA
Quick Start Manual Setting up the computer
Setting the speed unit
Entering the tire
circumference
Setting the clock display
Measuring screen
(Setup completed)
Setting the hour
Setting the minute
Clear all data (initialization) Clear all data (initialization)
Press the AC button on the back of the computer.
After full lighting of the screen, the computer switch-
es to the speed unit setting screen to start setup.
ACAC
Full lighting Setting the speed unit
Return to Contents
Next
Return

CATEYE STRADA
Quick Start Manual Setting up the computer
Entering the tire
circumference
Setting the clock display
Measuring screen
(Setup completed)
Setting the hour
Setting the minute
Setting the speed unit
Clear all data (initialization)
Setting the speed unit
Setting the speed unit
When the MODE button is pressed, either “km/h” or “mph”
is selected for the speed unit display. Select the display of
your choice.
After selecting, press the MENU button to proceed to the
next step “Entering the tire circumference”.
MENU
To the next step
MODE
km/h ↔mph
Return to Contents
Next
Return

CATEYE STRADA
Quick Start Manual Setting up the computer
Setting the clock display
Measuring screen
(Setup completed)
Setting the hour
Setting the minute
Entering the tire
circumference
Setting the speed unit
Clear all data (initialization) Entering the tire circumference
Enter the tire circumference (mm) of your bicycle with
4 digits using the tire circumference reference table.
Pressing the MODE button increases the value flashing, and
pressingandholdingtheMODEbuttonmovestothenextdigit.
After entering, press the MENU button to proceed to the
next step “Setting the clock display.
Entering the tire
circumference Move digitIncrease the value
MENU
To the next step
MODE
MODE
(Press and hold)
Return to Contents
Next
Return
Tire circum-
ference refer-
ence table

CATEYE STRADA
Quick Start Manual Setting up the computer
Measuring screen
(Setup completed)
Setting the hour
Setting the minute
Setting the clock display
Entering the tire
circumference
Setting the speed unit
Clear all data (initialization) Setting the clock display
When you press and hold the MODE button, “24h” flashes.
When the MODE button is pressed, either “12h” or “24h”
is selected for the clock display. Select the display of your
choice.
After selecting, press and hold the MODE button to pro-
ceed to the next step “Setting the hour”.
Clock display
To the next step
MODE
24h ↔12h
MODE
(Press and hold)
Return to Contents
Next
Return

CATEYE STRADA
Quick Start Manual Setting up the computer
Measuring screen
(Setup completed)
Setting the minute
Setting the hour
Setting the clock display
Entering the tire
circumference
Setting the speed unit
Clear all data (initialization) Setting the hour
Pressing the MODE button increases the value flashing
(“Hour” of the clock). Enter any value.
After entering, press and hold the MODE button to pro-
ceed to the next step “Setting the minute”.
Hour
To the next step
MODE
Increase the value
MODE
(Press and hold)
Return to Contents
Next
Return

CATEYE STRADA
Quick Start Manual Setting up the computer
Measuring screen
(Setup completed)
Setting the minute
Setting the hour
Setting the clock display
Entering the tire
circumference
Setting the speed unit
Clear all data (initialization) Setting the minute
Pressing the MODE button increases the value flashing
(“Minute” of the clock). Enter any value (Pressing and
holding MODE rapidly increases the value).
After entering, press the MENU button to switch to the
measuring screen.
Minute
MENU
Setup is completed
To the measuring screen
MODE
Increase the value
Return to Contents
Next
Return

CATEYE STRADA
Quick Start Manual Setting up the computer
Measuring screen
(Setup completed)
Setting the minute
Setting the hour
Setting the clock display
Entering the tire
circumference
Setting the speed unit
Clear all data (initialization) Now, setup of the computer is completed.
If the bracket and speed sensor are not installed on your
bicycle, return to Contents, click “How to install the brack-
et” and “How to install the speed sensor”, and then install
them according to the instructions.
Measuring screen
Return to Contents
Next
Return
Return to Contents

CATEYE STRADA
Quick Start Manual How to install the bracket
The Bracket being used in this movie is for wireless products and• there is no wire attached.
When you install the bracket band to your bicycle, tighten it so the wire will not be pinched by the stem•
or handlebar.
Return to Contents

Prepare the following parts from the packaged items.
Speed sensor
Magnet
Sensor rubber pad (x2) Sensor rubber pad (x3)
Hook
Nylon ties (x5)
Next

CATEYE STRADA
Quick Start Manual How to install the speed sensor
Fixing the wire
Adjust the clearance between
the speed sensor and magnet
Adjust the positions of the
speed sensor and magnet
Install the magnet
Winding the wire
(Installation is completed)
Install the speed sensor Install the speed sensor
Select the suitable size for the front fork diameter of
your bicycle from two different sensor rubber bands.
1 Attach the sensor hook to the sensor rubber band,
and install it to the right front fork of your bicycle.
2 Pass the speed sensor through the sensor rubber band
installed. Install the sensor rubber band so that it fits
in the hook on the top and bottom of the sensor.
You may use nylon ties instead of the sensor rub-*
ber band.
Hook
Speed sensor
Right front fork
Rubber band
Return to Contents
Next
Return

CATEYE STRADA
Quick Start Manual How to install the speed sensor
Fixing the wire
Adjust the clearance between
the speed sensor and magnet
Adjust the positions of the
speed sensor and magnet
Winding the wire
(Installation is completed)
Install the magnet
Install the speed sensor Install the magnet
Temporarily secure the magnet to the right side
spoke of the front wheel spoke.
Tighten the magnet to such an extent that it can be
moved.
Right side spoke
Magnet
To the SENSOR ZONE
Return to Contents
Next
Return

CATEYE STRADA
Quick Start Manual How to install the speed sensor
Fixing the wire
Adjust the clearance between
the speed sensor and magnet
Winding the wire
(Installation is completed)
Adjust the positions of the
speed sensor and magnet
Install the magnet
Install the speed sensor Adjust the positions of the speed sensor
and magnet
Adjust the position so that the magnet passes
through the SENSOR LINE of the speed sensor.
After adjusting, tighten firmly the magnet.
Magnet
Speed sensor
(inside the front fork)
SENSOR LINE
Return to Contents
Next
Return

CATEYE STRADA
Quick Start Manual How to install the speed sensor
Fixing the wire
Winding the wire
(Installation is completed)
Adjust the clearance between
the speed sensor and magnet
Adjust the positions of the
speed sensor and magnet
Install the magnet
Install the speed sensor Adjust the clearance between the speed
sensor and magnet
Adjust the clearance between the speed sensor and
magnet so that it is within 5 mm.
When the clearance with the magnet is more than
5 mm, install the speed sensor with 1 to 3 sensor
rubber pads in layers.
5 mm 5 mm
or
Magnet
Speed sensor
Sensor rubber pad
(1 to 3 sheets)
Return to Contents
Next
Return

CATEYE STRADA
Quick Start Manual How to install the speed sensor
Winding the wire
(Installation is completed)
Fixing the wire
Adjust the clearance between
the speed sensor and magnet
Adjust the positions of the
speed sensor and magnet
Install the magnet
Install the speed sensor Fixing the wire
Fix the wire to the front fork with nylon ties. Cut off
any excess nylon tie using a nipper.
Nylon ties
Pull securely
Return to Contents
Next
Return

CATEYE STRADA
Quick Start Manual How to install the speed sensor
Winding the wire
(Installation is completed)
Fixing the wire
Adjust the clearance between
the speed sensor and magnet
Adjust the positions of the
speed sensor and magnet
Install the magnet
Install the speed sensor Winding the wire
Wind the wire around the brake cable.
Caution: Adjust this section so that the wire is
not stretched when you turn the handle.
Now, speed sensor installation is completed.
See how to install the bracket, and then complete
the installation.
When the computer is not set up, return to Con-
tents, click “Setting up the computer”, and follow
the instructions.
