CDP 7000 User manual

CDP 7000
FAST SCREENING
ALCOHOL TESTER
OPERATION MANUAL
PLEASE READ THIS MANUAL CAREFULLY BEFORE
USING THE TESTER
Content
Catalogue
C.D.Products S.A.

1. INTRODUCTION…………………….………………………………………………..……1
2. ACCESORIES…………………………….………………………………………….…… 1
3. STRUCTURE………..………………………………………………………………..……2
3.1 APPEARANCE…………………………………………………………….….….2
3.2 DISPLAY……………………………………………………...……………….…..2
4. POWER ON/OFF BUTTON.…………………………….……….………………..………3
4.1. POWER ON ……..……………………………….………………………..……..3
4.2. POWER OFF……………………………………………………………..………3
4.2.1 Manual power off..……………………………………..………………...3
4.2.2 Power saving………………………………………..………….………..3
4.2.3 Low battery..…………………………………….……………..…………3
5. TESTING………………..…..…………………………………………………..….……….4
6. SETUP…………….………………………………………………………………….…….5
6.1. Calibration reminder.. …………………………………….……………..………6
6.2. Date setup……….. ……………………………………………...………………6
6.3. Measurement unit setup.....…………….………………………………………6
6.4. Blowing time……...………………………………………………………………6
6.5. Test result display time…..……. .……………….……………………..…….…7
7. TROUBLESHOOTING………….....………………………………..………………..……8
8.MAIN TECHINCAL INDEXES AND PARAMETERS…………… …………………..….8
9.MAINTENANCE……………..……………………………………………………………..9
C.D.Products S.A.

1
1. INTRODUCTION
The CDP 7000 breath tester is our latest development in portable breathalyzers for
Fast screening on the road or other situations. This device adopts as main component
the most novel and hi-tech fuel-cell sensor. You will be able to check, with great
precision and speed, the alcohol concentration level on a user’s breath. The CDP 7000
breath tester presents a compact keyboard and an intuitive and easy-to-use menu
that makes it precise and practical. The color LCD screen is very clear, allowing
correct day and night vision. It includes a high light alarm lamp and head lamp for the
user’s convenience. It is lightweight, and the blowing nozzle assures proper hygienic
conditions during testing.
This breath tester is ideal to carry out alcohol level tests at the start of the day or to
help prevent accidents and encourage safe driving conditions.
Main features:
Adopts advanced 16 bit low power consumption.
Fuel-cell sensor, high reliability and accuracy.
Color easy-read LCD indication.
Light indication function, matrix type warning lamp.
Simple keyboard operation.
Shows real time temperature and date.
Two alarm levels: acoustic and visual.
Low battery automatic power off function
Blowing time may be adjusted by user.
Measurement unit and blowing time adjustable by user.
Short warm-up time, fast and accurate response.
Designed so there is no contact with the user's mouth. The nozzle has been
designed to gather the air sample comfortably and correctly.
2. ACCESSORIES
Please, check that the box contains all components and accessories.
CDP 7000 Breath Tester
User manual
Inspection report
C.D.Products S.A.

2
3. STRUCTURE
3.1 Appearance
Fig. 1
3.2 Display
Fig. 2
1 Blowing
nozzle 4 Sling 7 Head lamp
2 Screen 5 USB Port (reserved) 8 Alarm lamp
3 Keyboard 6 Battery cover
C.D.Products S.A.

3
4. POWER ON/OFF BUTTON
4.1 Power On
Press the button during 1 second; the system will automatically begin the
self-check process. After emitting an alarm beep, the display will show the breath tester
model and version. The main menu will appear once the self-check concludes. (See
chart 2).
In the main menu, press the left button and the head lamp will light on. Press the left
button again , the head lamp will light off and the red alarm light will flash. Press the
left button again , the red light will light off and the green light indicator will flash.
Press the left button again and the lamp will turn off.
Important: The red and green lights will only flash when the main menu is in testing
mode. They can also be used as additional lights if their use is required.
4.2 Power off
4.2.1. Manual power off
To turn off the unit, press and hold the button for 3 seconds.
4.2.2. Power saving
This breath tester includes a power saving function. If the main menu remains on
but the unit is not used during 3 minutes or more, the breath tester will
automatically power off.
4.2.3 Low battery
The breath tester will automatically power off when the batteries die. Please
replace the batteries with new ones or recharge them (if they are rechargeable)
as soon as possible.
C.D.Products S.A.

4
The battery icons indicate: Table 1.
Full battery
Low battery
Battery partly consumed
Battery shortage, please change or
recharge the batteries.
5. TESTING
When the breathalyzer is turned on, the screen will show the main menu (see Fig. 2).
Take a deep breath and then blow into the tester through the blowing nozzle, smoothly
and evenly until the buzzer stops and you hear a “pop” sound. Then stop blowing.
After blowing, the screen will show “processing…” which means the tester is analyzing
the sample. The test result will appear on the screen once the analysis ends. This will
include the type of gas and concentration. Meanwhile, the lamp light will flash. The
results will appear in one of three different ways:
1) Normal: If the “normal” message appears above the concentration value, it means
that the test result is below the alarm level set before the test procedure. If the
result is “normal”, the green light will also flash.
2) Drink: If the “drinking” message appears above the concentration value, it means
that the test result is above the alarm level set before the test procedure. If this
happens, the breathalyzer will emit an acoustic alarm and the red light will flash.
3) Passive testing: If the person that should carry out the test does not want to
cooperate (the blowing air pressure is insufficient or blowing time is too short) it is
possible to carry out a passive test. Introduce clean air in the blowing tube to clean
any alcohol residuals before carrying out the test. When the screen shows the
message “Please blow”, allow the user to blow and the press the button.
The screen will show the result of the passive test after performing the analysis. If
the user cannot blow, allow clean air into the blowing tube for a few seconds to
eliminate any prior alcohol residuals, then place the blowing opening near the
C.D.Products S.A.

5
user’s nose and press the button. The screen will show the result of the test
once the analysis has concluded. Since a precise result requires actual exhaled air,
passive tests should be approximate and provisional conclusions. These tests
should not be considered definitive in a formal inspection.
Important: After carrying out a test, you may press any button to return to the test
menu, you can also program the “test result display time”. This parameter will
allow you to set how long the test results will be displayed on the screen before
automatically returning to the test menu to continue performing controls. If the
person that takes the test is appears very drunk, we recommend that you allow
clean air into the blowing tube in order to eliminate possible residuals from
previous alcohol tests, allowing more precise subsequent tests.
6. SETUP
In the main menu, press the right button to display the menu.
This submenu includes:
CALIBRATION DATE reminder
DATE setup
TIME setup
MEASUREMENT UNIT setup
ALARM setup
BLOWING TIME setup
RESULT TIME setup
Select any category by pressing the left button , then press the right button to go to
the next category.
C.D.Products S.A.

6
6.1. CALIBRATION DATE reminder
In this menu, you may see the days left until the next recommended calibration.
6.2. DATE-TIME setup
In the date-time setup menu, press the left button to choose the category. The
item selected will appear in blue. Then press the right button to change the value.
If you press the right button the values will change one by one. If you press and
hold the button, the values will change continuously. Press the button to exit the
date setup menu once you have finished. If the value has been changed, it will be
automatically saved when you exit the menu. The save interface will appear as a
reminder.
Important: The first row of numbers shows year-month-day from left to right.
The second row of numbers shows hour-minute from left to right.
6.3. MEASUREMENT UNIT setup
In the measurement unit setup menu, press the left button to choose the unit and
then press the right button to save the settings. Press the button to exit the
menu. The new measurement unit will be automatically saved when you exit this menu
if a change has been made. After changing the unit, the alcohol concentration alarm
levels will be automatically updated and the conversion will also be done automatically.
6.4. BLOWING TIME setup
You may change the blowing time. Press the left button to change this value, and
press the right button to save the change. Press to exit when you have
finished. The new blowing time will be automatically saved when you exit this menu if a
change has been made. If the value has been changed, it will be automatically saved
when you exit the menu. The save interface will appear as a reminder.
Suggestions:
1) Set the blowing time within a broad margin, so the residual air in the
blowing tube is eliminated completely and the test is more accurate.
C.D.Products S.A.

7
2) The distance between the user's mouth and the blowing opening
should be less than 3 cm during the test, so the air is not diluted and
the result will be more exact.
6.5 TEST RESULT DISPLAY TIME setup
The display time is how long the result will appear on the screen. To improve the
performance and efficiency of the breathalyzer, the result will be shown during a brief
period of time (which may be modified). The breathalyzer will then automatically return
to the test mode to continue with the tests. If this auto-return function is not required, you
may set the display time to “unlimited”. In this case, the result of the test will appear until
you press any button. You will then return to the test mode.
Press the left button to select how long you want the result displayed. Press the
right button to save the change. Press after setting the value to exit the
display time menu. If the value has been changed, it will be automatically saved when
you exit the menu. The save interface will appear as a reminder.
7. TROUBLESHOOTING
Table 2.
Fault Description
Possible Reason
Solutions
Unable to turn on the tester
Low battery
Change batteries
Battery polarity reversed
Refit the batteries
Inaccurate testing result
Expired sensor
Contact manufacturer to replace
the sensor
Blowing distance
inaccurate
Make sure tester’s mouth is close
to the blowing opening
Long time no calibration
Calibrate the tester
Wrong Display Time Wrong time setup
Reset the time
Battery not durable Battery capacity limited
Alkaline battery or rechargeable
Ni-Cd battery will work better
C.D.Products S.A.

8
Important: This breathalyzer includes four AA batteries of 1.5 V. You may also use 4 Ni-Cd
rechargeable batteries with a voltage of 1.2 V and normal capacity above 2000mA for
durability purposes. If you select Ni-Cd batteries, the battery type must be changed in the
breathalyzer program or the battery indication will be incorrect. To do this, power on the unit,
then press and the right button simultaneously during one second. You will see
the battery and voltage setup menu. Check the nominal voltage on the battery, then press
the right button to confirm the selection. You may now save the new setup. Press
to exit this menu.
8. MAIN TECHNICAL INDEXES AND PARAMETERS
Table 3.
Model
CDP 7000
Sensor type
Fuel-cell alcohol sensor
Measurement range 0～2.000mg/L（0～440mg/100ml）
Warm-up time
Warm-up not necessary
Response time <1s
Continuous working time
100-2000 times (depends on battery capacity）
Dimensions L×W×H: 284×68.5×74mm
Net weight
About 400g（with 4 batteries）
Recommended calibration periods:
6-12 months
9. CARE AND MAINTENANCE
Please read this manual carefully and follow all instructions before operation.
Avoid hitting or dropping the unit.
If necessary, use a humid cloth to clean the unit. Do not use water, solvents or
conventional cleaners which could damage the unit.
If the breathalyzer is used with very low batteries, the results could be erroneous.
Always use the batteries recommended by the manufacturer.
C.D.Products S.A.

9
The calibration of the tester should be done every 6 months to 1 year to ensure the
accuracy of the tester. Consult your distributor or the manufacturer.
For correct storage, always store the breathalyzer in a dry and well-ventilated place.
To assure reliable measurements, the person performing the test should preferably
abstain from drinking, eating or smoking for at least 15 minutes before blowing.
WARNINGS
1. Do not drive or operate machinery if you suspect or have reason to suspect your
behavior could be affected by an alcohol intake, even if the test indicates a level
of alcohol below 0,25 Mg/L in air.
2. If you drive or operate machinery after drinking alcohol, you do so at your own
risk. There are no express or implicit guarantees in relation to the use of the
device.
3. Liability is only limited to the cost of the unit. The warranty has a duration of 6
months from the unit’s date of purchase with regard to any manufacturing defects.
If you require technical support (warranty and operation questions), please
contact the CDP Customer Service Department at 34-902104060 or visit our
website: www.cdpsa.com where you will find further guidelines and instructions.
Other factors (breath, tobacco, quality of the air etc.) may affect the measurement, so
please use these values as a reference only.
C.D.Products S.A.

10
CONTACT DATA
C.D.Products S.A.
Polígono Industrial P-29.
28400 Collado Villalba –Madrid.
www.cdpsa.es
Customer service hotline: [phone]
Email: [e-mail]
Fax: [phone]
C.D.Products S.A.
