1] PRODUCT PRESENTATION
The A22K is ATRIUM’s powerful Web-Based high security module. The exibility of the A22K module allows it
to be set either as a 2-door controller or expander (2 in 1). The A22K includes an embedded web server that
combines performance and simplicity enabling you to manage Users/Cards, lock or unlock doors, view and print
system events and display controller information from any place in the world! Industry-unique and eortless
card enrollment mode minimizes system start up and simplies your life. A pre-assembled universal power
supply is included with every A22K making this unit an industry leader in eciency and simplicity.
 
(Wiegand or Auto-recognition High Security RS485 port)
 
 
 
 
 
 
 
 
 
 
 
 
 
 
 
 
 
 
 
 
 
 
 
 
 
 
 
 
 
ENCRYPTED
FULLY

4cdvigroup.com
A22K
High Security Access Control 2-Door Module
D1 D0
GND
12V
USB Backup Port
(Future use for disaster
recovery, user photos &
video clips)
New Microprocessor
•HTTPS enabled
• IPV6 ready
Increased Memory
Provides space for future
expansion and integration
CDVI Encryption
• RS-485 encrypted reader BUS using CDVI KRYPTO reader
• Supports 2 readers per port (Entry/Exit)
• OSDP-2 Compatible
AES 256 Encryption
Military grade Ethernet Port
AES 128 Encryption
(using Mifare DESFire EV2 card)
SSL/TLS
ENCRYPTION
A22K
ENCRYPTED 2-DOOR / 4-READER IP CONTROLLER
WHAT’S NEW
• CompatiblewithATRIUMA22Kcontroller
• FULLYsecureRS-485connection(4wires)
• Reads13.56MHzMifare®ClassicandDESFireEV1/EV2
• OSDP-2compatible
• NFCcompatible(mobilecredentialready)
• Upto10cm(4in)readrange
• Powerrequirements:12VDC
K1
KRYPTOHighSecurityCardReader
WARRANTY
YEAR
5

5
cdvigroup.com
A22K
High Security Access Control 2-Door Module
LAN or WAN RS485(4wires)IP(Ethernet)
A22K
ATRIUMController
K1
KRYPTOCardReader
TAG-EV2
MifareDESFireEV2
AES256
ENCRYPTION
AES256
ENCRYPTION
Say“NO”tocardcloningwithATRIUM’suniqueKRYPTOhighsecuritysolution.Eliminatecomplexandarduous
programmingusingtheATRIUMA22Kcontroller,CDVIMifareDesFireEV2credentialsandK1readers.
System-wideAESencryptionstopscardcloningandprovidesend-to-endsecurity.Whetheryouremoteinfrom
theinternetorconnectonyournetworkyoucanbesureKRYPTOhasyoucovered.
SSL/TLS
ENCRYPTION AES128
ENCRYPTION
Instant
High Security
Out of the Box

6cdvigroup.com
A22K
High Security Access Control 2-Door Module
2] NOTES AND RECOMMENDATIONS

This device complies with Part 15 of the FCC rules Class A. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and (2) this device must accept any interference received
including interference that may cause undesired operation. This class A digital apparatus meets all requirements
of the Canadian Interference Causing Equipment Regulations. The ATRIUM A22K is also compliant with
EN55022:1998, amendment 1:1995, Class A.

To comply with UL listings, the following requirements must be met:
• Use of UL listed readers
• Use of a UL recognized tamper switch on every housing cabinet for the A22K
• Use only UL listed cables
• Use only UL listed adaptors
Note: All circuits are power limited.

CDVI declared the following levels: Destructive Attack Level I, Line Security Level IV, Endurance Level IV,
Standby Power Level IV.
• Use only UL listed power supply
• Connect CDVI LED status indicator, part number 7020-0001-0000, to the DC Input gray terminals of
the A22K.
Backup battery provides operation of up to 12 hours but has been tested for 4 hours per Section 33 of
UL 294, fth edition.
The system’s location and wiring methods shall be in accordance with the National Electrical Code,
ANSI/NFPA 70.

For technical support in Canada or the U.S., call 1-866-610-0102, Monday to Friday from 8:00 a.m. to 8:00
p.m. EST. For technical support in your area, refer to the last page of this document or visit our website: www.
cdvigroup.com.

7
cdvigroup.com
A22K
High Security Access Control 2-Door Module
RECOMMENDED WIRING

 Wire Type  

RS485 Card Reader
(High Security Reader) 4 conductors, copper 26AWG (0.40mm) to 18AWG (1.02 mm) 1220m (4000ft.)
Wiegand card reader
and keypad
4 to 8 conductors, stranded, shielded (foil), drain
conductor. For example: Alpha 5196, 5198, 5386,
5388, Belden 9553
22AWG (0.64mm) to
18AWG (1.02mm) 150m (500ft.)
Zone input 2 conductors, copper 22AWG (0.64mm) 22AWG (0.64mm) 600m (2000ft.)
Door strike 2 conductors, solid copper 18AWG (1.02mm) 18AWG (1.02mm) 150m (500ft.)
Power Supply* 3 conductors, solid copper 18AWG (1.02mm) 14AWG (1.63mm)* 8m (25ft.)
Ethernet CAT 5/5e - 100m (300ft)
RS485 bus, Star or
Daisy Chain (no BIAS/
EOL required)
CAT 5/5e or 4 pairs 24AWG (0.51mm)
1220m (4000ft.)
4 conductors, copper 26AWG (0.40mm) to
18AWG (1.02 mm)
* The Minimum Size Equipment Conductors for the AC mains required are 14 AWG if made of Copper or 12
AWG if made of Aluminium or Copper-Clad Aluminium. Do not use any switch-controlled outlets to power the
system.

Doors 2 (expandable to 10 doors)
Cards / users 10,000 cards / users
Schedules 250 Schedules each supporting up to 100 time periods (dd, hh:mm)
Buered Events 25,000 events
Holidays 100 holidays
Access Levels 1000 access levels
Operating Temperature -20°C to +70°C (-4°F to +158°F)
Humidity 0% to 85% (non condensing)
System Autonomy Full Distributed Architecture (100% O-line Operation)
Firmware Online Upgradeable
PCB Dimensions 19.9cm (7.83”) x 12.38 cm (4.875”)
Cabinet Dimensions 29 cm (11.4”) high, 28 cm (11”) wide, 8 cm (3.15”) deep
Inputs
Readers
2 x Wiegand Readers with Multiple Protocol Support (Wiegand 26-bit, 30-bit & 44-bit)
or
4 x Auto-recognition High Security RS485 ports (if set as entry/exit door)
Keypads 2 x Wiegand Keypad with Multiple Protocol Support (Wiegand 8-bit & 26-bit)
Multi-Purpose Inputs 6 zone inputs (up to 12 using ZONE DOUBLING) supporting individual WIRE CUT &
WIRE SHORT supervision.
Box Tamper Normally Closed (N.C.) contact

8cdvigroup.com
A22K
High Security Access Control 2-Door Module

LOCAL BUS RS485 @ 57600Baud supporting star and/or daisy chain topologies up to 4000ft (1220 meters)
ETHERNET 10/100 Base-T, Auto Sensing, 100m(300ft)

AC Power 120-240Vac
Frequency 50Hz/60Hz
Output 24Vdc, 2.5A
AC Terminal Fuse 250Vac, 2.5 A, Time Lag, Slow Blow, Operating Temperature: -55oC to +125oC
Power Loss Indicator Yes (DC IN)
Do Not Connect to a Receptacle Controlled by a Switch.
Other 24Vac, 75VA 50/60Hz UL/ULC certied transformer can be used.

LK1, LK2 12Vdc @ 750mA
AUX 12Vdc @ 1A
Battery Against reversal, short, current limited/monitored

Battery Backup
Battery Capacity One 12Vdc 7Ah rechargeable acid/lead or gel cell backup battery (UL/ULC: YUASA #NP7-12
recommended, Europe: CDVI B7AH recommended). Ensure proper polarity.
Charging Current 250mA (default), 500mA, or 1A. Refer to the ATRIUM system manual to modify the battery
charging current.
Low Battery @ 11.8Vdc
Low Battery Restore @ 12.2Vdc
Low Battery Cut-O @ 10.5Vdc

Lock Output LK1 Maximum Current 750mA each
Lock Output LK2
Reader 1
Maximum Current 1000mA
Reader 2
Zone Inputs
LOCAL BUS
Outputs
RLY1, RLY2 Form C Relay, 5A @ 250Vac, 7A @ 125Vac, 7A @ 30Vdc

9
cdvigroup.com
A22K
High Security Access Control 2-Door Module
3] PACKAGE CONTENTS
This chapter details how to install and setup the ATRIUM A22K .
The A22K contains:
• One A22K module in its cabinet with connection diagram label
• Pre-assembled universal power supply with AC power cord plug
• USB Key (Software)
• Programming and master cards
• Credentials (pack of 25)
• Metal Box kit (See below)
• Installation kit (See below)

Kit






and

Bolts and Nuts 
Spacer





Support


enclosure

lock and key
1 3 2 each 1 1 1 4 1
Installation
Kit
Red and black

backup battery

1K Resistor 2.2K Resistor

for DC door
strikes or


door strikes or


(PCB Holder)
1 pair 22 10 2 2 7
If any item is missing, please notify your distributor immediately.

10 cdvigroup.com
A22K
High Security Access Control 2-Door Module

The cabinet is designed to be installed indoors, in a safe and secure location. Suggested locations include
electrical rooms, communication equipment rooms, closets or in the ceiling. To save time, wiring and facilitate
testing, install the cabinets at an equal distance between its controlled doors. Normal temperature and humidity
levels should be maintained.
Please note that other approved cabinets with approved tamper switch on the front cover and rear
surface can be used.
Cabinet Dimensions:
29 cm (11.4”) high, 28 cm (11”) wide, 8 cm (3.15”) deep
The Cabinet Can Accommodate:
One 12Vdc @ 4.5AH or 7AH, gel cell type batteries and wiring connections (15cm (6”) high,
6cm (2.5”) wide, 9 cm (3.54”) deep)
Battery Model  Capacity  Width Height
YUASA #NP7-12 12 Volt 7 Ah 151mm (5.94”) 65mm (2.56”) 97.5mm (3.84”)
YUASA #NP4-12 12 Volt 4.5 Ah 90mm(3.54”) 70mm (2.76”) 106mm (4.17”)
Multiple Conduit Knock-outs:
Two 19.05mm (0.75”) on each side and one 12.7mm (0.5”) on top
Minimum Clearance For Cabinet:
25cm (10”) clear space around all sides
38cm (15”) clear space in front of cabinet
Minimum Clearance From Electrical Interference:
2.4m (8ft.) from high voltage equipment or wiring and from electrical equipment likely to
generate interference
1.2m (4ft.) from telephone equipment or lines and 8m (25ft.) from transmitting equipment
The system’s location and wiring methods shall be in accordance with the National Electrical Code,
ANSI/NFPA 70.

11
cdvigroup.com
A22K
High Security Access Control 2-Door Module
4] MOUNTING INSTRUCTIONS
The box needs to be prepared before xing it to its location.

Installing tamper switches allows the A22K to detect when the cabinet door is opened and/or when the cabinet
is removed from the wall. If needed install the tamper switch(es) as follows:
Metal box
holes where
to x the wall
tamper switch

12 cdvigroup.com
A22K
High Security Access Control 2-Door Module
Cabinet Side View
Cabinet Door
Nut
Spacer
Spacer
Screw
Spacer
Install the wall tamper switch using the supplied bolts and nuts as shown in the following picture.
Install the tamper switch
plastic spacer on the back
at bottom left side of
the box as show in
the following picture.

13
cdvigroup.com
A22K
High Security Access Control 2-Door Module
Fix the tamper switch to
the bracket then mount
the bracket on the
mounting flange
Door
Tamper Switch
Bracket
Door Tamper Switch
Mounting Flange
Install the door tamper switch by aligning the switch holes to the pre-installed plastic bracket pins. Press rmly
to secure the tamper switch in position, then x the bracket to is mounting ange.
Refer to page 16 for wiring diagram.

14 cdvigroup.com
A22K
High Security Access Control 2-Door Module

Installing the box lock allows to secure the box from
unauthorized access. Installation procedure:
1. Remove the box door knock-out.
2. Insert the lock in the hole.
3. Slide the “U” metal part into the lock
groove to secure the lock in place.
Alternatively or complementary to the box lock,
the box may be secured by xing the cover to
its base using screws.
However this should be done only once the
installation is completed.
1. Use the 4 screws supplied to secure
the box cover to its base as shown
in the following picture.

15
cdvigroup.com
A22K
High Security Access Control 2-Door Module

Install the box to its location using 4 screws (not supplied) as shown in the following picture.
If the wall tamper switch is used, make sure that the tamper switch arm moves freely and is
completely pushed in when the enclosure is installed on the wall.

16 cdvigroup.com
A22K
High Security Access Control 2-Door Module

Install the 5 fasteners (PCB holder) supplied respectively to the box holes identied in red in the following
picture. Install the A22K PCB by aligning the fasteners with the corresponding PCB holes and pressing rmly to
secure the PCB in place.

15
cdvigroup.com
A22K
High Security Access Control 2-Door Module
5] WIRING DIAGRAM
Out of the box the A22K is ready for IP connectivity, fty (50) A22K per account. If you have more than one
A22K controller per account, one must be set as the “Master” controller to manage the others. These forty
(49) others are dened as “Sub-Controllers”.
The exibility of the A22K module allows it to be set also as an “Expander”. Up to four (4) A22K set as
an “Expander” can be connected to the RS485 Local Bus (orange connector) of a “Master” or
“Sub-Controllers”. ATRIUM give you a total of 500 doors system (100 doors connected IP + 400 doors
connected RS485). Simply adjust the “Module Type” jumper setting as shown below.
Module Type Jumper Setting
(Controller or Expander)
EX CTEX CT
or
Module is set as a
“2-Door Controller”
(Default Setting)
Module is set as a
“2-Door Expander”

16 cdvigroup.com
A22K
High Security Access Control 2-Door Module

LAN or WAN
BUZ GRN RED D1 D0 GND 12V BUZ GRN RED D1 D0 GND GNDC112V 12VREX1 GND GND C1 NO1 NC1LK1+ LK1- C2 NO2 NC2LK2+ LK2-TMPC2 12VREX2
+12V DC
+24V DC
-
+12V DC
-
+12V DC
A+
B-
Input 1
Input 2
Output 1
Output 2
BUZ GRNRED D1 D0 GND 12V BUZGRN RED D1 D0 GND GNDC112V 12VREX1 GND GND C1 NO1 NC1LK1+LK1- C2 NO2 NC2LK2+LK2-TMPC2 12VREX2
+12VDC
+24VDC
-
+12VDC
-
+12VDC
A+
B-
Input1
Input2
Output1
Output2
BUZ GRNRED D1 D0 GND 12V BUZGRN RED D1 D0 GND GNDC112V 12VREX1 GND GND C1 NO1 NC1LK1+LK1- C2 NO2 NC2LK2+LK2-TMPC2 12VREX2
+12VDC
+24VDC
-
+12VDC
-
+12VDC
A+
B-
Input1
Input2
Output1
Output2
BUZ GRNRED D1 D0 GND 12V BUZGRN RED D1 D0 GND GNDC112V 12VREX1 GND GND C1 NO1 NC1LK1+LK1- C2 NO2 NC2LK2+LK2-TMPC2 12VREX2
+12VDC
+24VDC
-
+12VDC
-
+12VDC
A+
B-
Input1
Input2
Output1
Output2
“MASTER”
CONTROLLER
The“Master”controller
managesuptoforty-nine(49)
“Sub-Controllers”.
(100doorsfullyIP)
IP CONNECTIVITY
OutoftheboxtheA22KisreadyforIPconnectivity,fty(50)A22Kperaccount.
IfyouhavemorethanoneA22Kcontrollerperaccount,onemustbesetas
the“Master”controllertomanagetheothers.Theseforty-nine(49)othersaredenedas“Sub-Controllers”.
RS485 CONNECTIVITY
AnA22Kcanbesetasan“Expander”.Uptofour(4)canbeconnectedtothe
RS485network(orangeconnector)ofthe“Master”andeach“Sub-Controller”.
A22K“Master”or“Sub-Controllers”
RS485port(orangeconnector).
A22Ksetas“Expander” A22Ksetas“Expander” A22Ksetas“Expander” A22Ksetas“Expander”
IP Network
Maximum300ft(100m)
How to set an A22K as an “Expander”
OnpowerOFF,movethe“Module Type”
jumpersettingtothetwopinsclosestto“EX”.
DO NOT useIPconnection
whenanA22Kissetasan
“Expander”.
“SUB-CONTROLLERS”
Uptoforty-nine(49)A22Kdenedas“Sub-Controllers”.
EX CT
+12V DC
+24V DC
-
+12V DC
-
+12V DC
A+
B-
Input 1
Input 2
Output 1
Output 2
READER DOOR 1
INPUT
DOOR 1
LOCK
DOOR 1
LOCK
DOOR 2
INPUT
DOOR 2READER DOOR 2
ENCLOSURE
TAMPER
SWITCH
INPUT
BUZ GRN RED D1 D0 GND 12V BUZ GRN RED D1 D0 GND GNDC112V 12VREX1 GND GND C1 NO1 NC1LK1+ LK1- C2 NO2 NC2LK2+ LK2-TMPC2 12VREX2
+12V DC
+24V DC
-
+12V DC
-
+12V DC
A+
B-
Input 1
Input 2
Output 1
Output 2
READER DOOR 1
INPUT
DOOR 1
LOCK
DOOR 1
LOCK
DOOR 2
INPUT
DOOR 2READER DOOR 2
ENCLOSURE
TAMPER
SWITCH
INPUT
BUZ GRN RED D1 D0 GND 12V BUZ GRN RED D1 D0 GND GNDC112V 12VREX1 GND GND C1 NO1 NC1LK1+ LK1- C2 NO2 NC2LK2+ LK2-TMPC2 12VREX2
+12V DC
+24V DC
-
+12V DC
-
+12V DC
A+
B-
Input 1
Input 2
Output 1
Output 2
READER DOOR 1
INPUT
DOOR 1
LOCK
DOOR 1
LOCK
DOOR 2
INPUT
DOOR 2READER DOOR 2
ENCLOSURE
TAMPER
SWITCH
INPUT
BUZ GRN RED D1 D0 GND 12V BUZ GRN RED D1 D0 GND GNDC112V 12VREX1 GND GND C1 NO1 NC1LK1+ LK1- C2 NO2 NC2LK2+ LK2-TMPC2 12VREX2
+12V DC
+24V DC
-
+12V DC
-
+12V DC
A+
B-
Input 1
Input 2
Output 1
Output 2
READER DOOR 1
INPUT
DOOR 1
LOCK
DOOR 1
LOCK
DOOR 2
INPUT
DOOR 2READER DOOR 2
ENCLOSURE
TAMPER
SWITCH
INPUT
BUZ GRN RED D1 D0 GND 12V BUZ GRN RED D1 D0 GND GNDC112V 12VREX1 GND GND C1 NO1 NC1LK1+ LK1- C2 NO2 NC2LK2+ LK2-TMPC2 12VREX2
+12V DC
+24V DC
-
+12V DC
-
+12V DC
A+
B-
Input 1
Input 2
Output 1
Output 2
READER DOOR 1
INPUT
DOOR 1
LOCK
DOOR 1
LOCK
DOOR 2
INPUT
DOOR 2READER DOOR 2
ENCLOSURE
TAMPER
SWITCH
INPUT
BUZ GRN RED D1 D0 GND 12V BUZ GRN RED D1 D0 GND GNDC112V 12VREX1 GND GND C1 NO1 NC1LK1+ LK1- C2 NO2 NC2LK2+ LK2-TMPC2 12VREX2
+12V DC
+24V DC
-
+12V DC
-
+12V DC
A+
B-
Input 1
Input 2
Output 1
Output 2
INPUT
POWER
SUPPLY
RS485
LOCAL
BUS
ETHERNET
PORT
SYSTEM STATUS
EXTRA
INPUTS/
OUTPUTS
ETHERNET LOCAL BUS LOCK 1 & 2
JUMPER SETTING
STATUS
24V DC INPUT/
BATTERY/
MODULE TYPE
BATTERY
BACKUP
READER DOOR 1
INPUT
DOOR 1
LOCK
DOOR 1
LOCK
DOOR 2
INPUT
DOOR 2READER DOOR 2
ENCLOSURE
TAMPER
SWITCH
INPUT
BUZ GRN RED D1 D0 GND 12V BUZ GRN RED D1 D0 GND GNDC112V 12VREX1 GND GND C1 NO1 NC1LK1+ LK1- C2 NO2 NC2LK2+ LK2-TMPC2 12VREX2
Usetwistedpairwiring
forRS485connection
(1pairforgroundand1
pairforA+B-)
Maximum4000ft
(1220m)
Communicationbetweenthe
“Master”controllerand
“Sub-Controllers”is
establishedviaTCP/IPONLY.
AES256
ENCRYPTION

17
cdvigroup.com
A22K
High Security Access Control 2-Door Module
+12V DC
+24V DC
-
+12V DC
-
+12V DC
A+
B-
Input 1
Input 2
Output 1
Output 2
READER DOOR 1
INPUT
DOOR 1
LOCK
DOOR 1
LOCK
DOOR 2
INPUT
DOOR 2READER DOOR 2
ENCLOSURE
TAMPER
SWITCH
INPUT
BUZ GRN RED D1 D0 GND 12V BUZ GRN RED D1 D0 GND GNDC112V 12VREX1 GND GND C1 NO1 NC1LK1+ LK1- C2 NO2 NC2LK2+ LK2-TMPC2 12VREX2
+12V DC
+24V DC
-
+12V DC
-
+12V DC
A+
B-
Input 1
Input 2
Output 1
Output 2
READER DOOR 1
INPUT
DOOR 1
LOCK
DOOR 1
LOCK
DOOR 2
INPUT
DOOR 2READER DOOR 2
ENCLOSURE
TAMPER
SWITCH
INPUT
BUZ GRN RED D1 D0 GND 12V BUZ GRN RED D1 D0 GND GNDC112V 12VREX1 GND GND C1 NO1 NC1LK1+ LK1- C2 NO2 NC2LK2+ LK2-TMPC2 12VREX2
+12V DC
+24V DC
-
+12V DC
-
+12V DC
A+
B-
Input 1
Input 2
Output 1
Output 2
READER DOOR 1
INPUT
DOOR 1
LOCK
DOOR 1
LOCK
DOOR 2
INPUT
DOOR 2READER DOOR 2
ENCLOSURE
TAMPER
SWITCH
INPUT
BUZ GRN RED D1 D0 GND 12V BUZ GRN RED D1 D0 GND GNDC112V 12VREX1 GND GND C1 NO1 NC1LK1+ LK1- C2 NO2 NC2LK2+ LK2-TMPC2 12VREX2
+12V DC
+24V DC
-
+12V DC
-
+12V DC
A+
B-
Input 1
Input 2
Output 1
Output 2
READER DOOR 1
INPUT
DOOR 1
LOCK
DOOR 1
LOCK
DOOR 2
INPUT
DOOR 2READER DOOR 2
ENCLOSURE
TAMPER
SWITCH
INPUT
BUZ GRN RED D1 D0 GND 12V BUZ GRN RED D1 D0 GND GNDC112V 12VREX1 GND GND C1 NO1 NC1LK1+ LK1- C2 NO2 NC2LK2+ LK2-TMPC2 12VREX2
+12V DC
+24V DC
-
+12V DC
-
+12V DC
A+
B-
Input 1
Input 2
Output 1
Output 2
READER DOOR 1
INPUT
DOOR 1
LOCK
DOOR 1
LOCK
DOOR 2
INPUT
DOOR 2READER DOOR 2
ENCLOSURE
TAMPER
SWITCH
INPUT
BUZ GRN RED D1 D0 GND 12V BUZ GRN RED D1 D0 GND GNDC112V 12VREX1 GND GND C1 NO1 NC1LK1+ LK1- C2 NO2 NC2LK2+ LK2-TMPC2 12VREX2
RS485 BUS
Up to 4 A22K set as “Expander”
can be connected per RS485 port.
DO NOT use IP port.
Maximum 1220m (4000 ft).

A22K set as “Controller”
is connected on a
network (LAN or WAN) and
manages all the modules
connected to its RS485 port.
Up to 50 A22K set as
“Controller” can be
connected per site for a
maximum of 500 doors.
When there is more than one
controller per site, one must
be designated as the “Master
Controller”. It will be the link
between the software (or web
server) and all modules.
See the ATRIUM software
manual or web server guide
on how to designate an A22K
controller as the “Master
Controller”.
EX CT
EX CT
EX CT
EX CT
EX CT
Module Type

Module Type

Module Type

Module Type

Module Type

LAN or WAN
Tablet Smartphone
WiFi
WiFi
Maximum
100m (300 ft).

18 cdvigroup.com
A22K
High Security Access Control 2-Door Module

Connecting the tamper switches allows the A22K to detect when the cabinet door is opened and/or when the
cabinet is removed from the wall. To install the tamper switches, see “Installing the Tamper Switches”.
To use both switches:
1. Connect one end of the supplied wire to the door tamper switch
terminal and the other end to the wall tamper switch terminal.
2. Connect the other terminal of the door tamper switch to the “TMP” terminals using the
supplied wire.
3. Connect the other terminal of the wall tamper switch to the “GND” terminals using the
supplied wire.
To use only one switch:
1. Connect one terminal of the tamper switch to the “TMP” terminals using the supplied wire.
2. Connect the other terminal of the same tamper switch to the “GND” terminals using the
supplied wire.
If you do not use the tamper switch, connect a wire between the “TMP” and “GND” terminals.
+12V DC
+24V DC
-
+12V DC
-
+12V DC
A+
B-
Input 1
Input 2
Output 1
Output 2
INPUT
POWER
SUPPLY
RS485
LOCAL
BUS
ETHERNET
PORT
SYSTEM STATUS
EXTRA
INPUTS/
OUTPUTS
ETHERNET LOCAL BUS LOCK 1 & 2
JUMPER SETTING
STATUS
24V DC INPUT/
BATTERY/
MODULE TYPE
BATTERY
BACKUP
Metal Box
Door Tamper Switch
(N.C.)
Metal Box
Wall Tamper Switch
(N.C.)
READER DOOR 1
INPUT
DOOR 1
LOCK
DOOR 1
LOCK
DOOR 2
INPUT
DOOR 2READER DOOR 2
ENCLOSURE
TAMPER
SWITCH
INPUT
BUZ GRN RED D1 D0 GND 12V BUZ GRN RED D1 D0 GND GNDC112V 12VREX1 GND GND C1 NO1 NC1LK1+ LK1- C2 NO2 NC2LK2+ LK2-TMPC2 12VREX2
