CDVI CDV47 User manual

2 WIRE VIDEO SYSTEM
CDV-47 LCD Monitor
ENGLISH
Please read this manual carefully before using the product, and keep it safe.
CDV47 USER MANUAL

1. Parts and Functions
Digital TFT LCD Screen
UNLOCK Button
TALK/MON Button
Microphone
Connection Port
Speaker
Mounting Hook
Mounting Hook
1 2 3
ON
DIPS
L1
L2
Emergency Button
Message Indicator
Key functions
-2-
DIP Settings
1 2 3
ON
Bit
DIP1&2
Bit State Description
DIP3
1 2 3
ON
1 2 3
ON
LCD screen Displaysthe visitors image
Emergency button Press for 3 secsto send an SOS message(CDV-GSM req.)
Message indicator Indicates a new visitor call record
Unlock button Press to release the door
Talk/Mon button Press to communicate with the visitor when called..
Press to display the camera view during standby mode.
Microphone Transmitsvoice communication
Mounting hook To secure monitor to bracket
Connection port Wiring and monitor setting
Speaker Receivesvoice communication
Reserved.
Set to OFF. When the monitor is in the middle of the line in daisy chain connection.
Set to ON. When the montior is at the end of the line.

2. Mounting & Wiring
145~160 cm
3. Main Menu
Touch the screen anywhere on monitor
in standby mode, the main menu page
will be shown as follows:
-3-
4. Basic Operation
1. Pressing the CALL lliwnoitatsroodtuoehtnonottub
ring the monitor and display the visitors image (if the
call is not answered, the monitor will switch off after
30 seconds).
2. Press TALK/MONbutton or touch icon
to talk (hands-free) to the visitor. When you have
TALK/MONbutton or touch icon again to end the
communication.
00:30 Front Door
It will display the
call source string

1. While talking with the visitor, Press UNLOCK Button or touch icon to
open the door for the visitor (if two locks are connected, touch unlock 2nd icon
to release the second door)
2. When the monitor is in standby mode, pressing TALK/MONButton will
display the view of outside door camera. Touching the Monitor icon on main
menu will access the "Door/Camera switching mode" - this is where multi door
stations and/or CCTV camera's are installed, you can select the door station or
CCTV camera you want to view. Press icon to exit back to the main menu.
Note: if the system connect 2 wire camera via camera controller, press the camera
1/2/3/4 to monitor the camera you want.press icon to exit and enter main menu
page.
5. Intercom Function
1. Inner Broadcast
Inner Broadcast and all the slave monitors will receive your audio broadcast at the
same time.
2. Inner Call
Call and all the slave monitors will ring at the same time, but whichever monitor
-4-
3.
4.
Touch Intercom icon on main menu to enter the intercom mode. Select one of the
icon options: Inner Broadcast, Inner Call, Name List Call and Call Guard Unit.

answers the call, a conversation can be started and the other monitors will stop
ringing.
3. Name List Call: A user in one apartment can call other apartments in the system.
Touch Name List Call icon. Select a name on the screen then touch icon to
call. Press / icon to view previous/next name list page. To rename, please
touch the line to edit (01, 02 etc), then the keypad page will appear and you can
input your new name in this page.
4.
5.
6.
7.
8.
9.
10. Call Guard Unit: A Monitor can be assigned as Guard Unit Monitor.To call, simply
press the icon.
6. Video/Picture Memory of Visitors
-5-
[ 01 ] Jim. Zhang
[ 02 ] Calo . Liu
[ 03 ] Jacko . Zhang
[ 04 ] Philips. Chen
[ 05 ] Hebe . Zhang
[ 06 ] Tony. Li
Name List
4.
Video/Picture Playback
Touch Playback icon on main menu, the recorded videos/pictures will be played on
the screen. The icon will Start/Pause the images recorded.
Video/Picture Recording of Visitor
Auto-recording and manual recording is available, auto-recording is the default. On
receipt of a call, after 3s the monitor will automatically record one video/picture. You
can touch icon during a call to record the visitor's video/image manually.
Note: The visitor picture memory function is a standard feature in the monitor, video &
audio is available with the addition of a Micro SD card.

-6-
Image:008/020 2014/06/23 14:36:55
7. Review Call Records
All the calls received by the montior, including door-station-to-monitor and monitor-to-
monitor, will be recorded and can be reviewed afterwards.
Touch Call Record icon on main menu to get into the call record mode.Unread call
records will be indicated by a red arrow. Press the unread record, and then touch icon
to play it.
Note:
Without SD card, 118 images can be stored memory
With SD card (up to 32GB Micro SD), video and audio can be recorded
Call Record 01/05
06-23 15:22 Calo.Liu
06-18 20:54 Smith
06-12 11:06 Vincent.Yang
05-29 08:39 Allen.Chen
05-27 21:43 Hebe.Zhang
04-20 13:16 Ben.Wu
Call Record 01/05
06-23 15:22 Calo.Liu
06-18 20:54 Smith
06-12 11:06 Vincent.Yang
05-29 08:39 Allen.Chen
05-27 21:43 Hebe.Zhang
04-20 13:16 Ben.Wu
Note:
It is not necessary to delete any records,
as when the memory becomes full the
newest call will be recorded and the
oldest call will automatically be deleted.

-7-
8. Do Not Disturb Function
Touch Do Not Disturb icon on main menu to get into the do not disturb mode.
You have 4 options: Normal, For 1 Hour, For 8 Hours and Always. You can select the
appropriate item according to your needs.
Do Not Disturb
Normal
In 1 Hour
In 8 Hours
Always
Note: When you select "For 1 Hour" or "For 8 Hours", bottom of the screen will display
the remaining time.
Refuse Call In: 00:58:32
9. Transfer Function
Touch Transfer icon on main menu to get into the transfer mode. Select 1, 2 or 3
and input the telephone number via the digital keypad. There are 3 types of divert mode:
Transfer Options
Don't Transfer
If No Answer
Simutaneously
1)
2)
3)
For 1 Hour
For 8 Hours
Do not
Disturb
1: Don't Transfer - calls from the outdoor station will not be diverted.
2: If No Answer - if nobody answer the call from the outdoor station within 30
seconds, the call will be diverted to the telephone number(s) you set. The monitor
will shut off immediately when the divert is sucessful, while not affecting the
communication between the outdoor station and the telephone/mobile.
3: Simutaneously - calls from outdoor station will be diverted to your telephone
immediately, but the monitor won't shut off when the divert is sucessful. If
the monitor answers the call at this time, the divert procedure will quit and
communication to the outdoor station will be via the monitor.

-8-
10. Light
On main menu page or in monitoring, touch Light icon to activate the light - the light
will be turned off automatically.
11. Basic Setup Instructions
Sound Settings
Touch icon on the main menu page then select "Sounds" from the Settings list. You
can set a variety of ring tones on this page (touch icon to exit the setting and return
to the main menu page).
Transfer Options
Don't Transfer
If No Answer
Simutaneously
1)
2)
3)
Transfer Device Info
Device -
SIM -
Network -
Signal Level -
Select Door 1, then the ring-tone you
prefer (use the left/right arrows to move
through tones). Repeat for Door 2 etc.
Note:1.Touch icon to display the transfer device info.
2.Touch
Note: the light function will be activated only when the system is connected to a light
via the SC6V module. If no connection made, then this function is unvalid. For more
information, please refer to the SC6V user instruction manual. Not available in UK.

-9-
Date & Time Settings
Touch icon on main menu page, then select "Date & Time" from the Settings list.
You can set the date & time on this page (touch icon to exit the setting and return to
the main menu page).
Note:
You can set your own time or you can
synchronize the system time.
Rename & Monitor Time Settings
Touch icon on main menu page, then select "More" from the Settings list. You can
rename the door station(s) and camera(s), also set the monitor time on this page (touch
icon to exit the setting and return to the main menu page).

-10-
To rename, please touch the line to edit, then the keypad page will appear and you can
input your new name in this page.
DOOR3 RENAME abc
DS-3_
12. SOS/SMS Function
To generate an emergency text, press Emergency button for 3 seconds to enter
the SOS/SMS page. Then conrm by touching icon to send the SOS/SMS.
Send SOS SMS ?
1. The Scene mode selection: Total 4 screen
modes can be selected in sequence:
Normal,
Brightly, Soft
and
User.
Whenever you modify
Brightness
or
colour, Scene
item will be set to
User
mode automatically.
2. Note that all the modications will be performed immediately after the operation.
Touch the window of image to exit the adjust page.
Screen and Volume Adjustment
SOS
During monitoring or talking, touch icon, the image Adjust page will be displayed.
An emergency text will be sent to the designated number. CDV-GSM required.

-11-
The restore to default function allows the user to recover the factory settings.
Enter main menu page, and touch icon, then select "About" item or touch the
logo to enter the "About" settings page. Touch icon, the default settings will
be loaded.
Touch icon to enter the "Memo Information" page, touch and icon to
copy the pictures to the SD card. Touch and icon to format the SD card and
restart.
14. Monitor Parameter Setting
1.Touch icon on
main menu page.
3.A digital keypad
will be shown.
How to enter the installation setting page
13. Restore to Default
About
Local Address 00.00
Video Standard AUTO
System Verson 00.01.00
Display Driver 1.0
Front 1.0
UI 1.0
Memo Information
SD Card --
Video Capacity ----
Video Usage ----
Flash
Image Capacity 0118
Image Usage 0000
Copy Pictures To SD ?
Memo Information
SD Card --
Video Capacity ----
Video Usage ----
Flash
Image Capacity 0118
Image Usage 0000
Format SD Card And Restart ?
About
Local Address 00.00
Video Standard AUTO
System Verson 00.01.00
Display Driver 1.0
Front 1.0
UI 1.0
INSTALLER SETUP 123
_
2.Touch UNLOCK
button on frame and
hold for 2s.

How to set the slave monitor address
How to set the monitor panel on

 
   
The system offers two methods of date and time.
The code number of 8008 is used to set the date format as month/day/year
The code number of 8009 is used to set the date format as day/month/year
The code number of 8012 is used to set the time format as 12 hour system
The code number of 8013 is used to set the time format as 24 hour system
How to set date and time format
-12-
How to set the name list
On the main menu select “intercom” – then select “Name List Call”.
Highlight the number you wish to name/change and select . A keyboard will appear,
enter/change the name then press ok to save.
Maximum 4 monitors can be connected in one apartment,one master monitor together
with 3 slave monitors, so you should set the address correctly.(Note: one monitor
must be set as master monitor)
The code of 8000 is used to set the master monitor.
The code of 8001 is used to set the rst slave monitor .
The code of 8002 is used to set the second slave monitor .
The code of 8003 is used to set the third slave monitor .
In default mode,when receive a calling, the master and slave monitors will ring at the
same time, the master monitor will display the image while the slave monitors will not.
The settings can be changed to allow the master monitor and all the slave monitors to
show the panel image at the same time when receiving a call, input the code 8006 on
each slave monitor.

How to set the monitor as a Guard Monitor
Unlock time:
How to set the unlock parameter
Unlock mode:
How to set the user code for the monitor
- please refer to the following table:
Input No. User Code Input No. User Code Input No. User Code
8201 Code=1 8212 Code=12 8223 Code=23
8202 Code=2 8213 Code=13 8224 Code=24
8203 Code=3 8213 Code=14 8225 Code=25
8204 Code=4 8215 Code=15 8226 Code=26
8205 Code=5 8216 Code=16 8227 Code=27
8206 Code=6 8217 Code=17 8228 Code=28
8207 Code=7 8218 Code=18 8229 Code=29
8208 Code=8 8219 Code=19 8230 Code=30
8209 Code=9 8220 Code=20 8231 Code=31
8210 Code=10 8221 Code=21 8232 Code=32
8211 Code=11 8222 Code=22
-13-
There are two unlock modes: 1.power-on- to-unlock(fail secure):unlock mode=0(default)
2.power-off-to-unlock(fail safe):unlock mode=1.
The code 8010 is used to set the unlock mode
The code 8011 is used to set the unlock mode to 1
The unlock time can be changed at any time, it can be set from 1 to 99 seconds.The codes
8401 to 8499 are used to set the unlock time to 1~ 99 seconds.
A Monitor can be assigned as Guard Unit Monitor; when the Guard Unit Monitor
answers the call, conversation with the guard person is started..
The code number of 8004 is used to set the monitor as a guard unit monitor and 8005 is
used to cancel this function.
Each monitor should be assigned an address in the system, total 32 addresses can be
set using codes 8200 to 8232 to set the addresses of 01 to 32

15. Specication
16. Precautions
●
●Power●supply●for●indoor●monitor:●● ● DC●20~28V●
●
●Power●consumption:● ●● Standby:●12.4mA●Working:●270mA
●
●Monitor●screen:● ● 7●Inch●digital●color●LCD
●
●Display●resolution:● ● 800*3(RGB)●x●480●pixels
●
●Video●signal:● ● 1Vp-p,●75Ω,●CCIR●standard
●
●Wiring:● ● 2●wires,●non-polarity
●
●Dimension:● ● 225●x●131●x●18mm
1) All components should be protected from shock or vibration, and be careful the
products are not impacted, knocked or dropped.
2) Please clean with a soft cotton cloth, please do not use a chemical cleaning agent. If
necessary, please use a little pure water or dilute soapy water to clean.
3) Image distortion may occur if the video monitor is mounted too close to a magnetic
eld eg microwaves, TV's, computers etc.
4) Please do not subject the monitor to wet, high temperature, dust, caustic and oxidation
gas environments, any of which could cause unpredictable damage.
5) Please use the right adaptor which is supplied by the manufacturer, or approved
by the manufacturer.
6) Pay attention to the high voltage inside the products, please refer service only to a
trained and qualied professional.
-14-

Note
-15-

The design and specifications can be changed without notice to the user. Right to
interpret and copyright of this manual are preserved.
CDV-47M (B/W)
