cecotec CONGA HYDROSTEAM 3030 ACTIVE User manual

Instruction manual
CONGA HYDRO 3030 ACTIVE

INDEX
1. Parts and components
2. Before use
3. Assembly
4. Operation
5. Cleaning and Maintenance
6. Troubleshooting
7. Technical specications
8. Disposal of old electrical appliances
9. Technical support and warranty

5
CONGA HYDROSTEAM 3030 ACTIVE
SAFETY INSTRUCTIONS
Keep this instruction manual for future use.
This product is designed only for household use. Commercial
use of this product voids the manufacturer’s warranty.
-To avoid risk of fire, electric shock or injury:
-Do not direct steam at people, animals or
electrical appliances.
-Do not expose the steam cleaner to rain.
-Keep the steam cleaner indoors.
-Unplug from power when not in use or before
performing maintenance or troubleshooting.
-Do not let the steam cleaner under supervision.
-Do not expose hair, loose clothing, fingers or body parts to
open or moving parts of the steam cleaner.
-Do not handle the steam cleaner with wet hands.
-Do not use the device when it has been dropped, damaged,
left outdoors or immersed in water.
-Never pull the cord, use it for transporting or as a handle,
force the cord against sharp edges or corners, or expose it
to hot surfaces.
-

6CONGA HYDROSTEAM 3030 ACTIVE
-To unplug the device, pull the plug, not the cord.
-Do not use the product in an enclosed space with
oil-based paint vapour, paint thinner, some mothproofing
substructures, flammable dust or other explosive or toxic
vapours.
-Do not use the steam cleaner as a toy.
-Do not use on leather, waxed furniture or polished floors,
synthetic fabrics, velvet or other delicate and steam-
sensitive materials.
-Do not immerse the appliance.
-Do not use it for heating.
-Do not use it for any purpose other than those described in
this manual.
-Use only accessories recommended by the manufacturer.
The use of accessories which have not been bought or
provided by Cecotec may cause fire, electric shock or injury.
-Never pour detergents, alcoholic, aromatic or descaling
products into the steam cleaner, as this could damage the
device or make it dangerous to use.
-Pay attention when using it near or with children.
-This device has a polarised plug. To reduce the risk of
electric shock, the device has a polarised plug (one blade is
wider than the other). This plug can only fit into a polarised
socket outlet in one way. If the plug does not fit completely
into the socket, turn the plug around. If it still does not t,
contact a qualied electrician to install a suitable plug. Do
not modify the plug.

CONGA HYDROSTEAM 3030 ACTIVE 27
ENGLISH
1. PARTS AND COMPONENTS
Fig. 1
1. Steam control button
2. Steam level indicator
3. Low body
4. Mop head
5. Cord hook
6. On/Off switch
7. Filter
8. Power cord
9. Water tank: 330 ml
10. Water measuring cup
11. Mop pad
12. Sliding carpet
13. Cord hook
14. Metal tube
15. Water inlet
2. BEFORE USE
- Take the product out of the box and remove all packaging materials.
- Check carefully if there is any damage. If any is observed, contact as soon as possible the
Technical Support Service of Cecotec for advice or reparation.
3. ASSEMBLY
- The steam cleaner assembly is quick and easy, in 3 steps.
- It contains the following parts.
Fig. 2
1. Handle
2. Low body
3. Mop head
4. Water tank: 330 ml
5. Mop pad
Assembly steps:
1. Place the mop head in the low body by assembling it in place.
2. Install the metal tube in the low body until it is assembled in the correct place.

CONGA HYDROSTEAM 3030 ACTIVE
28
ENGLISH
3. Install the dust tank to the body.
4. The steam cleaner assembly is done.
4. OPERATION
330 ml removable water tank
The water tank is in the low body. It is recommended to use distilled or demineralised water
instead of tap water. Otherwise, lime deposits may form. Fig. 3
Note:
- Turn the steam cleaner off when removing the water tank.
- Fill the water tank with the water measuring cup.
- Do not use chemical products on the water tank of the steam cleaner.
- It is recommended to remove lime at least once a month.
Steam level control
- The steam level indicator will stop ashing when the steam cleaner is ready to be used.
- Next, press the steam level button to choose the desired steam level.
Fig. 4
Steam control button
Steam level indicator
On/Off switch
Note:
Press the On button and then the steam control button.
Take into account that, when pressing the steam level button for the rst time, steam will be in
the maximum level. Set the desired level by pressing the steam control button.
Reusable mop cloths
The reusable mop cloths are machine-washable and suitable for use on virtually all hard oor
surfaces. Your steam cleaner includes two pads. The grey and white striped pads are used for
scrubbing heavily soiled oors and cleaning stubborn debris. Fig. 5
Mop pad
Steam cleaner preparation
Fig. 6
1. Place the pad on the mop head. Make sure that the quick release tab is behind.
a. Fill the water tank.
b. Press the buttons on both sides of the tank to remove it.
c. Remove the rubber plug from the back of the tank.
d. Fill the water tank and place the rubber plug again. For better results, water

CONGA HYDROSTEAM 3030 ACTIVE 29
ENGLISH
must be in room temperature.
2. Place the water tank again in the low body and carefully slide it in place.
3. Remove the power cord and introduce it in a 120 V power socket.
4. The indicator light will turn on when the steam cleaner is ready to be used. Press the
steam level button to choose the desired steam level.
Note
After the rst use or after lling the water tank, the pump can produce a sound. This is normal
and it should last at least some seconds.
Before cleaning
Sweep or vacuum the oor thoroughly before cleaning with the steam cleaner.
Hard oors cleaning
Your steam cleaner is designed to clean hard oors, like ceramic tile, vinyl, laminate, marble,
stone and sealed hardwood oors. The use of the steam cleaner on waxed or unwaxed oors
may result in a decrease in gloss. You must use the steam cleaner rst in an inconspicuous
area. Check the care instructions of the manufacturer of your oor.
1. Connect the unit and wait for 30 seconds for it to heat up. Choose the steam level to clean
the oor: Low (delicate oors), Medium (regular cleaning) and High (resistant or sticky
oors). Start cleaning by sliding the unit carefully over the oor surface. Fig. 7
Note
Press the On button and then the steam control button. Take into account that, when pressing
the steam level button for the rst time, steam will be in the maximum level. Set the desired
level by pressing the steam control button.
2. To turn off the steam cleaner, press the steam level button until the blue light on the
button is on.
3. When the steam cleaner stops emitting steam, unplug the unit. Remove the water tank,
rell it and continue cleaning.
Note
Make sure to disinfect the oor, use a microbre cloth and rub the oor back and forth at
least three times with continuous steam. For better results, remove the pad and wash it after
cleaning.
Sliding carpet
This accessory is installed in the mop head to allow the device to slide over carpets while
cleaning them. Fig. 8

CONGA HYDROSTEAM 3030 ACTIVE
30
ENGLISH
Note
- Make sure the sliding carpet is properly assembled inthe mop head. If it is not inthe correct
position, the sliding carpet will fall during the use of the steam cleaner.
- Move the steam cleaner continuously until it is nished. Do not leave the steam cleaner in
a steady position.
5. CLEANING AND MAINTENANCE
- Disconnect the power cord from the plug.
- Carefully remove the pad from the mop head. The pad can be hot.
- The remaining water in the water tank must be emptied before storing the device.
- The pad is machine-washable with hot water. Use only liquid detergents. For better
results, do not use softeners nor bleach. Allow the mop to dry.
- Wind the power cord in the hook in the back of the steam cleaner.
- Clean every steam cleaner surface with a soft cloth. Store the device in a protected and
dry area vertically.
- It is recommended to remove calcium in the water tank at least once a month, as well as
using a descaling agent for steam cleaners.
6. TROUBLESHOOTING
Warning:
To reduce the risk of electric shock, turn off the device and unplug it before carrying out any
maintenance or troubleshooting tasks.
Common problems
Problem Possible cause Solution
Poor or no steam Water tank empty Turn off the steam cleaner
and ll the water tank
Steam level not selected Select the steam level with
the button.
Water leakage Loose rubber plug Turn the steam cleaner and
remove the water tank.
Tighten the rubber.
Difcult use on
carpets
Sliding carpet not installed Make sure the sliding carpet
is properly assembled in the
mop head.

CONGA HYDROSTEAM 3030 ACTIVE 31
ENGLISH
Rust in the water tank The tank has not been
emptied
The remaining water in the
water tank must be emptied
before storing the device.
You cannot control the
steam level
The steam cleaner is off Press the On button and then
the steam control button.
The mop gets very wet Inadequate steam level Set a lower steam level.
It stops working Misuse or problem with the
product
Contact Customer Service:
FAQs
Question Answer
Are the cleaning cloths washable and
reusable?
Yes, the micro-bre cleaning cloths
are machine-washable. Use only liquid
detergents. For better results, do not use
softeners nor bleach. Allow the mop to dry.
On which oors can I use the steam cleaner? Your steam cleaner is designed to clean
hard oors, like ceramic tile, vinyl, laminate,
marble, stone and sealed hardwood oors.
The use of the steam cleaner on waxed or
unwaxed oors may result in a decrease in
gloss.
Do I need to activate the handle for it to
release steam or is it automatic?
The steam cleaner releases steam
automatically when you select the steam
level. You can select the steam level by
pressing the steam level button to clean the
oor: Low (delicate oors),
Medium (regular cleaning) and High (resistant
or sticky oors).
Can I use a cleaning solution with the steam
cleaner or should I just use water?
You cannot use cleaning solutions with the
steam cleaner. It is recommended to use only
distilled water to increase the steam cleaner
lifespan.
7. TECHNICAL SPECIFICATIONS
Product: Conga HydroSteam 3030 Active
Model: 03250
1500W,220-240V ~, 50-60Hz
IP X4
Made in China | Designed in Spain

CONGA HYDROSTEAM 3030 ACTIVE
32
ENGLISH
8. DISPOSAL OF OLD ELECTRICAL APPLIANCES
The European directive 2012/19/EU on Waste Electrical and Electronic
Equipment (WEEE) species that old household electrical appliances must
not be disposed ofwith the normalunsorted municipalwaste. Old appliances
must be collected separately, in order to optimise the recovery and recycling
of the materials they contain and reduce the impact on human health and
the environment.
The crossed out “wheeled bin” symbol on the product reminds you of your
obligation to dispose of the appliance correctly.
Consumers must contact their local authorities or retailer for information concerning the
correct disposal of old appliances and/or their batteries.
9. TECHNICAL SUPPORT AND WARRANTY
This product is under warranty for 2 years from the date of purchase, as long as the proof
of purchase is submitted, the product is in perfect physical condition, and it has been given
proper use, as explained in this instruction manual.
The warranty will not cover the following situations:
The product has been used for purposes other than those intended for it, misused, beaten,
exposed to moisture, immersed in liquid or corrosive substances, as well as any other fault
attributable to the customer.
The product has been disassembled, modied, or repaired by persons, not authorised by the
Cecotec ofcial Technical Support Service.
Faults deriving from the normal wear and tear of its parts, due to use.
The warranty service covers every manufacturing defect of your appliance for 2 years, based
on current legislation, except consumable parts. In the event of misuse, the warranty will not
apply.
If at any moment you detect any problem with your product or have any doubt, do not hesitate
to contact Cecotec ofcial Technical Support Service at [phone].

Fig./Img./Abb./Afb./ Rys. 1
Fig./Img./Abb./Afb./ Rys. 2
(1)( 2) (3)
(4)( 5)

Fig./Img./Abb./Afb./ Rys. 3
Fig./Img./Abb./Afb./ Rys. 4 Fig./Img./Abb./Afb./ Rys. 5
Fig./Img./Abb./Afb./ Rys. 6

www.cecotec.es
Cecotec Innovaciones S.L.
C/ de la Pinadeta s/n, 46930
Quart de Poblet, Valencia (Spain)
JM01210816
