Celabs AIO22HD User manual

All-in-One Player
AIO22HD
Document: AIO22HD_manual.pdf
Key Features:
INSTRUCTION MANUAL
3209 Wood Drive
Garland, TX 75041
Phone: [phone]
Toll free: [phone]
Fax: [phone]
www.celabs.net
WARRANTY
Cable Electronics, Inc. warrants this product to be free from defects in
material and workmanship, under normal use and service, for a period of
one year from the purchase by the original purchaser. If this product is
defective or malfunctions, Cable Electronics will replace or repair this unit (at
their option) within a reasonable time. No expressed or implied warranty is
made for any defects caused by immersion or exposure to liquids, abuse,
neglect, improper operation of unit, excess wear and tear and defects
resulting from unauthorized disassembly and or modification.
930-3524-01_Rev.A
True high definition video playback (1080p) and multi-layered touch
interaction. Interactive options include motion sensor, buttons, or
segmented touch screens
• Plays full 1080p content
• Available with up to 8 buttons
• Optional motion sensor
• Optional dynamic touch screen for complex interactive solutions
• USB port for auto update of content
• Multi-language OSD: English/Chinese/ other
• Built-in media player
• Built-in stereo speakers
• Content on SD Card
• Locking security door (protects Power Disconnect and SD card)
• Industrial grade metal chassis
• Two mounting options: key-hole slots and VESA 75 (3” x 3”)
Uses 4 M4 screws for mounting
• Reprogrammable timer, auto start, loop video, slide show features
Additional Photos:

Technical Specifications
Video Output:
Display size: 22"
Display area: 18.8” (H) x 10.6” (V)
Screen Resolution: 1920x1080
Brightness: 250 cd/m2
Ratio: 16:9
Contrast Ratio: 1000:1
Viewing angle: 170/160
Response time: 5ms
Colors: 16.7M
Media Support: JPEG, MPG, DIVX, AVI, MOV
Max resolution image: 1920x1080
Max resolution video: 1920x1080
Input voltage: 12v
Power supply(volts): AC110-220V
Audio: 1w, 8Ω
Working Temp: 32ºF~122ºF
Memory: SD, SDHC
Certificates and Approvals: FCC, CE, ROHS
“Media” Menu
Home (Main Menu)
Playback Formats:
Display
Media
Time
System
• Video: MPEG-1, MPEG-2, MPEG-4
• Audio: MP3, WAV
(MP3 minimum 32 Kbps, maximum 256 Kbps)
• Photo: JPEG, Motion JPEG (AVI)
(Motion JPG maximum 10 fps)
Panel keys: At main menu: While playing:
Up (V+) Navigate Up Volume up
Down (V-) Navigate Down Volume Down
Left Back one command Play Back one file
Right Next command Play Next file
Enter Select Go to main menu
Exit Go back one menu Go to main menu
Sorting:
By file name
By file date
Directory:
Enable
Disable
Resume Play:
On
Off
Text Auto Browser Speed:
Normal
FLASH:
Nand flash
“Time” Menu
Set Time
00:00:00
Set Date
YR/MO/DAY
PowerOn Time
00:00:00
PowerOFF Time
00:00:00
Auto PowerOnOff enable/disable
On
Off
“System” Menu
Language:
English
Chinese (Simplified)
Chinese (Traditional)
System Config:
Upgrade
Default
System Information
Califbrate touchscreen:
Yes
No
Play Mode:
Debug
Release
