Celikel CHARGER V Series Assembly instructions

CELIKEL CHARGER V
OPERTORS INSTRUCTION
MANUAL

TABLE OF CONTENTS
INTRODUCTION..............................................................................................................................
Using This Manual ........................................................................................................................
CERTIFICATE OF WARRANTY ............................................................................................................
Model and Serial Number Information ......................................................................................
SAFETY.............................................................................................................................................
PRODUCT TECHNICAL FEATURES .....................................................................................................
DELIVERY AND TRANSPORTATION ..................................................................................................
ATTACHING TO THE TRACTOR .........................................................................................................
ADJUSTMENT THE LENGHT OF SHAFT .............................................................................................
HYDRAULIC.......................................................................................................................................
BRAKES .............................................................................................................................................
LOADING SHOVEL (OPTIONAL) ........................................................................................................
FEED MIXTURE PREPARATION ........................................................................................................
MINERAL / PREMIX FILLING HOPPER ...............................................................................................
WEIGHING SYSTEM (Optional) ........................................................................................................
ADJUSTMENT OF STABLE KNIVE ......................................................................................................
MAINTENANCE.................................................................................................................................
LUBRICATION ...................................................................................................................................
CONVEYOR (Optional) .....................................................................................................................
POSSIBLE PROBLEMS AND SOLUTIONS............................................................................................

Dear User;
Congratulations for purchasing a Celikel Charger V. We appreciate your business. You have
purchased one of the best built, most reliable mixers available. Please read this user's and
operational manual carefully in order to prevent any possible malfunctions and to know more
closely before use your machine. This manual contains important warnings for the perfect
functioning of your machine maintenance practices and practical in use.
We wish to use your machine in good times.
CELIKEL TARIM MAKINELERI SAN. VE TIC. LTD. ŞTI.
USING THIS MANUAL
This manual should be considered a permanent part of your machine, and should remain with
the machine if you sell it.
This manual has been designed to help you become familiar with your unit.

CERTIFICATE OF WARRANTY
Warranty conditions
1. The warranty period for the product from the date of delivery to the user 1 (one) year.
2. Except for showing deformation depending on the usage and designated as parts supplies are under
the warranty of our company.
3. The maximum time to repair the product within thirty (30) days.
4. In case of failure of the product, repairing time will be added to the warranty period
5. The warranty period of product one to one replacement is up to the remaining warranty period of
the purchased product.
6. Every maintenance except for will made authorized and user would be out of warranty
7. Depending on the intensity of use of the product (knife, rubber bands, etc.) can not be replaced
under warranty parts.
8. Not manufactured by Çelikel products warranty period of the components and systems supplied as
finished is limited to the conditions specified by the supplier.
9. Supplied with the propeller such as the middle arm and shaft as a gift, it is out of warranty parts.
10.Service stations do not fall under warranty repair of transportation, packaging, parts and service
expenses are paid by the customer.
11.Users can not demand the approval of the guarantee in case of changes on the machine or original
spare parts if not used by Çelikel.
12.Use the machine unpropert and uncorrectly would not be under of the warranty.
13.Manufacturer is not responsible for maintenance which must is made by customer.
14.Unapproved and not signed by the customer documents are invalid in warranty.

15.Responsible is belong to dealers, agents or representatives of the manufacturer for filling in the
warranty document.
16.Purchased products are out of warranty in all kinds of changes to the warranty certificate.
Çelikel Tarım Makineleri San. ve Tic. Ltd. Şti
3. OSB İhsan Dede Cad. 13. Sok. No:10
Selçuklu / KONYA/ TÜRKİYE
[phone]
[e-mail]
Product Name : CHARGER V………
Model of Machine :
Serial Number :
Delivery Time :
Production Year :
Seller Company / Authorized Service
Stamp :
Sign :

MODEL AND SERIAL NUMBER INFORMATION
The serial number tag is located on the front lower panel.

SAFETY
Failure to follow instructions and safety precautions in this manual and in the safety decals
could result in severe injury or death.
Any person who will be operating or maintaining this mixer should first
read and understand this manual and all safety warnings on the unit.
This instruction manual should always be available to those responsible for
the operation and maintenance of this mixer.
Any person who does not understand the safety and operation instructions
contained in this manual should not be considered qualified to operate this
mixer.
Shut off engine and remove key before performing maintenance or repair
work.
Make sure the tractor is correctly positioned. The weight on the front of
the vehicle must be maximum 1500 kg. Please be sure that speed of PTO
not to fall under 540 RPM.

Always fire extinguisher should be kept on the tractor.
The tractor must always be taken first aid kit.
Keep riders off. Riders are subject to injury such as being struck by foreign
objects and being thrown off. Riders also obstruct the operator’s view
resulting in the machine being operated in an unsafe manner.
The person who will use the tractor must not be tired and sleepless.

Do not start the machine when someone around the tractor. Please try to
be safe from tractor and machine as much as possible when they are about
to work and have worked.
It is the responsibility of the customer to know the lighting and marking
requirements of the local highway authorities and to install and
maintain the equipment to provide compliance with the regulations.
Add extra lights when transporting at night or during periods of limited
visibility.
Danger from flying objects. Keep a safe distance from this
machine.
Please note that the rotating and moving parts of the machine have
pinching and pressing danger. Do not open or remove safety guards while
the feeder is connected to the tractor.

Avoid approaching any object while the machine is in motion. Please wait
until to intervene the machine completely immobile position. Stay clear of
sharp blade.
Do not operate mixer/feeder without safety shields in place. Rotating parts
can crush or dismember causing personal injury or death. Disconnect PTO
driveline before removing shields for adjustment or service.
Entanglement in rotating driveline can cause serious injury or death. Keep
tractor master shield and driveline shields in place at all times. Make sure
rotating shields turn freely. Wear close fitting clothing. Stop the engine and
be sure PTO driveline is stopped before making adjustments, connections,
or cleaning out PTO driven equipment.
High pressure oil easily punctures skin causing serious injury, gangrene or
death. İt injured, seek emergency medical help, immediate surgery is
required to remove oil. Do not use finger or skin to check for leaks. Lower
load or relieve hydraulic pressure before loosening fittings.
