Cessna 206 Owner's manual

ISSUE DATE:
PO Box 2119
265 Shannon Lane
Priest River ID 83856
Page
1 of 38
8/23/10
INCORPORATED
FILE NO.
REVISION
DATE
TITLE: Supplemental Airplane Flight Manual
A-10060
03/04/15
SUBTITLE:
Cessna 206 on Model 3400 Floats
REVISION: D
FAA APPROVED
SUPPLEMENTAL AIRPLANE FLIGHT MANUAL
FOR
CESSNA 206 SERIES FLOATPLANES
MODELS: 206, P206, P206A-E, U206, U206A-G,
TU206A-G, TP206A-E, T206H
Equipped With AEROCET 3400 Amphibious Seaplane Floats
Registration No.__________________
Serial No._________________
The information contained in this document is FAA approved material
which must be applied together with the basic FAA approved airplane
placards and markings and/or FAA approved Airplane Flight Manual. This
supplemental manual must be carried in the airplane when it is modified by
the installation of the Aerocet Model 3400 amphibious seaplane floats in
accordance with Supplemental Type Certificate (STC) No. SA01257SE.
The information contained in this document supersedes the basic airplane
markings and placards and/or Flight Manual covered in the items contained
herein. For Limitations, Procedures, and Performance information not
contained in this supplement, consult the basic airplane markings and
placards, and/or Flight Manual.
FAA Approved: ________________________
Manager, Seattle Aircraft Certification Office
Date: ______________

ISSUE DATE:
PO Box 2119
265 Shannon Lane
Priest River ID 83856
Page
3 of 38
8/23/10
INCORPORATED
FILE NO.
REVISION
DATE
TITLE: Supplemental Airplane Flight Manual
A-10060
03/04/15
SUBTITLE:
Cessna 206 on Model 3400 Floats
REVISION: D
FAA Approved
SECTION 1. GENERAL
This supplemental manual, applicable to those Cessna Model 206 Series
airplanes equipped with Aerocet Model 3400 Amphibious Seaplane Floats,
provides information and limitations not included in the basic FAA
approved markings and placards, and/or Airplane Flight Manual. Whenever
the words "Not Applicable" (NA) appear in this supplemental manual, they
are used to indicate that the related information may not be the same as that
shown in the Cessna markings and placards, and/or Flight Manual and are
not required by the airplane certification basis and, therefore, should not be
referenced. The aircraft is to be operated under the "NORMAL
CATEGORY" only.
PERFORMANCE – SPECIFICATIONS
(for model T206H see Section 5 for additional performance information)
SPEED: NA
CRUISE: NA
RATE OF CLIMB AT SEA LEVEL: EXCEEDS 550 FPM (CAR 3.85a)
SERVICE CEILING: NA
TAKEOFF PERFORMANCE ON WATER: NA
LANDING PERFORMANCE ON WATER: NA
TAKEOFF PERFORMANCE ON LAND: Increase take-off roll distance
by 10% factored @ 3600 Gross Weight Pounds using Hartzell PHC-C3YF-
1RF/F8468A-6R propeller
LANDING PERFORMANCE ON LAND: Increase landing roll distance
by 16% factored @ 3600 Gross Weight Pounds
STALL SPEED (POWER OFF, FORWARD CG @ 3744 lbs):
FLAPS UP: 61 KCAS
FLAPS DOWN 30º: 54 KCAS
MAXIMUM WEIGHT:
RAMP or DOCK: 3755 LBS.
TAKE-OFF FLOATS: 3744 LBS.
LANDING FLOATS: 3661 LBS.
TAKE-OFF WHEELS: 3735 LBS.
LANDING WHEELS: 3550 LBS.
EMPTY WEIGHT: SEE ACTUAL WT. & BALANCE FORM FOR
AIRCRAFT
MAXIMUM USEFUL LOAD: REF. ACTUAL WT. & BALANCE FORM
FOR A/C

ISSUE DATE:
PO Box 2119
265 Shannon Lane
Priest River ID 83856
Page
4 of 38
8/23/10
INCORPORATED
FILE NO.
REVISION
DATE
TITLE: Supplemental Airplane Flight Manual
A-10060
03/04/15
SUBTITLE:
Cessna 206 on Model 3400 Floats
REVISION: D
FAA Approved
PERFORMANCE – SPECIFICATIONS (Cont’d)
BAGGAGE ALLOWANCE:
IN AIRPLANE: NO CHANGE
IN EACH FLOAT: 100 LBS.
(CAUTION: ASSURE CG RANGE IS PROPER WHEN LOADING)
WING LOADING: NA
POWER LOADING: NA
RANGE: NA
FUEL CAPACITY: NO CHANGE
OIL CAPACITY: NO CHANGE
ENGINE: NO CHANGE
PROPELLER: One of the following propellers is required.
Models A through G:
The propeller installation is not covered by this STC and must be FAA
approved by a separate FAA approval, (such as TCDS, STC, or 337).
•Hartzell PHC-C3YF-1RF/F8468A-6R or greater in approved
diameter
•Hartzell PHC-C3YF-1RF/F8068-2 (-0 ok)
•Hartzell PHC-J3YF-1RF/F8068-2 (-0 ok)
•McCauley D3A34C401/90DFA-2 (-4,-8,-10 ok)
•McCauley D3A34C402/90DFA-2 (-4,-8,-10 ok)
Models H only:
•Hartzell HC-F3YR-1RF/F8468A-2R (-4R, -6R ok)
i.a.w. Aerocet STC
•McCauley B3D36C432/80VSA -1 (not less than 77.5")
i.a.w. Cessna TCDS

ISSUE DATE:
PO Box 2119
265 Shannon Lane
Priest River ID 83856
Page
5 of 38
8/23/10
INCORPORATED
FILE NO.
REVISION
DATE
TITLE: Supplemental Airplane Flight Manual
A-10060
03/04/15
SUBTITLE:
Cessna 206 on Model 3400 Floats
REVISION: D
FAA Approved
SECTION 2. LIMITATIONS
CENTER OF GRAVITY LIMITS:
Center of Gravity Range: (inches aft of reference datum –front face of
firewall)
(+42.1) to (+47.4) at 3744 lbs. Maximum G.W.
(+36.5) to (+47.4) at 2600 lbs. or less with a straight line
variation between points given.
WEIGHT LIMITS:
Maximum Ramp or Dock: 3755 lbs.
Maximum Take-off Floats: 3744 lbs.
Maximum Landing Floats: 3661 lbs.
Maximum Take-off Wheels: 3735 lbs.
Maximum Landing Wheels: 3550 lbs.
Maximum Weight in Baggage Compartment: NO CHANGE
Maximum Weight in Float Baggage Compartment: 100 lbs. each
AIRSPEED LIMITS:
KC AS KIAS
MPH
CAS
MPH
IAS
Never Exceed Speed (Vne)
No Change No Change No Change No Change
Max St ruct ur al Cruising (Vno )
No Change No Change No Change No Change
Max Maneuvering Speed (Va)
No Change No Change No Change No Change
Max. Speed with Flaps (Vfe)
No Change No Change No Change No Change
Max Ldg. Gear Operating Speed (Vlo) 118 120 136 138
Max Ldg. Gear Extended Speed (Vle) 148 150 170 172

ISSUE DATE:
PO Box 2119
265 Shannon Lane
Priest River ID 83856
Page
6 of 38
8/23/10
INCORPORATED
FILE NO.
REVISION
DATE
TITLE: Supplemental Airplane Flight Manual
A-10060
03/04/15
SUBTITLE:
Cessna 206 on Model 3400 Floats
REVISION: D
FAA Approved
MANEUVER LIMITS
The maneuver limits defined in the basic handbook are applicable to the
amphibian.
“Avoid slips with wing flaps extended”
FLAP LIMITATIONS
Approved Takeoff Range: 0° to 20°.
Approved Runway Landing Range: 0° to 30°.
Approved Water Landing Range: 0° to 30°.
NOTE: Wing flaps must be retracted to 20° immediately
following power application for a balked landing go-around.
AIR SPEED INDICATOR MARKINGS:
The airspeed indicator markings are the same as shown in the basic
markings/Flight manual. Due to differences in airspeed calibration and
speeds with floats installed, the indicated stall speeds and maximum
structural cruising speed vary slightly from airspeed indicator markings.
PLACARDS:
1. Aerocet P/N 35A-59330 Placard is located in plain view of the pilot:
“EMERGENCY
LANDING GEAR OPERATION
If electric driven hydraulic pump fails, use hand
operated pump to retract and extend landing gear.
Land on sod if gear position is unknown.
DO NOT LAND ON WATER UNLESS
GEAR IS FULLY RETRACTED”

ISSUE DATE:
PO Box 2119
265 Shannon Lane
Priest River ID 83856
Page
7 of 38
8/23/10
INCORPORATED
FILE NO.
REVISION
DATE
TITLE: Supplemental Airplane Flight Manual
A-10060
03/04/15
SUBTITLE:
Cessna 206 on Model 3400 Floats
REVISION: D
FAA Approved
PLACARDS: (Cont’d)
2. Aerocet P/N 36-15605 Placard is located near the emergency gear hand
pump:
“EMERGENCY HAND PUMP
OPERATING INSTRUCTIONS
1. Pull landing gear motor circuit breaker.
2. Move landing gear position switch to
desired position.
3. Rotate emergency gear selector valve to
desired position.
4. Pump emergency gear hydraulic pump until
gear lights show for desired position and
there is significant force on the pump
handle.
Always keep gear selector valve in OFF
position (detent engaged –handle pointed
toward pilot seat) except for emergency
operation.”
3.Aerocet P/N 35A-59332 Placard is located on the instrument panel:
“IN FLOATPLANE, AMPHIBIAN AND SKIPLANE RETRACT
FLAPS TO 20° IMMEDIATELY AFTER APPLYING POWER FOR
BALKED LANDING GO-AROUND.”
4. Refer to Cessna type data for required fuel placards.

ISSUE DATE:
PO Box 2119
265 Shannon Lane
Priest River ID 83856
Page
8 of 38
8/23/10
INCORPORATED
FILE NO.
REVISION
DATE
TITLE: Supplemental Airplane Flight Manual
A-10060
03/04/15
SUBTITLE:
Cessna 206 on Model 3400 Floats
REVISION: D
FAA Approved
PLACARDS: (Cont’d)
5. Aerocet P/N 35A-59334 Placard on instrument panel:
“IN FLOATPLANE, AMPHIBIAN AND SKIPLANE AVOID SLIPS
WITH FLAPS EXTENDED.”
6. Aerocet P/N 35-70006 Placard is located on aft part of console near
water rudder handle in the "RETRACT" position:
"WATER RUDDER
ALWAYS UP
EXCEPT
WATER TAXIING"
7. Aerocet P/N 35-70011 Placard is located in plain view of the pilot:
"AVOID TAIL-LOW TAKEOFFS AND LANDINGS
WITH FLOATPLANE STINGER INSTALLED
DURING OPERATIONS AS A LANDPLANE
8. Aerocet P/N 36-15601 Placard is located inside the float locker panels:
"MAX BAGGAGE: 100 LBS.
ARM: 32.4 in. AFT DATUM
9. Circuit Breaker Placards:
“PUMP PWR”, “PUMP RELAYS”, “GR. ADV. ELEC.”

ISSUE DATE:
PO Box 2119
265 Shannon Lane
Priest River ID 83856
Page
9 of 38
8/23/10
INCORPORATED
FILE NO.
REVISION
DATE
TITLE: Supplemental Airplane Flight Manual
A-10060
03/04/15
SUBTITLE:
Cessna 206 on Model 3400 Floats
REVISION: D
FAA Approved
SECTION 3. EMERGENCY PROCEDURES:
Emergency procedures in the FAA approved airplane placards and/or Flight
Manual generally apply except for airspeeds which may be different.
Emergency landings on water should be done with water rudders up,
aircraft slightly tail low on touchdown, and control wheel held full aft as the
floatplane decelerates on the water. Emergency landings on land should be
done with water rudders up, aircraft in a level attitude on touchdown, and
the control wheel full aft after contact. If damage occurs to the floats
causing compartments to flood, aggressively shift the weight (people &
baggage) in the opposite direction of damage in order to balance the aircraft
over the buoyant compartments.
EMERGENCY OPERATIONAL CHECKLISTS
ENGINE FAILURE
ENGINE FAILURE DURING TAKEOFF RUN (ON WATER)
1. Throttle -- IDLE.
2. Control Wheel -- FULL AFT.
3. Mixture -- IDLE CUT-OFF.
4. Ignition Switch -- OFF.
5. Master Switch -- OFF.
ENGINE FAILURE DURING TAKEOFF RUN (ON LAND)
1. Throttle -- IDLE.
2. Brakes -- APPLY.
3. Wing Flaps -- RETRACT.
4. Mixture -- IDLE CUT-OFF.
5. Ignition Switch -- OFF.
6. Master Switch -- OFF.

ISSUE DATE:
PO Box 2119
265 Shannon Lane
Priest River ID 83856
Page
10 of 38
8/23/10
INCORPORATED
FILE NO.
REVISION
DATE
TITLE: Supplemental Airplane Flight Manual
A-10060
03/04/15
SUBTITLE:
Cessna 206 on Model 3400 Floats
REVISION: D
FAA Approved
FORCED LANDINGS
EMERGENCY LANDING ON WATER WITHOUT ENGINE POWER
1. Landing Gear -- UP.
2. Airspeed -- 79 KIAS (flaps UP) 72 KIAS (flaps DOWN).
3. Mixture -- IDLE CUT-OFF.
4. Fuel Shutoff Valve -- OFF.
5. Ignition Switch -- OFF.
6. Master Switch -- OFF.
7. Water Rudders -- UP.
8. Wing Flaps -- AS REQUIRED.
9. Doors -- UNLATCH PRIOR TO TOUCHDOWN.
10. Touchdown -- SLIGHTLY TAIL LOW.
11. Control Wheel -- HOLD FULL AFT as amphibian decelerates.
EMERGENCY LANDING ON LAND WITHOUT ENGINE POWER
1. Landing Gear -- UP on soft or rough ground. DOWN on firm and
smooth ground.
2. Airspeed -- 79 KIAS (flaps UP) 72 KIAS (flaps DOWN).
3. Mixture -- IDLE CUT-OFF.
4. Fuel Shutoff Valve -- OFF.
5. Ignition Switch -- OFF.
6. Master Switch -- OFF.
7. Water Rudders -- UP.
8. Wing Flaps -- AS REQUIRED (30° recommended).
9. Doors -- UNLATCH PRIOR TO TOUCHDOWN.
10. Touchdown -- LEVEL ATTITUDE (if gear is up). SLIGHTLY TAIL
LOW (if gear is down).
11. Control Wheel -- FULL AFT (after contact if gear is up).
12. Brakes -- APPLY HEAVILY (if gear is down).

ISSUE DATE:
PO Box 2119
265 Shannon Lane
Priest River ID 83856
Page
11 of 38
8/23/10
INCORPORATED
FILE NO.
REVISION
DATE
TITLE: Supplemental Airplane Flight Manual
A-10060
03/04/15
SUBTITLE:
Cessna 206 on Model 3400 Floats
REVISION: D
FAA Approved
LANDING GEAR MALFUNCTION PROCEDURES
LANDING GEAR FAILS TO RETRACT
1. Master Switch -- ON.
2. Landing Gear Handle -- CHECK (handle full up).
3. Landing Gear Motor Circuit Breaker -- IN.
4. Emergency Hand Pump Selector Valve -- CHECK (in off position –
toward pilot seat).
5. Gear Relay Circuit Breaker -- IN.
6. Gear Advisory Circuit Breaker -- IN.
7. Gear Up Lights -- CHECK bulb operation (press-to-test).
8. Main Gear Visual Indicators -- VISUALLY CHECK (at float
inspection openings).
9. Landing Gear Handle -- RECYCLE.
10. Landing Gear Motor -- CHECK operation (motor indicator light,
ammeter and noise).
11. Cycle the Emergency Hand Pump Selector Valve to UP position and
back to OFF (this reduces pressure in the system allowing the pressure
switches to sense low pressure allowing the pump to cycle).
If the landing gear still does not retract and a water landing is desired:
12. Landing Gear Motor Circuit Breaker -- PULL.
13. Landing Gear Handle -- UP.
14. Emergency Hand Pump Selector Valve -- ROTATE (to UP position –
clockwise 90 deg.).
15. Emergency Hand Pump -- PUMP (up and down until gear is in UP
position - approximately 165 strokes -- there should be significant
force on the pump handle with the final stroke).
16. Gear Up Lights -- CHECK ILLUMINATED.
17. Main Gear Visual Indicators -- VISUALLY CHECK (at float
inspection openings). Nose gear -- VISUALLY CHECK (gear is nested
in the bow of the float).

ISSUE DATE:
PO Box 2119
265 Shannon Lane
Priest River ID 83856
Page
12 of 38
8/23/10
INCORPORATED
FILE NO.
REVISION
DATE
TITLE: Supplemental Airplane Flight Manual
A-10060
03/04/15
SUBTITLE:
Cessna 206 on Model 3400 Floats
REVISION: D
FAA Approved
LANDING GEAR MALFUNCTION PROCEDURES
LANDING GEAR FAILS TO EXTEND
1. Master Switch -- ON.
2. Landing Gear Handle -- CHECK (handle full down).
3. Emergency Hand Pump Selector Valve -- CHECK (in off position –
toward pilot seat)
4. Landing Gear Motor Circuit Breaker -- IN.
5. Gear Relay Circuit Breaker -- IN.
6. Gear Advisory Circuit Breaker -- IN.
7. Gear Down Lights -- CHECK bulb operation (press-to-test).
8. Main Gear Visual Indicators -- VISUALLY CHECK (at float
inspection openings).
9. Landing Gear Handle -- RECYCLE.
10. Landing Gear Motor -- CHECK operation (motor indicator light,
ammeter and noise).
11. Cycle the Emergency Hand Pump Selector Valve to DOWN position
and back to OFF (this reduces pressure in the system allowing the
pressure switches to sense low pressure allowing the pump to cycle).
If the landing gear still does not extend and a wheels-down landing is
desired:
12. Landing Gear Motor Circuit Breaker -- PULL.
13. Landing Gear Handle -- DOWN.
14. Emergency Hand Pump Selector Valve -- ROTATE (to DOWN
position – counterclockwise 90 deg.).
15. Emergency Hand Pump -- PUMP (up and down until gear is in DOWN
position - approximately 230 strokes -- there should be significant
force on the pump handle with the final stroke).
16. Gear Down Lights -- CHECK ILLUMINATED.
17. Main & Nose Gear Visuals -- VISUALLY CHECK (with mirrors &
note that the up indicators on the mains are not visible at the float
inspection openings).

ISSUE DATE:
PO Box 2119
265 Shannon Lane
Priest River ID 83856
Page
13 of 38
8/23/10
INCORPORATED
FILE NO.
REVISION
DATE
TITLE: Supplemental Airplane Flight Manual
A-10060
03/04/15
SUBTITLE:
Cessna 206 on Model 3400 Floats
REVISION: D
FAA Approved
GEAR UP LANDING (ON LAND)
1. Landing Gear -- CHECK UP (indicator lights and main gear latch
fittings).
2. Runway -- SELECT longest smooth ground or grass surface available.
3. Wing Flaps -- 30° (on final approach).
4. Airspeed -- 72 KIAS.
5. Master Switch -- OFF.
6. Doors -- UNLATCH PRIOR TO TOUCHDOWN.
7. Touchdown -- LEVEL ATTITUDE.
8. Control Wheel -- FULL AFT (after contact).
9. Mixture -- IDLE CUT-OFF.
10. Fuel Shutoff Valve -- OFF.
11. Ignition Switch -- OFF.
AMPLIFIED PROCEDURES
MECHANICAL FAILURE
If it is ascertained that a mechanical failure has occurred and the gear will
not achieve either a gear up or a gear down position with visual
confirmation, the best course of action will be dependent upon the nature of
the failure and the choices of landing surfaces available. In the unlikely
event that a landing gear has failed in an intermediate position, and cannot
be moved to either a Gear Up or Gear Down position, the amphibian should
be landed on land only.
- WARNING -
DO NOT land in the water with the wheels either partially or fully
extended. If the landing MUST be accomplished on water and the gear is
partially or fully extended, it is suggested that a power-on full stall landing
with full flaps (30°) would be the best procedure. Unlatch cabin doors prior
to touchdown except for the rear cargo door on the co-pilots side. Flaps
must be deployed prior to unlatching the rear cargo door otherwise the flaps
will not move with the door unlatched. During deceleration after
touchdown, with the gear extended, the float bows will submerge and
there is a high probability of flipping the amphibian onto its back
causing either fatal or serious injury.

ISSUE DATE:
PO Box 2119
265 Shannon Lane
Priest River ID 83856
Page
14 of 38
8/23/10
INCORPORATED
FILE NO.
REVISION
DATE
TITLE: Supplemental Airplane Flight Manual
A-10060
03/04/15
SUBTITLE:
Cessna 206 on Model 3400 Floats
REVISION: D
FAA Approved
SECTION 4. NORMAL PROCEDURES: (NOTE: THESE ITEMS
SUPPLEMENT THE CESSNA NORMAL PROCEDURES - BE SURE TO
FOLLOW THE CESSNA PROCEDURES EXCEPT AS NOTED BELOW)
BEFORE ENTERING FLOATPLANE
1. Inspect the floats and attachment for dents, cracks, punctures, etc.
2. Remove rubber plugs (which serve as stoppers on the standpipe in each
float compartment) and pump out any accumulation of water. Reinstall
rubber stoppers with enough pressure for a snug fit. (If there is an
excess of water, investigate the leakage - if there is red hydraulic fluid
in any water, investigate fittings and lines in that bay before
proceeding).
3. Landing Gear -- INSPECT. Check the main wheel oleo struts for
proper inflation; check the tires for cuts, bruises and proper inflation.
NOTE
Refer to placards on the main wheel oleo struts for
strut inflation procedures. Proper tire inflation for
6.00-6 main wheel tires is 55 psi; tire inflation for
the 10-3.50 nose wheel tires is 70 psi.
4. Inspect locker door latches – DETENTS ENGAGED, LATCHES
TURNED CLOCKWISE TO STOPS.
NOTE:
An un-latched locker bay door will cause a howl and may
bang against the float struts during flight. Aircraft should
be returned to field in normal fashion to avoid potential
damage, and to assess any possible problems. However,
as with any situation, “FLY THE AIRCRAFT!” rather
than make a rash decision. It is likely that little or no
damage will occur to locker door.
WARNING:
It is up to the pilot to determine whether the floats have taken on
water, which could adversely affect CG. Pump both floats before
every flight.

ISSUE DATE:
PO Box 2119
265 Shannon Lane
Priest River ID 83856
Page
15 of 38
8/23/10
INCORPORATED
FILE NO.
REVISION
DATE
TITLE: Supplemental Airplane Flight Manual
A-10060
03/04/15
SUBTITLE:
Cessna 206 on Model 3400 Floats
REVISION: D
FAA Approved
BEFORE STARTING ENGINE
1. Landing Gear Handle – DOWN (amphibian on land), or UP
(amphibian on water)
2. Water Rudder Operation – CHECK VISUALLY
3. Water Rudders – DOWN FOR TAXIING ON WATER – UP FOR
TAXIING ON LAND
4. Water Rudders – CHECK FREEDOM OF MOVEMENT &
SECURITY
BEFORE TAKEOFF
TAKEOFF
TAKEOFF ON WATER
1. Landing Gear – UP
2. Landing Gear Blue Indicator Lights – CHECK ILLUMINATED
3. Water Rudders – UP (retraction handle aft)
4. Wing Flaps – 20 DEGREES" (second notch)
5. Control Wheel – HOLD FAR AFT INITIALLY
6. Power – FULL THROTTLE & MAX RPM (advance slowly)
7. Mixture – LEAN FOR HIGH DENSITY ALTITUDE
8. Control Wheel – MOVE FORWARD TO ATTAIN PLANING
ATTITUDE
9. Control Wheel – APPLY LIGHT BACK PRESSURE TO LIFT OFF
10. Wing Flaps – UP AFTER OBSTACLES ARE CLEARED
Never attempt a takeoff without all blue indicator lamps illuminated –
any gear hanging down will drag the aircraft dangerously into an arc,
compromising takeoff distances, and endangering the occupants.
WARNING:
It is up to the pilot to determine whether the floats have taken on
water, which could adversely affect CG. Pump both floats before
every flight.

ISSUE DATE:
PO Box 2119
265 Shannon Lane
Priest River ID 83856
Page
16 of 38
8/23/10
INCORPORATED
FILE NO.
REVISION
DATE
TITLE: Supplemental Airplane Flight Manual
A-10060
03/04/15
SUBTITLE:
Cessna 206 on Model 3400 Floats
REVISION: D
FAA Approved
TAKEOFF ON LAND
1. Landing Gear – DOWN
2. Landing Gear Amber Indicator Lights – CHECK ILLUMINATED
3. Water Rudders – UP (retraction handle aft)
4. Wing Flaps – 20 DEGREES (second notch)
5. Power – FULL THROTTLE & MAX RPM (advance slowly)
6. Mixture – LEAN FOR HIGH DENSITY ALTITUDE
7. Control Wheel – APPLY LIGHT BACK PRESSURE TO LIFT OFF
8. Wing Flaps – UP AFTER OBSTACLES ARE CLEARED
9. Landing Gear – UP
BEFORE LANDING
BEFORE LANDING ON WATER
1. Landing Gear -- UP.
2. Landing Gear Blue Indicator Lights -- CHECK ILLUMINATED.
3. Visually check that nose gear are UP
During deceleration after a water touchdown, with the gear extended,
the float bows will submerge and there is a high probability of flipping
the amphibian onto its back causing either fatal or serious injury.
4. Water Rudders -- UP.
5. Wing Flaps -- 30°.
BEFORE LANDING ON LAND
1. Landing Gear -- DOWN.
2. Landing Gear Amber Indicator Lights -- CHECK ILLUMINATED.
3. Water Rudders -- UP.
4. Wing Flaps -- 30°.
LANDING
LANDING ON WATER
1. Touchdown -- SLIGHTLY TAIL LOW.
2. Control Wheel -- HOLD FULL AFT as amphibian decelerates to taxi
speed.
3. After landing – WATER RUDDERS DOWN

ISSUE DATE:
PO Box 2119
265 Shannon Lane
Priest River ID 83856
Page
17 of 38
8/23/10
INCORPORATED
FILE NO.
REVISION
DATE
TITLE: Supplemental Airplane Flight Manual
A-10060
03/04/15
SUBTITLE:
Cessna 206 on Model 3400 Floats
REVISION: D
FAA Approved
LANDING ON LAND
1. Touchdown -- SLIGHTLY TAIL LOW.
2. Control Wheel -- EASE FORWARD to lower wheels gently to
runway.
3. Braking -- MINIMUM REQUIRED
BALKED LANDING – "RETRACT FLAPS TO 20 DEG.
IMMEDIATELY AFTER APPLYING FULL POWER FOR
GO-AROUND"
SECURING AIRPLANE - "FUEL SELECTOR TO RIGHT OR LEFT
TANK POSITION TO PREVENT CROSSFEEDING"

ISSUE DATE:
PO Box 2119
265 Shannon Lane
Priest River ID 83856
Page
18 of 38
8/23/10
INCORPORATED
FILE NO.
REVISION
DATE
TITLE: Supplemental Airplane Flight Manual
A-10060
03/04/15
SUBTITLE:
Cessna 206 on Model 3400 Floats
REVISION: D
FAA Approved
SECTION 5. PERFORMANCE:
ALL MODELS EXCEPT T206H:
Airspeed Calibration - Essentially unchanged
STALL SPEEDS:
POWER OFF, FORWARD CG, 3744 LBS
FLAPS UP: 61 KCAS 70 MPH CAS
FLAPS DOWN (30 Deg.): 54 KCAS 62 MPH CAS
NOTE
ALTITUDE LOSS DURING STALL RECOVERY
MAY BE AS MUCH AS 200 FEET.
CLIMB RATE: EXCEEDS 550 FPM (CAR 3.85a)
MODEL T206H:
The following information is valid for model T206H which has a
turbocharged Lycoming engine (310 hp).
GLIDE
In the event of engine failure enroute with propeller wind milling, landing
gear up, flaps up.
RECCOMENDED GLIDE SPEED 83 KCAS 95 MPH CAS
Maximum horizontal distance traveled in still air
1.5 NM PER 1,000 FT ALTITUED LOST
SINK RATE 1,000 FPM

ISSUE DATE:
PO Box 2119
265 Shannon Lane
Priest River ID 83856
Page
19 of 38
8/23/10
INCORPORATED
FILE NO.
REVISION
DATE
TITLE: Supplemental Airplane Flight Manual
A-10060
03/04/15
SUBTITLE:
Cessna 206 on Model 3400 Floats
REVISION: D
FAA Approved
FLAPS UP
KIAS
60 70 80 90 100 110 120 130 140 150 160 170 180
KCAS
61 70 78 87 96 106 115 125 135 146 157 168 179
FLAPS 20°
KIAS
50 60 70 80 90 100 --- --- --- --- --- --- ---
KCAS
52 60 69 79 89 100 --- --- --- --- --- --- ---
FLAPS 30°
KIAS
50 60 70 80 90 100 --- --- --- --- --- --- ---
KCAS
54 61 70 80 91 104 --- --- --- --- --- --- ---
AIRSPEED CALIBRATION
NORMAL STATIC SOURCE
C OND ITIO NS :
Power Off
WE IGHT FLAP 0 ° 30 °45 °60 °
LBS DEFLECTION KIAS KCAS KIAS KCAS KIAS KCAS KIAS KCAS
3744 UP
59 60 64 64 70 71 84 84
20°
54 55 57 59 64 65 76 77
30°
49 53 52 57 58 64 69 76
NOTES:
1. Altitude loss during a stall recovery may be as much as 360 feet.
2. KIAS values are approximate.
STALL SPEEDS
MOST FORWARD CENTER OF GRAVITY
ANGLE OF BANK

ISSUE DATE:
PO Box 2119
265 Shannon Lane
Priest River ID 83856
Page
20 of 38
8/23/10
INCORPORATED
FILE NO.
REVISION
DATE
TITLE: Supplemental Airplane Flight Manual
A-10060
03/04/15
SUBTITLE:
Cessna 206 on Model 3400 Floats
REVISION: D
FAA Approved
C OND ITIO NS :
Landing Gear Down, Flaps 20°
2500 RPM, 39 inHg Manifold Pressure
Paved, Level, Dry Runway
Zero Wind
Liftoff Speed: 57 KIAS (approximately)
Speed at 50 Ft: 69 KIAS
Grnd Total Grnd Total Grnd Total Grnd Total Grnd Total Grnd Total
Press Roll Ft To Roll Ft To Roll Ft To Roll Ft To Roll Ft To Roll Ft To
Alt Ft Clear Ft Clear Ft Clear Ft Clear Ft Clear Ft Clear
In 50 Ft 50 Ft 50 Ft 50 Ft 50 Ft 50 Ft
Feet
Obstacle
Obstacle
Obstacle
Obstacle
Obstacle
Obstacle
S.L. 1523 2324 1611 2442 1703 2565 1798 2692 1896 2824 1997 2960
1000 1596 2449 1691 2576 1788 2709 1889 2846 1994 2988 2102 3134
2000 1676 2584 1776 2722 1880 2864 1988 3012 2100 3165 2215 3323
3000 1761 2731 1868 2879 1979 3033 2094 3193 2214 3357 2337 3527
4000 1852 2890 1967 3050 2086 3217 2209 3389 2337 3566 2469 3750
5000 1951 3063 2074 3236 2201 3416 2333 3601 2469 3794 2611 3992
6000 2058 3251 2189 3438 2325 3632 2466 3833 2612 4041 2764 4256
7000 2174 3455 2314 3658 2459 3868 2610 4085 2767 4310 2930 4543
8000 2298 3678 2448 3897 2604 4124 2766 4124 2935 4604 3109 4856
9000 2433 3920 2594 4158 2761 4404 2935 4659 3116 4924 3303 5198
10000 2579 4185 2752 4443 2932 4710 3119 4987 3313 5274 3514 5572
NOTES:
1. Obstacle takeoff technique as described in Section 4.
2. If brakes are not held, distances are from point where takeoff power is reached.
3. Decrease distances 10% for each 15 knots headwind. For operation
in tailwinds up to 10 knots, increase distances by 10% for each 3 knots.
4. For operation on dry, grass, hard runway, increase distances by 15% of
the "ground roll" figure.
5. For operation in air colder than this table provides, use the coldest (leftmost)
data for takeoff distances.
6. For operation in air warmer than this table provides, use extreme caution.
7. In grey shaded areas total takeoff distances over a 50 foot obstacle are predicted to
exceed 1 mile. Use caution!
OBSTACLE TAKEOFF DISTANCE FROM GROUND
3735 POUNDS
40°C
50°C
0°C
10°C
20°C
30°C
MAXIMUM TAKEOFF WEIGHT ON GROUND
