CEStronics Omega Flex Manual

OMEGA FLEX Radio switch
Fitting and Operating Instructions
Translated fitting and
operating instructions
version 1.3, 02/2015

Contents
Page 2 of 51
OMEGA FLEX Radio switch
1Contents
2Notes on the layout ................................................ 4
3Preface ................................................................... 5
3.1 Remarks ........................................................5
3.2 Manufacturer and Service.................................5
3.3 Target group ..................................................6
4For your safety.................................................. 7
4.1 Explanation of the safety notes .........................7
4.2 Intended use ..................................................7
4.3 CE Declaration of Conformity ............................8
4.4 Basic safety instructions...................................9
5Introduction ......................................................... 12
5.1 Description................................................... 12
5.2 Scope of delivery .......................................... 13
5.3 System components ...................................... 14
5.4 Master media ............................................... 15
6Fitting and commissioning ................................... 22
7Operating the door lock........................................ 26
8Lost master or locking medium ............................ 30
9Maintenance ......................................................... 31
10 Care...................................................................... 31
11 Spare Parts........................................................... 31
12 Trouble-shooting .................................................. 32
13 Disposal ............................................................... 33
14 Technical data ...................................................... 34
15 Glossary ............................................................... 36
16 Overview of the signals ........................................ 37
16.1 Signalling at the locking device ....................... 39

Contents
OMEGA FLEX Radio switch
Page 3 of 51
17 Concise Programming Guide................................. 40
17.1 Enabling and disabling learning mode .............. 41
17.2 Authorizing locking devices............................. 42
17.3 Enabling and disabling RF mode
(RF-INI-MASTER).......................................... 43
17.4 No RF link established.................................... 43
17.5 Authorizing optional media ............................. 44
17.6 Authorizing a locking medium ......................... 45
17.7 Deleting the authorization of a locking medium . 46
17.8 Deleting the authorizations of all locking media . 47
17.9 Using Emergency Key .................................... 47
18 Notes on the manufacturer's warranty................. 48
19 Index.................................................................... 49

Notes on the layout
Page 4 of 51
OMEGA FLEX Radio switch
2Notes on the layout
In these Fitting and Operating Instructions, various elements
are highlighted with defined layout features:
Additional information on the efficient use of the
OMEGA FLEX Radio switch
Reference to additional information
Notes on the correct disposal

Steps in a sequence of actions. Tips with this
symbol require you to perform an action

Preface
OMEGA FLEX Radio switch
Page 5 of 51
3Preface
These Fitting and Operating Instructions will help you fit and
use the OMEGA FLEX Radio switch (the "radio switch") as
intended, safely and advantageously.
Any person who programs, operates or disposes of this radio
switch must have read and understood the entire contents of
these Fitting and Operating Instructions.
These Fitting and Operating Instructions should be kept within
reach at all times as long as the radio switch is used.
These Fitting and Operating Instructions should be handed over
to the end users.

Be sure to use the most recent version of these
Fitting and Operating Instructions. Updated
versions are available free of charge at
www.ces.eu.
3.1 Remarks
These Fitting and Operating Instructions only apply to:
CEStronics OMEGA FLEX Radio switch, in all variants
3.2 Manufacturer and Service
The manufacturer from the radio switch is:
CEStronics GmbH
Friedrichstr. 243
42551 Velbert
Tel: [phone]
Fax: [phone]
www.ces.eu
For support in case of service please contact your CEStronics
partner.

Preface
Page 6 of 51
OMEGA FLEX Radio switch
3.3 Target group
These Fitting and Operating Instructions are intended for
trained fitting staff, maintenance staff and operators.
As regards the use of these Operating Instructions, it is
assumed that the necessary technical knowledge on how to use
the product as intended is available.
The necessary product training is provided by your professional
CEStronics partner. If this has not yet taken place, please
contact your professional CEStronics partner to obtain training
on the product.
NOTICE
Unintended condition of your system
possible!
If you are not fully familiar with the various
possibilities of your system, it may perform
unexpected functions.
If you program the OMEGA FLEX system, you
must be clearly aware of the consequences of
your programming to prevent undesired
results.
If there are functions of the OMEGA FLEX
system you do not understand, contact your
professional CEStronics partner to obtain
further information.
Always satisfy yourself that your programming
produces the desired result.

For your safety
OMEGA FLEX Radio switch
Page 7 of 51
4For your safety
4.1 Explanation of the safety notes
These Fitting and Operating Instructions include safety notes:
NOTICE
Attention notes warn against possible
property or environmental damage.
4.2 Intended use
The Radio switch serves to lock and unlock doors with locks for
which knob systems are permitted. It is exclusively intended
and may only be used for that purpose. The knob of the locking
cylinder must not be used for opening the door.
The radio switch must not be changed without our written
consent.
Any other use is considered to be improper and may result in
property damage or even personal injury.
CEStronics GmbH does not accept any liability for any damage
resulting from improper use.

For your safety
Page 8 of 51
OMEGA FLEX Radio switch
4.3 CE Declaration of Conformity

For your safety
OMEGA FLEX Radio switch
Page 9 of 51
4.4 Basic safety instructions
Observe all warnings and notes in these Fitting and Operating
Instructions when fitting, programming and using the radio
switch. Always keep these Fitting and Operating Instructions
near the radio switch.
To prevent danger to life and limb, the following safety
instructions must be observed:
4.4.1 Danger to life
Do not use the radio switch for doors with anti-panic
function, such as escape doors, for which a knob cylinder is
not permitted. Otherwise people may not be able to open
the door in emergencies and may be injured or killed.
Only use the radio switch for door locks for which knob
systems are permitted. In case of doubt, please contact the
manufacturer of the door or the door lock and satisfy
yourself that the radio switch is suitable for your door
system.
4.4.2 Danger of explosion
Live parts of the radio switch may cause an explosion. Do not
use the radio switch in potentially explosive atmospheres.
4.4.3 Danger of suffocation
Never allow children to play with packaging material and/or
plastic bags. There is a risk that children pull them over their
head and suffocate.
4.4.4 Danger of poisoning
Always keep the radio switch out of reach of children. There is
a risk that children swallow small parts such as batteries or
screws.

For your safety
Page 10 of 51
OMEGA FLEX Radio switch
4.4.5 Danger of property damage
To prevent property damage, the following safety instructions
should be observed:
Always have repairs performed by properly qualified
personnel.
Only use accessories and spare parts recommended by
CEStronics.
Do not use any drilling machines or cordless screwdrivers
when fastening the radio switch.
Only use the proper tools to open the locking device.
When fitting the locking device, make sure that the lock and
the plate/rose are in a perfect condition. Malfunctions of the
lock may impair the functioning of the locking device.
Make sure that the cylinder can be inserted through the
profile cylinder hole of the plate/rose and the lock without
jamming and without using force during the installation. If
this is not possible, align lock and plate/rose so as to
prevent jamming and/or bending of the locking cylinder
during its installation.
Do not use any lubricants or oils for the radio switch.
Do not drop the radio switch on the floor, on hard surfaces
or on hard objects.
Protect the electronic components of the radio switch
against water and other liquids.
The radio switch contains highly sensitive electronic parts
that may be damaged or destroyed through static charges.
Do not disassemble the radio switch in rooms with built up
static charge.
The inside knob of the locking cylinder/device may not be
used for outdoor application.

For your safety
OMEGA FLEX Radio switch
Page 11 of 51
4.4.6 Danger through environmental conditions
Do not use the radio switch in corrosive atmospheres
(chlorine, ammonia, lime water).
Only use the radio switch in rooms in which the humidity
does not exceed 95 %.
Do not use the radio switch in rooms with a high level of
dust formation.
Do not use the radio switch near sources of heat.
The Radio switch may only be exposed to temperatures
between 0 °C and +50 °C.
4.4.7 Danger of malfunctions
The reading units in the radio switch must not be covered with
any metallic material.

Introduction
Page 12 of 51
OMEGA FLEX Radio switch
5Introduction
5.1 Description
The radio switch is a simple, radio-frequency (RF) controlled
access organization system.
The radio switch comprises at least one OMEGA FLEX locking
cylinder or IES-shield by variant type /RF and one radio switch.
The electronic cylinder (locking device) can be controlled via
the radio switch from any existing access control system or
other devices that have a zero-potential switch as an enabling
element.
The radio switch evaluates the zero-potential switch and
enables the locking device via an AES encrypted RF signal.
The distance between the radio switch and the locking device
may be up to 10 m allowing a wide range of use of the devices
inside the building.
The radio switch was designed to allow incorporation in both
CES standard enclosures and existing devices of access control
systems.
The locking device comprises an RF transceiver and in addition
a Mifare reader and control unit so that in case of an
emergency, any Mifare Classic transponder may be used as a
key.
In case of a power failure or a failure of the access control
system, the user thus has a battery-operated locking device
with a Mifare transponder as an (emergency) key.
This means that the locking device can serve as an easily
installed replacement of electrical door openers or other actors
without requiring any wiring on the door.
Further applications are door intercoms, biometrical devices or
switching installations that permit a simple access control by
mobile phones.

Introduction
OMEGA FLEX Radio switch
Page 13 of 51
The device can be controlled via the radio switch from any
mobile or stationary device (such as GSM modems).
Up to four locking devices can be connected / registered with
one radio switch.
You can combine mechanical locking cylinders
and radio switches and/or access terminals in
one and the same locking system. In this case,
you can use transponder keys for both
mechanical and electronic locking cylinders from
CEStronics.
5.2 Scope of delivery
Before fitting and commissioning, please check the contents
of the package and the scope of delivery.
Check new devices for transport damage and inform your
dealer promptly if any damage is found.
Fig. 1 - Scope of delivery
1
Radio switch (Housing: CES Standard)
2
Power supply 12–24 V AC/DC

Introduction
Page 14 of 51
OMEGA FLEX Radio switch
5.3 System components
You can purchase various locking media from a
CEStronics partner to match your specific
requirements.
Fig. 2 –System components
1
Locking media: You can operate the locking device with
the following locking media:
transponder key
key fob
key fob slimLine
card.
2
Radio switch
3
Locking devices (locking cylinder, IES-shield)
4
SYSTEM-MASTER: The SYSTEM-MASTER is used to
authorize the PROGRAM-MASTERS for the system.
Each system has one and only one SYSTEM-MASTER.
5
PROGRAM-MASTER: The PROGRAM-MASTERS are used
to authorize locking media to operate the locking
cylinder.

Introduction
OMEGA FLEX Radio switch
Page 15 of 51
5.4 Master media
Further functions can be set manually using master media
without the need for auxiliary means such as PC or
programming cable/RF stick. You can obtain master media from
your CEStronics specialist partner:
5.4.1 SYSTEM-MASTER
The SYSTEM-MASTER grants all authorizations on the highest
level. For each locking system, there is one and only one valid
SYSTEM-MASTER.
With the SYSTEM-MASTER, you can authorize up to five
PROGRAM-MASTERS. In its basic version, a locking system
requires one SYSTEM-MASTER and one PROGRAM-MASTER
each to program your locking devices.
5.4.2 PROGRAM-MASTER
The PROGRAM-MASTER is used to authorize and delete the
authorization of your locking media.

Introduction
Page 16 of 51
OMEGA FLEX Radio switch
5.4.3 TIME-MASTER
With the TIME-MASTER, you set the opening time of the
locking device. During the opening time, your locking device
allows free access.
When the TIME-MASTER is detected, the locking device starts
beeping at one-second intervals until the TIME-MASTER is
removed out of the reading range.
The number of beeps determines the opening time.
To set the opening time of your locking devices with the TIME-
MASTER, proceed as follows:
Hold the TIME-MASTER in front of the locking device.
When the locking device detects the TIME-MASTER, it starts
beeping at one-second intervals. The number of beeps
determines the opening time.

Introduction
OMEGA FLEX Radio switch
Page 17 of 51
5.4.4 RF-INI-MASTER
The RF-INI-MASTER is used to switch your /NET locking devices
into online (RF) mode and into learning mode. Your locking
devices must be in this mode to establish a cooperation with
the radio switch.
To set the RF mode (Online mode) of your locking devices
with the RF-INI-MASTER, proceed as follows:
Keeping the RF INI MASTER about two seconds before your
locking device.
As a result, you get a short green signal and a short sound.
To put your locking device in the offline mode, proceed as
follows:
Keeping the RF INI master before the locking device, until
the following signaling is finished.
As a result, you get the green signal for about five seconds, as
well as an acoustic signal.

Introduction
Page 18 of 51
OMEGA FLEX Radio switch
5.4.5 RF-TRACE-MASTER
The RF-TRACE-MASTER serves to verify the quality of the radio
frequency (RF) link between the Radio switch and your
authorized locking devices.
Hold the RF-TRACE-MASTER for about two seconds in front
of your locking device.
The function is performed immediately.
The RF-TRACE-MASTER triggers the following signals of your
locking devices:
Green LED of your OMEGA FLEX locking device flashes
twice: very strong RF link.
Green LED of your OMEGA FLEX locking device flashes once:
adequate RF link.

Introduction
OMEGA FLEX Radio switch
Page 19 of 51
Red and green LEDs flash alternately or simultaneously:
weak RF link.
Red LED of your OMEGA FLEX locking device flashes: No RF
link established and trouble-shooting required.

During the verification, the Radio switch emits the
same signals as the locking device.

Introduction
Page 20 of 51
OMEGA FLEX Radio switch
5.4.6 EMERGENCY-KEY
The emergency key is a master key that is authorized to lock
your locking devices irrespective of your settings.
The emergency key gives you access at all times to every
locking device in your OMEGA FLEX system.
The emergency key is available as a key, a key fob and as an
identification card.
The emergency key always has top priority and can also be
used to open devices that have been set to blocking state.
NOTICE
An unauthorised person may be able to
acquire the emergency key and gain access.
Keep the emergency key in a safe place.
Prevent it getting into the hands of
unauthorised persons.
Emergency key authorisation is carried out manually via the
SYSTEM MASTER or by remote programming.
