CFLY obtain User manual

User manual

Contents
Aircraft Diagram
OBTAIN Open way
Remote Controller Diagram
Gimbal Specification
Aircraft operate
Flight preparing
Flight mode
4
3
5
8
9
10
18
12
16
Remote Controller Operation
Return 15
Aircraft indicator light shown

OBTAIN is a foldable drone with stable camera,possessed flexible
flying mode.
· Record 1080P video and take 500w Pixel picture,easily to capture
complicated shot.
· The Maximum flight speed approach 43km/h.
· The Maximum flight time approach 26mins.
Aircraft Diagram
4
①②
③
④
⑤
⑥
⑦

1. 2. 3.Drone head indicator light Propeller Gimbal
4.Electric machinery 5.Intelligent Battery
6.Drone status indicator light 7.Battery capacity light
8.Power Switch
All the arms of aircraft are fold on delivery, please open the arms as
below.
5
⑧
OBTAIN Open way

1.At first, please open the front arms, as below shown:
2.Second, Make the back arm vertical Straight down rotate 180°,
then horizontal spread outside 60°.
6
180°

·
·
then horizontal spread outside 60°.
Must open the front arms before you open the back arms.
The back arm MUST open vertical Straight down rotate 180°,
Please prepare aircraft by the above steps!!
7
60°
3.Spread Propeller

Remote Controller Diagram
8
Control stick
5.Indicator light
6.
1.
2.Mobile phone Holder
3.Channel reservation
4.
Antenna
Switch of Flight Mode
8.Switch of Take off/Land
9.Power switch
10.Stretch Button of holder
11.Switch of Return
12.Switch of Follow Me
7.Switch of Picture/Video
⑴
⑵
⑶⑷
⑸
⑹
⑺
⑻
⑼
⑴
⑽
⑾⑿
⑹

Open the smart phone Holder, and adjust the position of antenna,
as picture shown.
1.Press the button beside mobile device support to extend
2.Adjust mobile device support to clamp mobile device
3.Connect mobile device and controller with Wifi
a.Expand the antenna outward b.Rotating antenna
c.Adjust the antenna to 45°
degrees with the remote
control and expand the
mobile device support
e.Put mobile device in
mobile device support
d.Put the battery into the back
slot of the remote control with
Positive and negative-grid current.
Remote Controller Operation
9

Gimbal Specification
①
②
②
②Camera
3-Axis
Remove the gimbal cover and gimbal clamp from the camera.
as below:
Gimbal Specification:
10

Roll:-30°~30°
Yaw:-45°~45°
Pitch:
-90°~0°
3-Axis gimbal can trun at three directions,make shot easier：
③
SD slot
Do not remove the Micro SD card from the OBTAIN when it
is turned on.
To ensure the stability of the camera system, single video
recordings are capped at 30 minutes.
11

Aircraft operate
Flight preparing
3.Insert battery to
aircraft battery slot.
2.Make remote controller power switch on.
1.Insert SD card to SD slot.
SD
12

4.Put aircraft on the ground
Make sure capacity of battery is full when you use battery
at very first time
Before flight,please make sure aircraft on the ground
Please leave aircraft immediately when you power aircraft on
13
5.Short press once, and then long press 2s for turn off the drone.
5.when the green light on, Show it have GPS, Return Point was
setting. You can fly it.At this moment, you can press one key take
off /Land button for starting your wonderful fly time.

6.After the aircraft fly,you can control aircraft by controller stick.
14
S
P
A
a.P Mode, should be get GPS
stable Signal, then you can
fly your drone.
Or start as the following instruction.
Left joystick Right joystick
b.Control aircraft by controller stick.
Throttle/Up
Right rotate
Left rotate
Down
Forward
Backward
allocate throttle/up and forward at same time,the aircraft
will fly forward very fast
Left
sideways
Fly
Right
sideways
Fly

15
Return
When the drone fly far away from you or unknown direction,
you can press on” Return” switch, and wait for the drone come
back to you. When the drone is falling, you can control the Pitch
and Rudder-Aileron for safe land.
When the drone out of control, It will automatic Return.
When the drone in Low battery, It will automatic Return.
OFF
ON
When the drone Landed, please wait until the propeller stop working,
and then you can turn off the power of drone.( Short press once, and
then long press 2s). Finally, Turn off the controller.
Power Switch of drone Power Switch of Controller
Right joystick
Forward
Backward
Left sideways Fly Right sideways Fly

After selecting S mode, the drone rotates by Itself.
Flight mode
S (Fly around the point) Mode：When choose S mode, the aircraft
will fly around by itself, Press righr joystick to backward and Widening
circle radius, the aircraft will be surround 360 based on widening
circle radius.Operation as below:
Operation as below:
16
S
P
A

P Mode( GPS Location) :When choose P mode, GPS signal will
give the order to the aircraft, The aircraft will be automatic
adjusted by the GPS Signal.
A Mode( Height Control) :When choose A mode, its Hand-Mode,
you can control the aircraft for all kind of complicate flight by
yourself.
Through the Remote Controller operate the
aircraft fly around the point.
Right joystick
Forward
Backward
17
Left sideways Fly Right sideways Fly

18
Aircraft indicator light shown: The Front LED light just show the
direction of aircraft. The red light of aircraft will keep on when
it power on. The Back LED Light show the flight status , please
follow the below indication light status of flight.
Front LED indicator light
Flight mode
indicator light
Aircraft indicator light shown
Aircraft indicator light statement:
Normal
System self-test
Blue & red light flash alternately Compass horizontal rotation calibration
Green light Keep on GPS Location
Remote Controller connect
USE Visual system Location
GPS haven't Location
Green light double flash
Green light flash
×2
Red & green light flash alternately Compass vertical rotation calibration
Normal display when
Calibration complete
Indicator status Status description
Warning!
Red light Keep on Serious mistake
Blue light flash Without Remote controller signal
Red light double flash Serious low-voltage alarm
Red light flash Low-Voltage alarm
Blue & green light flash alternately Errors in compass data,
Need to be calibrated
×2
Front LED indicator light
R
R
R
R
Blue light double flash
B
G
G
G
G
Blue light keep on
B
B R
B
B
×2
G

www.cfly-cn.com
