OPERATOR'S MANUAL
MODEL #100722
3500 LB. (1588 KG) WINCH
REV 20201222 Champion Power Equipment, Inc., Santa Fe Springs, CA USA
or visit championpowerequipment.com
SAVE THESE INSTRUCTIONS. This manual contains important safety precautions which should be read and
understood before operating the product. Failure to do so could result in serious injury. This manual should remain
with the product.
Specifications, descriptions and illustrations in this manual are as accurate as known at the time of publication,
but are subject to change without notice.
REGISTER YOUR PRODUCT ONLINE
at championpowerequipment.com

100722 - 3500 LB. (1588 KG) WINCH TABLE OF CONTENTS
2
TABLE OF CONTENTS
Introduction................................. 3
Safety Definitions ......................... 3
Important Safety Instructions ......... 4
Operation Symbols............................... 5
Controls and Features ................... 6
Winch .......................................... 6
Parts Included ................................... 8
Assembly .................................... 9
Mounting the Winch .............................. 9
Solenoid/Contactor Location ...................... 9
Install the Rocker Switch ........................ 10
Wiring the Winch................................ 10
Wiring Diagram ................................. 12
Switch Wiring Diagram .......................... 12
Operation .................................. 13
General Tips for Safe Operation................... 13
Self Recovery .................................. 13
Synthetic Rope Abrasion Sleeve .................. 14
Winching Techniques A-Z ........................ 14
Maintenance .............................. 15
Lubrication..................................... 15
Synthetic Rope Replacement ..................... 15
Synthetic Rope ................................. 15
Specifications ............................ 16
Performance Specifications ...................... 16
Troubleshooting.......................... 17

100722 - 3500 LB. (1588 KG) WINCH INTRODUCTION
3
INTRODUCTION
Congratulations on your purchase of a Champion Power
Equipment (CPE) product. CPE designs, builds, and
supports all of our products to strict specifications and
guidelines. With proper product knowledge, safe use, and
regular maintenance, this product should bring years of
satisfying service.
Every effort has been made to ensure the accuracy and
completeness of the information in this manual at the time
of publication, and we reserve the right to change, alter
and/or improve the product and this document at any time
without prior notice.
CPE highly values how our products are designed,
manufactured, operated, and serviced as well as
providing safety to the operator and those around the
winch. Therefore, it is IMPORTANT to review this product
manual and other product materials thoroughly and
be fully aware and knowledgeable of the assembly,
operation, dangers and maintenance of the product before
use. Fully familiarize yourself, and make sure others who
plan on operating the product fully familiarize themselves
too, with the proper safety and operation procedures
before each use. Please always exercise common sense
and always err on the side of caution when operating the
product to ensure no accident, property damage, or injury
occurs. We want you to continue to use and be satisfied
with your CPE product for years to come.
When contacting CPE about parts and/or service, you will
need to supply the complete model and serial numbers
of your product. Transcribe the information found on your
product’s nameplate label to the table below
CPE TECHNICAL SUPPORT TEAM
1-877-338-0999
MODEL NUMBER
100722
SERIAL NUMBER
DATE OF PURCHASE
PURCHASE LOCATION
SAFETY DEFINITIONS
The purpose of safety symbols is to attract your
attention to possible dangers. The safety symbols, and
their explanations, deserve your careful attention and
understanding. The safety warnings do not by themselves
eliminate any danger. The instructions or warnings they
give are not substitutes for proper accident prevention
measures.
 DANGER
DANGER indicates a hazardous situation which,if not
avoided, will result in death or serious injury.
 WARNING
WARNING indicates a hazardous situation which, if not
avoided, could result in death or serious injury.
 CAUTION
CAUTION indicates a hazardous situation which, if not
avoided, could result in minor or moderate injury.
 NOTICE
NOTICE indicates information considered important,
but not hazard-related (e.g., messages relating to
property damage).

100722 - 3500 LB. (1588 KG) WINCH IMPORTANT SAFETY INSTRUCTIONS
4
IMPORTANT SAFETY
INSTRUCTIONS
 WARNING
Cancer and Reproductive Harm –
www.P65Warnings.ca.gov
 WARNING
Do not use as a hoist for overhead lifting.
Do not use this winch for lifting or moving people or
animals.
Never step over the cable/rope when operating under
load.
Always maintain a safe distance to the opposite side of
the cable/rope when operating under load.
 WARNING
Never exceed the rated capacity.
Be aware that the cable/rope may break before the
motor stalls.
For heavy loads at or near rated capacity, always use a
snatch block to reduce the load on the cable/rope.
 WARNING
Do not use the winch to secure or hold a vehicle for an
extended period of time.
Always apply stop blocks to the wheels of the vehicle
when on an incline.
Do not use the winch to secure a vehicle for
transporting purposes.
Never move the vehicle to pull a load (towing) when
operating the winch cable/rope.
Never release the free-spool clutch when there is a
load on the winch.
 WARNING
Disconnect the remote control and battery leads when
not in use.
 WARNING
Avoid “shock loads” by using the control switch
intermittently to take up the slack in the cable/rope.
“Shock loads” can exceed the rated capacity of the
cable/rope and drum.
 CAUTION
Use a winch hook strap when handling the hook for
spooling or unspooling the cable/rope.
 CAUTION
Always use gloves to protect hands when handling the
cable/rope. Never let the cable/rope slide through your
hands.
 WARNING
When re-spooling the cable/rope, ensure that it spools
in the under-wind position with the cable/rope entering
the drum from the bottom, not the top.
To re-spool correctly, and while wearing gloves, keep
a slight load on the cable/rope while pushing the
remote button to draw in the cable/rope. Walk toward
the winch not allowing the cable to slide through your
hands. Do not let your hands get within 12 inches
(30 cm) of the winch while re-spooling. Turn off the
winch and repeat the procedure until a few feet of
cable/rope are left. Disconnect the remote control and
finish spooling by rotating the drum by hand with the
clutch disengaged. Keep hands clear of the fairlead
and drum while the winch is under power .
 CAUTION
Do not wrap the cable/rope around any object and
hook it back onto itself.

100722 - 3500 LB. (1588 KG) WINCH IMPORTANT SAFETY INSTRUCTIONS
5
 CAUTION
Duration of winching pulls should be kept as short as
possible.
If the motor becomes excessively hot to the touch, stop
winching immediately and let it cool down for a few
minutes. Do not pull for more than one minute at or
near the rated load.
 CAUTION
If the motor stalls, do not maintain power to the winch.
Electric winches are designed and made for
intermittent use and should not be used in constant
duty applications.
Operation Symbols
Some of the following symbols may be used on this
product. Please study them and learn their meaning.
Proper interpretation of these symbols will allow you to
more safely operate the product.
Symbol Meaning
Turn the clutch to the “IN” position
to retract the rope.
Turn the clutch to the “OUT”
position to release the rope.
Positive battery terminal
Negative battery terminal
Positive winch terminal
Negative winch terminal
