OPERATOR'S MANUAL
MODEL #201162
4000 LB. (1,814 KG) WINCH
or visit championpowerequipment.com
READ AND SAVE THIS MANUAL. This manual contains important safety precautions which should be read
and understood before operating the product. Failure to do so could result in serious injury. This manual should
remain with the product.
Specifications, descriptions and illustrations in this manual are as accurate as known at the time of publication,
but are subject to change without notice.
REGISTER YOUR PRODUCT ONLINE
at championpowerequipment.com
SERIAL NO. LABEL
Champion Power Equipment, Inc., Santa Fe Springs, CA USA
3361-M-OP RE V 20211124 EN

201162 - 4000 LB. (1,814 KG) WINCH TABLE OF CONTENTS
2
TABLE OF CONTENTS
Introduction ................................. 3
Safety Definitions .......................... 3
Important Safety Instructions ........... 4
Operation Symbols.............................. 5
Controls and Features ..................... 6
Winch ......................................... 6
Parts Included .................................. 8
Assembly .................................... 9
Assembling the Winch ........................... 9
Contactor/Solenoid Location .................... 10
Installing the Mini-Rocker Switch ................ 10
Wiring the Winch............................... 10
Test Winch Operation........................... 11
Wiring Diagram ................................ 12
Switch Wiring Diagram ......................... 12
Operation .................................. 13
General Tips for Safe Operation.................. 13
Self Recovery ................................. 13
Winching Techniques A-Z ....................... 14
Maintenance .............................. 15
Lubrication.................................... 15
Cable Assembly Replacement ................... 15
Specifications............................. 17
Performance Specifications ..................... 17
Troubleshooting .......................... 18

201162 - 4000 LB. (1,814 KG) WINCH INTRODUCTION
3
INTRODUCTION
Congratulations on your purchase of a Champion Power
Equipment (CPE) product. CPE designs, builds, and
supports all of our products to strict specifications and
guidelines. With proper product knowledge, safe use, and
regular maintenance, this product should bring years of
satisfying service.
Every effort has been made to ensure the accuracy and
completeness of the information in this manual at the
time of publication, and we reserve the right to change,
alter and/or improve the product and this document at
any time without prior notice.
Since CPE highly values how our products are designed,
manufactured, operated and are serviced, and also highly
value your safety and the safety of others, we would
like you to take the time to review this product manual
and other product materials thoroughly and be fully
aware and knowledgeable of the assembly, operation,
dangers and maintenance of the product before use. Fully
familiarize yourself, and make sure others who plan on
operating the product fully familiarize themselves too,
with the proper safety and operation procedures before
each use. Please always exercise common sense and
always err on the side of caution when operating the
product to ensure no accident, property damage, or injury
occurs. We want you to continue to use and be satisfied
with your CPE product for years to come.
When contacting CPE about parts and/or service, you will
need to supply the complete model and serial numbers
of your product. Transcribe the information found on your
product’s nameplate label to the table below
CPE TECHNICAL SUPPORT TEAM
1-877-338-0999
MODEL NUMBER
201162
SERIAL NUMBER
DATE OF PURCHASE
PURCHASE LOCATION
SAFETY DEFINITIONS
The purpose of safety symbols is to attract your
attention to possible dangers. The safety symbols, and
their explanations, deserve your careful attention and
understanding. The safety warnings do not by themselves
eliminate any danger. The instructions or warnings they
give are not substitutes for proper accident prevention
measures.
 DANGER
DANGER indicates a hazardous situation which,if not
avoided, will result in death or serious injury.
 WARNING
WARNING indicates a hazardous situation which, if not
avoided, could result in death or serious injury.
 CAUTION
CAUTION indicates a hazardous situation which, if not
avoided, could result in minor or moderate injury.
 NOTICE
NOTICE indicates information considered important,
but not hazard-related (e.g., messages relating to
property damage).

201162 - 4000 LB. (1,814 KG) WINCH IMPORTANT SAFETY INSTRUCTIONS
4
IMPORTANT SAFETY
INSTRUCTIONS
 WARNING
Do not use as a hoist for overhead lifting.
Do not use this winch for lifting or moving people or
animals.
Never step over the cable/rope when operating under
load.
Always maintain a safe distance to the opposite side
of the cable/rope when operating under load.
 WARNING
Never exceed the rated capacity.
Be aware that the cable/rope may break before the
motor stalls.
For heavy loads at or near rated capacity, always use
a snatch block to reduce the load on the cable/rope.
 WARNING
Do not use the winch to secure or hold a vehicle for an
extended period of time.
Always apply stop blocks to the wheels of the vehicle
when on an incline.
Do not use the winch to secure a vehicle for
transporting purposes.
Never move the vehicle to pull a load (towing) when
operating the winch cable/rope.
Never release the free-spool clutch when there is a
load on the winch.
 WARNING
Disconnect the remote control and battery leads when
not in use.
 WARNING
Avoid “shock loads” by using the control switch
intermittently to take up the slack in the cable/rope.
“Shock loads” can exceed the rated capacity of the
cable/rope and drum.
 CAUTION
Use a winch hook strap when handling the hook for
spooling or unspooling the cable/rope.
 CAUTION
Always use gloves to protect hands when handling
the cable/rope. Never let the cable/rope slide through
your hands.
 WARNING
When re-spooling the cable/rope, ensure that it
spools in the under-wind position with the cable/rope
entering the drum from the bottom, not the top.
To re-spool correctly, and while wearing gloves, keep
a slight load on the cable/rope while pushing the
remote button to draw in the cable/rope. Walk toward
the winch not allowing the cable to slide through your
hands. Do not let your hands get within 12 inches
(30 cm) of the winch while re-spooling. Turn off the
winch and repeat the procedure until a few feet of
cable/rope are left. Disconnect the remote control and
finish spooling by rotating the drum by hand with the
clutch disengaged. Keep hands clear of the fairlead
and drum while the winch is under power .
 CAUTION
Do not wrap the cable/rope around any object and
hook it back onto itself.
 CAUTION
Duration of winching pulls should be kept as short as
possible.
If the motor becomes excessively hot to the touch,
stop winching immediately and let it cool down for a
few minutes. Do not pull for more than one minute at
or near the rated load.
 CAUTION
If the motor stalls, do not maintain power to the winch.
Electric winches are designed and made for
intermittent use and should not be used in constant
duty applications.

201162 - 4000 LB. (1,814 KG) WINCH IMPORTANT SAFETY INSTRUCTIONS
5
Operation Symbols
Some of the following symbols may be used on this
product. Please study them and learn their meaning.
Proper interpretation of these symbols will allow you to
more safely operate the product.
Symbol Meaning
Turn the clutch to the “IN”
position to retract the rope.
Turn the clutch to the “OUT”
position to release the rope.
Positive battery terminal
Negative battery terminal
Positive winch terminal
Negative winch terminal

201162 - 4000 LB. (1,814 KG) WINCH CONTROLS AND FEATURES
6
CONTROLS AND FEATURES
Read this operator’s manual before operating your winch. Familiarize yourself with the location and function of the
controls and features. Save this manual for future reference.
Winch
1. Motor – 1.4 HP (1 kW) 12V DC motor provides
power to the planetary gear mechanism.
2. Tie Bars – Durable all-metal construction tie bars
for increased structural rigidity
3. Winch Drum – The winch drum is the cylinder on
which the cable/rope is stored. It can feed or wind
the cable/rope depending on the remote winch
switch.
4. Cable/Rope – 7/32 in. × 49 ft. (5.4 mm × 15 m)
galvanized aircraft cable designed specifically for
load capacity of 4000 lb. (1814 kg).
5. Braking System – Braking action is automatically
applied to the winch drum when the winch motor is
stopped and there is a load on the cable/rope.
6. Planetary Gear System – The reduction gears
convert the winch motor power into extreme pulling
forces. This system allows high torque while
maintaining compact size and light weight.
7. Clutch – The clutch allows the operator to
manually disengage (“Out”) the spooling drum from
the gear train, free spool. Engaging the clutch (“In”)
locks the winch into the gear system.
7
1
2
345
6

201162 - 4000 LB. (1,814 KG) WINCH CONTROLS AND FEATURES
7
8. Hand Strap – Used to assist cable/rope rope feed.
9. Roller Fairlead – When using the winch at an
angle the roller fairlead acts to guide the cable/rope
onto the drum and minimizes damage to the cable/
rope from abrasion on the winch mount or bumper.
10. Mini-rocker Switch – Rocker switch with
handlebar mount for powering the cable/rope in or
out of your winch drum.
11. Solenoid/Contactor – Power from the vehicle
battery flows through the weather sealed contactor
before being directed to the winch motor.
12. Mounting Channel – Winch mount to attach the
winch to your vehicle.
13. Winch Connection Cables – Used to connect the
contactor to the winch motor and the contactor to
the vehicle battery.
14. Clevis Hook – Provides a means for connecting the
looped ends of cables to an anchor.
15. Wire Tap – Allows the ability to splice the end of
the red wire on the mini-rocker switch to an ignition
or keyed controlled power source.
16. Cable Ties – Attaches the mini-rocker switch cable
to the chassis of your vehicle.
8
12
10
14
11
15
13
16
9

201162 - 4000 LB. (1,814 KG) WINCH CONTROLS AND FEATURES
8
Parts Included
Assembly Parts
Part Part Qty Hardware Hardware
Qty Tool(s) Needed
Torque
lbf-ft
(N.m)
Winch Body 1
Hexagon Head Bolt M8 x 25 41x 13mm wrench or socket 6.1-7
(8.2-9.5)
Flat Washer Ø8 4
Lock Washer Ø8 4
Mounting
Channel 1
Roller Fairlead 1
Hexagon Head Bolt
M10 x 20 21x 16mm wrench or socket 11.8-12.6
(16 -17.1)
Lock Washer Ø10 2
Lock Nut M10 21x 16mm wrench or socket
Mini-Rocker
Switch 1
Hexagon Socket Head
Screw M5 x 18 11x 4mm allen wrench 2.2-3
(3-4)
Hexagon Socket Head
Screw M5 x 25 21x 4mm allen wrench 2.2-3
(3-4)
Flat Washer Ø5 3
Lock Washer Ø5 3
Nut M5 31x 8mm wrench or socket
Wire Tap 1
Contactor 1
Hexagon Head Bolt M6 x 25 41x 10mm wrench or socket 4.1-4.9
(5.6-6.6)
Flat Washer Ø6 4
Lock washer Ø6 4
Lock Nut M6 41x 10mm wrench or socket
Battery Wires
- Red 1
Battery Wires -
Black 1
Winch Wires -
Yellow 1
Winch Wires -
Blue 1
Clevis Hook 1Needle nose pliers
Yellow Strap 1

201162 - 4000 LB. (1,814 KG) WINCH ASSEMBLY
9
ASSEMBLY
Your CPE 4000 lb. (1814 kg) winch is designed with a
bolt pattern that is standard in this class of winch. Many
winch mounting kits are available that utilize this bolt
pattern for the most popular trucks, SUV’s and ATV’s.
 CAUTION
See Parts Included Assembly Parts section for torque
ratings. Mounting bolts must be SAE grade 5 or better
and torque to 34 ft. lbs (46 N.m).
Assembling the Winch
1. Insert M10×20 (A) bolts through the mounting
channel (B) holes and attach the roller fairlead (C)
to the mounting channel with the M10 lock nuts (D)
and lock washers (E) provided.
A
E
CD
B
2. Turn the winch upside down. Place the mounting
channel on the winch, making sure the winch is
centered in the middle of it.
3. Thread the M8×25 (F) bolts through the Ø8 lock
(G) and flat washers (H), and then thread through
the mounting channel. Tighten the bolts. DO NOT
overtighten.
F
H
G
4. Turn winch right side up. Disengage the clutch by
moving the clutch to the “Out” position – the arrow
will be to the back of the winch as shown. Release
the cable/rope and pull through the roller fairlead.
Out
Clutch
5. Attach the clevis hook to the cable/rope by
removing cotter pin and pin, then thread through
and reattach the pin and cotter pin.
6. Add hand strap to the clevis hook.
 CAUTION
If utilizing a mounting plate, ensure that the three
major sections (motor, drum, and gear housing) are
properly aligned. Proper alignment of the winch will
allow for even distribution of the full rated load.
 NOTICE
The type of vehicle to which the winch and mounting
channel will be applied, will dictate the type of
mounting kit that should be used (Speed MountTM
hitch adapter, standard mounting channel, or specialty
mounting kit).

201162 - 4000 LB. (1,814 KG) WINCH ASSEMBLY
10
Contactor/Solenoid Location
Find a location for the contactor/solenoid. It is
recommended that the contactor/solenoid be mounted
close to the battery in a clean, dry location. Make sure
the location chosen allows for sufficient clearance from
all metal components. Drill mounting holes if required.
Once a location is found, DO NOT install the unit until all
wiring is completed (see wiring section).
 NOTICE
Terminals coming in contact with metal will cause a
direct short, possibly causing contactor/solenoid and/
or battery damage.
Installing the Mini-Rocker Switch
1. Decide which handlebar the mini-rocker switch will
be mounted on. The mini-rocker switch is usually
installed on the left handlebar.
2. Use a piece of electrical tape (not provided) around
the handlebar to help prevent rotation of the mount.
Loosen the hardware and mount to the handlebar.
Tighten the mini-rocker switch in place. DO NOT
overtighten or tighten/clamp over any hoses or
cables.
Once the mini-rocker switch is mounted, the wires
can be routed back to where the solenoid/contactor
is located.
Make sure the handlebars have full range of motion
and then secure the mini-rocker switch’s cable with
the supplied cable ties.
Wiring the Winch
 CAUTION
NEVER route electrical cables across any sharp
edges, through and/or near moving parts, or near
parts that may become hot.
 CAUTION
Battery cables should NOT be drawn tight. Leave
some slack for cable movement.
 NOTICE
You may need to use a test light to locate a suitable
wire. The wire should only have power when the key is
in the ON position.
 NOTICE
Depending on the location of the solenoid/contactor,
you may need to use the black and red cables in place
of the yellow and blue, and the yellow and blue in
place of the red and black. Just remember that this
also changes the diagram.
1. Connect the yellow and blue cables to the motor
terminals on the winch. (Yellow to the positive
(+) terminal of the motor. Blue to the negative (-)
terminal of the motor). Tighten the terminal nuts
on the motor. DO NOT over tighten. Route the other
ends to the solenoid/contactor location.
2. Connect the yellow and blue cables to the solenoid/
contactor (yellow to yellow and blue to blue).
DO NOT tighten nuts.

201162 - 4000 LB. (1,814 KG) WINCH ASSEMBLY
11
3. Connect the red and black cables to the solenoid/
contactor (red to red and black to black). DO NOT
tighten nuts. Route the other ends to the vehicle’s
battery.
4. Connect the red lead to the positive (+) terminal of
the vehicle’s 12 volt battery.
5. Connect the rocker switch to the solenoid/contactor
(black to black and green to green).
6. Splice the end of the red wire on the rocker switch,
to an ignition (keyed) controlled power source using
the supplied wire tap.
7. Once all wiring is connected to the solenoid/
contactor it can then be mounted using the
supplied M6 hardware.
8. Tighten the solenoid/contactor terminal nuts.
DO NOT over tighten.
9. Connect the black lead to the negative (-) terminal
of the vehicle’s 12 volt battery.
10. Place all terminal boots over terminals and secure
all cables with cable ties or electrical tape (not
included).
11. Check for proper drum rotation. Turn the clutch to
the “Out” position (free spooling). Pull out some
cable from the drum, and then turn the clutch to
the “In” position to engage the gears.
Out
Clutch
In
With some applications the motor leads may need to be
rotated to avoid interference with other components.
Leads default position Leads rotated 90°
Test Winch Operation
When testing the winch for correct connections and
operation.
1. Make sure there are no exposed terminals or
wiring.
2. Wiring to all components is correct.
3. All loose wires are secured.
4. Turn the vehicle ignition switch to the ON position,
but DO NOT start the vehicle.
5. Check the winch for proper operation using the
rocker switch. The cable/rope should spool in and
out in the direction indicated on the switch.
6. Press the “Out” button on the mini-rocker switch. If
the drum is turning and releasing more cable/rope,
then your connections are accurate. If the drum is
turning and collecting more cable/rope then reverse
the leads on the motor. Repeat and check rotation.
Press the “In” button on the mini-rocker switch as
a final test.
Out In

201162 - 4000 LB. (1,814 KG) WINCH ASSEMBLY
12
Wiring Diagram
Blue
Yellow
Black
Positive (+)
Positive (+)
Negative (–)
Switch Wiring Diagram
Black
Green
Red
Ignition Wire
Solenoid/Contactor
Battery
Black
Green
Red

201162 - 4000 LB. (1,814 KG) WINCH OPERATION
13
OPERATION
General Tips for Safe Operation
Your winch is rated at a 4000 lb. (1814 kg) capacity in
first layer (max) when spooling the first rope layer on the
drum. Overloads can damage the winch, motor and/or
wire rope. For loads over 50% we recommend the use of
the pulley block/snatch block (not included) to double the
wire rope line. This will aid in two ways:
–reduce the number or cable/rope layers on the drum,
as well as,
–reduce the load on the cable/rope by as much as
50%.
When doubling the line back to the vehicle, attach to the
tow hook, frame or other load bearing part. The vehicle
engine should be kept running during operation of the
winch to minimize battery drain and maximize power
and speed of the winch. If the winch is used for a
considerable time with the engine off the battery may be
drained and too weak to restart the engine.
Get to know your winch before you actually need to use
it. We recommend that you set up a few test runs to
familiarize yourself with rigging techniques, the sounds
your winch makes under various loads, the way the cable
spools on the drum, etc.
Inspect the wire rope and equipment before each use.
A frayed or damaged rope shall be replaced immediately.
Use only manufacturer’s identical replacement
cable/rope with the exact specifications.
Inspect the winch installation and bolts to ensure that all
bolts are tight before each operation. Store the remote
control inside your vehicle in a place that it will not be
damaged.
Any winch that appears to be damaged in any way,
is found to be worn, or operates abnormally MUST
BE REMOVED FROM SERVICE UNTIL REPAIRED. It is
recommended that the necessary repairs be made by
a manufacturer’s authorized repair facility.
Pull only on areas of the vehicle as specified by the
vehicle manufacturer. Only attachments and/or adapters
supplied by the manufacturer are to be used.
Self Recovery
Locate a suitable anchor such as a strong tree trunk or
boulder. Always use a sling (not included) as an anchor
point.
Your winch is equipped with a roller fairlead to help guide
the cable/rope and to reduce binding on short side pulls.
Do not winch from an acute angle as the cable/rope will
pile up on one side of the drum causing damage to cable/
rope and the winch.
Correct Incorrect
Short pulls from an angle can be used to straighten the
vehicle. Long pulls should be done with the cable/rope at
a 90° angle to the winch/vehicle. When pulling a heavy
load, place a blanket or jacket over the cable/rope 5 – 6’
(1.5 – 1.8 m) from the hook. In the event of a broken
cable/rope it will dampen the snap back.

201162 - 4000 LB. (1,814 KG) WINCH OPERATION
14
For additional protection open the hood of the vehicle.
For pulls over 2,000 lb (907.2 kg), we recommend the
use of the snatch block/pulley block to double line the
cable/rope.
This reduces the load on the winch and the strain on the
rope by approximately 50%.
Single Line Double Line
Winching Techniques A-Z
a. Take time to assess your situation and plan your
pull.
b. Always wear heavy leather gloves when handling
cable/rope.
c. Disengage the clutch to allow free-spooling and
also save battery power.
d. Always use supplied hand strap whenever spooling
rope in or out, during installation and during
operation.
e. Pull out the cable/rope to your desired anchor point
using the hand strap.
f. Secure the clevis hook to the anchor point: Sling,
chain or snatch block. Do not attach the hook back
onto the cable/rope.
g. Engage the clutch.
h. Connect the mini-rocker switch to the winch.
i. Start your engine to ensure power is being
replenished to the battery.
j. Drape a blanket or jacket over the cable/rope
approximately 5 – 6’ (1.5 – 1.8 m) from the hook.
Open the hood for added protection.
k. Power in the cable/rope guiding the rope under
tension to draw up the slack in the rope. Once the
rope is under tension, stand clear. Never step over
the cable/rope.
l. Double check your anchors and make sure all
connections are secure.
m. Inspect the cable/rope. Make sure there are at least
5 wraps of cable/rope around the winch drum. Your
rope is marked with red on wrap 5 to 6 as a visual
indicator.
Red
n. Clear the area. Make sure all spectators stand clear
and that no one is directly in front or behind the
vehicle or anchor point.
o. Begin winching. Be sure that the cable/rope is
winding evenly and tightly around the drum. The
vehicle that is being winched can be slowly driven
to add assistance to the winching process. Avoid
shock loads; keep the cable/rope under tension.
p. The vehicle to be winched should be placed in
neutral and the emergency brake released. Only
release the brake pedal when under full tension.
Avoid shock loads to the winch. This can damage
the winch, rope and vehicle.
q. The winch is meant for intermittent use. Under full
load with a single line rig do not power in for more
than a minute without letting the motor cool down
for a few minutes and then resume the winching
operation.
r. The winching operation is complete once the
vehicle is on stable ground and is able to drive
under its own power.
s. Secure the vehicle. Be sure to set the brakes and
place the vehicle in park.
t. Release the tension on the cable/rope. The winch
is not meant to hold the vehicle for long periods of
time.
u. Disconnect the cable/rope from the anchor.
v. Rewind the cable/rope. Make sure that any rope
already on the drum has spooled tightly and neatly.
If not, draw out the rope and re-spool from the
point where the rope is tight.

201162 - 4000 LB. (1,814 KG) WINCH MAINTENANCE
15
w. Always keep hands clear of cable/rope, hook loop,
hook and roller fairlead opening during installation,
operation, and when spooling in or out.
x. Secure the hook and hand strap.
y. Disconnect the mini-rocker switch.
z. Clean and inspect connections and mounting
hardware for next winching operation.
MAINTENANCE
The owner/operator is responsible for all periodic
maintenance.
Complete all scheduled maintenance in a timely manner.
Correct any issue before operating the winch.
 WARNING
Never operate a damaged or defective winch.
 WARNING
Improper maintenance will void your warranty.
 NOTICE
For service or parts assistance, contact our help line
at 1-877-338-0999.
Lubrication
All moving parts within the electric winch have been
lubricated using high-temperature lithium grease at the
factory. No internal lubrication is required. Lubricate rope
assembly periodically using a light penetrating oil.
Cable Assembly Replacement
1. Move the clutch to the “Out” position.
Out
2. Remove clevis hook, pin, cotter pin and hand strap.
Remove roller fairlead to allow easier access.
Remove protective sleeve, as applicable.
3. Extend the cable/rope to its full length manually. A
set screw will need to be removed to fully remove
the cable/rope from the drum. Remove old cable/
rope.
4. Attach the new cable/rope.
When re-spooling the cable/rope, ensure that it
spools in the under-wind position with the cable/
rope entering the drum from the bottom, not the
top.
5. Replace set screw and tighten to
3.7–4.4 lbf-ft (5–6 Nm).
6. Move the clutch to the “In” position.
In

201162 - 4000 LB. (1,814 KG) WINCH MAINTENANCE
16
7. To re-spool correctly, and while wearing gloves,
keep a slight load on the cable/rope while pushing
the mini-rocker switch button “In” to draw in the
cable/rope.
In
8. Walk toward the winch not allowing the cable/
rope to slide through your hands. Do not let your
hands get within 12” (30 cm) of the winch while
re-spooling. Turn off the winch and repeat the
procedure until a few feet of cable/rope are left.
Disconnect the mini-rocker switch and finish
spooling by rotating the drum by hand with the
clutch disengaged; set clutch to “Out.” Keep hands
clear of the roller fairlead and drum while the winch
is under power.
9. Once completed, set clutch back to “In” and do a
few tests with the cable/rope in and out to make
sure operation is as expected.
10. Reattach the clevis hook to the synthetic cable/rope
by adding the pin and reattach the cotter pin.

201162 - 4000 LB. (1,814 KG) WINCH SPECIFICATIONS
17
SPECIFICATIONS
Performance Specifications
Model .................................... 201162
Rated Pull....................... 4000 lb. (1814 kg)
Gear Reduction Ratio ......................... 180:1
Motor..... Series wound motor 1.4 HP (1 kW) (12V DC)
Duty Cycle .................... Intermittent use only
Drum Size................... 3.2 in. (L) × 1.7 in. (D)
[80 mm (L) × 44 mm (D)]
Cable/Rope Type................... Galvanized Steel
Cable/Rope Dimensions .......49 ft. (L) × 7/32 in. (D)
[15 m (L) × 5.4 mm (D)]
Net Weight ........................ 25.6 lb. (11.6 kg)
Length ........................ 13.5 in. (34.4 cm)
Width .......................... 4.5 in. (11.5 cm)
Height.......................... 4.9 in. (12.4 cm)
Bolt Pattern ........ 4.9 in. × 3 in. (12.4 cm × 7.6 cm)
Line Speed and Motor Current (First Layer)
Line Pull lg 01000 2000 3000 4000
kg 0454 907 1361 1814
Line Speed (12V DC) FPM 12.8 11.5 8.9 6.2 3.3
MPM 3.9 3.5 2.7 1.9 1.3
Motor Current (12 V DC) A28 90 150 200 220
Run Time* Minutes 1 1 1 1 1
Cooling Time** Minutes 5 5 5 5 5
Line Pull and Cable/Rope Capacity Per Layer
Line of Cable/Rope 12 3 4 5
Rated Line Pull lb 4000 3414 2942 2584 2247
kg 1814 1549 1334 1172 1020
Cable/Rope Capacity FT 8.5 18.7 30.5 44 49
Minutes 2.6 5.7 9.3 13.4 15
–Use double line and snatch block for pulling loads over 50%.
* If the motor becomes uncomfortably hot to the touch, stop winching immediately and let it cool down for 5 minutes. Do not pull for more than
one minute at or near the rated load.
* *Electric winches are designed and made for intermittent use and should not be used in constant duty applications.

201162 - 4000 LB. (1,814 KG) WINCH TROUBLESHOOTING
18
TROUBLESHOOTING
Problem Cause Solution
Motor does not turn on.
Switch assembly not connected
properly.
Insert switch assembly all the way into the
connector.
Loose battery cable connections. Tighten nuts on all cable connections.
Contactor malfunctioning.
Tap contactor to loosen contacts. Apply 12
volts to coil terminals directly. A clicking
indicates proper activation.
Defective switch assembly. Replace switch assembly.
Defective motor.
Check for voltage at armature port with
switch pressed. If voltage is present,
replace motor.
Water has entered motor. Allow to drain and dry. Run in short burst
with load until completely dry.
Motor runs but drum does not
turn. Clutch (cam ring) not engaged.
Move cam ring to the “In” position.
If problem persists, a qualified technician
needs to check and repair.
Motor runs slowly or without
normal power.
Insufficient current or voltage.
The battery is weak, recharge. Run winch
with vehicle motor running (battery should
have a strong charge).
Loose or corroded battery cable
connections. Clean, tighten, or replace.
Motor overheating. Winch running time too long. Allow winch to cool down periodically.
Motor runs in one direction only. Defective or stuck contactor. Tap contactor to loosen contacts. Repair or replace contactor.
Defective switch assembly. Replace switch assembly.
For further technical support:
Technical Support Team
Toll Free 1-877-338-0999
[e-mail]

WARRANTY*
CHAMPION POWER EQUIPMENT
2 YEAR LIMITED WARRANTY
Warranty Qualifications
To register your product for warranty and FREE lifetime
call center technical support please visit:
https://www.championpowerequipment.com/register
To complete registration you will need to include a copy
of the purchase receipt as proof of original purchase.
Proof of purchase is required for warranty service.
Please register within ten (10) days from date of
purchase.
Repair/Replacement Warranty
CPE warrants to the original purchaser that the
mechanical and electrical components will be free of
defects in material and workmanship for a period of
two years (parts and labor) from the original date of
purchase and 180 days (parts and labor) for commercial
and industrial use. Transportation charges on product
submitted for repair or replacement under this warranty
are the sole responsibility of the purchaser. This
warranty only applies to the original purchaser and is not
transferable.
Do Not Return The Unit To The Place
Of Purchase
Contact CPE’s Technical Service and CPE will
troubleshoot any issue via phone or e-mail. If the
problem is not corrected by this method, CPE may,
at its option, authorize other means of repair and/or
replacement.
Warranty Exclusions
This warranty does not cover the following repairs and
equipment:
Normal Wear
Products with mechanical and electrical components
need periodic parts and service to perform well. This
warranty does not cover repair when normal use has
exhausted the life of a part or the equipment as a whole.
Installation, Use and Maintenance
This warranty will not apply to parts and/or labor if the
product is deemed to have been misused, neglected,
involved in an accident, abused, loaded beyond the
product’s limits, modified, installed improperly or
connected incorrectly to any electrical component.
Normal maintenance is not covered by this warranty
and is not required to be performed at a facility or by a
person authorized by CPE.
Other Exclusions
This warranty excludes:
–Cosmetic defects such as paint, decals, etc.
–Wear items such as winch cable, etc.
–Accessory parts such as storage covers.
–Failures due to acts of God and other force majeure
events beyond the manufacturer’s control.
–Problems caused by parts that are not original
Champion Power Equipment parts.
Limits of Implied Warranty and
Consequential Damage
Champion Power Equipment disclaims any obligation to
cover any loss of time, use of this product, freight, or any
incidental or consequential claim by anyone from using
this product. THIS WARRANTY IS IN LIEU OF ALL OTHER
WARRANTIES, EXPRESS OR IMPLIED, INCLUDING
WARRANTIES OF MERCHANTABILITY OR FITNESS FOR
A PARTICULAR PURPOSE.
A unit provided as an exchange will be subject to the
warranty of the original unit. The length of the warranty
governing the exchanged unit will remain calculated by
reference to the purchase date of the original unit.
This warranty gives you certain legal rights which may
change from state to state or province to province. Your
state or province may also have other rights you may be
entitled to that are not listed within this warranty.
Contact Information
Address
Champion Power Equipment, Inc.
12039 Smith Ave.
Santa Fe Springs, CA 90670 USA
www.championpowerequipment.com
Customer Service
Toll Free: 1-877-338-0999
[e-mail]
Fax no.: 1-562-236-9429
Technical Service
Toll Free: 1-877-338-0999
[e-mail]
 EMERGENCY 24 HOUR SUPPORT: 1-562-204-1188
