“CONCORD” RECLINER
Operating Instructions
and Service Manual
1-800-998-5018
www.championchair.com

(1)
OM00220 220 Manual REV 2 110118
CONTENTS
ITEM PAGE
Contents 1
In-Service Information 2
Special notes 3
Chair capacity information 4
Receiving new chairs 5-7
New chair inspection 6
To report damage 6
Return authorization 7
Storage 7
In-service procedures 8
Operating instructions 9-11
Operation warnings and cautions 9
For safe recliner operation 10
Staff assistance 10
Swing arm operation 11
Accessories 12,13
Use of IV pole 13
General maintenance and care of chairs 14-16
General cleaning precautions 15
General cleaning- vinyl 15
General cleaning – plastic table tops 16
General infection control - vinyl 16
Warranty procedure 17
Service information 18
Parts identification 18
Service Parts Form 19
Concord chair schematics 20-24
Full explosion 20
Seat explosion 20
Back explosion 21
Foot board explosion 21
Arm explosion 22
Base explosion 23
Concord chair parts listing 24

(2)
OM00220 220 Manual REV 2 110118
In-Service Information
It is very important to Champion that our customers review all the materials in the in-service
package they receive.
By reviewing the in-service materials provided, you increase the useful life of the products by
helping to prevent their improper use, which may lead to premature damage and wear. You are
also helping to validate your warranty, as warranties cover material and workmanship failures, not
misuse or abuse. Use these in-service tools for new employees and as a “refresher” for current
employees.
The following resources are available for you to assist your staff and patients in operating the
chairs properly.
Website: www.championchair.com
Operators Manuals on CD
Vinyl Cleaning Manual also on CD
YouTube: www.youtube.com/user/ChampionChair1992
Field Sales Reps
In House Sales Reps
Network of Service Technicians
In House Service Team
You should receive an Operator’s Manual on CD with each shipment of chairs you receive from
Champion. If you did not, or would like information on any of these additional resources, please
contact Champion’s customer service department at 800-998-5018.
NOTE: Not all chair functions, options and/or accessories are covered in the CD.
NOTE: This recliner assumes three distinct positions: Upright position; leg rest is down and the
back is in its most vertical position, TV position, back is reclined slightly and leg rest is up, and
recline position; the leg rest is up and the back is completely reclined.
NOTE: The information contained in this document is subject to change without notice.

(3)
OM00220 220 Manual REV 2 110118
WELCOME!
Champion Manufacturing Inc. would like to thank you for selecting our products. We take great
care in making certain that our products leave the factory in flawless condition. Our products are
properly packaged to arrive in that same condition.
SPECIAL NOTES
WARNING/CAUTION These terms refer to actions that may result in injury to chair
occupant or staff member and/ or damage to your product. Damage caused by improper
operation of your chair is not covered by your warranty.
WARNING: Staff or others operating the product or moving the occupant must be
aware of the location of the occupant’s hands and feet. Operators must confirm that
the occupant’s extremities are safely located before moving the chair from position to
position, adjusting the position of the chair or moving the occupant from the chair.
WARNING: Place chair in a fully reclined position when cleaning or maintaining
your chair. Your recliner has moving parts that create pinch points. This chair moves
easily without an occupant in the chair and may create pinch points when not is these
positions.
WARNING: This recliner is designed to meet the needs of a wide range of
occupants. Some occupants, due to their unique medical condition, may need
assistance as they sit down or rise from a seated position. It is the responsibility of
the care provider to assess these needs and provide assistance to frail, weak, or
otherwise unsteady occupants. Failure to follow these instructions can result in
occupant falls with potentially serious injury resulting.
CAUTION: This chair is NOT designed to transport occupants.
NOTE: The information contained in this document is subject to change without notice.

(4)
OM00220 220 Manual REV 2 110118
CHAIR CAPACITY INFORMATION
CONCORD RECLINERS:
220 series: 275 lbs.

(5)
OM00220 220 Manual REV 2 110118
RECEIVING NEW CHAIRS
CAUTION: New chair inspection must be done by someone who understands the
instruction pages. Improper operation of the chair may damage the chair and void
your warranty.
It is important to realize that signing the Bill of Lading upon receipt of new product is confirmation
not only that the product that has been received is in the proper amount, but also that it has been
received in satisfactory condition. Once the Bill of Lading is signed there is generally no recourse
against the shipping agent for shipping damage. You have the right to make the driver wait while
you examine the product. Please take advantage of this right. Carefully cut the plastic banding
that secures the packaging; scissors do this safely. Remove the packaging from the chair, lift the
top lid from the tube and remove the tube from the bottom lid. Remove the plastic bag from the
product. Cut straps that secure the casters, unlock the casters and remove the chair from the
packaging.
Depending on how you chose to receive your new product when you placed your order; your
chairs may arrive fully assembled or require some assembly. (If your product is fully assembled;
skip ahead to page 6 “New Chair Inspection”, operating all functions and options). If your product
requires some assembly, please continue with this page.
If you ordered your chair with KD (Knocked Down) packaging assembly is required.
Tools needed: Two 7/16” wrenches.
It is very important to fully assemble the chair so that, in addition to examining the vinyl surfaces,
you may operate the chair through all of the recline functions and operate all the chair’s options
including trendelenburg to ensure that your product is in the same flawless condition in which it
left the factory.
To complete the assembly of a chair that was shipped partly assembled, remove the back
assembly from its position on top of the chair’s base. Identify the back of the base assembly.
Locate the black metal uprights of the mechanism between the arms, along both sides of the base
at the back.
Look at the bottom of the back pillow assembly along each side for the black metal bayonet
mounts which will slide onto the uprights of the mechanism. (Fig. 1 – following page) The back
assembly should be placed front face down on the base assembly with the bottom end toward the
back of the chair frame. Remove the middle bolt on each side of the bayonet mount. Raise the
back assembly placing the bayonet mount on the metal uprights of the base. Once the back is
secure on the base, replace the middle bolt and tighten with your wrenches.
WARNING: Once the back has been assembled, pull upward on the back assembly
to verify it has locked securely in place. If the back rises up, repair the assembly;
using the procedure above.

(6)
OM00220 220 Manual REV 2 110118
Figure 1
New chair inspection
1. Remove all packing material including foam wrap and poly bag. If desired, the bag may
be replaced after examination.
2. Examine chair surfaces for damage.
3. Operate all chair functions and options. This may include tables, casters and chair
positions. Do this immediately upon receipt of your chairs.
To report damage
1. If the freight carrier is still at your location (it is your right to hold the freight carrier
while you thoroughly inspect your delivery), note any damage on the bill of lading. Be
sure to keep shipping cartons, pallets and other shipping materials to prove damage to
the freight carrier. It is also important to save an undamaged carton and pallet in case
the chair must be returned to the factory.
2. Call Champion’s customer service immediately to report the damage: 800-998-5018.
3. All claims must be filed by the consignee and reported to Champion Manufacturing Inc.
within 5 days of receipt of the shipment.
BAYONET MOUNTS
MECHANISM UPRIGHTS
(LH NOT VISIBLE)
REAR VIEW OF CHAIR
CHAIR BACK
CHAIR BASE
BOLTS
MIDDLE BOLT
ONE PER SIDE
MUST BE REMOVED AND RE-INSTALLED
(SEE INSTRUCTIONS ABOVE)

(7)
OM00220 220 Manual REV 2 110118
Return authorization
1. Champion customer service must authorize all returns. Champion customer service will
issue a return authorization number by fax or email. The customer does have the right
to refuse any damaged chair from the carrier at the time of delivery.
2. All returns must be sent prepaid by the sender with exception of provable shipping
damage.
Storage
1. Cover chair and store in a dry area.
2. DO NOT place objects on top of the chair that may damage the vinyl.

(8)
OM00220 220 Manual REV 2 110118
IN-SERVICE PROCEDURES
Before chairs are put into service, all personnel should review this manual.
In the belief that an actual demonstration of the product is more effective than written
instructions, an on-site in-service by a Champion representative may be available depending upon
the delivery circumstances.
WARNING: Place chair in a fully reclined position when cleaning or maintaining
your chair. Your chair has moving parts that create pinch points. This chair moves
easily without an occupant in the chair and may create pinch points when not in these
positions.
WARNING:Never place your hands near or on a recliner mechanism when it is
in motion. Never clean or maintain a chair when an occupant is in the chair. The
occupant is able to control the chair’s position and may move the chair position
unexpectedly, creating pinch points.
WARNING: Keep hands, feet and legs clear of the recline mechanism.
WARNING: When closing the leg rest by hand, make sure your hand is placed on
the top upholstered surface of the footboard only not under the edges or the flip board
as this product has moving parts that my create pinch points. Keep all body parts clear
of the recline mechanism, latches, leg rest and other moving parts
CAUTION:
1. DO NOT overload chair. Observe the specified maximum weight capacity for
the chair model that you have selected.
2. DO NOT attempt to force the chair into position; permanent damage may
result. The chair works with normal effort when operated properly.

(9)
OM00220 220 Manual REV 2 110118
OPERATING INSTRUCTIONS
WARNING: Staff or others operating the product or moving the occupant must be
aware of the location of the occupant’s hands and feet. Operators must confirm that
the occupant’s extremities are safely located before moving the chair from position to
position, moving the chair from place to place, or moving the occupant from the chair.
WARNING: DO NOT overload chair. Observe the specified maximum weight
capacity for the chair model that you have selected.
WARNING: Occupant should always enter and exit the chair in the upright
position. The occupant should never enter or exit the chair with the leg rest up.
Occupants should never “straddle” the extended leg rest or dangle their legs over the
sides of the extended leg rest.
WARNING: Always return the chair to full recline position after using
Trendelenburg.
WARNING: NEVER place your hands near or on the recline mechanism when it is in
motion. DO NOT put your hands where you cannot see.
WARNING: Verify that all casters are locked before the occupant enters or exits
the recliner.
CAUTION: The push handle is not designed to be used to raise the front or rear
casters off the floor when there is an occupant in the chair; doing so may cause
damage to the chair.
CAUTION: The chair works with very little effort when operated correctly. DO NOT
use excessive force to move the recliner to any position. Doing so could result in
permanent damage to the recliner.
CAUTION: DO NOT attempt to close the chair’s leg rest while in the full recline
position. Doing so may damage the recline mechanism. Return the chair to the “TV”
position before closing the leg rest.
Note: The Concord recliner assumes three distinct recline positions: Upright Position; leg rest is
down and the back is in its most vertical position, “TV” Position; leg rest is up and the back is
somewhat reclined. Recline Position; the leg rest is up and the back is completely reclined.

(10)
OM00220 220 Manual REV 2 110118
For safe recliner operation:
1. Always set all the caster brakes before allowing your occupant to get in or out of the chair.
Release the caster brakes only when the chair is being relocated; and reset the caster brakes
upon arriving at your destination. Never assume that the caster brakes have been set; check
to ensure that the caster brakes are engaged before helping anyone in or out of the recliner.
WARNING: DO NOT enter or exit the chair with the leg rest extended.
2. Occupant should always enter (or exit) the recliner with the chair in the upright position.
3. Once seated the occupant should sit fully back in the chair.
4. To recline to the “TV” Position, the occupant should grip the top of the chair arms and apply
pressure to the chair arms and chair back to start the chair moving back. To move further to
thel Recline Position, continue to apply pressure backward. Note that it may be necessary that
the occupant reposition their grip on the arms, moving further back on the arm to move to the
Recline Position.
5. Once in the full Recline Position, staff may use the Trendelenburg feature by stepping on the
pedal on either side of the chair and pressing downward on the back of the recliner. The
Trendelenburg pedals are located under the bottom of each arm. To return from
Trendelenburg, release pressure from the foot pedal and raise the back to the Recline Position.
The Trendelenburg pedal will automatically lock once tin the Recline Position. This prevents
the chair from going into Trendelenburg unexpectedly.
Staff assistance:
CAUTION: DO NOT “step” on the footrest to close the recliner. Doing so can
damage the recline mechanism.
WARNING: When closing the leg rest by hand, make sure your hand is placed on
the top upholstered surface of the footboard only, not under the edges of the flip
board as this product has moving parts that may create pinch points. Keep all body
parts clear of the recline mechanism, latches, leg rest and other moving parts.
To assist an occupant in reclining the chair, simply apply backward pressure to the front of the
chair back pillow. This will start the recline motion and can be stopped in the desired position;
“TV” or Recline. To move the chair from a Reclined Position back to the Upright Position, apply
upward pressure to the back, from the rear, to start the chair moving upward.
CAUTION: This chair is NOT designed to transport occupants.

(11)
OM00220 220 Manual REV 2 110118
Swing Arm Operation:
WARNING:Your recliner has moving parts that create pinch points. When the
swing arms are open, those points are fully exposed. Occupants should NEVER be left
in a chair with the arms in the opened position. THE CHAIR SHOULD NOT BE LEFT
UNATTENDED, WITH THE ARMS UNLATCHED.
CAUTION: Be aware of the path the arm is taking. Swinging the arm into objects
may result in vinyl damage. It is recommended that opening the arm be done with the
chair in the fully upright position or the fully reclined position. If the arm on your
chair is equipped with a fold-down table, relocate any items on the table top and fold
the table top down prior to moving the arm.
Swing arms hinge at the back and may be opened a full 180 degrees. To do this, standing at the
side of the chair, grasp the release handle and lift to release, and swing the arm open.
Once a patient transfer or maintenance is complete, the arm should be returned to the locked
position. To do this, swing the arm back toward the front of the chair until you hear the “click” of
the release handle being secured by the latch; pull outward on the arm to ensure the arm is
securely latched. It may be necessary to lift slightly to move the arm into position for the handle
to latch.

(12)
OM00220 220 Manual REV 2 110118
ACCESSORIES
Accessories are items that may be ordered with your chair at the time of purchase or added by
your technician at any time. Instructions are provided as well as phone support. Discuss any
concerns you may have with the service team at the time you place your order.
WARNING: DO NOT use table as a seat.
CAUTION: Remove items and fold tables down prior to moving the chair.
Foldaway Side Tables
The foldaway side tables are mounted to the arms of the chair. There can be one on either side of the
chair. The side tables can also be ordered with cup holders.
IV Pole
Stainless construction, 1” diameter IV pole features two or four rams horn hooks, adjustable with infinite
positions; extended effective length 64”.
IV Pole Bracket
This bracket is used to mount IV pole on backside of either or both arms and accommodates a 1” diameter
pole.
IV Pole Base
The IV pole base accepts transfer of IV pole from chair bracket to IV pole base allowing patient to be mobile
and free of the chair.
Head Pillow/Lumbar Support
This removable cushion can be used for head or lumbar support. The pillow attaches around back of chair
with hook and loop fastener strap to allow placement of pillow at various positions to best suit the occupant.
Oxygen Tank Bracket
Left side only: bracket holds most O2tanks on the back of the chair arm.
Arm Covers:
Arm covers minimize the wear-and-tear on recliner arms. They fit snugly on the arm of the chair and are
easy to clean.
NOTE: Chair, options and /or accessories covered in this manual may change without notice.

(13)
OM00220 220 Manual REV 2 110118
Note: Some components may have a different appearance as shown in the picture due to multiple
models of chairs. The serial number of the chair identifies the exact build of your chair assisting
Customer Service in the choice of the proper components for your chair.

(14)
OM00220 220 Manual REV 2 110118
GENERAL MAINTENANCE AND CARE OF CHAIRS
WARNING: Place chair in a fully upright and securely latched position or a fully
reclined position when cleaning or maintaining your chair. Your recliner has moving
parts that create pinch points. This chair moves easily without an occupant in the
chair and may create pinch points when not in these positions.
WARNING: You should NEVER clean or maintain your recliner with an occupant in
the chair.The occupant is able to control the chair’s position and may move the chair
position unexpectedly, creating pinch points.
CAUTION: Occupants who wear or use new unwashed articles of clothing may
create a permanent fabric dye stain on the vinyl surface of the chair. This is beyond
our control and may not be covered by your warranty.
It is not necessary or recommended that moving parts of the chair be lubricated. Keeping the chair
clean is the main maintenance requirement.
It is recommended that the underside of the chair be checked periodically for waste materials that
have fallen under the chair.
The ease with which your recliner operates is controlled by the recline mechanism of your chair.
The actuation setting from the factory is not adjustable.
If a part becomes worn or broken, see the sections entitled service and warranty for information.
Periodically, check that the hinge fasteners, latch mount, release mount and back mount fasteners
are secure. (How often depends on the amount of use the option receives. We suggest monthly,
and then tailor to your findings.)
The top of each latch mount has plastic buttons that are designed wear points. Check the buttons
and replace when worn to prevent damage to the arm’s vinyl covers. Again, we suggest periodic
checks that are then tailored to your findings. (How often depends on the amount of use the
option receives. We suggest monthly, and then tailor to your findings.)
Periodically, check the back mount brackets to verify they are securely latched in place. This can
be done by pulling upward on the back. The back should not freely pull upwards off of the recline
mechanism. If this occurs, firmly press the back down onto the recline mechanism and recheck
that it is securely latched. (How often depends on the amount of use the option receives. We
suggest monthly, and then tailor to your findings.) If it does not latch into place, discontinue the
use of the chair and contact Champion customer service for replacement parts 800-998-8018.

(15)
OM00220 220 Manual REV 2 110118
GENERAL CLEANING PRECAUTIONS
WARNING:When solvent type cleaners are being used, care should be exercised.
KEEP AWAY from fire or flame and use in a well ventilated area.
CAUTION: High pressure wash or “hosing down” chairs is not recommended.
CAUTION: Use of vinyl “conditioners” or “protectants” is not recommended. Vinyl
“conditioner” or “protectants” can cause plasticizers to migrate out of the vinyl
causing it to become “boardy” and eventually embrittled. This will prematurely age
your vinyl and is not covered under warranty.
Some institutional cleaners or disinfectants may cause discoloration of the vinyl. Use of cleaners,
other than those recommended by the vinyl manufacturer, is at the clinics own risk. Follow the
vinyl manufacturer’s cleaning recommendations. If you are unsure of your vinyl pattern
and color, please call Champion’s customer service department with the serial number from your
chair. The serial number can be found on the back frame of the chair on the left hand side.
Certain medications may produce a metabolite in the patient’s perspiration which can stain or
discolor fabric. If you have any questions, please call Champion’s customer service department at
800-998-5018.
GENERAL CLEANING – VINYL
IMPORTANT: For specific cleaning instructions, please see manufacturer’s cleaning
instructions included in the Vinyl Cleaning Instructions also on this in-service disk.
Chairs are constructed of various vinyls; depending upon the customer’s preference. Each vinyl
manufacturer has a cleaning process that they endorse for their product. Each manufacturer
produces their product with a protective finish to help keep staining agents from penetrating the
vinyl and becoming a permanent stain. It is always important to remove a spill as soon as
possible after it happens, as this reduces the possibility that the stain will penetrate
the protective coating and migrate into the vinyl, becoming a permanent stain.
All manufacturers recommend a process of several different steps for cleaning their vinyl. It is
especially important to use all steps, in order, when working on a complex spill (one that has
several different potential staining agents).
BEGIN by cleaning with a non-abrasive, all purpose household cleaner using a soft cloth or damp
sponge. Rinse with clean water.
Follow with solvent type cleaner using a soft bristle brush or soft cloth. Use at full strength.
Follow with a clean water rinse and pat dry.
CAUTION: Limit use of strong active solvent cleaners per manufacturer’s
instructions; unlimited use may remove the protective finish on the material
NEXT use strong active solvent cleaners. This may be used with a soft cloth, again limit use
per manufacturer’s instruction; unlimited use may remove the protective finish. This
cleaner should be followed with a clean water rinse.

(16)
OM00220 220 Manual REV 2 110118
GENERAL CLEANING – PLASTIC TABLE TOPS
CAUTION: Do not use strong solvents such as Picrin®. They will damage your
table top. Champion does not recommend the product “Goof-Off®”
CAUTION: Compounds that are safe to use on the vinyl surfaces of your chair may
not be appropriate for cleaning your table top.
It is always easier to clean the table immediately after a spill. When the residue from a spill has
dried on the table, a soft bristle brush may be used to help bring it back into solution. Rinse the
surface with clean water. For residue that is not readily soluble in bleach and water, try hot water
and dish washing liquid. Rinse and use absorbent material to remove as much liquid as possible.
You may also try rubbing alcohol, applying a small amount of alcohol with a cloth, rubbing the
dried-on residue. It may take several applications to dissolve the residue. On any remaining
material, you may try nail polish remover (acetone and water) with a soft cloth.
GENERAL INFECTION CONTROL – VINYL
Note: Infection control standards are the responsibility of the facility. Bleach solution
recommendations from a vinyl manufacturer are not intended to supersede the facility’s infection
control standards. Information from the vinyl manufacturer is meant to establish an upper limit
beyond which damage might occur.
WARNING: NEVER mix ammonia, or a cleaner with ammonia, with bleach as
dangerous compounds may result.
CAUTION: Do not use an iodine based solution since vinyl is an iodinophil material
and will stain under this condition. If a solution other than a bleach solution is used
and you are uncertain if it is iodine based, please test on a hidden portion (bottom
back flap) of the vinyl.
All vinyl manufacturers recommend use of bleach and water as a disinfectant. For standards
specific to your particular vinyl, consult your vinyl cleaning instructions located in a separate file on
this disk. For your disinfection standard consult your facility’s standard. For maximum allowable
bleach concentration consult information specific to the vinyl your chair is upholstered with per the
manufacturer’s cleaning instructions.
If you are using disinfection agents other than bleach and water; do not hesitate to call
Champion’s Customer Service for assistance in determining whether there may be any concerns
about that agent and the vinyl that you have chosen.
For any upholstery that is not Champion approved, the customer is responsible for
obtaining cleaning instructions on that specific covering. This would include all COM
(Customers Own Material) or custom vinyls.
If you do not know what vinyl your recliner is upholstered in, call Champion’s
customer service 800-998-5018 with the serial number of your chair to obtain
assistance.

(17)
OM00220 220 Manual REV 2 110118
WARRANTY PROCEDURE
File a Warranty Claim
Calling customer service may institute a warranty claim. At that time, you will be asked to provide:
●your name and facility name
●your phone, fax number, email address
●the serial number of your product, and
●the nature of your problem
Having the above information available at the time that you call will speed the process. In order
to provide prompt accurate service, it may be necessary to request further information about the
chair function to accurately define the problem.
Warranty Coverage
Your coverage is per the Champion warranty. A copy of the current warranty was provided with
this manual for your convenience. Please read this document.
Warranty Does Not Apply If:
●Repairs have been made that were not authorized or under the
direction of Champion Manufacturing Inc.’s service department.
●Required repairs are due to normal wear and tear.
●Product has been abused, improperly used or maintained.
●Alterations have been made to the chair.
●Improper cleaning agents have been used.
●Repairs have been made with parts other than Genuine Champion repair parts.
Whether your claim is covered under warranty may not always be determined at the time of your
call. Where the possibility of improper use exists, a determination will be made upon receipt of
damaged components or product. In these cases. components or product will be shipped with the
express understanding that if damage is not covered by warranty all costs are the
responsibility of your facility.
Note: Shipping charges are not covered under warranty with the exception of provable shipping
damage.

(18)
OM00220 220 Manual REV 2 110118
SERVICE INFORMATION
The mission of the customer service department is to get your chair up and running as quickly as
possible. It is critical that the customer service department know what product you have, and
exactly what is wrong with the product. If you have questions or problems, you should never
hesitate to call for assistance: 800-998-5018.
The most timely and cost effective way for your chair to be repaired is for the Champion’s
customer service department to work with your maintenance department or equipment technician.
Determining the Problem
What is wrong with the chair should be determined by troubleshooting. The customer service
department will assist you with this by asking you questions about the chair function.
Serial Number
The chair serial number identifies the precise configuration of your chair; this is critical to receiving
correct components and instructions. This number is required to process your request.
The serial number is located in the back of the chair on the lower left side on the label entitled
Champion Manufacturing -Serial #xxxxxx.
PARTS IDENTIFICATION
To identify worn or damaged components please refer to appropriate product schematics.
To obtain repair part numbers refer to the parts listing key using the schematics page and item
number.
Parts orders may be placed by using the convenient fax order form in this manual or by calling
Champion’s customer service 800-998-5018.
When placing an order by phone you will be asked to provide:
●your name and facility name
●your phone, fax number, email address
●the serial number of your product, and
●the nature of your problem
Having the above information available at the time you call will expedite the process. In order to
provide prompt, accurate service it may be necessary to request further information about the
chair function to accurately define the problem.

(19)
OM00220 220 Manual REV 2 110118
SERVICE PARTS FORM
Please duplicate form for use
Ship to: Shipping instructions:
Facility:______________________________ Ground: ______
Address:______________________________ 3rd day: _______
______________________________ 2nd day: _______
City: ___________________ State_____ Zip________ Next day: _____
Telephone: (_____) _____ / _________ Fax : (_____) _____ / _________
Reminder: if no shipping choice is made, the least expensive way will be used.
Bill to:
Facility:______________________________
Address:______________________________
______________________________
City:____________________ State_____ Zip_________
Order placed by: Purchase order #: ______________
Name:________________________________ No order will be processed
Phone: (_____) _____ / _______ Ext.: ______ without a P.O. & SN number.
Email:_____________________________________
Model number: _________________________ Serial number: _________________
Part number
Page no. / part no.
Quantity
Champion Manufacturing Inc.
2601 Industrial Parkway
Elkhart, IN 46516
Phone: [phone] fax: [phone]
