Chargery 5006B User manual

5006B 5008B 50010B
for up to 10S LiPo & LiFe
5mV voltage accuracy
500W charge power
1.3A balance current
2.8” TFT CD display
T hanks for your purchasing the 500W CHARGER for your RC.
R ead the ENTIRE instruction anual to beco e fa iliar with the features/functions of the device
before operating.
F eel free to send an e ail to [email protected] or call at 86 755 2643 6165 should you have
any questions and suggestions.
Jason Wang

Synchronous Balancer/Char er/Dischar er 5006B 5008B 50010B V1.10T
www.chargery.com page 2 total 16
Chargery 5006B,5008B,50010B Series charger uses advanced Synchronous buck-boost DC/DC converter
technology, high power, high current and high-performance power conversion circuit. The maximum charge
power up to 500W, the maximum charge/discharge current is up to 20A. The charger can charge up to 10S iPo,
ilo, iFe, with maximum 1.3A balance current, adopts unique balance circuit resume fast all cells voltage.
Safety Notes
Please read the manual completely before using, to make sure you can use this device better and more safely.
1. Keep the charger away from children and pets at all times.
2. Never leave the charger unsupervised when charging or discharging. If you leave, disconnect the battery to
prevent any unexpected dangers or damage.
3. Ensure the charger program and settings match the battery pack otherwise the battery will be damaged and
a dangerous situation may arise, especially for ithium batteries which may cause a fire.
4. Do not mix batteries of different types, different capacities or from different manufacturers.
5. Never charge or discharge any battery having evidence of leaking, expansion/swelling, damaged outer cover
or case, color-change or distortion.
6. Do not place the charger or any battery on a flammable surface or near a combustible material while in use.
Do not charge or discharge on a carpet, cluttered workbench, paper, plastic, vinyl, leather or wood, inside an
R/C model or inside a full-sized automobile.
7. Do not try to charge “non-rechargeable” dry cells.
8. Never block the air intake holes and Don't use the charger in a refrigerated or high temperature
environment.
9. Do not allow water, moisture, metal wires or other conductive material into the charger.
10. Do not exceed the battery manufacturer’s suggested maximum charge and discharge rates.
11. Carefully follow the battery pack manufacturer’s recommendations and safety advice.
Copyri ht
Copyri ht@Char ery Power Co., Ltd. All ri hts reserved.
Without prior written consent by Shenzhen Chargery Power Co., td, any units or individual extract and copy
parts or entire contents of this manual, and transmission in any form is illegal and strictly prohibited.
The product described in this manual, may include copyright software ownership belonged to Shenzhen Chargery
Power Co., td and its licensee, except getting the permission from relevant rights holders, otherwise any copy,
distribute, modify, excerpt, decompile, disassemble, decrypt, reverse engineering, lease, transfer, sub-license,
as well as other acts of infringement of software copyright is strictly prohibited, but apart from the restrictions
prohibited by applicable law.

Synchronous Balancer/Char er/Dischar er 5006B 5008B 50010B V1.10T
www.chargery.com page 3 total 16
Special Features
1. Unique charge architecture realized better transient response to any changes of voltage on input and output.
2. The charger use advanced ADC measurement technology, high accuracy, high voltage and high current
detection circuit. The maximum voltage measurements tolerance is within 5mV at up to 10S iPo battery.
3. The charger adopts advance balance circuit and Algorithm, constant 1.3A per cell balance current is very
useful for large capacity battery pack, the feature can resume all cell voltage balance status at the shortest
time. Over temperature protection make sure the system safety during balance.
4. Charger internal temperature protection. When the internal temperature exceeds the reduce temperature,
the output power is automatically decreased; and the charger will stop working when temperature exceeds
the shut-down temperature.
5. Intelligent fan control circuit sense internal temperature via temperature sensor, to thereby control the fan
speed.
6. TFT CD screen provides rich information including current, voltage, power, capacity, time, working status
and temperature and so on.
7. The charger features a maximal safety protection,
 Reversed polarity protection on input and output,
 Anti-spark on input and output
 Wrong battery pack connection protection when multi battery pack connected in series on adapter
board.
 Charge time, charge capacity and battery temperature protection
8. Supports upgrading the firmware program by USB port.
Specifications
1. Input voltage: DC 10-28V, 30V max.
2. Input Current: 25A maximal
3. Charge current: 0.1-20A, 500W max.
4. Discharge Current: 0.1-10A, 35W max.
5. Accuracy of the cell voltage: -5mV/+5mV
6. Balance current: 1.3A per cell only for iPoly, i-ion and iFePO4 battery pack
7. Battery Type: iPoly, i-ion, iHV, iTo, iFePO4, NiMh/NiCd, Pb acid(VR A) battery pack
5006B 5008B 50010B
iPo/ iHV battery
1)
1-6S 1-8S 1-10S
iTo battery 1-6S 1-8S 1-10S
iFePO4 battery 1-6S 1-8S 1-10S
NiMH/NiCd battery
2)
1-20S 1-24S 1-30S
Pb battery 1-12S (24V) 1-12S (24V) 1-18S (48V)
1) The terminal voltage per cell can be set up to 4.40V only for High Voltage iPo battery. i-ion,
NMC( LiNiMnCoO2 ) battery is also be supported.
2) NiMh/NiCd cell count is identified automatically
Mechanical Characteristics
 Size：154*114*33 ( ×W×H, mm) or 6.1×4.48×1.3 ( ×W×H, inch)
 Weight: 680g
 Input power cable: AWG14 wire, 600mm length

Synchronous Balancer/Char er/Dischar er 5006B 5008B 50010B V1.10T
www.chargery.com page 4 total 16
Packa in Content
 Charger unit: 1pcs
 Power cable: 1pcs, AWG14 wire, 320mm length with 4mm gold male connector
 USB data line: 1pcs
 Temperature sense lead: 1pcs
 adapter wire: 1pcs, connect charger to adapter board
 adapter board:1pcs
Interface
DC Input Input power supply or battery, DC voltage range is 10V to 28V, absolutely 30V maximal
USB port Connect to PC update the firmware by Chargery UpdateTool.
Output port Connect to battery discharge or charge.
Temperature
sensor port
Connect to temperature sensor monitor battery temperature, the sensor must be pasted
tightly battery during charge or discharge. battery temperature can affect battery life and
performance seriously, the maximal temperature should not be over 40 ℃ during charge.
Balance port Connect to adapter board or battery directly for Balance charge or Balance only.
STOP/SET When the charger operate any program, Press STOP button terminate it.
In main interface, and no any program operate, Press for 2 seconds get the cell and battery
impedance.
DOWN Decrease parameter value or alternate menu item
UP Increase parameter value or alternate menu item
ENTER/START
In main interface, press for 3 seconds, the unit will enter into function interface directly,
press for 3 seconds will operate last program directly.
In Battery Type interface, press for 3 seconds, the unit will enter into charger setting menu.
In Memory Select interface, press for 3 seconds, the unit can edit memory name
In function interface, press for 3 seconds, the unit will operate chosen program.
DC Input
USB port
STOP/SET
DOWN
UP
ENTER/START
Output port
Temperature Sensor
Balance port

Synchronous Balancer/Char er/Dischar er 5006B 5008B 50010B V1.10T
www.chargery.com page 5 total 16
Pro ram Settin
1. In Battery Type interface, Press ENTER/START button for 3
seconds enter into CHARGER SETTING interface.
2. Press UP or DOWN button select the item, press STOP/SET
shortly make the value flash, and press UP or DOWN change
the value. Press STOP/SET button shortly confirm the
change. After finish all setup, press STOP/SET for 3 seconds
quit the setup menu.
3. When quit setup mode, The charger will save all parameters
till next change.
NOTE: Please keep the default setup unless for special purpose.
Parameters Min. Default Max. Step unit
Temperature Unit Celsius Fahrenheit
Fan ON, Fan start temperature 35 40 50 1 ℃
Shut Down, the charger stop working when internal
heat sink temperature reach the value 50 70 70 1 ℃
Battery Temp. Cut 25 40 80 1 ℃
Maximal Capacity, maximal charged capacity 10 120 200 1 %
Safety Timer, maximal charged time
(1)
1 120 9999 1 min
Key Beeper ON OFF
Alarm Tone 5 10 20 1 second
Done Tone
(2)
CD Back- ight Time
(3)
1 10 255 1 min
Charge power 10 500 500 1 W
Discharge power 5 35 35 1 W
Cell Voltage Calibration
(4)
NOTES:
1) if alternate choose OFF, the safety timer will be inactive.
2) Done tone sound have 4 mode: 30seconds, 3 min, 5times and always. press ENTER/START or STOP/SET
turn off the sound.
3) Always will make the CD Back- ight is ON till power off the charger
4) Cell Volta e Calibration is not recommended, all voltage and current is calibrated before delivery.
when need calibrate cell voltage, In Battery Type interface,please press ENTER/START Button for 3 seconds
enter into CHARGER SETTING interface, press DOWN button select Cell Voltage Calibration and press
ENTER/START button shortly enter into calibration interface as following picture.
a) Choose Cell Voltage Calibration and
press ENTER/START button shortly,
you will find cells voltage, press
ENTER/START and UP/DOWN modify
voltage according to standard
voltage, choose NEXT and press
ENTER/START button for 3 seconds
save.
b) Choose Default Cell Voltage and press ENTER/START shortly resume all cell voltage to default value.
c) Press ENTER/START for 3 seconds return previous interface.
