CA-8 & CA-8F Easy Controller User’s Manual
CA-8 Easy & CA-8F Foot Controller
Quick Overview
If you have misplaced the User’s Manual for the fixture you are attempting to control, you can
locate it by visiting WWW.CHAUVETLIGHTING.COM
The CA-8 & CA8F Controllers provide additional wired remote functionality to a
designated range of CHAUVET DMX lighting fixtures. Depending on the fixture
the Function and Mode buttons will have varying affect. Please refer to the user’s
manual supplied with the applicable lighting fixture for detailed button
functionality.
Stand-By
In general, this
function will
provide a blackout
mode to all units
connected. A
blackout turns all
lamps off.
Function
The function button is a multi-
purpose button providing for the
selection of minor program
changes, such as strobing, step
advancement, fast/slow selection
and more features that heavily
depend on the particular lighting
fixture you are controlling. The user
will need to review the section
about the CA-8 Easy Controller in
the Users Manual of the lighting
fixture he/she is controlling to
determine the specific outcome.
Mode
This button also
serves a multi-
purpose function.
Depending on the
lighting fixture,
the mode button
could make
available the
selection of
programs, audio
enable or
slow/fast speeds.
Please refer to the user’s manual supplied with the applicable lighting fixture for detailed button functionality.
CA-8F Foot Controller Dimensions
Individual product: 7 x 9.25 x 1.75 in (178 x 235 x 44.5 mm)
Shipping: 9 x 9.75 x 2.63 in (229 x 248 x 67 mm)
