Chauvet COLORstrip Footswitch User manual

Footswitch (LED-FS1)
User Manual

Page 2 of 10 COLORstrip™ Footswitch User Manual Rev. 3
TABLE OF CONTENTS
1. Before You Begin................................................................................3
What Is Included ...........................................................................................3
Unpacking Instructions..................................................................................3
Claims...................................................................................................................3
Text Conventions..........................................................................................3
Icons.............................................................................................................3
Document Information...................................................................................3
Product at a Glance.......................................................................................4
Safety Notes .................................................................................................4
2. Introduction.........................................................................................5
Product Overview..........................................................................................5
3. Setup...................................................................................................6
Power ...........................................................................................................6
Mounting.......................................................................................................6
Orientation.............................................................................................................6
4. Operation ............................................................................................7
Foot Controller Functions..............................................................................7
Speed <2> Button Functions Table.........................................................................7
5. Technical Information ........................................................................8
Product Maintenance ....................................................................................8
General Troubleshooting...............................................................................8
Contact Procedure ........................................................................................9
CHAUVET® Contact Information...................................................................9
Returning Products to CHAUVET®................................................................9
6. Technical Specifications..................................................................10

COLORstrip™ Footswitch User Manual Rev. 3 Page 3 of 10
1.BEFORE YOU BEGIN
What Is
Included
•1 x COLORstrip™ Footswitch
(LED-FS1)
•1 x 10 ft 6-pin DIN cable
•1 x Warranty Card
•1 x User Manual
Unpacking
Instructions
Immediately upon receipt, carefully unpack the product
and check the container to make
sure you have received all the parts indicated above in good condition.
Claims
If the container or the material inside the container (the product and
included
accessories) appear damaged from shipping, or show
signs of mishandling, notify the
carrier immediately, not CHAUVET®.
Failure to do so in a timely manner may invalidate
your claim with the carrier. In addition, keep the container and all the pa
cking material
for inspection.
For other issues such as miss
ing components or parts, damage not related to shipping,
or concealed damage, file a claim with CHAUVET®
within seven (7) days of receiving
the merchandise.
Text
Conventions
Convention
Meaning
1~512
A range of values
50/60
A set of values of which only one can be chosen
Settings
A menu option not to be modified
Menu > Settings
A sequence of menu options to be followed
<ENTER>
A key to be pressed on the product’s control panel
ON
A value to be entered or selected
Icons
Icon Meaning
Critical installation, configuration, or operation information. Failure
to comply with this information may render the product partially or
completely inoperative, cause damage to the product, or cause
harm to the user.
Important installation or configuration information. Failure to
comply with this information may prevent the product from
functioning correctly.
Useful non-critical information.
Document
Information
The information and specifications contained in this document are subject to change
without notice. CHAUVET® assumes no responsibility or liability for any errors or
omissions that may appear in this manual.
CHAUVET® reserves the right to update the
existing document or to create a new document to correct any errors or omissions.
You can download the latest version of this document from www.chauvetlighting.com.
© Copyright 2013 CHAUVET®. All rights reserved.
Printed in P.R.C.
Electronically published by CHAUVET® in the United States of America.
Author
Date
Editor
Date
A. Leon 06/14/13 T. Yeago 06/17/13

Page 4 of 10 COLORstrip™ Footswitch User Manual Rev. 3
Product at a
Glance
Use on Dimmer
x
Auto Programs
x
Outdoor Use
x
Fixed voltage (120 V or 230 V)
Switchable voltage (120 V/230 V)
Auto-ranging Power Supply
x
Sound-Activated
x
Replaceable Fuse
Circuit breaker
x
DMX
x
User-Serviceable
x
Master/Slave
x
Duty Cycle
x
Safety Notes
Please read the following Safety Notes carefully before working with the product. The
Notes include important safety information about installation, usage, and maintenance.
•Always connect the product to a grounded circuit to avoid the risk of electrocution.
•Always disconnect the product from the power source before cleaning.
•Make sure the power cord is not crimped or damaged.
•Never disconnect the product from power cord by pulling or tugging on the cord.
•
Make sure there are no flammable materials close to the product when operating.
•Always make sure that the voltage of the outlet to which you are connecting the
product is within the range stated on the decal or rear panel of the product.
•The product is for indoor use only! (IP20) To prevent risk of fire or shock, do not
expose the product to rain or moisture.
•Always install the product in a location with adequate ventilation, at least 20 in (50
cm) from adjacent surfaces.
•Never connect the product to a dimmer.
•Never carry the product from the power cord or any moving part. The maximum
ambient temperature (Ta) is 104° F (40° C). Do not operate the product at higher
temperatures.
•In the event of a serious operating problem, stop using the product immediately.
•Never try to repair the product. Repairs carried out by unskilled people can lead to
damage or malfunction. Please contact the nearest authorized technical assistance
center.
•Keep this User Manual for future consultation. If you sell the product to another
user, be sure that they also receive this document.

COLORstrip™ Footswitch User Manual Rev. 3 Page 5 of 10
2.INTRODUCTION
Product Overview
Power Indicator
LED
6-pin DIN cable
connection (rear)
Scene Button
Speed Button
Function Button
Blackout Button
