TFX-SWF Foot Controller User Manual
TFX-SWF
Stage Wash™ Foot Controller
Quick Overview
STAND-BY FUNCTION MODE
TFX- WFS
The TFX-SWF is a compact, easy to operate, stand-alone foot controller for the Stage Wash™
950, 1550 and 1800. The TFX-SWF will activate built in programs in the unit.
TFX-SWF Specifications
Shipping: 8.97 x 5.31 x 1.57 in (228 x 135 x 40 mm)
Weight: 3.1 lbs (1.4 Kgs)
Linkin
g
cable: 10m 8-
p
in cable
NOTICE!
The TFX-SWF Foot Controller is used only in master/slave mode. Connect the 8-pin connector of
the foot controller into its respective connector on the first unit in the daisy chain. The table below
describes the functions of the TFX-SWF Controller.
Technical Support
Address: Service Dept.
3000 N 29th Ct, Hollywood, FL 33020 (USA)
Support Email: [email protected]
Tel: [phone] Press 4
Fax: (954) 929
-
5560 Attention Service
Stand By Mode Function
Auto
Led 1: Off
Led 2: Off
Fixtures will run built in programs
automatically
Audio
Led 1: Off
Led 2: On
Fixtures will run built in programs to the
sound.
Manual
Led 1: On
Led 2: Off
Full/CB:
Hold: pedal to set to Full On
Bump: Pedal to set dimming levels
Blackout
Manual
Led 1: On
Led 2: On
Full/CB:
Hold: pedal to set dimming levels
Release: Pedal to set to Full On
LED 1 LED 2
