Chauvet Q-WASH 560Z-LED User manual

Quick Reference Guide

Q-Wash 560Z-LED QRG
Page 2 of 16
About This
Guide
The Q-Wash 560Z-LED Quick Reference Guide (QRG) contains connection
and mounting information, as well as menu options and DMX values.
Disclaimer
Refer to the User Manual for detailed information and instructions. You
can download the User Manual from the CHAUVET® website:
www.chauvetpro.com.
Read ALL the disclaimers and Safety Notes in this document, as well as
those in the product’s User Manual before installing, operating, or
maintaining this product.
Safety Notes
DO NOT open this product unless instructed. It contains no user
serviceable parts.
DO NOT look at the light source when this product is on.
DO NOT touch the product when it is operating because it may be hot.
DO NOT cover the ventilation slots when the product is operating to
avoid internal overheating.
DO NOT install or operate this product where there is less than 50 cm to
the nearest surface to allow adequate ventilation around it.
DO NOT leave any flammable material within 50 cm from this product
while operating or connected to the power outlet to minimize the risk of
fire.
DO NOT carry this product from the head. Use the handles instead.
DO NOT lift the unit by the housing. Use the handles instead.
DO NOT mount this product overhead without using a safety cable.
DO NOT operate this product outdoors or in any location where dust,
excessive heat, water, or humidity may affect it.
DO NOT operate this product if you see damage on the housing, lenses,
or cables. In any of these cases, have the damaged parts replaced by an
authorized technician immediately.
DO NOT connect this product to a dimmer or rheostat.
ONLY connect this product to a grounded and protected circuit.

Q-Wash 560Z-LED QRG
Page 3 of 16
What Is
Included
One Q-Wash 560Z-LED
One IEC Power Cord With
Edison Plug (US market)
One Safety Cable
Two Omega Brackets
Warranty Card
Quick Reference Guide
Features
12 or 15-channel RGBWA LED moving yoke wash product
Pan: 540
Tilt: 270
RGBWA color static mixing with or without DMX control
Vector speed channel for RGBWA color mixing
Variable zoom
Variable electronic strobe
Continuously variable electronic dimmer (0~100%)
Built-in automated programs
Remote product reset and vector speed channel
255-step fully customizable program
Dimming speed control via control panel or DMX
Recall auto or custom programs via control panel or DMX
Color temperature presets (3,200~10,000 K)

Q-Wash 560Z-LED QRG
Page 4 of 16
Product
Description
The Q-Wash 560Z-LED is an RGBWA LED moving yoke wash product.
This product consists of a base section and a moving yoke. The head
contains the 91 RGBWA LEDs and the zoom motors. The base section has
the 3- and 5-pin DMX input and output sockets, the IEC power input
connector, and the LCD-based control panel.
Product Overview
Power Input IEC
Socket
Power Switch
Fuse holder
3-pin DMX In
3-pin DMX Out
5-pin DMX Out
5-pin DMX In
Control panel

Q-Wash 560Z-LED QRG
Page 5 of 16
AC Power
The Q-Wash 560Z-LED has an auto-ranging power supply that works with
an input voltage range of 100~240 VAC, 50/60 Hz.
Replacing
the Fuse
1. Disconnect this product from the power outlet.
2. Using a flat head screwdriver, wedge the tip into the slot of the fuse
holder.
3. Pull out the installed fuse by prying the safety cap out of the housing.
4. Remove the blown fuse from the safety cap and replace with a fuse of
the exact same type and rating.
5. Insert the fuse holder back in place and reconnect power.

Q-Wash 560Z-LED QRG
Page 6 of 16
DMX Linking
The Q-Wash 560Z-LED will work with a DMX controller using a regular
DMX serial connection.
If you are not familiar with the DMX standard, download the DMX Primer
document from www.chauvetpro.com.
DMX Connection
The Q-Wash 560Z-LED uses a regular DMX data connection for its DMX
personalities: Advanced, Basic, and G1.
Download the Q-Wash 560Z-LED User Manual.
Refer to the Setup chapter to learn how to connect this product to DMX.
Refer to the Operation chapter to learn how to configure this product for
DMX.
Master/Slave
Connection
The Q-Wash 560Z-LED uses the DMX data connection for its Master/Slave
mode.
Download the Q-Wash 560Z-LED User Manual.
Refer to the Setup chapter to learn how to connect for master/slave
operation.
Refer to the Operation chapter to learn how to configure master/slave
operation.

Q-Wash 560Z-LED QRG
Page 7 of 16
Mounting
Before mounting this product, read the Safety Notes at the beginning of this
Guide and in the User Manual.
Refer to the Setup chapter in the User Manual for detailed mounting
instructions.
Product
Mounting
Diagram
Floor Mounting
Overhead Mounting
C Clamps (not included)
Omega brackets (included)
Safety cable (included)

Q-Wash 560Z-LED QRG
Page 8 of 16
Programming
Refer to the User Manual for detailed instructions on programming this
product.
Control Panel
Description
Button
Function
<MENU>
Exit from the current menu or function
<ENTER>
Enable the currently displayed menu or accept the currently
selected value
<UP>
Navigate upward through the menu list and increase the
numeric value when in a function
<DOWN>
Navigate downward through the menu list and decrease the
numeric value when in a function
Password
After being prompted, enter the following password by pressing:
<UP>, <DOWN>, <UP>, <DOWN>, <ENTER>.
This password cannot be changed and will be the password you use each
time you are prompted.
Start Address
To ensure you can fully access all channels in each DMX mode, the highest
recommended DMX addresses are as follows:
Mode
Address
Advanced
498
Basic
501
G1
498

Q-Wash 560Z-LED QRG
Page 9 of 16
Menu Options
Main Level
Programming Levels
Description
INTRO
ADDRESS
001~512
Selects a starting DMX address
RESET
NO/YES
Resets the product’s custom settings
FAN
HIGH
Select the fan’s operation mode.
NOTE: Product’s controller will force the fan to
High if the product’s internal temperature becomes
too high, despite any manual or DMX setting
NORMAL
LOW
AUTO
RUN
DMX512
Selects DMX running mode
AUTO 1
Selects the first automatic program
AUTO 2
Selects the second automatic program
CUSTOM
Selects the user customizable program
SLAVE
Selects the Slave running mode
TEST
Starts the product’s test sequence
CHANNELS
BASIC
Selects the 11-channel DMX mode
ADVANCED
Selects the 15-channel DMX mode
G1
Selects the 15-channel DMX mode
DISPLAY
60 CLOSE
Turns off the display after 60 seconds
BRIGHT
Keeps the display on
KEYLOCK
NO/YES
Activates/deactivates the control panel password
DIMMER
DIMMER 4~1
Slow (DIM 4) to fast (DIM1) dimmer curves
DIMMER 0
Linear dimmer
INFO
EDITION
Shows the version of the installed S/W
INVERT
Pan
NORMAL/
REVERSE
Defines the pan direction
Tilt
Defines the tilt direction
Dimmer
Defines the direction of the dimmer fader
Use
NO/YES
Activates the changes
RANGE
P/Start
000~255
Sets the pan start point (restricted range)
P/Finish
Sets the pan end point (restricted range)
T/Start
Sets the tilt start point (restricted range)
T/Finish
Sets the tilt end point (restricted range)
Use
Activates the changes
SPECIAL
Black delay
NO/YES
Activates the move-in black delay (3 s)
Reset
DMX
The DMX controller can reset the product
SYSTEM
The control panel can reset the product
Power
NORMAL/
HIGH
LEDs illuminate at normal or high intensity
NOTE: Product will return to Normal if
temperature becomes too high
Color
UC
White output matches that of older products
RGBTOW
White output set by RGB-W
OFF
White output defined by RGBW faders
Fan
DMX
The DMX controller can set the fan speed
SYSTEM
The control panel can reset the fan speed
Continues on the next page

Q-Wash 560Z-LED QRG
Page 10 of 16
Main Level
Programming Levels
Description
EDIT
STEP
000~255
Selects the program step
PAN
Selects the pan position
TILT
Selects the tilt position
SPEED
Selects the pan/tilt speed
RED
Combines red, green, blue, white, and amber to
obtain a custom color
GREEN
BLUE
WHITE
AMBER
DIMMER
Selects the dimmer value
STROBE
Selects the strobe frequency and mode
ZOOM
Select the zoom position
DIMSPEED
Selects the dimmer speed
TIME
Selects the step duration
USE
No/Yes
Activates the changes
EXTRA
PASSWORD
****
Opens the Extra menu (refer to next page)

Q-Wash 560Z-LED QRG
Page 11 of 16
Extra Menu
1st Level
2nd Level
3rd Level
4th Level
Description
Calib
3200 K
Red
000~255
Sets color temperature for Macro > White 1
Green
Blue
3400 K
Red
000~255
Sets color temperature for Macro > White 2
Green
Blue
4200 K
Red
000~255
Sets color temperature for Macro > White 3
Green
Blue
4900 K
Red
000~255
Sets color temperature for Macro > White 4
Green
Blue
5600 K
Red
000~255
Sets color temperature for Macro > White 5
Green
Blue
5900 K
Red
000~255
Sets color temperature for Macro > White 6
Green
Blue
6500 K
Red
000~255
Sets color temperature for Macro > White 7
Green
Blue
7200 K
Red
000~255
Sets color temperature for Macro > White 8
Green
Blue
8000 K
Red
000~255
Sets color temperature for Macro > White 9
Green
Blue
8500 K
Red
000~255
Sets color temperature for Macro > White 10
Green
Blue
10000 K
Red
000~255
Sets color temperature for Macro > White 11
Green
Blue
RGB-W
Red
000~255
Sets color temperature for Special > Color > RGBtoW
Green
Blue
Default
Default
No/Yes
N/A
Defaults the product to factory settings

Q-Wash 560Z-LED QRG
Page 12 of 16
DMX Values
BASIC
Channel
Function
Value
Percent/Setting
1
Pan
000 255
0~540º
2
Tilt
000 255
0~270º
3
Red
000 255
0~100%
4
Green
000 255
0~100%
5
Blue
000 255
0~100%
6
White
000 255
0~100%
7
Amber
000 255
0~100%
8
Power and Color
Macro
000 005
006 010
011 030
031 050
051 070
071 090
091 110
111 130
131 150
151 170
171 200
201 205
206 210
211 215
216 220
221 225
226 230
231 235
236 240
241 245
246 250
251 255
No function
High power
R: 100% G: Up B: 0%
R: Down G: 100% B: 0%
R: 0% G: 100% B: Up
R: 0% G: Down B: 100%
R: Up G: 0% B: 100%
R: 100% G: 0% B: Down
R: 100% G: Up B: Up
R: Down G: Down B: 100%
R: 100% G: 100% B: 100% W: 100%
White 1: 3200 K
White 2: 3400 K
White 3: 4200 K
White 4: 4900 K
White 5: 5600 K
White 6: 5900 K
White 7: 6500 K
White 8: 7200 K
White 9: 8000 K
White 10: 8500 K
White 11: 10,000 K
9
Dimmer
000 255
0~100%
10
Strobe
000 009
010 255
No function
01~20 Hz
11
Zoom
000 255
6~37º
12
Control
000 019
020 039
040 059
060 079
080 099
100 119
120 139
140 149
150 159
160 169
170 179
180 199
200 219
220 235
236 239
240 243
244 247
248 251
252 255
No function
Pan/tilt black activation
Pan/tilt black deactivation
Automatic fan speed
Slow fan speed
Normal fan speed
High fan speed
Auto program 1 (3 s activation delay)
Auto program 2 (3 s activation delay)
Test (3 s activation delay)
Custom program (3 s activation delay)
No function
Reset (3 s activation delay)
No function
DIM0 (3 s activation delay)
DIM1 (3 s activation delay)
DIM2 (3 s activation delay)
DIM3 (3 s activation delay)
DIM4 (3 s activation delay)

Q-Wash 560Z-LED QRG
Page 13 of 16
ADVANCED
Channel
Function
Value
Percent/Setting
1
Pan
000 255
0~540º
2
Pan Fine
000 255
Fine movement control
3
Tilt
000 255
0~270º
4
Tilt Fine
000 255
Fine movement control
5
Pan/Tilt Speed
000 255
Fast~Slow
6
Red
000 255
0~100%
7
Green
000 255
0~100%
8
Blue
000 255
0~100%
9
White
000 255
0~100%
10
Amber
000 255
0~100%
11
Power and Color
Macro
000 005
006 010
011 030
031 050
051 070
071 090
091 110
111 130
131 150
151 170
171 200
201 205
206 210
211 215
216 220
221 225
226 230
231 235
236 240
241 245
246 250
251 255
No function
High power
R: 100% G: Up B: 0%
R: Down G: 100% B: 0%
R: 0% G: 100% B: Up
R: 0% G: Down B: 100%
R: Up G: 0% B: 100%
R: 100% G: 0% B: Down
R: 100% G: Up B: Up
R: Down G: Down B: 100%
R: 100% G: 100% B: 100% W: 100%
White 1: 3200 K
White 2: 3400 K
White 3: 4200 K
White 4: 4900 K
White 5: 5600 K
White 6: 5900 K
White 7: 6500 K
White 8: 7200 K
White 9: 8000 K
White 10: 8500 K
White 11: 10,000 K
Continues on the next page

Q-Wash 560Z-LED QRG
Page 14 of 16
ADVANCED
Channel
Function
Value
Percent/Setting
12
Dimmer
000 255
0~100%
13
Strobe
000 009
010 255
No function
01~20 Hz
14
Zoom
000 255
6~37º
15
Control
000 019
020 039
040 059
060 079
080 099
100 119
120 139
140 149
150 159
160 169
170 179
180 199
200 219
220 235
236 239
240 243
244 247
248 251
252 255
No function
Pan/tilt black activation
Pan/tilt black deactivation
Automatic fan speed
Slow fan speed
Normal fan speed
High fan speed
Auto program 1 (3 s activation delay)
Auto program 2 (3 s activation delay)
Test (3 s activation delay)
Custom program (3 s activation delay)
No function
Reset (3 s activation delay)
No function
DIM0 (3 s activation delay)
DIM1 (3 s activation delay)
DIM2 (3 s activation delay)
DIM3 (3 s activation delay)
DIM4 (3 s activation delay)

Q-Wash 560Z-LED QRG
Page 15 of 16
G1
Channel
Function
Value
Percent/Setting
1
Pan
000 255
0~540º
2
Pan Fine
000 255
Fine movement control
3
Tilt
000 255
0~270º
4
Tilt Fine
000 255
Fine movement control
5
Pan/Tilt Speed
000 255
Fast~Slow
6
Red
000 255
0~100%
7
Green
000 255
0~100%
8
Blue
000 255
0~100%
9
White
000 255
0~100%
10
Power and Color
Macro
000 005
006 010
011 030
031 050
051 070
071 090
091 110
111 130
131 150
151 170
171 200
201 205
206 210
211 215
216 220
221 225
226 230
231 235
236 240
241 245
246 250
251 255
No function
High power
R: 100% G: Up B: 0%
R: Down G: 100% B: 0%
R: 0% G: 100% B: Up
R: 0% G: Down B: 100%
R: Up G: 0% B: 100%
R: 100% G: 0% B: Down
R: 100% G: Up B: Up
R: Down G: Down B: 100%
R: 100% G: 100% B: 100% W: 100%
White 1: 3200 K
White 2: 3400 K
White 3: 4200 K
White 4: 4900 K
White 5: 5600 K
White 6: 5900 K
White 7: 6500 K
White 8: 7200 K
White 9: 8000 K
White 10: 8500 K
White 11: 10,000 K
11
Dimmer
000 255
0~100%
12
Strobe
000 009
010 255
No function
01~20 Hz
13
Zoom
000 255
6~37º
14
Dim Speed
000 009
010 029
030 069
070 129
130 189
190 255
Uses display menu setting
DIM0 (3 s activation delay)
DIM1 (3 s activation delay)
DIM2 (3 s activation delay)
DIM3 (3 s activation delay)
DIM4 (3 s activation delay
15
Control
000 019
020 039
040 059
060 079
080 099
100 119
120 139
140 149
150 159
160 169
170 179
180 199
200 219
220 255
No function
Pan/tilt black activation
Pan/tilt black deactivation
Automatic fan speed
Slow fan speed
Normal fan speed
High fan speed
Auto program 1 (3 s activation delay)
Auto program 2 (3 s activation delay)
Test (3 s activation delay)
Custom program (3 s activation delay)
No function
Reset (3 s activation delay)
No function

Q-Wash 560Z-LED QRG
Page 16 of 16
Contact Us
World Headquarters
CHAUVET®
General Information
Address: 5200 NW 108th Avenue
Sunrise, FL 33351
Voice: [phone]
Fax: [phone]
Toll free: [phone]
United Kingdom and Ireland
CHAUVET® Europe Ltd.
General Information
Address: Unit 1C
Brookhill Road Industrial Estate
Pinxton, Nottingham, UK
NG16 6NT
Voice: [phone]
Fax: [phone]
Technical Support
Voice: [phone] (Press 4)
Fax: [phone]
Email: [e-mail]
Technical Support
Email: [e-mail]
World Wide Web
www.chauvetpro.com
World Wide Web
www.chauvetlighting.co.uk
Outside the U.S., United Kingdom, or Ireland, contact your distributor of
record. Follow their instructions to request support or to return a product.
Visit our Web site for contact details.
Q-Wash 560Z-LED QRG –Rev. 13
© Copyright 2011 CHAUVET®
All rights reserved.
Printed in the P. R. C.
