Chauvet NIMBUS User manual

User Manual

Page 2 of 11 Nimbus™ User Manual (Rev. 07)
TABLE OF CONTENTS
1. Before You Begin .............................................................................. 3
What Is Included ............................................................................................... 3
Unpacking Instructions ...................................................................................... 3
Claims ........................................................................................................................ 3
Text Conventions .............................................................................................. 3
Icons .................................................................................................................. 3
Document Information ....................................................................................... 3
Safety Notes ...................................................................................................... 4
2. Introduction ....................................................................................... 5
Product Overview .............................................................................................. 5
Product Dimensions .......................................................................................... 6
3. Setup.................................................................................................. 7
AC Power .......................................................................................................... 7
About Dry Ice and CO² ...................................................................................... 7
Dry Ice Warnings ............................................................................................... 7
4. Operation ........................................................................................... 8
Basic Instructions .............................................................................................. 8
Operation ................................................................................................................... 8
5. Technical Information ....................................................................... 9
Maintenance ...................................................................................................... 9
General Troubleshooting................................................................................... 9
Contact Procedure .......................................................................................... 10
CHAUVET® Contact Information .................................................................... 10
Returning Products to CHAUVET® ................................................................ 10
6. Technical Specifications..................................................................11

Nimbus™ User Manual (Rev. 07) Page 3 of 11
1. BEFORE YOU BEGIN
What Is
Included
 1 x Nimbus™
 1 x Power Cord
 1 x Warranty Card
 1 x Quick Reference Guide
Unpacking
Instructions
Immediately upon receipt, carefully unpack the product and check the container to make
sure you have received all the parts indicated above in good condition.
Claims
If the container or the material inside the container (the product and included
accessories) appear damaged from shipping, or show signs of mishandling, notify the
carrier immediately, not CHAUVET®, upon receipt. Failure to do so in a timely manner
may invalidate your claim with the carrier. In addition, keep the container and all the
packing material for inspection.
For other issues such as missing components or parts, damage not related to shipping,
or concealed damage, file a claim with CHAUVET® within seven (7) days of receiving
the merchandise.
Text
Conventions
Convention
Meaning
1~512
A range of values
50/60
A set of values of which only one can be chosen
Settings
A menu option not to be modified
Menu > Settings
A sequence of menu options to be followed
<ENTER>
A key to be pressed on the product’s control panel
ON
A value to be entered or selected
Icons
Icon
Meaning
This paragraph contains critical installation, configuration, or
operation information. Failure to comply with this information may
render the product partially or completely inoperative, cause
damage to the product, or cause harm to the user.
This paragraph contains important installation or configuration
information. Failure to comply with this information may prevent
the product from functioning correctly.
This paragraph reminds you of useful, although not critical,
information.
Document
Information
The information and specifications contained in this document are subject to change
without notice. CHAUVET® assumes no responsibility or liability for any errors or
omissions that may appear in this manual. CHAUVET® reserves the right to update the
existing document or to create a new document to correct any errors or omissions.
You can download the latest version of this document from www.chauvetlighting.com.
© Copyright 2011 CHAUVET®. All rights reserved
Electronically published by CHAUVET® in the United States of America
Author
Date
Editor
Date
A. Diaz
09/30/11
B. Pillow
09/30/11

Page 4 of 11 Nimbus™ User Manual (Rev. 07)
Safety Notes
Please read the following Safety Notes carefully before working with the product. The
Notes include important safety information about installation, usage, and maintenance.
 Always connect the product to a grounded circuit to avoid the risk of electrocution.
 Always disconnect the product from the power source before cleaning.
 Make sure the power cord is not crimped or damaged.
 Never disconnect the product from power cord by pulling or tugging on the cord.
 Make sure there are no flammable materials close to the product when operating.
 Do not touch the product’s housing when operating because it may be very hot.
 Do not mount the product on a flammable surface (linoleum, carpet, wood, paper,
carton, plastic, etc.)
 The product’s nozzle is very hot during operation and it remains hot for a long time
after operation has stopped.
 The CO² exits the nozzle at a very high temperature. Keep a minimum distance of
6.5 ft (2 m) from the nozzle to the nearest object.
 Do not use the product as a space heater.
 Do not handle dry ice with bare hands. Thick gloves must be worn.
 Do not swallow dry ice. It may lead to severe internal injuries.
 Before breaking the dry ice, cover it with a piece of cloth or place the block in a cloth
bag. Eye protection must be worn.
 Do not use in a confined space. Make sure the room is well ventilated before
beginning usage.
 Dry ice should never be stored in a sealed container. It can lead to a pressure build-
up and a risk of an explosion.
 For safety reasons, we do not recommend mounting the product in any capacity.
Operate the product while it is on the ground only.
 During warm up and operation, water will be scolding hot. Do not place your hand
into the water.
 Do not remove basket when the unit is plugged in or when heaters are hot.
 Always make sure that the voltage of the outlet to which you are connecting the
product is within the range stated on the decal or rear panel of the product.
 The product is for indoor use only! (IP20) To prevent risk of fire or shock, do not
expose the product to rain or moisture.
 Always install the product in a location with adequate ventilation, at least 20 in (50
cm) from adjacent surfaces.
 Be sure that no ventilation slots on the product’s housing are blocked.
 Never connect the product to a dimmer.
 Never carry the product from the power cord or any moving part
 The maximum ambient temperature (Ta) is 104° F (40° C). Do not operate the
product at higher temperatures.
 In the event of a serious operating problem, stop using the product immediately.
 Never try to repair the product. Repairs carried out by unskilled people can lead to
damage or malfunction. Please contact the nearest authorized technical assistance
center.
 Do not continue to use the machine once visibility is reduced to 20” (50cm) or
below.
 Do not direct output continuously directly at anything within close proximity of the
discharge nozzle.
 The area in front of the product may become wet during operation. Make sure not to
use near smooth floors as they may become slippery.
 Water temperature should be about 175° F for optimal operation.
 Keep this User Manual for future consultation. If you sell the product to another
user, be sure that they also receive this document.

Nimbus™ User Manual (Rev. 07) Page 5 of 11
2. INTRODUCTION
Product Overview
Output Nozzle
Optional Power In
Power In
Lid Latch (x2)
Carry Handle (x2)
LED Indicators
Operation Output
Lever
Lid Latch

Page 6 of 11 Nimbus™ User Manual (Rev. 07)
Product Dimensions

Nimbus™ User Manual (Rev. 07) Page 7 of 11
3. SETUP
AC Power
The Nimbus™ has a fixed voltage power supply and can work with an input voltage of
either 120 V, 60 Hz or 230 V, 50 Hz, depending on the specific model.
To determine the product’s power requirements (circuit breaker, power outlet, and
wiring), use the current value listed on the label affixed to the product’s back panel, or
refer to the product’s specifications chart. The listed current rating indicates the
product’s average current draw under normal conditions.
Always connect the product to a protected circuit (circuit breaker or fuse). Make
sure the product has an appropriate electrical ground to avoid the risk of
electrocution or fire.
Never connect the product to a rheostat (variable resistor) or dimmer circuit, even
if the rheostat or dimmer channel serves only as a 0 to 100% switch.
About Dry Ice
and CO²
Dry ice is a solid form of carbon dioxide. The term “dry ice” is used because of its ability
to sublimate — the process of transforming from a solid directly to a gas without any
liquid formation. Dry ice reaches a temperature of minus 189.5° F (-87.5° C).
When immersed in hot or boiling water, dry ice sublimates and agitates the water. The
released cold CO² gas causes the water vapor to form water droplets in the air. This
expansion of gas and moisture pushes its way out of the machine. Because the CO² is
cold and heavy, the moisture sinks to the floor. The droplets in the air create the fog
effect.
Dry Ice
Warnings
 DO NOT cover or plug the output nozzle during operation. Compressing the dry ice
will cause a chemical reaction that may lead to an explosion.
 Do not handle dry ice with bare hands. Thick gloves must be worn.
 Do not swallow dry ice. It will lead to severe internal injuries.
 Before breaking the dry ice, cover it with a piece of cloth or place the block in a cloth
bag. Eye protection must be worn.
 Do not use in a confined space. Make sure the room is well ventilated before
beginning usage.
 Dry ice should never be stored in a sealed container that can lead to a pressure
build-up and a risk of an explosion.

Page 8 of 11 Nimbus™ User Manual (Rev. 07)
4. OPERATION
Basic
Instructions
 The top plate has two LED indicators – one red and one green. The red LED
indicates that the heater is on, and the green LED indicates when the water is at its
optimal operating temperature. The heater will not turn on unless there is enough
water.
 As the dry ice sublimates, the green LED indicator will turn off indicating that the
water temperature has dropped below its optimal operating temperature. This is
normal and the Nimbus™ will continue to operate until all the dry ice has been used.
 During operation, the top plate becomes very hot. DO NOT TOUCH!
 There is an optional power input next to the main power input to increase the rate in
which the water is heated. Use the included power cable and connect this secondary
input to a separate circuit to heat the water in half the time. Do not plug both power
cords into the same circuit as the breaker will trip.
 The dry ice must be stored inside the internal basket for optimal performance. Do not
remove this basket as serious bodily injury may occur.
Operation
1. Place the machine on a level surface. Plug the power cord into the wall.
2. Raise the basket to its highest level with the operation lever.
3. Open the lid and fill with water until the red light comes on. The container can hold up
to 4.5 gallons (17 liters).
4. Using protective gear, load the basket with up to 10 lbs of dry ice. The dry ice should
be loaded at the last possible moment.
5. Close and latch the lid.
6. Grab the operating lever and slowly lower the handle to the middle notch for low
output or all the way down for high output.
7. When output slows or stops, raise and refill the basket.
Due to water evaporation, you may need to refill the Nimbus™ with water to trigger the
red light on. Once the red light comes on, repeat steps 4 through 7.

Nimbus™ User Manual (Rev. 07) Page 9 of 11
5. TECHNICAL INFORMATION
Maintenance
The Nimbus requires minimal upkeep in order to maintain optimum performance.
However, some steps are needed in order to clean and maintain the product for
maximum usage. The recommended procedure is as follows:
1. After usage, wait for the machine to fully cool down.
2. Dump all water from the internal tank from the product.
3. If there is any water left over, wait until it has cooled down before transporting. You
may risk bodily harm and damage to transport items if the water is still hot.
General Troubleshooting
Symptom
Possible Cause
Possible Action
Circuit breaker keeps
blowing
 Excessive load on the circuit
 Make sure that the total load does not
exceed 80% of the breaker or fuse
nominal current
 Short circuit along the power lines
 Check the power lines and power cords
Product does not power
up
 No energy on power outlet
 Check power outlet
 Change to another outlet
 Loose or damaged power cord
 Check the power cord
 Internal problem
 Send product for repair
If you still experience problems after trying the above solutions, contact
CHAUVET® Technical Support.

Page 10 of 11 Nimbus™ User Manual (Rev. 07)
Contact
Procedure
In case you need to return a product or request support, follow the procedure below:
 If you live in the US, contact CHAUVET® World Headquarters (see below).
 If you live in the UK or Ireland, contact CHAUVET® Europe Ltd.(see below).
 If you live in any other country, DO NOT contact CHAUVET®. Instead, contact your
distributor of record. Refer to our Web site for contact details of distributors outside
the US, United Kingdom, or Ireland.
CHAUVET®
Contact
Information
World Headquarters
CHAUVET®
General Information
Address: 5200 NW 108th Avenue
Sunrise, FL 33351
Voice: [phone]
Fax: [phone]
Toll free: [phone]
United Kingdom & Ireland
CHAUVET® Europe Ltd.
General Information
Address: Unit 1C
Brookhill Road Industrial Estate
Pinxton, Nottingham, UK
NG16 6NT
Voice: [phone]
Fax: [phone]
Technical Support
Voice: [phone] (Press 4)
Fax: [phone]
Email: [e-mail]
Technical Support
Email: [e-mail]
World Wide Web
www.chauvetlighting.com
World Wide Web
www.chauvetlighting.co.uk
If you live outside the US, United Kingdom, or Ireland, contact your distributor of
record and follow their instructions on how to return CHAUVET® products to
them. Visit our Web site for contact details.
Returning
Products to
CHAUVET®
Call the corresponding CHAUVET® Tech Support office and request a Return
Merchandise Authorization (RMA) number before shipping the product. Be prepared to
provide the model number, serial number, and a brief description of the cause for the
return.
You must send the merchandise prepaid, in its original box, and with its original packing
and accessories. CHAUVET® will not issue call tags.
Clearly label the package with the RMA number. CHAUVET® will refuse any product
returned without an RMA number.
Write the RMA number on a properly affixed label. DO NOT write the RMA number
directly on the box.
Before sending the product, clearly write the following information on a piece of paper
and place it inside the box:
 Your name
 Your address
 Your phone number
 The RMA number
 A brief description of the problem
Be sure to pack the product properly. Any shipping damage resulting from inadequate
packaging will be your responsibility. As a suggestion, proper UPS packing or double-
boxing is always a safe method to use.
CHAUVET® reserves the right to use its own discretion to repair or replace
returned product(s).

Nimbus™ User Manual (Rev. 07) Page 11 of 11
6. TECHNICAL SPECIFICATIONS
Dimensions and
Weight
Length
Width
Height
Weight
20 in (513 mm)
18 in (465 mm)
19 in (470 mm)
Empty: 28.6 lbs (13 kg)
Full: 75 lbs (34 kg)
Note: Dimensions in inches rounded to the nearest decimal digit.
Power
Power Supply Type
Range
Voltage Selection
Model specific
120 V, 60 Hz or 230 V, 50 Hz
Voltage specific
Parameter
Single Element
Dual Element
Consumption
1500 W
3000 W
Operating
12.6 A
25.2 A
Power I/O
US/Worldwide
UK/Europe
Power input connector
Neutrik® powerCON® A
Neutrik® powerCON® A
Heat
Parameter
Heat Up Time
Reheat Time
Single Element
50 min
30 min
Dual Element
30 min
15 min
Average Runtime
Tank Capacity
Dry Ice Capacity
6 min
4.5 gal (17 l)
10 lbs (4.5 kg)
Thermal
Maximum External Temp.
Max Water Temperature
104° F (40° C)
175º F (79º C)
Ordering
Product Name
Item Code
Item Number
Nimbus™ (120 V)
09050429
NIMBUS
Nimbus™ (220 V)
09050451
220VNIMBUS
