Check-line SLW User manual

78,0°F | 6,16% | 456kg/m
3
| -27,3td | 0,64aw | 51,9%r.H. | 14,8%abs | 100,4g/m
2
| 09m/s | 4,90Ugl | 1
Always read this user manual before using the humimeter SLW!
User Manual
humimeter SLW & TMT-425
Moisture meter
for water content determination of textiles
Moisture meter
Version 3.0
®

humimeter SLW User Manual
Page 2
Your humimeter SLW at a glance
The main unit with probe
No. Name
1 Measuring tips
2 Measuring head
3 USB port (optional)
4 Display
5 Keypad
6 Rubber protection cover
3
4
2
1
6
5

Page 3
The main unit for external sensor
No. Name
1 Sensor connector
2 USB port (optional)
3 Display
4 Keypad
5 Rubber protection cover
6 Hand electrode holder
7 Plastic mounting ring
8 Electrodes
6
7
1
8
2
4
5
3

humimeter SLW User Manual
Page 4
Rear of the main unit
No. Name
1 Battery compartment
The display
Nr Bezeichnung
1 Characteristic curve
2 Material moisture in % ("6.1 Definition of
material moisture")
3 Display symbols
4 Temperature display
1
1
2
4
3

Page 5
The display symbols
Symbol Name Symbol Name
Enter No
Up Change input
level
Down OK
Back Change menu
Enter numbers Enter data
Enter letters View measurements
Continue / go right Delete measurements
Left On/off button, display
light
Yes Save measured value
The menus
The device has three different menus: Data Log, product selection and main menu:
Product selection menu
No. Name
1 Change menu
2 Display illumination / device on/off
3 For changing the product type
21 3

humimeter SLW User Manual
Page 6
Data Log menu
No. Name
1 Change menu
2 Display illumination / device on/off
3 Save measured value
4 Show the last recorded values
Main menu
The main menu comprises the following menu items:
• Edit Logs:
Manual Logs, Clear Logs
• Print Logs:
Last Log, All Logs, Clear Logs
• Send Logs:
Manual Logs, Clear Logs
• Options:
Bluetooth, Date/Time, Log Time, Language, Unlock, °C/°F, BL On Time, Auto Off
Time, Materialcalibration, Password, Reset
• Status
21 3 4

Page 7
Table of contents
Your humimeter SLW at a glance ������������������������������������������������ 2
The main unit with probe ......................................................................................... 2
The main unit for external sensor .............................................................................3
Rear of the main unit ...............................................................................................4
The display ...............................................................................................................4
The display symbols .................................................................................................5
The menus ............................................................................................................... 5
1� Introduction ������������������������������������������������������������������ 10
1.1 Information about this user manual ...................................................... 10
1.2 Limitation of liability .............................................................................. 10
1.3 Symbols used in this manual .................................................................11
1.4 Customer service .................................................................................. 11
2� For your safety �������������������������������������������������������������� 12
2.1 Proper use ............................................................................................12
2.2 Improper use ........................................................................................12
2.3 User qualications ................................................................................. 12
2.4 General safety information .................................................................... 13
2.5 Warranty .............................................................................................. 13
3� After receipt of your device ����������������������������������������� 13
3.1 Unpack the device ................................................................................ 13
3.2 Making sure that all of the components have been included ................. 14
3.2.1 SLW with probe's scope of supply .........................................................14
3.2.2 SLW for external sensor's scope of supply ............................................. 14
3.3 Inserting batteries .................................................................................15
3.4 Inserting the measuring tips ..................................................................16
4� Using the device - Basics ���������������������������������������������� 16
4.1 Switching the device on ........................................................................16

humimeter SLW User Manual
Page 8
4.2 Selecting the product type ....................................................................17
4.3 Basic operation of the hand electrode holder ........................................17
4.3.1 Connecting the hand electrode holder ..................................................17
4.3.2 Disconnecting the hand electrode holder ..............................................17
4.3.3 Inserting the electrodes ......................................................................... 18
4.4 Taking a measurement .......................................................................... 18
4.5 Switching the device off ........................................................................ 18
5� The measuring process ������������������������������������������������� 19
5.1 Taking a measurement .......................................................................... 19
5.2 Hold function - Freezing the displayed values ........................................20
5.2.1 Activating the Hold function in the options menu .................................20
5.2.2 Using the Hold function ........................................................................20
5.3 Saving individual readings .....................................................................21
5.3.1 Activating the manual saving function in the options menu .................. 21
5.3.2 Using the manual saving option ............................................................21
5.4 Saving several readings (a measurement series) at the same time .......... 22
5.5 Viewing individual readings ................................................................... 24
5.6 Viewing individual readings from a series of measurements ................... 24
5.7 Deleting all measured values (data log) ................................................. 25
5.8 Deleting individual measurement series .................................................25
5.9 Deleting single values from a series of measurements ............................ 26
6� Product types ���������������������������������������������������������������� 27
6.1 Denition of material moisture .............................................................. 28
6.2 Denition of moisture content ..............................................................28
7� Using the LogMemorizer program ������������������������������ 29
7.1 Installing/opening the program .............................................................29
7.2 Exporting measured values to a computer .............................................29
8� Checking on the device's status ���������������������������������� 32

Page 9
9. Conguringthedevice������������������������������������������������� 33
9.1 Turning on Bluetooth ............................................................................33
9.2 Adjusting the date/time .......................................................................33
9.3 Selecting a language ............................................................................. 34
9.4 Activating options ................................................................................. 34
9.5 Deactivating options .............................................................................35
9.6 Selecting °C/°F ...................................................................................... 35
9.7 Reducing the device's power consumption ............................................ 36
9.7.1 Conguring the display illumination time ..............................................36
9.7.2 Conguring automatic switch-off ......................................................... 36
9.8 Conguring the material calibration function ........................................37
9.9 Changing the password ........................................................................37
9.10 Resetting the device to its factory settings .............................................38
10� Cleaning and maintenance ������������������������������������������ 38
10.1 Changing batteries ...............................................................................38
10.2 Care instructions ................................................................................... 39
10.3 Cleaning the device .............................................................................. 39
11� Faults ����������������������������������������������������������������������������� 40
12� Storage and disposal ���������������������������������������������������� 41
12.1 Storing the device .................................................................................41
12.2 Disposing of the device .........................................................................41
13� Device information ������������������������������������������������������� 42
13.1 EC declaration of conformity ................................................................. 42
13.2 Technical data ....................................................................................... 43

humimeter SLW User Manual
Page 10
1. Introduction
1.1 Information about this user manual
This user manual is designed to enable you to use the humimeter SLW safely and ef-
fectively. It is part of the device, has to be stored nearby and must be easily accessible
to users at all times.
All users are required to carefully read and make sure that they have understood this
user manual before using the humimeter SLW. All of the safety and operating instruc-
tions detailed in this manual have to be observed to ensure the safety of the device.
1.2 Limitation of liability
All of the information and instructions provided in this user manual have been com-
piled on the basis of the current standards and regulations, the state of the art, and the
extensive expertise and experience of Schaller Messtechnik GmbH.
Schaller Messtechnik GmbH does not accept any liability for damage associated with
the following, which also voids the warranty:
• Non-observance of this operating manual
• Improper use
• Inadequately qualified users
• Unauthorised modifications
• Technical changes
• Use of unapproved spare parts
This fast measuring procedure can be affected by a range of different factors. For this
reason, we recommend periodically checking the device’s measurements with a stand-
ardised oven-drying method.
We, as the manufacturer, do not accept any liability for any incorrect measurements
and associated consequential damage.

Page 11
1.3 Symbols used in this manual
All safety informations provided in this manual are shown with a corresponding
symbol.
WARNING
It is essential to observe this warning. Non-compliance can lead to serious
irreversible or fatal injury.
CAUTION
It is essential to observe this warning. Non-compliance can lead to injury.
ATTENTION
It is essential to observe this warning. Non-compliance can lead to damage to
property or equipment.
iInformation
This symbol indicates important information that enables users to use the de-
vice more efficiently and cost-effectively.
1.4 Customer service
For technical advice, please contact our customer service department at:
Schaller Messtechnik GmbH
Max-Schaller-Straße 99
A - 8181 St.Ruprecht an der Raab
Telephone: [phone]
Fax: [phone] - 901
E-mail: [e-mail]
Internet: www.humimeter.com
© Schaller Messtechnik GmbH 2019

humimeter SLW User Manual
Page 12
2. For your safety
The device complies with the following European directives:
• Restriction of Hazardous Substances in Electrical and Electronic Equipment
(RoHS)
• Electromagnetic compatibility (EMC)
The device corresponds to state-of-the-art technology. However, it is still associated
with a number of residual hazards.
These hazards can be avoided through strict observance of our safety information.
2.1 Proper use
• Easy to use device for quickly measuring the moisture content of textiles
• The device must only be used for taking measurements on products defined in
the following sections of this manual (see "6. Product types").
2.2 Improper use
• The device is not suitable for measuring material with a temperature over
+40°C.
• The device is not waterproof and must be protected from water and fine dust
(IP40).
2.3 User qualifications
Only those persons are permitted to operate the device who can be expected to carry
out the work reliably. Persons whose reactions are affected, e.g. by drugs, alcohol or
medication, are not allowed to operate with the device.
All persons using this device must have read, understood and follow the instructions
provided in this manual.

Page 13
2.4 General safety information
To avoid personal injury and damage to property, always observe the following safety
instructions:
• Remove the batteries if the device is not used for a prolonged period of time
(4 weeks).
• Keep the measuring tips away from your body throughout all activities.
• Keep the measuring tips away from other people throughout all activities.
• In case of damages or loose parts on the device, remove the batteries and con-
tact Schaller Messtechnik GmbH or your dealer.
All of the device’s technical features have been inspected and tested before delivery.
Every device has a serial number. Do not remove the tag with the serial number.
2.5 Warranty
The warranty does not apply to:
• Damage resulting from non-observance of the operating manual
• Damage resulting from third-party interventions
• Products that have been used improperly or modified without authorisation
• Products with missing or damaged warranty seals
• Damage resulting from force majeure, natural disasters, etc.
• Damage from improper cleaning
• Damage due to leaking batteries
• Damage resulting from improper strain (pressure, bending) of the ram electrode
or the measuring tips
• Damage from dropping the device
3. After receipt of your device
3.1 Unpack the device
• Take the device out of its packaging.
• Next, make sure that it is not damaged and that no parts are missing.

humimeter SLW User Manual
Page 14
3.2 Making sure that all of the components have been included
Make sure that all of the components have been included by checking the package
contents against the following list:
Optional accessories base device:
• humimeter USB data interface module - USB stick with software and USB cable
• Battery powered portable thermo-printer (only possible together with humimeter
USB data interface module) - Described in a separate operating manual
• Bluetooth module (only possible together with humimeter USB data interface
module) - Described in a separate operating manual
3.2.1 SLW with probe's scope of supply
• humimeter SLW
• 10 pieces of measuring tips without insulation (60 mm)
• 4 pieces of AA Alkaline batteries
• Rubber protection cover
• Plastic case
• User manual
Optional accessories:
• 2 replacement tips for measuring electrodes, without insulation, 255 mm length
• 2 replacement tips for measuring electrodes, insulated, 60 mm length
3.2.2 SLW for external sensor's scope of supply
• humimeter SLW
• Hand electrode holder incl. BNC cable with 1 m length
• 4 pieces of AA Alkaline batteries
• Rubber protection cover
• Plastic case
• User manual
Optional accessories:
• SLW-E023: Surface electrode, diameter : 23 mm
• SLW-E100: Needle electrode, needle length: 100 mm
• SLW-E325: Rod electrode, rod length: 325 mm
• SLW-E025: Needle electrode, needle length: 6 x 25 mm

Page 15
3.3 Inserting batteries
1. Remove the rubber protection
cover.
»Humimeter SLW with probe:
Remove the rubber protection
from the top of the housing (fig-
ure1and2).
»Humimeter SLW with Hand electrode holder:
Disconnect it (see "4.3.2 Disconnecting the hand elec-
trode holder") before you pull the rubber protection off
the bottom of the housing.
»If your device is provided with an optional USB port,
remove the protection cap of the USB socket before.
2. Take hold of the device with one hand, press your thumb
onto the engraved area of the battery compartment(1)
and drag downwards(2) (figure3).
3. Insert the batteries with negative and positive terminals
matching those indicated on the battery compartment.
Press down the batteries so that they lay flat on the bot-
tom of the housing (figure 4).
»As soon as all batteries have been inserted, the device
switches on automatically.
4. Slide the battery cover onto the housing until it clicks into
place (figure5). Then mount the rubber protection cover onto the housing.
»Humimeter SLW with probe:
start with the side on which the battery cover is.
»Humimeter SLW with Hand electrode holder:
start with the side on which the sensor plug is positioned..
1 2
3
4
5

humimeter SLW User Manual
Page 16
3.4 Inserting the measuring tips
• Unscrew the two nuts located on the
measuring head (figure 6) counterclock-
wise.
»Loosen only the upper nuts. The botto
nuts must not be loosened!
• Insert one measuring tip per nut from
behind through the nut (figure 7).
»Measuring tips without insulation (article no. 12521) always
measure the wettest spot across the entire insertion depth.
»By using insulated measuring tips (article no. 11482) it is
possible to determine humidity at a defined measuring depth, as
these only measure at the measuring tip.
• Now screw the nuts with measuring tips to the threads located
on the measuring head and tighten the nuts by hand (figure 8).
WARNING
Risk of injury
Risk of injury due to measuring tips
►Keep the measuring tips away from your body throughout all activities.
►Keep the measuring tips away from other people throughout all activities.
4. Using the device - Basics
4.1 Switching the device on
• Press the button for 3 seconds.
»The display will then show the status indicator
(figure10).
»After inserting the batteries, the device switches on
automatically.
6 7
8
9
10

Page 17
4.2 Selecting the product type
To do so: The device has to be in the product selection menu (figure 11).
For an overview of the different product types and the criteria for selecting them,
please refer to "6. Product types".
1. Press the or button to move from one
product to the next Or
2. Press the or button for 3seconds to open
the product type overview (figure 12).
3. Use the arrow keys to move from one product type
to the next
4. and keep any of them pressed to scroll through the
types.
5. Confirm your selection by pressing
»The product type you selected will now be shown at the top of the display.
4.3 Basic operation of the hand electrode holder
4.3.1 Connecting the hand electrode holder
• Connect the hand electrode holder to the device.
»Pay attention to the elevations at the socket and the
guides in the plug and their correct positioning (figure
13).
• Now tighten the plug clockwise with a quarter turn.
»The plug snaps noticeably at the end of the guides.
4.3.2 Disconnecting the hand electrode holder
• Press the plug with slight force towards the device
(figure 14).
• Now turn the plug counterclockwise with a quarter
turn to the beginning of the guides (figure 15).
• Now pull the plug straight off the device.
»This should be done without great effort.
11
12
13
14
15

humimeter SLW User Manual
Page 18
4.3.3 Inserting the electrodes
• Unscrew the dark-grey plastic
fastening ring on the head of the
hand electrode holder (figure 16).
»In case of an already inserted
electrode, pull it straight out of
the hand electrode holder.
• Place the two male contact pins of
the electrode on the female sock-
ets on the head of the hand electrode holder (figure 17)
and press them together with enough force (figure 18).
»You don't have to pay attention to the correct polarity of
the contacts.
• Screw the dark-grey plastic fastening ring back onto the
head of the hand electrode holder and hand-tighten it..
WARNING
Risk of injury
Risk of injury due to the Elektrodenspitzen
►Keep the Elektroden tips away from your body throughout all activities.
►Keep the Elektroden tips away from other people throughout all activities.
4.4 Taking a measurement
• For information on how to take a measurement, see section "5. The measuring
process".
4.5 Switching the device off
To do so: The device has to be in the product selection or the Data Log menu. It is not
possible to switch off the device when it is in the main menu.
Press the button for 3 seconds.
16 17
18

Page 19
5. The measuring process
5.1 Taking a measurement
To do so: Let your device adjust to the surrounding tem-
perature before the measurement.
• Hold the device in one hand and insert the measur-
ing/electrode tips into the material (figure 19) or
press the surface electrode onto the material to be
measured (figure 20).
»Make sure that the sample is not damaged by the
measuring/electrode tips..
»Do not drop the device!
• The device will now instantly display the moisture
content on the display (figure 21).
»The displayed value flashes when the moisture
content exceeds the measuring range of the
selected product type (figure 22). A flashing value
signals the end of the measuring range. The meas-
uring range is dependent on the product type (see
"6. Product types").
»Once the reading has been taken, it can be saved
on the device (see "5.3 Saving individual readings"
or "5.4 Saving several readings (a measurement
series) at the same time").
WARNING
Risk of injury
Risk of injury due to the Mess-/Elektrodenspitzen
►Keep the Mess-/Elektroden tips away from your body throughout all activi-
ties.
►Keep the Mess-/Elektroden tips away from other people throughout all
activities.
iInformation - Measuring accuracy
This rapid and non-destructive measuring procedure allows you to take
moisture readings at a number of different points. When saving the individual
readings, the device will automatically calculate the readings’ average (see "5.4
Saving several readings (a measurement series) at the same time").
19
20
21
22

humimeter SLW User Manual
Page 20
iInformation - Incorrect readings
Always make sure to select the correct product type for the material you are
measuring. This prevents taking incorrect readings (see "11. Faults").
5.2 Hold function - Freezing the displayed values
The device can be configured in such a way that the information being shown on the
display will freeze at the touch of a button until a new button is pressed. This function
can be very useful when e.g. taking readings in spaces where it is not possible to see
the display (e.g. overhead).
5.2.1 Activating the Hold function in the options menu
To do so: The device has to be switched on and be in the product selection menu.
1. Press twice or hold for 2 seconds.
2. Select Options. To do so, press or and con-
firm by pressing .
3. Select Log Time (figure 23). To do so, press or
and confirm by pressing .
4. Select Hold (figure 24). To do so, press or
and confirm by pressing .
»The setting has been saved.
5. Press to leave the Options menu.
6. Press to leave the main menu.
5.2.2 Using the Hold function
To do so: The device has to be switched on and be in the Data Log menu (see "Data
Log menu" page 6).
• Press .
»The current reading will be frozen. All of the four
symbols will now be displayed as (figure 25).
• To reactivate the frozen display, simply press any
button.
23
24
25
