Endress+Hauser Levelflex M FMP40 Application guide

BA366F/00/en/01.08
No. 71060890
Valid as of software version:
01.08.zz
Description of Device Functions
Levelflex M FMP40, FMP41C, FMP45
Guided Level Radar for Interface Measurement with HART
6FMP40 FMP41C FMP45

Basic Setup Levelflex M
2Endress+Hauser
Basic Setup
...
DK2
DK1
SD
SD
UB
UB
DL
LL
LL
F
F
LILI
UP
DI
DI
E
LN
LN
E
safety settings linearisation extended calibr.
basic setup (standard)
optio
n (description see BA366F)
tank shape process properties empty calibr. full calibr. upper block.dist
partially filled
fully flooded
Standard
Standard
E = empty calibr. (= zero) - setting in 005
F = full calibr. (= span) - setting in 006
D = distance interface (distance flange / DK ) - display in 0A6
L = level interface (distance probe end / DK ) - display in 0A5
D = distance complete level - display in 0A5
L = level complete - display in 0A6
LN = probe length - setting in 033
UB = upper blocking distance - setting in 059
UP = thickness upper medium
SD = safety distance - setting in 015
I
I
L
L
2
1
flange:
reference point of
measurement
partially filled ÉCoax probe
partially flooded ÉRod probe

Levelflex M Basic Setup
Endress+Hauser 3

Table of contents Levelflex M
4Endress+Hauser
Table of contents
1 Notes on using this manual . . . . . . . . . . . 6
1.1 Using the table of contents to locate a function
description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
1.2 Using the graphic display of the function menus to locate
a function description . . . . . . . . . . . . . . . . . . . . . . . 6
1.3 Using the index of the function menu to locate a
function description . . . . . . . . . . . . . . . . . . . . . . . . 6
1.4 General structure of the operating menu . . . . . . . . . 7
1.5 Display and operating elements . . . . . . . . . . . . . . . . 8
1.6 Commissioning . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2 Levelflex M function menu . . . . . . . . . . 12
3 Function group "Basic Setup" (00) . . . 14
3.1 Function "Measured Value" (000) . . . . . . . . . . . . . 14
3.2 Function "Tank Properties" (002) . . . . . . . . . . . . . 14
3.3 Function "Process Propert." (004) . . . . . . . . . . . . . 15
3.4 Function "Empty Calibr." (005) . . . . . . . . . . . . . . . 15
3.5 Function "Full Calibr." (006) . . . . . . . . . . . . . . . . . 16
3.6 Function "Upper Block. Dist." (059) . . . . . . . . . . . 16
3.7 Function "Medium Property" (003) . . . . . . . . . . . . 18
3.8 Display (008) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
4 Function group "Safety Settings" (01) . 20
4.1 Function "Outp. on Alarm" (010) . . . . . . . . . . . . . 20
4.2 Function "Outp. on Alarm" (011) . . . . . . . . . . . . . 21
4.3 Function "Outp. Echo Loss" (012) . . . . . . . . . . . . . 22
4.4 Function "Delay Time" (014) . . . . . . . . . . . . . . . . 22
4.5 Function "Safety Distance" (015) . . . . . . . . . . . . . . 23
4.6 Function "In Safety Distance" (016) . . . . . . . . . . . 23
4.7 Function "Ackn. Alarm" (017) . . . . . . . . . . . . . . . . 25
5 Function group
"Length Adjustment" (03) . . . . . . . . . . . 26
5.1 Function "Probe" (032) . . . . . . . . . . . . . . . . . . . . . 26
5.2 Function "Probe Length" (033) . . . . . . . . . . . . . . . 26
5.3 Function "Determine Length" (034) . . . . . . . . . . . 26
6 Function group "Linearization" (04) . . 27
6.1 Function "Level/Ullage" (040) . . . . . . . . . . . . . . . 27
6.2 Function "Linearization" (041) . . . . . . . . . . . . . . . 28
6.3 Function "Customer Unit" (042) . . . . . . . . . . . . . . 31
6.4 Function "Tab No" (043) . . . . . . . . . . . . . . . . . . . 32
6.5 Function "Level" (044) . . . . . . . . . . . . . . . . . . . . . 32
6.6 Function "Volume" (045) . . . . . . . . . . . . . . . . . . . 33
6.7 Function "Max. Scale" (046) . . . . . . . . . . . . . . . . . 33
6.8 Function "Diameter Vessel" (047) . . . . . . . . . . . . . 33
7 Function group
"Extended Calibration" (05) . . . . . . . . . 34
7.1 Function "Selection" (050) . . . . . . . . . . . . . . . . . . 34
7.2 Function "Installation" (007) . . . . . . . . . . . . . . . . . 34
7.3 Function "Medium Property2" (018) . . . . . . . . . . . 35
7.4 Function "Range of Mapping" (052) . . . . . . . . . . . . 36
7.5 Function "Start Mapping" (053) . . . . . . . . . . . . . . . 36
7.6 Function "Pres. Map. Dist." (054) . . . . . . . . . . . . . 36
7.7 Function "Delete Map." (051) . . . . . . . . . . . . . . . . 37
7.8 Function "Echo Qual. Level" (055) . . . . . . . . . . . . 37
7.9 Function "Echo Qual. Inter." (056) . . . . . . . . . . . . 38
7.10 Function "Offset" (057) . . . . . . . . . . . . . . . . . . . . . 38
7.11 Function "Output Damping" (058) . . . . . . . . . . . . 38
8 Function group "Output" (06) . . . . . . . 39
8.1 Function "Assignment PV" (035) . . . . . . . . . . . . . . 39
8.2 Function "Assignment SV" (036) . . . . . . . . . . . . . . 39
8.3 "Assignment TV" function (037) . . . . . . . . . . . . . . 39
8.4 Display "PV and SV" (038) . . . . . . . . . . . . . . . . . . 40
8.5 Display "TV and QV" (039) . . . . . . . . . . . . . . . . . . 40
8.6 Function "Commun. Address" (060) . . . . . . . . . . . 40
8.7 Function "No. of Preambles" (061) . . . . . . . . . . . . 41
8.8 Function "Low Output Limit" (062) . . . . . . . . . . . . 41
8.9 Function "Current Output Mode" (063) . . . . . . . . 42
8.10 Function "Fixed Curr. Value" (064) . . . . . . . . . . . . 43
8.11 Function "Simulation" (065) . . . . . . . . . . . . . . . . . 43
8.12 Function "Simulation Value" (066) . . . . . . . . . . . . 45
8.13 Function "Output Current" (067) . . . . . . . . . . . . . 45
8.14 Function "4mA Value" (068) . . . . . . . . . . . . . . . . . 45
8.15 Function "20mA Value" (069) . . . . . . . . . . . . . . . . 45
9 Function group
"Envelope Curve" (0E) . . . . . . . . . . . . . 46
9.1 Function "Plot Settings" (0E1) . . . . . . . . . . . . . . . . 46
9.2 Function "Recording Curve" (0E2) . . . . . . . . . . . . 46
9.3 Function "envelope curve display" (0E3) . . . . . . . . 47
10 Function group "Display" (09) . . . . . . . 50
10.1 Function "Language" (092) . . . . . . . . . . . . . . . . . . 50
10.2 Function "Back to Home" (093) . . . . . . . . . . . . . . . 50
10.3 Function "Format Display" (094) . . . . . . . . . . . . . . 51
10.4 Function "No. of Decimals" (095) . . . . . . . . . . . . . 51
10.5 Function "Sep. Character" (096) . . . . . . . . . . . . . . 51
10.6 Function "Display Layout " (098) . . . . . . . . . . . . . . 52
10.7 Function "Display Test" (097) . . . . . . . . . . . . . . . . 52
11 Function group "Diagnostics" (0A) . . . 53
11.1 Function "Present Error" (0A0) . . . . . . . . . . . . . . . 54
11.2 Function "Previous Error" (0A1) . . . . . . . . . . . . . . 54
11.3 Function "Clear Last Error" (0A2) . . . . . . . . . . . . . 54
11.4 Function "Reset" (0A3) . . . . . . . . . . . . . . . . . . . . . 55
11.5 Function "Unlock Parameter" (0A4) . . . . . . . . . . . 56
11.6 Function "Dist. Level" (0A5) . . . . . . . . . . . . . . . . . 58
11.7 Function "Dist. Interface" (0A6) . . . . . . . . . . . . . . 58

Levelflex M Table of contents
Endress+Hauser 5
11.8 Function "Application Par." (0A8) . . . . . . . . . . . . . 59
12 Function group
"System Parameter" (0C) . . . . . . . . . . . . 60
12.1 Function "Tag No." (0C0) . . . . . . . . . . . . . . . . . . . 60
12.2 Function "Protocol+SW No." (0C2) . . . . . . . . . . . . 60
12.3 Function "Serial No." (0C4) . . . . . . . . . . . . . . . . . . 60
12.4 Function "Distance Unit" (0C5) . . . . . . . . . . . . . . . 61
12.5 Function "Download Mode" (0C8) . . . . . . . . . . . . . 62
13 Function group "Service" (0D) . . . . . . . 63
14 Troubleshooting . . . . . . . . . . . . . . . . . . . . 64
14.1 Troubleshooting instructions . . . . . . . . . . . . . . . . . 65
14.2 System error messages . . . . . . . . . . . . . . . . . . . . . . 66
14.3 Application errors . . . . . . . . . . . . . . . . . . . . . . . . . 68
14.4 Software history . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Function menu index . . . . . . . . . . . . . . . . . 71

1 Notes on using this manual Levelflex M
6Endress+Hauser
1 Notes on using this manual
There are various ways of getting to the device function you require or the parameters to be entered.
1.1 Using the table of contents to locate a function
description
All the functions are listed by function group (e.g. "Basic Setup", "Security Settings", etc.) in the table
of contents. The page reference/link shows you exactly where to find the detailed descriptions of
the functions in question.
The table of contents can be found on →ä4.
1.2 Using the graphic display of the function menus to
locate a function description
This step-by-step, top-down approach starts with the function groups, the highest level, and works
down through the matrix to the description of the function you need.
All the available function groups and functions of the device are listed in the table (→ä12). Select
the function group or a function needed for your particular application. The page reference/link
shows you exactly where to find the detailed description of the function group or function in
question.
1.3 Using the index of the function menu to locate a
function description
To ease orientation within the function menu, a position is shown on the display for each function.
The function menu index (→ä71) which lists the codes for all the functions in alphabetical or
numerical order takes you to the function in question via a page reference or link.

Levelflex M 1 Notes on using this manual
Endress+Hauser 7
1.4 General structure of the operating menu
The operating menu is made up of two levels:
•Function groups (00, 01, … , 0C, 0D):
The individual operating options of the device are split up roughly into different function groups.
The function groups that are available include: "Basic Setup", "Safety Settings", "Output",
"Display", etc.
•Functions (001, 002, 003, …, 0D8, 0D9):
Each function group consists of one or more functions. The functions perform the actual operation
or configuration of the device. Numerical values can be entered here and parameters can be
selected and saved. The functions available for the "Basic Setup"(00) function group include:
"Tank Properties"(002), "Process Propert."(004), "Empty Calibration"(005), etc.
If, for example, the application of the device is to be changed, carry out the following procedure:
1. Select the "Basic Setup"(00) function group
2. Select the "Tank Properties"(002) function (where the tank level is selected).
1.4.1 Identifying the functions
To ease orientation within the function menus (See →ä12), a position is shown on the display for
each function.
The first two digits identify the function group:
The third digit numbers the individual functions within the function group:
In the following section, the position is always indicated in brackets (e.g."Tank Properties" (002))
after the function described.
• Basic Setup 00
• Safety Settings 01
• Length Adjustment 02
…
• Basic Setup 00 →• Tank Properties 002
• Process Properties 004
…
Function
Function group
005

1 Notes on using this manual Levelflex M
8Endress+Hauser
1.5 Display and operating elements
Four lines with 20 characters each. Display contrast adjustable through key combination.
Fig. 1: Layout of the display and operating elements
The VU331 LCD display can be removed to ease operation by simply pressing the snap-fit (see
graphic above). It is connected to the device by means of a 500 mm cable.
1.5.1 Display
Liquid crystal display (LCD):
Four lines with 20 characters each. Display contrast adjustable through key combination.
Fig. 2: Display
ENDRESS + HAUSER
E
+
–
ENDRESS+HAUSER
MICROPILOTII
ENDRESS+HAUSER
MICROPILOTII
IP65
IP65
OrderCode:
Ser.-No.:
OrderCode:
Ser.-No.:
Messbereich
Measuringrange
Messbereich
Measuringrange
U16...36VDC
4...20mA
U16...36VDC
4...20mA
max.20m
max.20m
MadeinGermany Maulburg
MadeinGermany Maulburg
T>
70°C:
At>85°C
T >70°C :
At>85°C
LCD
(liquid crystal display)
Symbols
3 keys
snap-fit
X
X
X
X
S
S
O
OFF
F
F
HOME
FG00 F000 F001 F002 F003 F004 ...
FG01
FG02
FG03
FG04
FG05
FG06
FG07
...
ENDRESS + HAUSER
E
+
–
Description
Position indicator
Primary measuring value
Unit
Symbol
Selection list
Function groups -> Functions
Help text
Envelope
curve
Secondary measuring value

Levelflex M 1 Notes on using this manual
Endress+Hauser 9
1.5.2 Display symbols
The following table describes the symbols that appear on the liquid crystal display:
Tab. 1-1 Meaning of the symbols
1.5.3 Key assignment
The operating elements are located inside the housing and are accessible for operation by opening
the lid of the housing.
Function of the keys
Tab. 1-2 Function of the keys
Symbol Meaning
ALARM_SYMBOL
This alarm symbol appears when the device is in an alarm condition. If the symbol flashes, this indicates a
warning.
LOCK_SYMBOL
This lock symbol appears when the device is locked,i.e. if no input is possible.
COM_SYMBOL
This communication symbol appears when data transmission via HART is in progress.
Key(s) Meaning
Oor VNavigate upwards in the picklist
Edit numeric value within a function
Sor WNavigate downwards in the picklist
Edit numeric value within a function
Xor ZNavigate to the left within a function group
FNavigate to the right within a function group, confirmation
Oand F
or
Sand FContrast settings of the LCD
Oand Sand F
Hardware lock / unlock
After a hardware lock, operation of the device via display or
communication is not possible!
The hardware can only be unlocked via the display. A release code must
be entered to do so.

1 Notes on using this manual Levelflex M
10 Endress+Hauser
1.5.4 Operation with VU331
Fig. 3: Selecting functions and configuring parameters (basic menu)
XX
X
X
S
SS
OOO
F
>3 s
F
...
2x
ENDRESS + HAUSER
E
+
–
F
Selection and configuration in Operation menu:
Group Selection
Function Group
unction
Note!
Selection menus:
Parameter function
Typing in numerals and text:
numeral / text
function
function
Group selection
Measured value display
1.) Change from Measured Value Display to by pressing
2.) Press or to select the required (e.g.. "basic setup (00)") and confirm by pressing
First f (e.g. "tank shape (002)") is selected.
The active selection is marked by a in front of the menu text.
3.) Activate Edit mode with or .
a) Select the required in selected (e.g. "tank shape (002)") with or .
b) confirms selection appears in front of the selected parameter
c) confirms the edited value system quits Edit mode
d) / (= ) interrupts selection system quits Edit mode
a) Press or to edit the first character of the (e.g. "empty calibr. (005)")
b) positions the cursor at the next character continue with (a) until you have completed your input
c) if a symbol appears at the cursor, press to accept the value entered
system quits Edit mode
d) / (= ) interrupts the input, system quits Edit mode
4) Press to select the next (e.g. "medium property (003)")
5) Press / (= ) once return to previous (e.g. "tank shape (002)")
Press / (= ) twice return to
6) Press / (= ) to return to
F
SO
F
OS
SO
F
F
OS X
OS
F
F
OS X
F
OS X
OS X
OS X
➜
✔
➜✔
➜
➜
➜
➜
➜
➜
Return to
Group Selection
basic setup
safety settings
length adjustment
tank shape
part. filled
fully flooded
linearisation
extended calibr.
process proper.
standard
fast change
slow change
test no Filter

Levelflex M 1 Notes on using this manual
Endress+Hauser 11
1.6 Commissioning
1.6.1 Switching on the measuring device
When the device is switched on for the first time, the following messages appear on the display:
⇒
⇓After 5 s, the following message appears
⇓After 5 s, the following message appears
⇓After 5 s or after you have pressed Fthe following
message appears
Select the language
(this message appears the first time the device is
switched on)
⇓
Select the basic unit
(this message appears the first time the device is
switched on)
⇓
The current measured values PV (interface layer) and SV
(level) are displayed in the standard settings.
⇓After Fis pressed, you reach the group selection.
This selection enables you to perform the basic setup
ENDRESS + HAUSER
E
+
–

2 Levelflex M function menu Levelflex M
12 Endress+Hauser
2 Levelflex M function menu
Function group Function Description
Basic Setup 00 ⇒Measured Value 000 →See →ä14
(See →ä14) Tank Properties 002 →See →ä14
⇓Process Properties 004 →See →ä15
Empty Calibration 005 →See →ä15
Full Calibration 006 →See →ä16
Upper Block. Distance 059 →See →ä16
Medium Property 003 →See →ä18
Safety Settings 01 ⇒Outp. on Alarm 010 →See →ä20
(See →ä20) Outp. on Alarm 011 →See →ä21
⇓Outp. Echo Loss 012 →See →ä22
Delay Time 014 →See →ä22
Safety Distance 015 →See →ä23
In Safety Dist. 016 →See →ä23
Ackn. Alarm 017 →See →ä25
Length Adjustment 03 ⇒Probe 032 →See →ä26
(See →ä26) Probe Length 033 →See →ä26
⇓Determine Length 034 →See →ä26
Linearization 04 ⇒Level/Ullage 040 →See →ä27
(See →ä27) Linearization 041 →See →ä28
⇓Customer Unit 042 →See →ä31
TabNo 043 →See →ä32
Level 044 →See →ä32
Volume 045 →See →ä33
Max. Scale 046 →See →ä33
Diameter Vessel 047 →See →ä33
Extended Calibration 05 ⇒Selection 050 →See →ä34
(See →ä34) Installation instructions 007 →See →ä34
⇓Medium Property2 018 →See →ä35
Range of Mapping 052 →See →ä36
Start Mapping 053 →See →ä36
Distance/Measured Value 008 →See →ä19
Pres. Map. Dist. 054 →See →ä36
Delete Map. 051 →See →ä37
Echo Qual. Level 055 →See →ä37
Echo Qual. Interface 056 →See →ä38
Offset 057 →See →ä38
Output Damping 058 →See →ä38

Levelflex M 2 Levelflex M function menu
Endress+Hauser 13
Function group Function Description
Output 06 ⇒Assignment PV 035 →See →ä39
(See →ä39) Assignment SV 036 →See →ä39
⇓Assignment TV 037 →See →ä39
PV and SV 038 →See →ä40
TV and QV 039 →See →ä40
Commun. Address 060 →See →ä40
No. of Preambles 061 →See →ä41
Low Output Limit 062 →See →ä41
Current Output Mode 063 →See →ä42
Fixed Current 064 →See →ä43
Simulation 065 →See →ä43
Simulation Value 066 →See →ä45
Output Current 067 →See →ä45
4mA Value 068 →See →ä45
20mA Value 069 →See →ä45
Envelope Curve 0E ⇒Plot Settings 0E1 →See →ä46
(See →ä46) Recording Curve 0E2 →See →ä46
⇓Envelope Curve Display 0E3 →See →ä46
Display 09 ⇒Language 092 →See →ä50
(See →ä50) Back to Home 093 →See →ä50
⇓Format Display 094 →See →ä51
No. of Decimals 095 →See →ä51
Sep. Character 096 →See →ä51
Display Layout 098 →See →ä52
Display Test 097 →See →ä52
Diagnostics 0A ⇒Present Error 0A0 →See →ä54
(See →ä53) Previous Error 0A1 →See →ä54
⇓Clear Last Error 0A2 →See →ä54
Reset 0A3 →See →ä55
Unlock Parameter 0A4 →See →ä56
Dist. Level 0A5 →See →ä58
Dist. Interface 0A6 →See →ä58
Application Param. 0A8 →See →ä59
Function group Function Description
System Parameter 0C ⇒Tag No. 0C0 →See →ä60
(See →ä60) Protocol+SW No. 0C2 →See →ä60
⇓Serial No. 0C4 →See →ä60
Distance Unit 0C5 →See →ä61
Download Mode 0C8 →See →ä62
Service D00 ⇒Service level D00 →See →ä63

3 Function group "Basic Setup" (00) Levelflex M
14 Endress+Hauser
3 Function group "Basic Setup" (00)
3.1 Function "Measured Value" (000)
This function displays the current measured value in the selected unit(see "Customer Unit"(042)
function). The number of digits after the decimal point can be selected in the "No. of
Decimals"(095) function.
The standard settings for PV and SV assignment are as follows:
PV corresponds to the interface layer; SV = total level
3.2 Function "Tank Properties" (002)
This function is used to select the tank properties.
Depending on the settings, the system searches for one (flooded) echo or 2 (partially filled) echoes.
Options:
• Partially Filled
• Flooded
Partially Filled
The system searches for 2 signals in the measuring range. The upper signal is assigned to the total
level and the lower signal to the level of the interface layer. The difference between the two levels
corresponds to the thickness of the upper phase.
Flooded
The biggest signal in the measuring range is evaluated. If the signal for the total level is within the
upper blocking distance, the signal detected corresponds to the level of the interface layer. If an echo
is not found, echo loss is detected.
!Note!
• If "Flooded" is selected, it is absolutely essential that the upper signal for the total level is within
the upper blocking distance so that it is not evaluated incorrectly. The setting for the upper
blocking distance is an integral part of the basic setup if "Flooded" is selected.
• A change in the total level when "Flooded" is selected impacts the accuracy.
⇒
ENDRESS + HAUSER
E
+
–
⇒
ENDRESS + HAUSER
E
+
–
⇒
ENDRESS + HAUSER
E
+
–

Levelflex M 3 Function group "Basic Setup" (00)
Endress+Hauser 15
3.3 Function "Process Propert." (004)
Use this function to adapt the device reaction to the filling speed in the tank. The setting influences
an intelligent filter and affects the total level and interface layer level in the same way.
Options:
• Standard
• Fast Change
•SlowChange
• Test: No Filter
3.4 Function "Empty Calibr." (005)
This function is used to enter the distance from the flange (reference point of the measurement) to
the minimum level (=zero).
⇒
ENDRESS + HAUSER
E
+
–
Options: Standard Fast Change Slow Change Test: No Filter
Application: For all normal applications, bulk
solids and liquids with low to
medium filling speeds and
sufficiently large tanks.
Small tanks, primarily with
liquids, at high filling speeds.
Applications with severe surface
movement, e.g. caused by
agitator, primarily large tanks
with low to medium filling
speeds.
Shortest reaction time:
• For test purposes
• Measurement in small tanks
at high filling speeds, if "Fast
Change" setting is too slow.
2-wire electronics: Dead time: 4 s
Rise time: 18 s
Dead time: 2 s
Rise time: 5 s
Dead time: 6 s
Rise time: 40 s
Dead time: 1 s
Rise time: 0 s
⇒
ENDRESS + HAUSER
E
+
–
0%
E
E = empty calibration (= zero)

3 Function group "Basic Setup" (00) Levelflex M
16 Endress+Hauser
3.5 Function "Full Calibr." (006)
This function is used to enter the distance from the minimum level to the maximum level (=span).
3.6 Function "Upper Block. Dist." (059)
For rod probes and for rope probes with lengths of up to 8 m, the upper blocking distance is preset to
0.1 m on delivery.
Blocking distances and measuring range depending on probe type
At the lower end of the probe, accurate measuring is not possible, see section "Maximum measured
error" on →ä17.
⇒
ENDRESS + HAUSER
E
+
–
100%
0%
F
DK2
DK1F = full calibration (= span)
Fmax = E – upper blocking distance
⇒
ENDRESS + HAUSER
E
+
–
FMP40
LN [m] UB [m]
min max min
Coax probes 0.3 4 0
16 mm rod probe in the bypass 0.3 4 0.1 a)
a. The indicated blocking distances are preset. The upper blocking distance UB can be entered manually.
6 mm rod probe in the bypass 0.3 2 0.1 a)
Rope probe in free field b)
b. Measurements in free field available on request
110
c)
c. Larger measuring range available on request.
0.1 a)

Levelflex M 3 Function group "Basic Setup" (00)
Endress+Hauser 17
Note!
When installing in flooded bypasses, the blocking distance is used to map the total level echo. It may
have to be adjusted to suit local conditions.
Maximum measured error
Typical data under reference conditions:
DIN EN 61298-2, percentage values in relation to the span.
If the reference conditions are not met, the offset/zero point arising from the mounting situation
may be up to ±12 mm for rope and rod probes. This additional offset/zero point can be
compensated for by entering a correction (function "Offset" (057)) during commissioning.
FMP41C/FMP45 LN [m] UB [m]
min max min
Rod probe in bypass 0.3 4 0.1 a)
a. The indicated blocking distances are preset.
Rope probe b) in free field
(not FMP41C)
b. Measurements in free field available on request.
135
c)
c. Larger measuring range available on request.
0.1 a)
Coax probe
(not FMP41C) 0.3 4 0
Output: Digital Analog
Sum of non-linearity, non-
repeatability and hysteresis
Level (electronic version level and
interface measurement):
FMP40, FMP45
– Measuring range up to 10 m: ±3 mm
– Measuring range > 10 m: ± 0.03 %
FMP45 with coax probe:
– Measuring range ±5 mm
FMP41C:
– Measuring range up to 10 m: ±5 mm
– Measuring range > 10 m: ± 0.05 %
For PA-coated rope probes:
– Measuring range up to 5 m: ±5 mm
– Measuring range > 5 m: ±0.1 %
± 0.06 %
Interface (only for electronic version "K"
interface measurement):
Measuring range up to 10 m: ±10 mm
If the thickness of the interface is <60 mm,
the interface can no longer be differentiated
from the overall level such that both output
signals are identical.
Offset / Zero ±4 mm ± 0.03 %

3 Function group "Basic Setup" (00) Levelflex M
18 Endress+Hauser
Differing from this, the following measuring error is present in the vicinity of the level
(electronic version level and interface measurement):
If for rope probes the DC value is less than 7, then measurement is not possible in the area of the straining
weight (0 to 250 mm from end of probe; lower blocking distance).
Differing from this, the following measuring error is present for the thin interface (only for
electronic version "K" interface measurement):
L00-FMP4xIxx-05-00-00-en-001
3.7 Function "Medium Property" (003)
Use this function to enter the dielectric constant of the upper medium (upper phase).
L00-FMP4xxxx-05-00-00-en-001 L00-FMP4xxxx-05-00-00-en-002
rod probe and coax probe
-80
-60
-40
-20
0
20
40
60
80
0 50 100 150 200 250 300
distance from probe end [mm]
sum of non-linearity, non-repeatability
and hysteresis [mm]
DC = 2
DC > 7
rope probe
-80
-60
-40
-20
0
20
40
60
80
0 50 100 150 200 250 300
distance from probe end [mm]
sum of non-linearity, non-repeatability
and hysteresis [mm]
DC > 7
0
±10
±20
±30
±40
±50
060200
maximum measured error
[mm]
upper
medium
thickness of upper medium
[mm]
rod probe (example),also valid for coax probe
lower medium
No measurement
possiblein
this area
Interface
⇒
ENDRESS + HAUSER
E
+
–

Levelflex M 3 Function group "Basic Setup" (00)
Endress+Hauser 19
Options:
•2.00
The tables below divide the DK values by product group. However, it is not sufficient to assume a
typical value. For accurate interface measurement, it is necessary to determine the DK of the upper
medium (upper phase) as accurately as possible and enter the value in this function.
The DK of the upper medium must be known and constant. The DK can be determined via the DK
manual SD106F. If there is an interface of known thickness, the DK can also be calculated
automatically by FieldCare.
3.8 Display (008)
The measured distances from the reference point to the product level and the interface are shown.
Check whether the values correspond to the actual distances. The following cases can occur:
• Distances correct -> continue with group selection
• Distance to level incorrect -> empty tank/bypass and perform mapping over the entire probe
length.
• Distance to interface incorrect -> check entry for "Medium Prop." (003).
DC (εr) Typical liquids
1.4 to 1.6 – Condensed gases, e.g. N2, CO2
1.6 to 1.9
– Liquefied gas, e.g. propane
–Solvent
–Freon
–Palmoil
1.9 to 2.5 – Mineral oils, fuels
2.5 to 4
– Benzene, styrene, toluene
–Furan
– Naphthalene
4 to 7
– Chlorobenzene, chloroform
– Cellulose spray
– Isocyanate, aniline
>7
– Aqueous solutions
– Alcohols
– Ammonia
⇒
ENDRESS + HAUSER
E
+
–
⇒
⇓After 3 s, the following message appears
ENDRESS + HAUSER
E
+
–

4 Function group "Safety Settings" (01) Levelflex M
20 Endress+Hauser
4 Function group "Safety Settings" (01)
4.1 Function "Outp. on Alarm" (010)
Use this function to select the reaction of the device to an alarm condition.
Options:
• MIN (<= 3.6mA
• MAX (22mA)
•Hold
• User-specific
MIN (<= 3.6mA)
If the device is in an alarm condition, the output is changed as follows:
• HART: MIN alarm 3.6 mA
MAX 110% 22mA
If the device is in an alarm condition, the output is changed as follows:
• HART: MAX alarm 22 mA
⇒
ENDRESS + HAUSER
E
+
–
⇒
ENDRESS + HAUSER
E
+
–
(110%)
(-10%)
3.6
t
[mA]
22
-99999
t
HART PA / FF
HART PA / FF
(110%)
(-10%)
3.6
t
[mA]
22 +99999
t
