Chef-Master HEC823 User manual

Chefmaster Pie Cabinets
Instruction Manual
Model
HEC823 –Small Pie Cabinet
HEC824 –Large Pie Cabinet

2
Thank you for purchasing your Chefmaster Pie Cabinet. To make full use
of the product please read this manual carefully before using the product
and keep it safe for future reference.
Safety Tips
If you find any damage when the product is unpacked, contact your
Chefmaster supplier within 24 hours of receipt of goods
Always position on a flat stable surface
Repairs should always be carried out by a qualified technician.
Do not use this appliance outside
Always switch off or unplug the unit before cleaning
Always open or close the doors gently to avoid damaging glass
Move by holding the product by the base
Always allow the Pie Cabinet to cool down before cleaning, maintaining
or moving to avoid the risk of burns
DO NOT use the appliance for anything other than its intended use
If the power cord becomes damaged it must be replaced by a qualified
technician
This product is not designed to be used by persons with reduced
physical or mental capabilities, lack of experience or knowledge, unless
they are given suitable supervision, this includes children.
Pack Contents
1 x Chefmaster Pie Cabinet
4 x Removable Shelf for HEC823 or
5 x Removable Shelf for HEC824
1 x Crumb Tray
1x Manual
Before Use
Remove all packaging including all protective plastic from your
Chefmaster Pie Cabinet
Position on a flat surface, ensure the ventilation in the supporting area is
good
Wipe the product thoroughly with soft damp cloth only
Connect the plug to a suitable mains socket
The product will now be ready to turn on

3
Operation
Set the thermostat to desired temperature from 30-90°C
The orange indicator will be on and the unit will cycle on and off to
maintain the set temperature
Temperature can be monitored with the dial next to the temperature
control
Set the thermostat to “0” to turn off
Note: This product is for maintaining temperature only. It is NOT suitable
for cooking or heating food from cold
Cleaning & Maintenance
Before cleaning disconnect the Pie Cabinet from the electricity supply
Allow the appliance to cool before cleaning
DO NOT immerse the pie cabinet in water, or use jet/pressure washers
to clean it
The inner body of the appliance should be wiped down at the end of
each day's operation. Additional cleaning may be required depending
on frequency of use
Warm soapy water is recommended for cleaning. Cleaning agents may
cause damage or leave harmful residues when used for a prolonged
period on stainless steel.
Troubleshooting
Condition
Possible Cause
Solution
The unit is
plugged in but
heating and
indicator light is
not on
1. The unit is not switched on
2. The plug or lead are damaged
3. The fuse has blown
1. Check the unit is correctly
plugged in and thermostat is
set above 30°C
2. Contact your Chefmaster
distributor
3. Replace the fuse
The unit is
heating but
indicator light is
not on
The indicator light may have to
be replaced
Contact your Chefmaster
distributor

4
Transportation and Storage
Please handle your pie cabinet with care to prevent any damage to the unit
and internal parts. The appliance should be stored in a well ventilated area.
Do not store any flammable objects near the equipment.
Technical Information
HEC823
Voltage ~230v 50/60Hz
Power 1.0Kw
Weight 21kg
Dimensions 640 x 360 x 530
Capacity 50 pies
HEC824
Voltage ~230v 50/60Hz
Power 1.0Kw
Weight 35kg
Dimensions 865 x 360 x 625
Capacity 100 pies
Chefmaster Pie Cabinet is supplied with a 3 pin plug and lead with a 13
amp fuse
Appliance must be earthed
If in doubt contact a qualified electrician or your Chefmaster distributor
Disposal
Under WEEE regulations this product must not be disposed of as household
waste. To prevent damage to the environment and humans this product must
be disposed of in an approved and environmentally friendly recycling process.
For more information on how to dispose of this correctly please contact your
Chefmaster distributor or local authority responsible for waste disposal.

5
Compliance
All Chefmaster parts and products have under gone a stringent testing process
to ensure that comply with all European standards and specifications.
All Chefmaster products carry the CE approval symbol.
