Citizen 6702 User manual

3
CONTENTS
1. Product Features ............................................................................. 4
2. Component Names ........................................................................... 5
Operating procedure overview
3. Viewing the Watch Indications ........................................................ 7
Year indication
4. Before Using the Watch-Reference position verification-............ 9
5. Setting the Time .............................................................................. 10
6. Setting the Calendar ....................................................................... 11
7. Calling the Calendar ....................................................................... 12
8. When Problem Occurs ................................................................... 14
9. Adjusting the Reference Positions ............................................... 16
Reference positioning failure warning function
10. Precautions ..................................................................................... 18
11. Specifications.................................................................................. 24
English

2. Component Names
4 5
1. Product Features
This product is an analog quartz watch that uses to hands to show the hour,
minutes, and seconds, indicate the hours on a 24-hour basis, and furnish
calendar information (year, month, date, and day of the week).
This watch equipped a fully automatic calendar, which automatically adjusts the
end of each month, including the months of a leap year. One useful feature of
this watch enables you to quickly call up a future or past calendar at one touch
of a button.
Any repairs of this product, excluding the band, should be conducted at a
Citizen Service Center. For repair and inspection please contact the place
of purchase or contact a Citizen Service Center directly.
* The design varies from one model to another.
* Ensure that the crown is always placed in the normal position during normal use of
the watch.
Using the watch with the crown pulled to the first or second click position will shorten
the battery life. Even while the watch is not being used, leave the crown in the
normal position.
Year hand
Hour hand
Day of the week
Button (C)
(reset button)
Month hand
Year indicator
Minute hand
Button (A) (future button)
24-hour hand
Crown
Second hand
Button (B) (past button)
Date hand
Month indicator

6 7
Crown
Operation Normal position First click position Second click position
Calls a future
calendar (forward). Adjusts the year.
--
Calls a past
calendar
(backward).
Adjusts the month
and day of the
month.
--
Returns you to the
present calendar
display.
-- --
-- --
Adjusts the time.
Pressing button (A)
Pressing button (B)
Pressing button (C)
Rotating the crown
[Operating procedure overview] 3. Viewing the Watch Indications
[Viewing the time] [Viewing the calendar]
Hour hand Minute hand
24-hour
hand
Second
hand
Day of the
week
Month
Year
Date

8 9
[Year indication]
The year hand indicates the years that are arranged in a
straight line as shown below.
In the widely used Gregorian calendar, a leap year is
roughly defined as a year that is divisible by four.
However, years divisible by four are not regarded as a
leap year and counted as a common year if its quotient
obtained by dividing by 100 is not divisible by four (e.g.,
years 1900 and 2100).
During the period of 1901 to 2099, a leap year occurs at
4-year intervals according to this regularity, and the same
calendared information is repeated on a 28-year cycle.
The year indication scale for this watch is also repeated
on a 28-year cycle. Therefore, the same calendar applies
to all the aligned years that the year hand points to.
(Example: The same calendar applies to the years 1916,
1944, 1972, 2000, 2028, 2056, and 2084.)
2084
2056
2028
2000
1972
1944
1916
4. Before Using the Watch -Reference position verification-
Before the use of the watch, you should perform the following procedure to verify that
the reference position is properly set for each hand of the watch.
If the reference positions are not correctly set, the calendar feature does not properly
work.
Year 2000
Sunday
December
31st day
[Verifying the reference position]
(1) With the crown placed in the normal position,
hold down button (C) for about 2 seconds. The
year, month, date, and day-of-the-week hands
then quickly move to their reference positions.
(2) Verify that the hands are placed in the
reference positions (Sunday, December 31,
2000).
(3) Return to the present calendar display mode
by pressing button (C) or allowing the
reference position verification state to prevail
for about 30 seconds.
*If the hands are not placed in the reference
positions, correct their reference positions as
directed in Section 9, Adjusting the Reference
Positions.
(C)

10 11
(1) When the second hand indicates 0
second, pull the crown out to the
second click position.
(2) Rotate the crown as needed to set
the time.
Carefully note the 24-hour hand to
distinguish between an A.M.
(before noon) hour and P.M. (after
noon) hour.
(3) Properly push the crown into its
normal position in accordance with
a standard time signal or the like.
*While you are performing a time
setting procedure, the time and
calendar do not coordinate with
each other. Therefore, the calendar
indication remains unchanged even
if the 24-hour hand passes the 12
midnight point.
5. Setting the Time
Hour
hand Minute hand
Time setting
position
Crown
Normal
position
24-hour hand
Second hand
(1) Pull the crown out to the first
click position.
(2) Press button (A) to set the year.
The year hand advances by one
year at each press of button (A).
Holding down this button rapidly
advances the year.
(3) Press button (B) to set the month
and date. (The month and date
hands coordinate with each
other.)
The date hand advances by one
day at each press of button (B).
Holding down this button rapidly
advances the date.
(4) Properly push the crown into its
normal position.
6. Setting the Calendar
Year
Day of the
week Month
Date
Calendar
setting
position
Crown
Normal position

12 13
* The day of the week is automatically set in accordance with the year, month
and date settings.
* Do not change the calendar indication during the time between about 9 p.m.
and 1 a.m. If you change the calendar indication during such a period of time,
the calendar indication may fail to change on the next day.
* This calendar is fully automatic (perpetual calendar). Once it is properly
adjusted, you do not have to readjust the end of each month, including the
months for a leap year.
* If the calendar is adjusted for a nonexistent day, it is automatically corrected to
indicate the first day of the next month after you push the crown into its normal
position (e. g., February 30
-
>March 1).
* The month hand position may slightly deviate from normal at the end or
beginning of a month. If such a situation occurs, note the date hand position to
determine the current month (distinguish between the two successive months).
7. Calling the Calendar
You can call a past or future calendar that is within the range from March 1,
1900 to February 28, 2100.
This calendar feature offers various capabilities. For example, you can
determine the day of the week of your birth date or search for a year in which
Christmas Day, your birthday, or other specific day falls on a Sunday.
[Calling the calendar]
(1) With the crown placed in the normal position, you can shift the calendar
indication toward the future or past by pressing button (A) or (B). The
calendar indication changes by one day at each press of button (A) or (B).
(Holding down the button rapidly changes the calendar indication.)
(2) The watch automatically returns to the present calendar display mode at the
press of button (C) or after an elapse of 30 seconds.
*While the calendar is being called, the second hand makes a 2-second
motion (moves two graduations at 2-second intervals) to indicate that the
calendar call process is in progress.
(A): Calls a future calendar (forward).
(B): Calls a past calendar (backward).
(C)

14 15
8. When Problem Occurs
[The year hand moves rapidly in reverse direction.]
The reference positioning procedure is not properly completed. That is why the
“reference positioning failure warning function” is activated.
Properly adjust the reference positions of all hands as directed in Section 9,
Adjusting the Reference Positions.
[The calendar indication is incorrect.]
If the watch is severely shocked, the hand’s reference positions may deviate
from the normal.
Properly adjust the reference positions of all hands as directed in Section 9,
Adjusting the Reference positions.
[The watch operates erratically.]
The watch may occasionally perform an abnormal operation (e.g., the hands
may rotate in an unusual manner) if it is adversely affected by static electricity or
severely shocked.
In this instance, properly adjust the reference positions of all hands as directed
in Section 9, Adjusting the Reference Positions.
[After battery replacement]
After battery replacement, be sure to properly adjust the reference positions of
all hands as directed in Section 9, Adjusting the Reference Positions.
The watch does not properly function until the reference position adjustment
procedure is completed.

16 17
9. Adjusting the Reference Positions
If the reference positions are not properly adjusted for all hands, the watch
improperly operates.
When the reference positions are found improper, perform the following
procedure to adjust the reference position of each hand. (This procedure must
also be completed after battery replacement.)
Year
Day of the week
Month
Day of the month
Crown
(1) Pull the crown out to the
second click position.
(2) Simultaneously press
three buttons that are
designated (A), (B), and
(C). This causes the
year, month, date, and
day-of-the-week hands
to sequentially start
moving.
(3) Press button (A) to set the year hand
to the year 2000.
(4) Press button (B) to set the month and
date hands to December 31. (The
month hand moves in conjunction
with the day hand.)
(5) Press button (C) to place the day-of-
the-week hand in the Sunday (SUN)
position.
*Continued pressing of button (A) and
button (B) will forward the hands
rapidly.
Reference position=December 31,
2000 (sun.)
<Reference positioning failure warning function>
If you push the crown into its normal position without performing the button
manipulation procedure after completion of Steps (1) and (2), the year hand
rapidly moves in reverse direction to alert you that the reference positions are
improperly adjusted.
When you encounter the above situation, adjust the reference positions of all
hands by performing the specified procedure again.

1918
NO NO NO NO
OK NO NO NO
OK OK NO NO
Moderate exposure to
water (washing, kitchen
work, swimming, etc.)
Marine sports
(skin diving)
Scuba diving
(with air tank)
Operation of the
crown or button with
moisture visible
Examples of use
For correct use within the design limits of the watch, confirm the level of water-
resistance of your watch, as indicated on the dial and case, and consult the table.
OK
OK
OK
Minor exposure to water
(washing face, rain, etc.)
Indication
WATER RESIST or
no indication
WATER
RESIST(ANT)
Water-resistant to
3 atmospheres
WR 50 or WATER
RESIST 50
WATER
RESIST(ANT) 5 bar or
WATER RESIST(ANT)
Water-resistant to
5 atmospheres
WR 100/200 or
WATER RESIST 100/200
WATER RESIST(ANT)
10bar/20 bar or
WATER RESIST(ANT)
Water-resistant to
10 / 20 atmospheres
Dial Case (Case back) Specification
10. Precautions
CAUTION: Water-resistance performance
There are several types of water-resistant watches, as
shown in the following table.
The unit "bar" is roughly equal to 1 atmosphere.
* WATER RESIST(ANT) xx bar may also be indicated
as W.R. xx bar.

2120
• If seawater enters the watch, place the watch in a box or plastic bag and
immediately take it in for repair. Otherwise, pressure inside the watch will
increase, and parts (crystal, crown, buttons, etc.) may come off.
CAUTION: Keep your watch clean.
• Dust and dirt tend to be deposited in gaps in the back of the case or band.
Deposited dust and dirt may cause corrosion and soil your clothing. Clean the
watch occasionally.
Cleaning the Watch
• Use a soft cloth to wipe off dirt, perspiration and water from the case and
crystal.
• Use a soft, dry cloth to wipe off perspiration and dirt from the leather band.
• To clean a metal, plastic, or rubber watchband, wash away dirt with mild soap
and water. Use a soft brush to remove dust and dirt jammed in the gaps in the
metal band. If your watch is not water-resistant, take it to your dealer.
NOTE: Avoid using solvents (thinner, benzine, etc.), as they may mar the finish.
WARNING: Handling of the battery
• Keep the battery out of the reach of small children. If a child swallows the
battery, contact a physician immediately.
• Water-resistance for daily use (to 3 atmospheres): This type of watch is water-
resistant to minor exposure to water. For example, you may wear the watch
while washing your face; however, it is not designed for use underwater.
• Upgraded water-resistance for daily use (to 5 atmospheres): This type of
watch is water-resistant to moderate exposure to water. You may wear the
watch while swimming; however, it is not designed for use while skin diving.
• Upgraded water-resistance for daily use (to 10/20 atmospheres): This type of
watch may be used for skin diving; however, it is not designed for scuba or
saturated diving using helium gas.
CAUTION
• Do NOT operate the crown or button with wet fingers or when the watch is
wet. Water may enter the watch and compromise water-resistance.
• If the watch is used in seawater, rinse with fresh water afterward and wipe with
a dry cloth.
• If moisture has entered the watch, or if the inside of the crystal is fogged up
and does not become clear within a day, immediately take the watch to your
dealer or Citizen Service Center for repair. Leaving the watch in such a state
will allow corrosion to form inside.

Timekeeping will become inaccurate if you place the watch close to magnetic
health equipment such as a magnetic necklace or a magnetic latch of a
refrigerator door or handbag clasp or the earphone of a mobile phone. If this
has occurred, move the watch away from the magnet and reset the time.
• Do NOT place the watch close to household appliances that generate static
electricity.
Timekeeping may become inaccurate if the watch is exposed to strong static
electricity, such as is emitted from a TV screen.
• Do NOT subject the watch to a strong shock such as dropping it onto a hard
floor.
• Avoid using the watch in an environment where it may be exposed to
chemicals or corrosive gases.
If solvents, such as thinner and benzine, or substances containing such
solvents come in contact with the watch, discoloration, melting, cracking, etc.
may result. If the watch comes in contact with mercury used in thermometers,
the case, band or other parts may become discolored.
<Periodical inspections>
Your watch requires inspection once every two or three years for safety and long
use.
To keep your watch water resistant, the packing needs to be replaced regularly.
Other parts are required to be inspected and replaced as necessary.
Ask for Citizen geuine parts during replacement. 2322
CAUTION: Replacing the battery
• For replacement of the battery, take your watch to your dealer or Citizen
Service Center.
• Replace the battery as soon as possible if the service life of the battery has
expired. Leaving a depleted battery in the watch may result in leakage, which
can damage the watch severely.
CAUTION: Operating environment
• Use the watch within the operating-temperature range specified in the
instruction manual.
Using the watch where temperatures are outside the specified range, may
result in deterioration of functions or even stoppage of the watch.
• Do NOT use the watch in places where it is exposed to high temperature,
such as in a sauna.
Doing so may result in a skin burn.
• Do NOT leave the watch in a place where it is exposed to high temperature,
such as the glove compartment or dash-board of a car.
Doing so may result in deterioration of the watch, such as deformation of
plastic parts.
• Do NOT place the watch close to a magnet.

24
11. Specifications
1. Caliber No.: 6702
2. Type: Analog quartz watch
3. Accuracy: Within ±20 seconds per month
(When worn at normal temperature of +5°C ~ +35°C / 41°F to 95°F)
4. Operating temperature range:
- 10°C ~ +60°C / 14°F to 140°F
5. Display functions:
• Time: hour, minute, second, 24-hour hand
• Calendar: year, month, date, day of the week (full auto calendar)
6. Additional functions:
• Function to access the past and future calendars
• Reference positioning failure warning function
7. Battery used: Silver oxide battery 1 pce.
8. Battery life: approximately 3 years (when accessing the 15 calendars a day)
* Specifications are subject to change without notice.
