clage MCX 3 User manual

Zip
Instantaneous Hot Water
Electronically controlled instantaneous water heater
MCX: 27300, 27400 and 27600 models
Instructions for the user
These appliances deliver water not exceeding 50°C in accordance with AS3498

2
Instructions for user - MCX - 801052 - January 2020 v1.20 Art.no: 9120-15036
Contents
1. Safety instructions..............................................................................................3
2. Overview ..................................................................................................... 5
3. Technical data .................................................................................................6
4. Description of the appliance ..................................................................................... 6
5. Typical installations.............................................................................................7
6. Operation .....................................................................................................8
Temperature setting ............................................................................................ 8
Key lock and temperature lock.................................................................................... 8
Additional features ............................................................................................. 8
7. Cleaning and Maintenance ......................................................................................9
8. Troubleshooting and service ....................................................................................10

3
Instructions for user - MCX - 801052 - January 2020 v1.20 Art.no: 9120-15036
1. Safety instructions
Please read these instructions carefully before installing or using the appliance!
Keep the instructions handy with the appliance for future use!
Installation, initial operation and maintenance of this appliance must only be con-
ducted by an authorised professional, who will then be responsible for adherence to
applicable standards and installation regulations. We assume no liability for any dam-
ages caused by failure to observe these instructions.
• Do not use the appliance until it has been correctly installed and unless it is
in perfect working order.
• Do not remove the front cover under any circumstances before switching off
the mains electrical supply to the unit.
• Never make technical modifications, either to the appliance itself or the
electrical leads and water pipes.
• The appliance must be earthed at all times.
• Pay attention to the fact that water temperatures in excess of approx. 43 °C
are perceived as hot, especially by children, and may cause a feeling of
burning. Please note that the fittings and taps may be very hot when the
appliance has been in use for some time.
• The appliance is only suitable for domestic use and similar applications
inside closed rooms, and must only be used to heat incoming water from
the mains supply.
• The appliance must never be exposed to frost.
• The values stated on the rating plate must be observed.
• In case of malfunction, disconnect the fuses immediately. In case of leaks,
cut off the mains water supply instantly. Repairs must only be carried out by
the customer service department or an authorised professional.
• This appliance can be used by children aged 3years and above and persons
with reduced physical, sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or instruction concern-
ing use of the appliance in a safe way and understand the hazards involved.
Children shall not play with the appliance. Cleaning and user maintenance
shall not be performed by children without supervision.
• If the appliance is factory equipped with a power supply cable, it must be
replaced with an original spare cable from the manufacturer in case of dam-

4
Instructions for user - MCX - 801052 - January 2020 v1.20 Art.no: 9120-15036
To observe additionally for pressureless installation:
• The water outlet behind the devices must not be blocked, and the water
flow must not be restricted.
• The water outlet facilities, such as jet control and other outlet unit, must be
decalcified regularly. Deposits must be removed in regular intervals.
• Only the fittings recommended by the manufacturer may be used.
age by an authorised technician in order to avoid any hazards.
• For appliances with direct connection, an all-pole disconnecting device
with a contact opening width of ≥3 mm per phase must be provided at the
installation end, according to Australian wiring rules AS/NZ3000.
• The wall bracket must be secured with the supplied screws and dowels. The
appliance must be secured to the wall bracket. The appliance may only be
operated if it has been properly mounted on the wall bracket.
• The prescribed nominal pressure stated on the rating plate may not be
exceeded at any time.
• The required water resistance may not fall below the value stated on the
rating plate at any time.
1. Safety instructions
• This appliance is not suitable for hot water supply to showers.

5
Instructions for user - MCX - 801052 - January 2020 v1.20 Art.no: 9120-15036
2. Overview
When ordering spare parts, please always specify the appliance model and serial number.
Parts in Bold Type are available as Spare Parts. Other parts are available on request
Pos. Part.-No. Description
6 93184 MCX complete fixing set (wall bracket with
screws and dowels)
7 99407 Temperature sensor (polarity protection)
not shown:
MCX 3 mains cable with earthed plug, cable
seal and strain relief
MCX 4 mains cable (without plug), cable seal
and strain relief
MCX 6 mains cable (without plug), cable seal
and strain relief
MCX set of small spare parts (seals, nozzle
for cable entry, terminal, installation grease,
screws, wheel nut & discs)
99430 Aerator / flow restrictor
1
7
6
5
4
3
2
Pos. Part.-No. Description
1 MCX cover with control panel
2 99403 MCX heating cartridge 3.5 kW /230V
99404 MCX heating cartridge 4.4 kW /230V
99405 MCX heating cartridge 5.7 kW /230V
3 MCX Safety temperature limiter (STB) with
modification instructions, contact fitting,
seals etc.
• 2-pole
• 1-pole
4 99406 MCX Filter
5
MCX water connector-set with two water
connectors and seals (mounted and greased)
fastening safety earthing terminal and filter

6
Instructions for user - MCX - 801052 - January 2020 v1.20 Art.no: 9120-15036
3. Technical data
The Zip instantaneous water heaters are compact electronically controlled water heaters. It is intended to provide economical heat-
ing of water for a wash basin when installed together with a sanitary water fitting. When the hot-water tap is opened, the heater
switches itself on automatically when the minimum water flow rate is exceeded and heats the water as it passes through the appli-
ance.
There are 3 available temperature settings, 35°C, 38 °C and 45 °C.
For best performance, always fit the special flow controller included with the appliance. This controller is inserted into the outlet at
the end of the tap and fits into any standard sleeve size M 22/24.
The maximum possible outlet temperature is determined by the temperature of the incoming water, the rate of flow and the heating
power of the appliance.
This appliances deliver water not exceeding 50°C in accordance with AS3498.
4. Description of the appliance
Model MCX 3 MCX 4 MCX 6
Part no. 27300 27400 27600
Energy efficiency class A *)
Capacity Liter 0.2
Nominal pressure MPa (bar) 1 (10)
Connecting type pressure resistant / pressureless
Heating system Bare wire heating system IES®
Required water resistance
at 15 °C in Ω cm ≥ 1100 ≥ 800 ≥ 800
Electric supply 1~ / N / PE 220 – 240 V AC
Nominal power rating 3,5 kW 4,4 kW 5,7 kW
Nominal current 15 A 19 A 25 A
Temperature choice 35 °C – 38 °C – 45 °C
Factory temperature setting 38 °C
Maximum inlet temperature 70 °C
Factory flow setting at 3 bar 2,0 l/min 2,5 l/min 3,3 l/min
Maximum temperature
increase at rated power and
a flow rate of…
1)
2,0 l/min 25 K 31 K 41 K
2,5 l/min 20 K 25 K 33 K
3,0 l/min 17 K 21 K 27 K
3,5 l/min 14 K 18 K 23 K
4,0 l/min 12 K 16 K 20 K
Requiredl/min to switch on l/min 1,2 1,5 1,5
Requiredl/min to switch off l/min 1,0 1,3 1,3
Min. required cable size 2) see note 2)
Weight filled with water ca. 1.5 kg
Dimensions (H × W × D) 13.5 × 18.6 × 8.7 cm
Protection class acc. to VDE 1
Type of protection according to VDE IP 25
*) The declaration complies with the EU regulation No812/2013
1) Temperature rise (Kelvin) + cold-water temperature = maximum hot-water temperature (°C) ≤ 70°C
2) The cross sectional area of the connection cable must be in accordance with the power rating of the appliance and the specific requirements of AS/NZS 3000. The
cable size must not exceed 4 mm2

7
Instructions for user - MCX - 801052 - January 2020 v1.20 Art.no: 9120-15036
5. Typical installations
Unvented installation (closed
outlet) with tap for pressurised
appliances
Fit flow controller:
MCX 3/4: CSP 3
MCX 6/7: CSP 6
Electrical connection with
mains power cable (shorten
if necessary)
Angle valve approx. 550
Top edge of wash basin approx. 850
Axis wall bracket approx. 520
Cable entry approx. 553
Angle valve G⅜"
Dimensions in mm

8
Instructions for user - MCX - 801052 - January 2020 v1.20 Art.no: 9120-15036
6. Operation
Temperature setting
The touch key allows you to select one of the three preset temperatures.
Every key press sets the temperature to the next level:
35 °C 38 °C 45 °C (max.)
Press the key once again starts the cycle all over.
The current selected temperature is indicated by one of three coloured LEDs.
Key lock and temperature lock
The current selected temperature setting can be locked against unintended alteration. Thus, the temperature cannot be changed by
a single keypress anymore.
Activate keylock / Deactivate keylock:
Press and hold touch key for approx. 5seconds until the active LED goes out, then release the touch key.
Three coloured LEDs
Touch key
Additional features
As the control panel’s energy saving feature, the active LED turns off automatically about 20seconds after the last operation (e.g.
tapping or temperature selection).
To identify the selected setting at any time, the LED can be enabled permanently and the LED standby function will then be disabled
with the following procedure:
• Close tap (water stop).
• Keep sensor key touched permanently for more than 7seconds. Due to the keylock function the LED always goes out after 5sec-
onds for about 1.5seconds and lights up again.
• While still holding down the key, open the tap now, the LED will go out shortly as confirmation.
• Then release the touch key and close tap (water stop).
If the tap is opened or the touch key is used in LED standby mode (LED off), the last active LED lights up (wake up), but the tempera-
ture setting will not change yet. Only when pressed once again, the temperature setting will be adjusted.
The LED Standby function can be activated in the same way again.
NB:
This function is retained even after power failure.

9
Instructions for user - MCX - 801052 - January 2020 v1.20 Art.no: 9120-15036
7. Cleaning and Maintenance
• The appliance and the fittings should only be cleaned with a damp cloth. Do not use
abrasive or chlorine-based cleaning agents or solvents.
• Keep the control panel area dry!
• Clean the flow controller or the hand-shower regularly and replace as necessary.
• Dirt and scale deposited in the pipes and heater will affect the function of the
heater. Typical indications include reduced rate of flow or noisy flow. In such cases,
have the heater inspected by a technician and, if necessary, have the filter in the
cold-water inlet cleaned.

10
Instructions for user - MCX - 801052 - January 2020 v1.20 Art.no: 9120-15036
8. Troubleshooting and service
Repairs must only be carried out by
authorised professionals.
If a fault in your appliance cannot be
rectified with the aid of this table,
please contact the service organisa-
tion of your importer or the Central
Customer Service Department. Please
have the details of the typeplate at
hand.
This instantaneous water heater was manufactured conscientiously and checked sev-
eral times before delivery. First attempt to switch the house fuses off and on again in
order to reset the electronics. Next, try to remedy the problem with reference to the
following table. In doing so, you will avoid unnecessary expense of customer service
assistance.
Fault Cause Action
No water flows Water supply is turned off Open the main water valve and the
shut-off valve
Water flows
more slowly than
expected
The flow controller is not
fitted Fit the special flow controller
Water pressure is not suf-
ficient
Check the water flow pressure or
let check the water flow adjust-
ment by an authorized technician
Dirt in the pipes
Remove any dirt from the filter,
valves and taps / check the techni-
cal data
The heater switch-
es itself on and off
Water pressure is varying,
flow rate is too low
Remove any dirt / increase the flow
water pressure, close other taps,
open the shut-off valve further
Water remains
cold
Water pressure is not suf-
ficient
Let adjust the water flow by an
authorized technician, open the
shut-off valve, fit the special flow
controller, check water pressure
Dirt Remove dirt from the inlet and
outlet
Hot water tem-
perature varies
Supply voltage varies Check the supply voltage
Water connections mixed
up Check installation
Hot water tempe-
rature too low and
one LED flashes
slowly
Flow rate is too high or
inlet temperature is too
low
Adjust the flow either at the tap,
the valve or have the flow adjusted
by a authorized technician
One LED flashes
rapidly and water
remains cold
Defective temperature
sensor
Replace temperature sensor
(authorized technician)
Defective heating ele-
ment
Replace heating element (author-
ized technician)
All LEDs flash
rapidly and water
gets warm
Defective control panel
cable
Reposition control panel connector
(authorized technician)
Replace control panel (authorized
technician)
All LEDs flash
rapidly and water
remains cold
Defective power unit Contact Zip customer service
LED turns off
shortly after key-
press
Keylock is active Deactivate keylock (see page 8)

11
Instructions for user - MCX - 801052 - January 2020 v1.20 Art.no: 9120-15036
8. Troubleshooting and service
LED flashes after
keypress
Touch key was not
touched in centre
Don‘t touch the touch key for
approx. 3seconds (until LED lights
up normally); for proper handling,
touch the touch key right in the
centre
Touch key calibration
active
No LED lights LED Standby active
Check LED by touching the
touchkey.
If still no LED lights up, check the
fuses!
If the connection cable is damaged, it must be replaced with an original spare cable
from the manufacturer by an authorised technician in order to avoid any hazards.
If you cannot rectify the fault with the aid of the troubleshooting table, please contact
customer service.

Instructions for user - MCX - 801052 - January 2020 v1.20 Art.no: 9120-15036
Head Office
Zip Water (Aust) Pty. Ltd
ABN: 46 000 578 727
67-77 Allingham Street
Condell Park NSW 2200
Postal: Locked Bag 80
Bankstown 1885 Australia
Website: www.zipwater.com
Telephone: [phone]
Free Call: 1 800 638 633
As Zip’s policy is one of continuous
product improvement, changes to
specifications may be made without
prior notice. Images in this booklet
have been modified and may not be
true representations of the finished
goods.
