Clarion VX709 User manual

VX709
-1-
Service Manual
Published by Service Dept.
Printed in Japan
ClarionCo.,Ltd.
7-2,Shintoshin,Chuo-ku,Saitama-shi, Saitama 330-0081Japan
ServiceDept.: 7-2,Shintoshin,Chuo-ku,Saitama-shi, Saitama330-0081Japan
Tel:[phone] FAX: [phone]
298-6650-00 Feb.2009
Model
This product is a lead free model.
Lead free solder is used in PWB stamped LF mark.
Please keep the following conditions when you repair.
1. Use lead free solder.
* Koki's lead free solder S3X-55M 0.6mm
(CLARION Parts No.642-0231-01)
* Koki's lead free solder S3X-55M 1.0mm
(CLARION Parts No.642-0231-02)
2. Use a nitrogen solder system.
3. Do not use "General solder" and "Lead free solder"
together.
2-DIN DVD Multimedia Station
With CeNET & 7-inch Touch Panel
Control
( QZ-6074B-A )
Original model Manual No.
MAX685BT(QZ-6072B-A) 298-6566-00
NOTES
* The tuner of this unit is DSP type. When the tuner pack
is exchanged, it is necessary to adjust for S-meter etc.
The special equipment is used for an accurate adjust-
ment.
* DSP IC(IC1) cannot be removed with an ordinary sol-
dering iron because of the pad type.
* It is different from the adjustment display published in
the original service manual according to the connected
navigation unit.
* Manufactured under license from Dolby Laboratories.
"Dolby" and the double-D symbol are trademarks of Dolby
To engineers in charge of repair or
inspection of our products.
Before repair or inspection, make sure to follow the
instructions so that customers and Engineers in charge
of repair or inspection can avoid suffering any risk or
injury.
1. Use specified parts.
The system uses parts with special safety features against fire
and voltage. Use only parts with equivalent characteristics
when replacing them.
The use of unspecified parts shall be regarded as remodeling
for which we shall not be liable. The onus of product liability
(PL) shall not be our responsibility in cases where an accident
or failure is as a result of unspecified parts being used.
2. Place the parts and wiring back in their original positions after
replacement or re-wiring.
For proper circuit construction, use of insulation tubes, bond-
ing, gaps to PWB, etc, is involved. The wiring connection and
routing to the PWB are specially planned using clamps to keep
away from heated and high voltage parts. Ensure that they are
placed back in their original positions after repair or inspec-
tion.
If extended damage is caused due to negligence during re-
ORIGINAL SERVICE MANUAL
The base of this model is MAX685BT. This manual chiefly
publishes the difference point with the base model. Please
refer to the following service manual of the basic model.
Laboratories.
* This product includes technology owned by Microsoft
Corporation and cannot be used or distributed without a
license from MSLGP.
* We cannot supply PWB with component parts in prin-
ciple. When a circuit on PWB has failure, please repair it
by component parts base. Parts which are not mentioned
in service manual are not supplied.
* Specification and design are subject to change without
notice for further improvement.

VX709 -2-
pair, the legal responsibility shall be with the repairing com-
pany.
3. Check for safety after repair.
Check that the screws, parts and wires are put back securely
in their original position after repair. Ensure for safety reasons
there is no possibility of secondary ploblems around the re-
paired spots.
If extended damage is caused due to negligence of repair, the
legal responsibility shall be with the repairing company.
4. Caution in removal and making wiring connection to the parts
for the automobile.
Disconnect the battery terminal after turning the ignition key
off. If wrong wiring connections are made with the battery con-
nected, a short circuit and/or fire may occur. If extensive dam-
age is caused due to negligence of repair, the legal responsi-
bility shall be with the repairing company.
5. Cautions in soldering
Please do not spread liquid flux in soldering.
Please do not wash the soldering point after soldering.
6. Cautions in soldering for chip capacitors
Please solder the chip capacitors after pre-heating for replace-
ment because they are very weak to heat.
Please do not heat the chip capacitors with a soldering iron
directly.
7. Cautions in handling for chip parts.
Do not reuse removed chips even when no abnormality is ob-
served in their appearance. Always replace them with new
ones. (The chip parts include resistors, capacitors, diodes, tran-
sistors, etc).
Please make an operation test after replacement.
8. Cautions in handling flexible PWB
Before working with a soldering iron, make sure that the iron
tip temperature is around 270 . Take care not to apply the
iron tip repeatedly(more than three times)to the same patterns.
Also take care not to apply the tip with force.
9. Turn the unit OFF during disassembly and parts replacement.
Recheck all work before you apply power to the unit.
10.Cautions in checking that the optical pickup lights up.
The laser is focused on the disc reflection surface through the
lens of the optical pickup. When checking that the laser opti-
cal diode lights up, keep your eyes more than 30cms away
from the lens. Prolonged viewing of the laser within 30cms
may damage your eyesight.
11.Cautions in handling the optical pickup
The laser diode of the optical pickup can be damaged by elec-
trostatic charge caused by your clothes and body. Make sure
to avoid electrostatic charges on your clothes or body, or dis-
charge static electricity before handling the optical pickup.
11-1. Laser diode
The laser diode terminals are shorted for transportation in or-
der to prevent electrostatic damage. After replacement, open
the shorted circuit. When removing the pickup from the mecha-
nism, short the terminals by soldering them to prevent this
damage.
11-2. Actuator
The actuator has a powerful magnetic circuit. If a magnetic
material is put close to it. Its characteristics will change. En-
sure that no foreign substances enter through the ventilation
slots in the cover.
11-3. Cleaning the lens
Dust on the optical lens affects performance.
To clean the lens, apply a small amount of isopropyl alcohol to
lens paper and wipe the lens gently.
1
56
7
23
4
7-1 7-2 7-3 7-4
15A FUSE
Top view of
unit
Setplate
COMPONENTS
QZ-6074B-A
1. Main unit ----------- 1
2. Remote control unit RCB-198-600 1
(Battery CR2025 ----------- 1)
3. Extension lead 854-6471-50 1
(15A FUSE 120-0150-00 1)
4. RCA-pin cord 855-5565-50 1
5. Finisher 383-0752-00 1
6. Spacer 347-8242-00 1
7. Parts bag ------------ 1
7-1. Electro tap 060-0018-00 1
7-2. Screw(M5x8) 716-0496-51 8
7-3. Machine screw(M5x8) 714-5008-4B 8
7-4. Rubber part 345-3799-20 12
CAUTION
Use of controls, adjustment, or performance of procedures
other than those specified herein, may result in hazardous
radiation exposure.
The compact disc player should not be adjusted or repaired
by anyone except properly qualified service personnel.

VX709
-3-
EXPLANATION OF IC
IC503 NEC uPD70F3348GJ-UEN-A Main Controller
Terminal Description for QZ-6074B-A
pin 1: A Vref 0 : - :Analog reference voltage.
pin 2: A VSS : - : Analog ground.
pin 3: T S DATA :I/O:BUS-TUNER serial data input/output.
pin 4: T S CK : O : BUS-TUNER serial clock output.
pin 5: A Vref 1 : - :Analog reference voltage.
pin 6: RDS CK :IN: RDS clock pulse input.
pin 7: AV ON : O : On command output to the power supply
section.
pin 8: FLASH MODE :IN: Flash memory mode setting input.
pin 9: VDD : - : Positive voltage supply.
pin 10: REG C : - : Capacitor connection.
pin 11: GND : - : Ground.
pin 12: X in :IN: Crystal connection.
pin 13: X out : O : Crystal connection.
pin 14: RESET :IN: Reset signal input.
pin 15: XT I :IN: Oscillation terminal.
pin 16: XT O : O : Oscillation terminal.
pin 17: SOURCE :IN: Source Key input.
pin 18: BU 9V DET :IN: Backup 9V detection.
pin 19: BU 6V DET :IN: Backup 6V detection.
pin 20: NU :IN: Not in use.
pin 21: CATS DET :IN: Backup voltage detection for CATS.
pin 22: DSP SDA :I/O:Serial data input/output for the digital sig-
nal processor.
pin 23: DSP SCL : O : Clock pulse output to the DSP IC.
pin 24: HSY INH : O : Internal/External synchronisation select.
pin 25: FLASH TX : O : Flash memory Serial data output.
pin 26: FLASH RX :IN: Flash memory Serial data input.
pin 27: ENAB : O : Reset pulse output to the inverter IC.
L=reset.
pin 28: DIMMER : O : PWM output.
pin 29: M PLS :IN: Motor pulse input.
pin 30: NAVI ON : O : The image signal ON command output for
the navigation.
pin 31: BUS + : O : IE-BUS data output.
pin 32: BUS - :IN: IE-BUS data input.
pin 33: GND : - : Ground.
pin 34: VDD : - : Positive voltage supply.
pin 35: USB S DATA :I/O:USB serial data input/output.
pin 36: USB S CK : O : USB serial clock output.
pin 37: Motor 1 F : O : H = Open.
pin 38: Motor 1 R : O : H = Close.
pin 39: Motor 2 F : O : H = Tilt Up.
pin 40: Motor 2 R : O : H = Tilt Down.
pin 41: Motor PWR : O : L = High Speed.
pin 42: OFFSET DET :IN: The emergency signal input from the pow-
er IC.
pin 43: SYS ACC : O : ACC detection signal output.
pin 44: USB RESET : O : USB reset output.
pin 45: USB ACC : O : USB ACC ON signal output.
pin 46: USB REQ :IN: USB request input.
pin 47: Amp Standby : O : Standby signal output to the amplifier.
pin 48: AMP MUTE : O : Muting signal output to the Audio power
amplifier.
pin 49: DT RESET : O : DT IC reset output.
pin 50: ANT REV :IN: DT IC signal input.
pin 51: XM ON : O : XM ON signal output.
pin 52: LINE ACT :IN: DT IC signal output.
pin 53: IRI :IN: The remote control signal input.
pin 54: SUB S DATA :I/O:Sub controller serial data input/output.
pin 55: SUB S CK : O : Clock pulse output to the sub micro com-
puter.
pin 56: INES ON : O : Inner escutcheon illumination ON signal
output.
pin 57: TV MODE : O : TV MODE signal output.
pin 58: OSD RST : O : Reset pulse output for the on screen dis-
play IC.
pin 59: XM RX :IN: XM serial data input.
pin 60: XM TX : O : XM serial data output.
pin 61: DVD TX : O : Serial data output to the DVD mechanism.
pin 62: DVD RX :IN: Serial data input from the DVD mecha-
nism.
pin 63: W REMCOM :IN: Wired remote controller signal input.
pin 64: BLKO : O : Blanking signal output.
pin 65: VID / RGB : O : L = Video, H = RGB.
pin 66: FL ON : O : The fluorescent light of the LCD ON sig-
nal output.
pin 67: BEEP : O : Beep out.
pin 68: OSD RX :IN: Serial data input from on-screen-display
IC.
pin 69: OSD TX : O : Serial data output to on-screen-display IC.
pin 70: OSD SCK : O : Clock pulse output to the on screen dis-
play IC.
pin 71: OSD CE : O : Chip enable output to on-screen-display
IC.
pin 72: SUB RQST :IN: The request signal input from the sub
micro computer.
pin 73: SUB RESET : O : Sub reset output.
pin 74: OPN/CLS KEY :IN: Open / close key input.
pin 75: EJECT SW :IN: Eject switch signal input.
pin 76: DCP DET :IN: DCP detection siganl input.
pin 77: ROM EN : O : ROM enable signal output.
pin 78: OSD DOT 1 : O : OSD DOT 1
pin 79: OSD DOT 2 : O : OSD DOT 2
pin 80: OSD DOT 3 : O : OSD DOT 3
pin 81: Panel ON : O : LCD panel ON signal output.
pin 82: FAN ON : O : The fan on signal output.
pin 83: Freq SEL : O : Frequency select.
pin 84: FROM RY/BY :IN: FROM ready / busy. L = busy.
pin 85: EEP DO : O : Serial data output to EEP-ROM.
pin 86: NU : O : Not in use.
pin 87: EEP SCK : O : Clock pulse output to EEP-ROM.
pin 88: EEP CE : O : EEP-ROM chip enable signal out.
pin 89: EEP DI :IN: Serial data input from EEP-ROM.
pin 90: NU :IN: Not in use.
pin 91: KS in 0 :IN: Key scan input.
pin 92: KS in 1 :IN: Key scan input.
pin 93: KS in 2 :IN: Key scan input.
pin 94: NU :IN: Not in use.
pin 95: KS out 0 : O : Key scan output.
pin 96: KS out 1 : O : Key scan output.
pin 97: KS out 2 : O : Key scan output.
pin 98: NU : O : Not in use.
pin 99: USA/3rd :IN: L = 3rd area, H = North America.
pin100: NTSC/PAL :IN: NTSC/PAL select signal input.
pin101: XM OC :IN: XM over current signal input.
pin102: NU :IN: Not in use.
pin103: B VSS : - : Ground for the bus interface section.
pin104: B VDD : - : Positive voltage supply for the bus inter-
face section.
pin105: ILL DET :IN: Illumination ON signal input.
pin106: BUS ILL : O : Illumination-ON signal output for the Ce-
NET.
pin107: ILL ON : O : The illumination ON signal output.
pin108: Blink LED : O : LED Blinking signal output.
pin109: D IND : O : H = Disk indicator ON.
pin110: NU :IN: Not in use.
pin111: NU :IN: Not in use.
pin112: DSP RST : O : Reset pulse output to the DSP IC.
pin113: DSP INIT :IN: Initial finished signal input from the Radio-
Audio-DSP.
pin114: NU :IN: Not in use.
pin115: NU :IN: Not in use.
pin116: AM/FM 8V ON : O : AM/FM 8V ON signal output.

VX709 -4-
pin117: RDS DATA :IN: RDS serial data input.
pin118: AM/FM 5V ON : O : AM/FM 5V ON signal output.
pin119: NU : - : Not in use.
pin120: NU :IN: Not in use.
pin121: DAC RESET : O : Reset pulse output to the DAC.
pin122: TEST MODE : O : Test point.
pin123: OP/CL :IN: H inputting separate the internal ADC from
the internal DSP.
pin124: NU :IN: Not in use.
pin125: NU :IN: Not in use.
pin126: PHOTO IN :IN: Photo sensor signal input.
pin127: SYS MUTE : O : System muting signal output.
pin128: SUB MUTE : O : Sub-zone audio mute signal output.
pin129: TILT VR :IN: Input-terminal of internal ADC to read the
value of tilt-volume.
pin130: FAN TEMP :IN: Input of the internal ADC to detect the
temperature.
pin131:DVD ON 1 : O : DVD 3.3V power supply ON signal output.
pin132:DVD ON 2 : O : DVD 5V power supply ON signal output.
pin133:DVD ON 3 : O : DVD 8V power supply ON signal output.
pin134: DVD RST : O : Reset signal output to the DVD mecha-
nism.
pin135: C SN : O : Inage secretor control signal output.
pin136: C CK : O : Inage secretor serial clock output.
pin137: C DTI : O : Inage secretor serial data output.
pin138: VIDEO RST : O : Video reset signal output.
pin139: BACK GEAR :IN: The back gear signal input. H = back.
pin140: PKB :IN: Parking brake signal input.
pin141: AMP REM DET :IN: Remote controller wire short detection.
pin142: AMP REM : O : ON signal output to the amplifier.
pin143: AUTO ANT : O : Auto antenna control signal output.
pin144: ACC IN :IN: ACC ON flag input.
052-3409-20 Toshiba TMP92CD28AFG-7D07 Controller
Terminal Description
pin 1: RESET :IN: Reset signal input.
pin 2: BU DET :IN: Backup detection signal input.
pin 3: ACC DET :IN: ACC detection signal input.
pin 4: NU : - : Not in use.
pin 5: ST REQ :IN: Request signal input.
pin 6: D VDD : - : Positive voltage supply for the digital sec-
tion.
pin 7: XT 1 :IN: 3.14MHz crystal connection. (sub-clock)
pin 8: XT 2 : O : 3.14MHz crystal connection. (sub-clock)
pin 9: PW E : O : External power supply control output.
pin 10: D VSS : - : Digital ground.
pin 11: D VDD : - : Positive voltage supply for the digital sec-
tion.
pin 12: 1.5V : O : 1.5V regulator output.
pin 13: VDD : - : Positive voltage supply.
pin 14: VDD : - : Positive voltage supply.
pin 15: 1.5V : O : 1.5V regulator output.
pin 16: D VDD : - : Positive voltage supply for the digital sec-
tion.
pin 17: D VSS : - : Digital ground.
pin 18: NU : - : Not in use.
pin 19: NU : - : Not in use.
pin 20: NU : - : Not in use.
pin 21: NU : - : Not in use.
pin 22: NU : - : Not in use.
pin 23: NU : - : Not in use.
pin 24: NU : - : Not in use.
pin 25: NU : - : Not in use.
pin 26: D VSS : - : Digital ground.
pin 27: D VDD : - : Positive voltage supply for the digital sec-
tion.
pin 28: REQ O : O : Request signal output.
pin 29: NU : - : Not in use.
pin 30: NU : - : Not in use.
pin 31: NU : - : Not in use.
pin 32: NU : - : Not in use.
pin 33: P ON 2 : O : Power ON signal output.
pin 34: NU : - : Not in use.
pin 35: NU : - : Not in use.
pin 36: IC Ready In :IN: Authentication system ready input.
pin 37: IC Reset Out : O : Authentication system reset output.
pin 38: NU : - : Not in use.
pin 39: NU : - : Not in use.
pin 40: NU : - : Not in use.
pin 41: NU : - : Not in use.
pin 42: NU : - : Not in use.
pin 43: NU : - : Not in use.
pin 44: D VSS : - : Digital ground.
pin 45: D VDD : - : Positive voltage supply for the digital sec-
tion.
pin 46: NU : - : Not in use.
pin 47: NU : - : Not in use.
pin 48: NU : - : Not in use.
pin 49: NU : - : Not in use.
pin 50: NU : - : Not in use.
pin 51: NU : - : Not in use.
pin 52: NU : - : Not in use.
pin 53: NU : - : Not in use.
pin 54: NU : - : Not in use.
pin 55: NU : - : Not in use.
pin 56: NU : - : Not in use.
pin 57: NU : - : Not in use.
pin 58: DSP ACK :IN: DSP acknowledge.
pin 59: DSP LP : O : DSP latch pulse output.
pin 60: DSP CS : O : Chip select signal output to the DSP.
pin 61: DSP RESET : O : DSP reset pulse output.
pin 62: D VSS : - : Digital ground.
pin 63: D VDD : - : Positive voltage supply for the digital sec-
tion.
pin 64: NU : - : Not in use.
pin 65: P ON 3 : O : Power ON signal output.
pin 66: HSSW :IN: Mode set.
pin 67: HSSW 2 :IN: Mode set.
pin 68: SRAM STNDO : O : SRAM standby output.
pin 69: BOOT :IN: Flash Memory Write mode selection.
pin 70: NU : - : Not in use.
pin 71: LR CK : O : LR clock output.
pin 72: AM 1 :IN: Function Mode.
pin 73: X 2 : - : Main clock.
pin 74: D VSS : - : Digital ground.
pin 75: X 1 : - : Main clock.
pin 76: D VDD : - : Positive voltage supply for the digital sec-
tion.
pin 77: USB OC :IN: USB over current.
pin 78: USB P ON : O : USB opwer on.
pin 79: USB D+ : - : USB positive line.
pin 80: USB D- : - : USB negative line.
pin 81: AM 0 :IN: Function Mode.
pin 82: DSP REQ :IN: DSP request input.
pin 83: D VSS : - : Digital ground.
pin 84: IC Data Out : O : Authentication system data output.
pin 85: IC Data In :IN: Authentication system data input.
pin 86: IC CK : O : Authentication system clock output.
pin 87: DSP TX : O : Serial data output to the DSP.
pin 88: DSP RX :IN: DSP serial data input.
pin 89: DSP CK : O : Serial clock output to the digital signal
processor.
pin 90: I2C SDA :I/O:I2C serial data input/output.
pin 91: I2C CK :IN: I2C serial clock input.
pin 92: AUDIO CK : O : Audio data bit clock output.

VX709
-5-
pin 93: AUDIO DO : O : Audio data output.
pin 94: GATE : O : Gate signal input.
pin 95: D VDD : - : Positive voltage supply for the digital sec-
tion.
pin 96: NU : - : Not in use.
pin 97: NU : - : Not in use.
pin 98: NU : - : Not in use.
pin 99: NU : - : Not in use.
pin100: D VSS : - : Digital ground.
052-7079-40 Toshiba TC58FVM5B3AFTG65
CMOS Flash Memory
Terminal Description
pin 1: A 15 :IN: Address signal input.
pin 2: A 14 :IN: Address signal input.
pin 3: A 13 :IN: Address signal input.
pin 4: A 12 :IN: Address signal input.
pin 5: A 11 :IN: Address signal input.
pin 6: A 10 :IN: Address signal input.
pin 7: A 9 :IN: Address signal input.
pin 8: A 8 :IN: Address signal input.
pin 9: A 19 :IN: Address signal input.
pin 10: A 20 :IN: Address signal input.
pin 11: WE :IN: Write enable signal input.
pin 12: RESET :IN: Reset signal input.
pin 13: NU : - : Not in use.
pin 14: WP/ACC :IN: The write protection signal input / The
acceleration signal input.
pin 15: RY/BY : O : The ready/busy signal output.
pin 16: A 18 :IN: Address signal input.
pin 17: A 17 :IN: Address signal input.
pin 18: A 7 :IN: Address signal input.
pin 19: A 6 :IN: Address signal input.
pin 20: A 5 :IN: Address signal input.
pin 21: A 4 :IN: Address signal input.
pin 22: A 3 :IN: Address signal input.
pin 23: A 2 :IN: Address signal input.
pin 24: A 1 :IN: Address signal input.
pin 25: A 0 :IN: Address signal input.
pin 26: CE :IN: Chip enable signal input.
pin 27: VSS : - : Negative supply voltage.
pin 28: OE :IN: Output enable signal input.
pin 29: D 0 :I/O:Data input/output.
pin 30: D 8 :I/O:Data input/output.
pin 31: D 1 :I/O:Data input/output.
pin 32: D 9 :I/O:Data input/output.
pin 33: D 2 :I/O:Data input/output.
pin 34: D 10 :I/O:Data input/output.
pin 35: D 3 :I/O:Data input/output.
pin 36: D 11 :I/O:Data input/output.
pin 37: VDD : - : Positive supply voltage.
pin 38: D 4 :I/O:Data input/output.
pin 39: D 12 :I/O:Data input/output.
pin 40: D 5 :I/O:Data input/output.
pin 41: D 13 :I/O:Data input/output.
pin 42: D 6 :I/O:Data input/output.
pin 43: D 14 :I/O:Data input/output.
pin 44: D 7 :I/O:Data input/output.
pin 45: D 15/A-1 :I/O:Data input/output. A-1 address input.
pin 46: VSS : - : Negative supply voltage.
pin 47: BYTE/WORD :IN: Byte / Word selection.
pin 48: A 16 :IN: Address signal input.
REF No. PART No. DESCRIPTION
REF No. PART No. DESCRIPTION
REF No. PART No. DESCRIPTION
ELECTRICAL PARTS LIST
The following parts are different from MAX685BT. The other
parts are the same as MAX685BT.
Main PWB(B2) section
(Please refer to page 30 of service manual for MAX685BT.)
IC402 052-7079-40 TC58FVM5B3ATG65
IC408 051-5331-90 MM1228XFBE
IC503 ----------- uPD70F3348GJ-
UEN-A
(032500-052)
R443 119-1211-15 1/10W 120 ohm
LCD PWB(B3) section
(Please refer to page 32 of service manual for MAX685BT.)
IC901 060-8086-91 UGZZ5-618B(B/T
module)
R875 032-0140-81 1/10W 3.9k ohm F
R876 119-5611-15 1/10W 560 ohm
R878 119-4731-15 1/10W 47k ohm
R887 119-2231-15 1/10W 22k ohm
USB PWB(B6) section
(Please refer to page 36 of service manual for MAX685BT.)
IC2 052-3409-20 TMP92CD28AFG-
7D07

VX709 -6-
45
44
43
38
40
49
47
6
6
36
35
37 42
41
40
39
37
12
18
18
48
20
22
20
19
17
17
6
6
18
26
25
30 32 27 28
24
23
8
4
429
420
30
17
17
34
31
33
6
6
18
1
2
3
32
9
8
10
11
12
4
4
10
13
12
14
16
6
621
4
63
6
64
58
50
59
52
55
56 57
51
8
30
18
18
54
53
46
15
60
6
6
6
7
5
4
61
62
Rear cover of escutcheon
EXPLODED VIEW / PARTS LIST
Main section

VX709
-7-
NO. PART NO. DESCRIPTION Q'TYNO. PART NO. DESCRIPTION Q'TY
1 932-0121-80 SLIDE MECH 1
2 716-3577-00 DECORAT. SCREW 2
3 335-7903-00 BUSH 2
4 716-0878-50 SCREW(M2.6X5) 11
5 039-3224-00 FPC 1
6 714-2604-8B MACHINE SCREW (M2.6x4) 24
7 309-0853-00 FRONT PLATE 1
8 074-3014-82 SOCKET (32P) 3
9 074-3014-76 SOCKET (26P) 1
10 013-6312-50 SWITCH 2
11 001-7064-92 DIODE 1
12 --------------- JOINT PWB 1
13 001-7038-92 DIODE 1
14 074-3013-58 SOCKET (8P) 1
15 880-2091D TUENR PACK 1
16 331-4503-00 PWB HOLDER 1
17 780-2604-51 SCREW(M2.6x4)(LOCK) 4
18 714-2606-8H MACHINE SCREW(M2.6x6) 13
19 312-0493-00 SIDE CHASSIS-R 1
20 076-3011-82 PLUG 3
21 347-8599-00 NSULATOR 2
22 780-2604-50 IT SCREW(M2.6x4) 2
23 --------------- MAIN PWB 1
24 074-1231-08 SOCKET (8P MIN) 1
25 101-1018-30 TRANSISTOR 1
26 102-3420-50 TRANSISTOR 1
27 074-4030-00 SOCKET (18P) 1
28 051-2060-00 IC 1
29 076-3006-58 PLUG 1
30 714-2610-8B MACHINE SCREW(M2.6x10) 5
31 313-2032-00 HEAT SINK-C 1
32 074-1194-00 SOCKET (13P Ce-NET) 1
33 331-4504-00 IC HOLDER 1
34 312-0492-00 SIDE CHASSIS-L 1
35 -------------- USB PWB 1
36 816-3028-50 FLAT WIRE 1
37 335-0833-01 LEAD HOLDER 2
38 855-0645-50 EXTENSION LEAD 1
39 331-4501-00 CONNECT HOLD-M 1
40 714-3004-8B MACHINE SCREW(M3x4) 2
41 020-3053-00 DC-MOTOR 1
42 780-2614-50 SCREW(M2.6x14)(LOCK) 2
43 855-0613-52 USB CABLE 1
44 855-5436-51 RCA PIN CORD 1
45 345-3799-20 RUBBER PART 1
46 347-8527-00 SHADE 1
47 312-0494-00 LOWER CHASSIS 1
48 347-8504-00 INSHLATOR 1
49 331-4502-00 CONNECT HOLD-T 1
50 313-2031-00 HEAT SINK 1
51 076-0714-20 PLUG 1
52 076-3011-76 PLUG 1
53 347-8507-00 E SHEET 1
54 345-8504-00 CUSHION 1
55 092-4000-51 ANT-RECEPT 1
56 --------------- TUNER PWB 1
57 075-0339-00 JACK 2
58 039-3223-00 FPC (MECH) 1
59 929-2150-80 DVD-MECH-MODULE 1
60 276-0605-00 SETPLATE 1
61 716-1851-00 SCREW(M2x2)(LOCK) 2
62 039-3276-00 PWB 1
63 310-1831-01 UPPER CASE 1
64 312-0495-00 UPPER CHASSIS 1
NOTE
*No.17, No.42 and No.61 are the screw of lock type. Please do not reuse.
*When internal parts of DVD mechanism module(No. 59) are exchanged, it is necessary to do inspection and adjustment with
special equipment. Please do not exchange internal parts of DVD mechanism module(No. 59) without the special equipment.

VX709 -8-
61
61
60
39
43
40
41
41
42
46
44 45
50
49 48
47 51
47
47
63
52 53
54
55 2
56
57
58
56
59
5758
2
23 22
16
17
21 20
19 18
15
37
38
31
29
28 27
26
27 26
62
34
33
32
35
30
25
30
24 29
29
31 27
26
26
27
26
27
26
29
29 29
36
10
11
14 13 12
8
9
2
2
1
2
2
4
5
76
3
32
2
NO. PART NO. DESCRIPTION Q'TYNO. PART NO. DESCRIPTION Q'TY
Escutcheon section
1 370-6315-04 ESCUTCHEON 1
2 780-2003-03 SCREW(M2x3)(LOCK) 12
3 347-8501-00 SHADE 4
4 382-8553-01 BUTTON (- / +) 1
5 382-8552-01 BUTTON (<< / >>) 1
6 347-8477-00 DOUBLE FACE 1
7 378-0556-01 BADGE 1
8 347-8478-00 COVER FILM 1
9 347-8500-00 SPACER 1
10 335-8196-00 ILLUMI PLATE 1
11 382-8554-01 BUTTON (SRC) 1
12 347-8502-00 SHADE 2
13 382-8555-01 BUTTON(MENU) 1
14 335-8197-00 ILLUMI PLATE 1
15 335-8195-00 IR-FILTER 1
16 382-8550-02 BUTTON (M) 1
17 382-8551-02 BUTTON (TEL) 1
18 345-6222-00 CUSHION 1
19 382-8549-02 BUTTON (ISR) 1
20 382-8548-01 BUTTON (OPEN/CLOSE) 1
21 335-8200-00 ILLUMI PART 1
22 345-6129-00 RUBBER SHEET 2
23 081-0041-00 MICROPHONE 1
24 345-6130-00 RUBBER SHEET 2
25 039-3226-00 FPC 1
26 013-6312-50 SWITCH 10
27 001-7097-90 DIODE 10
28 060-4017-90 IR-RECIEVER 1
29 778-2004-01 PAD SCREW (M2x6) 9
30 001-7098-90 DIODE 2
31 074-2236-65 SOCKET (15P) 2
32 716-1468-01 SCREW (M2x2.5) 2
33 060-8084-00 BLUETOOTH ANT 1
34 331-4498-00 ANT-HOLDER 1
35 347-8475-00 FILM 1
36 001-7103-90 DIODE 1
37 347-8476-00 FILM 1
38 039-3225-00 FPC 1
39 013-9718-00 TOUCH PANEL SWITCH 1
40 347-8474-00 SPACER 2
41 347-8473-00 SPACER 2
42 347-8511-00 SPACER 1
43 379-0474-00 INDICATOR (LCD) 1
44 347-8498-00 DOUBLE FACE 2
45 347-8499-00 COVER FILM 1
46 331-4497-00 LCD HOLER 1
47 073-0762-90 TERMINAL 4
48 076-0529-02 PLUG 1
49 781-2002-50 SCREW(M2x2) 1
50 331-4532-00 EARTH PLATE 1
51 331-4499-00 SHIELD CASE 1
52 074-2233-60 SOCKET (60P) 1
53 074-2225-66 SOCKET (16P) 2
54 074-2219-54 SOCKET (4P) 1
55 074-2226-80 SOCKET (30P) 1
56 716-1611-50 SCREW(M2.6x4) 4
57 335-7074-00 ROLLER 2
58 750-6746-10 ROLLER SPRING 2
59 331-4500-00 REAR-CVR 1
60 940-8228-02 INNER-ES ASSY 1
61 780-2604-52 SCREW(M2.6x4)(LOCK) 4
62 --------------- SWITCH PWB 1
63 --------------- LCD PWB 1
NOTE
*No.2 and No.61 are the screw of lock type. Please do not reuse.
