Clarke CSG1C Instruction Manual

OPERATION & MAINTENANCE
INSTRUCTIONS
GC10/17 ISS2
ORIGINAL INSTRUCTIONS
AIR STAPLER
MODEL NO: CSG1C
PART NO: 3110375

2
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
INTRODUCTION
Thank you for purchasing this CLARKE product.
Before attempting to use this product, please read this manual thoroughly and
follow the instructions carefully. In doing so you will ensure the safety of yourself
and that of others around you, and you can look forward to your purchase
giving you long and satisfactory service.
The Clarke CSG1-C is ideal for packaging, carpet laying, upholstery etc.

3
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
SPECIFICATION
Please note that the details and specifications contained herein are correct at
the time of going to print. However CLARKE International reserve the right to
change specifications at any time without prior notice.
GUARANTEE
This product is guaranteed against faulty manufacture for a period of 12
months from the date of purchase. Please keep your receipt which will be
required as proof of purchase.
This guarantee is invalid if the product is found to have been abused or
tampered with in any way, or not used for the purpose for which it was
intended.
Faulty goods should be returned to their place of purchase, no product can
be returned to us without prior permission.
This guarantee does not effect your statutory rights.
Model Numbers CSG1-C
Staple Sizes 22 gauge/ 4-16mm (9mm crown)
Magazine Capacity 180
Drive Speed 120 shots/min
Min. Hose Size (ID) 6 mm (1/4”)
Operating Pressure 4.1 - 6.9 bar (60-100psi)
Air Consumption 0.27 cfm
Air Inlet Size 10mm Quick Fit
Dimensions (L x W x H) 219 x 46 x 146 mm
Sound Power Level (LwA dB) 91 dB(A)-1pW (K factor 2.5dB(A)
Vibration Levels Less than 2.5 m/s2
Weight 0.85 kg

4
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
SAFETY WARNINGS
WORK AREA SAFETY
1. Keep work area clean and well lit. Cluttered or dark areas invite accidents.
2. Do not operate power tools in explosive atmospheres, such as in the
presence of flammable liquids, gases or dust. Power tools create sparks
which may ignite the dust or fumes.
3. Keep children and bystanders away while operating a power tool.
Distractions can cause you to lose control.
PERSONAL SAFETY
1. Stay alert, watch what you are doing and use common sense when
operating a power tool. Do not use a power tool while you are tired or
under the influence of drugs, alcohol or medication. A moment of
inattention while operating power tools may result in serious personal injury.
2. Use personal protective equipment. Always wear eye protection.
Protective equipment such as dust mask, non-skid safety shoes, hard hat,
or hearing protection used for appropriate conditions will reduce personal
injuries.
3. Do not overreach. Keep proper footing and balance at all times. This
enables better control of the power tool in unexpected situations.
4. Dress properly. Do not wear loose clothing or jewellery. Keep your hair,
clothing and gloves away from moving parts. Loose clothes, jewellery or
long hair can be caught in moving parts.
POWER TOOL USE AND CARE
1. Do not force the power tool. Use the correct power tool for your
application. The correct power tool will do the job better and safer at the
rate for which it was designed.
2. Do not use the power tool if the switch does not turn it on and off. Any
power tool that cannot be controlled with the switch is dangerous and
must be repaired.
3. Store idle power tools out of the reach of children and do not allow persons
unfamiliar with the power tool or these instructions to operate the power
tool. Power tools are dangerous in the hands of untrained users.
WARNING: READ ALL SAFETY WARNINGS AND ALL INSTRUCTIONS.
FAILURE TO FOLLOW THE WARNINGS AND INSTRUCTIONS MAY RESULT IN
SERIOUS INJURY.
WARNING: SAVE THIS DOCUMENT FOR FUTURE REFERENCE.

5
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
4. Maintain power tools. Check for misalignment or binding of moving parts,
breakage of parts and any other condition that may affect the power tool's
operation. If damaged, have the power tool repaired before use. Many
accidents are caused by poorly maintained power tools.
5. Use the power tool, accessories and tool bits etc. in accordance with these
instructions, taking into account the working conditions and the work to be
performed. Use of the power tool for operations different from those
intended could result in a hazardous situation.
6. Have your power tool serviced by a qualified repair person using only
identical replacement parts. This will ensure that the safety of the power
tool is maintained
STAPLER SPECIFIC SAFETY WARNINGS
1. Always assume that the machine contains staples. Careless handling of the
stapler can result in unexpected firing of nails and personal injury.
2. Do not point the stapler towards yourself or anyone nearby. Unexpected
triggering will discharge the staples causing an injury.
3. Do not actuate the stapler unless it is placed firmly against the workpiece.
If the tool is not in contact with the workpiece, the fastener may be
deflected away from your target.
4. Disconnect the tool from the airline when the staples jam in the tool. While
removing a jammed staple, the stapler may be accidentally activated if it
is connected.
5. Do not use this stapler for fastening electrical cables. It is not designed for
electric cable installation and may damage the insulation of electric
cables thereby causing electric shock or fire hazards.
6. Never drive in staples at the edge of a work surface, as the edge could fail
and fly off, endangering yourself or others in the vicinity.
7. Never fire tool at an angle. it must be perpendicular to the work surface
TRANSPORTATION
1. Never carry the tool by the air supply hose.
2. Never carry the tool with your finger on the trigger.
STORAGE
1. When not in use the tool must be disconnected from the air supply and
stored in a dry place out of the reach of children.
2. Avoid storing the tool in environments where the temperature is below 0o

6
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
THE COMPRESSED AIR SUPPLY
AIR SUPPLY REQUIREMENTS
• Use only clean, dry, regulated compressed air as a power source.
• Air compressors used with the impact wrench must comply with the
appropriate European Community Safety Directives.
• A build-up of moisture or oil in the air compressor will accelerate
wear and corrosion in the impact wrench. ensure any moisture is
drained from the compressor daily and the inlet filter is kept clean.
• Line pressure, or hose ID., should be increased to compensate for
unusually long air hoses (over 10M). Minimum hose dia. should be
6mm (1/4”) ID., and fittings should have the same inside dimensions.
• The air hose must be rated at least 150% of the maximum operating
pressure of the tool.
• A typical air line layout is shown above. If an automatic in-line filter/
regulator is used, it will keep the tool in good condition, but should
be regularly checked and topped up with oil. SAE 10 oil should be
used, and the lubricator adjusted to approx 2 drops per minute.
WARNING: COMPRESSED AIR CAN BE DANGEROUS. ENSURE THAT YOU
ARE FAMILIAR WITH ALL PRECAUTIONS RELATING TO THE USE OF
COMPRESSORS AND COMPRESSED AIR SUPPLIES.

7
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
• The minimum hose diameter should be 5/16”(8mm) ID and fittings
should have the same internal dimensions.
• Never exceed the maximum operating pressure for the tool. It is
recommended that air pressure to this tool does not exceed 90 psi
at the tool when running. Higher pressures and unclean air will
shorten the life of the tool due to faster wear and is a possible safety
hazard.
• Tools of this type operate on a wide range of air pressures. It is
recommended that air pressure be set to between 60 and 100psi. at
the tool when running.
• The air inlet used for connecting air supply, is a 10mm Quick Fit type.
• If required, connect an in-line mini oiler to the tool. A mini oiler helps
to prolong the life of the air tool.
• If a mini-oiler is not being used, run a few drops of oil through the tool
before use. It can be entered through the air inlet.
• Connect a suitable hose to the female air inlet.
• Connect the other end of the hose to the air supply.
• Turn on the air supply and check for air leaks. Rectify any found
before proceeding.
Your air tool is now ready for use.
You can fit a whip hose with a quick fit coupling if required (available from
your Clarke dealer.).

8
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
ASSEMBLY
Ensure the stapler is not loaded, then,
with the air supply turned off,
connect the air line to the stapler at
the quick fit coupling.
Turn the safety catch to the position
shown, to prevent the trigger from
being pulled.
Then with the tool pointed away from
you and anyone in the vicinity,
depress the magazine catch, pull out
the magazine and load with
appropriate staples,
Push the magazine back until it locks
in position,
Your stapler is now ready for use.
OPERATION
Turn on the air supply, and check for air leaks. If any are apparent, rectify
before proceeding. Ensure the operating pressure is set to between 4.1-6.9bar
(55-95 psi), depending upon the size of nail used and type of material being
worked. The harder the material, and bigger the nail, the higher the pressure.
Hold the tool so that it is at right angles to the work. Lower it so that the Safety
Element touches the work surface and is forced upwards. This movement
releases the trigger, which may now be pulled, driving the staple.
CLEARING A JAM
Should the stapler jam, turn OFF the air supply and set the safety catch to
prevent the trigger from being pulled before opening the magazine to free
the jammed staple.

9
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
DISCONNECTING THE AIR SUPPLY
Do not disconnect the air supply hose until the air supply has been shut down
and the compressed air released.
1. Refer to the compressor instruction manual for the procedure to shut down
and release the compressed air.
2. Once the pressure has been released, disconnect the air supply hose from
the air tool.
MAINTENANCE
DAILY
1. Before use, drain water from the compressed air supply.
2. Check and clean, if fitted, the air inlet gauze filter.
3. A bottle of CLARKE Air Line Oil** is supplied with the kit. Squirt a few drops of
oil approx. 3cc), into the air inlet.
4. This should be carried out regardless of whether or not an air line lubricator
is used.
5. Use a clean dry cloth or brush to keep the stapler/nailer clean and free of
dirt. Do not use solvent or alcohol based cleaners as they could damage
the casing.
6. The use of parts other than CLARKE replacement parts may result in safely
hazards, decreased tool performance and will invalidate your warranty.
DURING USE
For lubricating the internal components when in operation, an air line
lubricator should be used, with Clarke Air Line Oil**, adjusted to 2 drops per
minute.
If an air line lubricator is NOT used, this procedure should be repeated after
every two to three hours of use.
STORAGE
If the stapler is to be stored, or is idle for longer than 24 hours, run a few drops
of Clarke Air Line Oil** into the air inlet before storing.
WARNING: MAKE SURE THAT THE STAPLER IS DISCONNECTED FROM THE
AIR SUPPLY BEFORE STARTING ANY CLEANING OR MAINTENANCE
PROCEDURES.

10
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
Pour a few drops of CLARKE airline oil, into the air inlet. This should be carried
out regardless of whether or not an in-line mini oiler is used. If an in-line mini
oiler is not used, this procedure should be repeated after every two to three
hours of constant use.
PERFORMANCE
Please note that factors other than the tool may effect its operation and
efficiency such as reduced compressor output, excessive drain on the airline
moisture or restrictions in the air-line, or the use of connectors of improper size
or poor condition which will reduce air supply.
Grit or gum deposits inside the tool may also reduce its efficiency. This
condition can be corrected by cleaning out the air strainer and flushing out
the tool with gum solvent or oil, or failing this the motor may require
dismantling.
**Clarke Air Line Oil (part no. 3050825) is available from your CLARKE dealer.
SERVICE AND REPAIRS
If the tool runs erratically or becomes inefficient although the air supply is in
good order, it may be necessary to dismantle the tool. Such servicing and
repair work should be carried out by qualified service technicians.
STORAGE
If the tool is to be stored, or is idle for longer than 24 hours, run a few drops of
Clarke air line oil into the air inlet, and run the tool for 5 seconds in order to
lubricate the internal parts.
When not in use, disconnect from air supply, clean tool and store in a safe, dry
place.
ACCESSORIES
A wide range of accessories is available including filter/regulators, lubricators,
high-pressure hoses (5 to 50 metres) etc. Contact your CLARKE dealer for
further information or CLARKE International Service Department on 01992
565333.

11
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
CONSUMABLES
Staples - 9mm Crown - Type 71
Length Part No:
8mm 1800400
10mm 1800402
12mm 1800403

12
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
DECLARATION OF CONFORMITY

13
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
PARTS DIAGRAM

14
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
PARTS LIST
When requesting spare parts, please quote reference HTCSG1C01 onwards.
No Description No Description
1 Bolt M5 x 50 27 Trigger
2 Exhaust Deflector 28 Circlip 2.5 dia
3 Compression Spring 29 Bolt M5 x 20
4 Rectangular Washer 30 Spring Washer 5
5 Cylinder Cover 31 Nose Guide
6 O-Ring 11.7 x 2.1 32 Spacer
7 O-Ring 16.2 x 2.1 33 Fixed Magazine
8 Piston 34 Stop Plate
9 Collar 35 Bolt M4 x 6
10 O-Ring 2.65 x 30.2 36 Spring Washer 4
11 Cylinder 37 Pusher
12 O-Ring 2.65 x 18 38 Pusher Spring
13 Main Piston 39 Magazine Catch
14 Shock Absorber 40 Stepped Pin
15 Sealing Washer 41 Pin M2 x 10
16 Gun Body 42 Bolt M4 x 12
17 Washer 43 Movable Magazine
18 Rectangular Washer 44 Pusher
19 Trigger Valve Seat 45 Pulley
20 Trigger Valve Stem 46 Pusher Spring
21 O-Ring 1.7 x 2 47 Spring
22 Trigger Valve Guide 48 Nut M5
23 O-Ring 11.2 x 2 49 Rubber Handle
24 Safety Latch 50 O-Ring 35.5 x 2.3
25 Compression Spring 51 End cap
26 Stepped Pin 52 Quick Release Coupling

15
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
NOTES
__________________________________________________________________________
__________________________________________________________________________
__________________________________________________________________________
__________________________________________________________________________
__________________________________________________________________________
__________________________________________________________________________
__________________________________________________________________________
__________________________________________________________________________
__________________________________________________________________________
__________________________________________________________________________
__________________________________________________________________________
__________________________________________________________________________
__________________________________________________________________________
__________________________________________________________________________
