Clarke STRONG-ARM CSA10BB Instruction Manual

WARNING: Read these instructions before using the machine
OPERATION & MAINTENANCE
INSTRUCTIONS
GC0913
10 TONNE HYDRAULIC BENCH PRESS
MODEL NO: CSA10BB
PART NO: 7614020

2
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or Servi[email protected]
INTRODUCTION
Thank you for purchasing this CLARKE 10 Tonne Hydraulic Bench Press.
Before attempting to operate the machine, it is essential that you read this
manual thoroughly and carefully follow all instructions given. In doing so you
will ensure the safety of yourself and that of others around you, and you can
also look forward to the press giving you long and satisfactory service.
GUARANTEE
This CLARKE product is guaranteed against faulty manufacture for a period of
12 months from the date of purchase. Please keep your receipt as proof of
purchase.
This guarantee is invalid if the product is found to have been abused or
tampered with in any way, or not used for the purpose for which it was
intended.
Faulty goods should be returned to their place of purchase, no product can
be returned to us without prior permission.
This guarantee does not effect your statutory rights.
SAFETY PRECAUTIONS
• During assembly or if the press is moved, always call for the help of an
assistant, do not manhandle single-handedly.
• Always bolt the press down to a suitably strong bench.
• Ensure the press is located on a strong bench with adequate light.
• Before applying a load, ensure all press bed support pins are fully engaged.
• Ensure that hydraulic hoses and couplings are completely sound.
• Before use, always ensure the workpiece is firmly secure and stable.
• Always clean spills of hydraulic oil immediately as this can be dangerous in a
workshop environment.
• Do not exceed the rated capacity of the press.
• Do not allow any person who is inexperienced in the use of hydraulic presses,
to use the press unless they are under direct supervision.
• Do not allow anyone to work directly in front of the press when it is in use.

3
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
• Never tamper with the press. The safety valve is calibrated and sealed at the
factory; do not attempt to change the setting.
• Use only the recommended hydraulic oil.
• Components of this press are specially designed to withstand the rated
capacity. Do not substitute bolts, pins, or any other components.
• Always apply the load under the centre of the ram. Offset loads can
damage the ram or ram mount and may cause the work piece to eject.
• Before operating, check for signs of cracked welds, bent bed pins, loose or
missing bolts, or any other structural damage. Do not operate if any of these
conditions exist. Have repairs made only by authorised service centre.
• Remove load from press bed before attempting to adjust bed height.
• Press only on a work piece supported by the press bed.
• When using accessories such as arbor plates, be certain they are centered
below the ram and are in full contact with the bed.
• Parts being pressed may splinter, shatter, or be ejected from the press. Due to
varied applications, it is your responsibility to always use adequate guards,
wear eye protection and protective clothing when operating this press.
• Keep hands and fingers away from parts that may pinch and shift.
• Failure to heed these warnings may result in damage to the equipment, or
failure resulting in property damage, personal, or even fatal injury.
• DO NOT use extension tubes on the pump handle. Excessive effort can cause
damage and/or accidents.
UNPACKING
Ensure the press and its components suffered no damage during transit and
that all components are present. Should any loss or damage become
apparent, please contact your CLARKE dealer immediately.
TOOLS REQUIRED
• Spanners to suit M6, M8 and M10 nuts/bolts, or an adjustable wrench.
• PTFEtape
ACCESSORIES
A mandrel set (including storage bracket and pressure plate) is not supplied
with the press but is available from your dealer as Clarke part no 7615060.

4
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or Servi[email protected]
INVENTORY
ASSEMBLY
IMPORTANT: Due to the weight of the press components, we recommend
that you get assistance during installation.
IMPORTANT: We strongly recommend that the press be firmly secured to a
firm and level bench using suitable bolts (not supplied).
IMPORTANT: Do not locate your press where it will be open to the elements,
Severe weather conditions will damage the hydraulic components.
1. Attach the feet to the frame,
using the nuts, bolts and washers.
2. With the help of an assistant, lift
the frame assembly upright and
manoeuvre it to its intended
location on the workbench.
3. Insert the ram through the hole in
the base plate and secure in
position using the locking collar.
1 x Frame 1 x Pump
2 x Base Supports 1 x Pump Handle
1 x Ram with Locking Collar 1 x Hose (attached to pump)
1 x Pressure Gauge 1 x Press Bed (Frame)
2 x Bed Support Pins 2 x Bed blocks (V-blocks)
1 x Fixing Kit containing bolts, washers & nuts

5
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
4. Unfasten the protective end cap
and screw the hose to the
threaded connection of the
hydraulic ram.
• We recommend sealing the thread
with PTFE tape. Take care not to let
any oil escape while connecting
the hose.
5. Screw the pressure gauge to the
connecting nut on top of the ram
cylinder.
• Seal the thread with PTFE tape,
ensuring it is tight when the gauge is
facing the front of the press.
6. Attach the pump assembly to the
frame using the fixing bolts and
washers. Fit one bolt first to bear
the weight and use the
adjustment provided by the
upper bolt.
• The pump can be installed on
either side of the frame but will
usually be assembled for a right-
handed press operator.
7. Screw the pump handle into the
pump actuating lever.
8. Unscrew the filler plug and
withdraw the dipstick. Check that
the pump is filled with hydraulic oil
up to the level shown on the
dipstick.

6
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or Servi[email protected]
9. If obtained, bolt the mandrel
storage bracket to the side of the
frame using the bolts supplied.
10. Store the mandrels (if obtained)
including the adaptor, in their
positions on the bracket.
11. Insert the bed support pins into
the holes in the columns at the
required position. Then set the
bed frame in position on the pins.
HYDRAULIC PUMP/RAM OPERATION
1. Before using the press, purge any
air from the system by opening
the release valve by turning it anti-
clockwise and pumping several
full strokes to eliminate any air
bubbles. Tight the release valve
before continuing.
2. Check all parts are secure and
correctly aligned before using the
press.
The press is now ready for use.
POSITIONING THE BED
1. Position the bed at the desired height, so it will be as close as possible to
the ram when the workpiece is mounted on it.

7
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
FITTING THE MANDRELS OR PRESSURE CAP
Mandrels are available as an
adaptor kit, any of which may be
connected to the end of the ram
using the adaptor.
Alternatively, the basic ram pressure
cap can be fitted as shown. Secure
the pressure cap by tightening the
grub screw with a suitable hex key.
If one of the mandrels is required, the
adaptor must be fitted instead of the
pressure cap. Secure the adaptor by
tightening the grub screw with a
suitable hex key.
Select your mandrel depending
upon the size of the workpiece
bearing surface.
The mandrel can then be pushed
into the adaptor where the built-in
spring clip will hold it in place.
Store the mandrels in their positions
on the mounting bracket when not in
use.

8
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or Servi[email protected]
OPERATION
1. Place the workpiece on the bed. It must be completely stable and
supported by packing or shims where required. ‘Heel’ blocks (arbor plates)
are supplied, which locate on the bed. Place the workpiece on a
combination of these to give it stability
NOTE: Any packing pieces or shims used MUST be capable of
withstanding the pressure that will be brought to bear, and MUST
be of sufficient size with sufficient surface area, so as to avoid the
possibility of slipping or springing out. Mating surfaces MUST be
horizontal so that the force being exerted will NOT be at an angle.
2. Close the release valve by turning
it clockwise until tightly closed.
3. Pump the handle to bring the ram
very lightly into contact with the
workpiece.
4. Manoeuvre the workpiece so that
the desired point of contact is
directly beneath the centre of the
ram.
5. When satisfied that the workpiece
is correctly aligned and is completely stable in that position, slowly pump
the handle so that the ram begins to exert pressure on the workpiece.
Continue to pump the handle whilst standing to the side. Do NOT stand
directly in front of the work and constantly monitor the process, ensuring
the ram and work remain completely in line and there is no risk of slipping.
6. When the process is complete, turn the release valve anticlockwise in small
increments to release ram pressure and allow removal of the workpiece.
CAUTION: DO NOT POINT LOAD THESE ACCESSORIES AS THEY ARE NOT
DESIGNED TO TAKE THE FULL FORCE OF THE RAM IN ONE SPOT. ENSURE
THEY ARE ADEQUATELY SUPPORTED.
WARNING: NEVER USE EXTENSIONS TO THE RAM PUMPING HANDLE.

9
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
MAINTENANCE
• A visual inspection must be made before each use of the press, checking for
leaking hydraulic fluid and damaged, loose, or missing parts.
• Owners and/or users should be aware that repair of this equipment requires
specialised knowledge and facilities. It is recommended that a thorough
annual inspection of the press be made and that any defective parts be
replaced with genuine Clarke parts.
• Any press which appears to be damaged in any way, is found to be badly
worn, or operates abnormally SHOULD BE REMOVED FROM SERVICE until the
necessary repairs are made.
• If the press is not to be used for any length of time, store it with the ram piston
withdrawn and the operating handle in the lowered position to protect the
moving parts.
PERIODICALLY
• Check the press frame to make sure all bolts are tight and inspect for
cracked welds, bent, loose or missing parts.
• Check the hydraulic connections for leaks. Replace or properly repair any
damaged or leaking hydraulic components before using. In the event of
leaking seals, oil can be topped up via the filler plug at the end of the unit.
Oil should be level with the mark on the dipstick. If necessary top up with
CLARKE hydraulic oil, Part No 3050830. This task is carried out with the ram
fully retracted.
• If any rust is apparent it must be removed completely and the paint restored.
DE-COMMISSIONING THE PRODUCT
Should the product become completely unserviceable and require disposal,
draw off the oil into an approved container and dispose of the product and
the oil according to local regulations.

10
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or Servi[email protected]
TROUBLESHOOTING
Problem Probable Cause Remedy
Pump will not work. Dirt on valve seat/warn
seals.
Bleed pump unit or have
unit overhauled with new
seals.
Pump will not produce
pressure.
Pump feels hesitant
under load.
Pump will not lower
completely.
Air-lock in system. Open the release valve
and remove the oil filler
plug. Pump the handle a
couple of full strokes and
close the release valve.
Replace the filler plug.
Pump will not deliver
pressure.
Reservoir could be over-
filled or have low oil level.
Check oil level by
removing the filler plug
and topping up to the
correct level.
Pump feels hesitant
under load.
Pump cup seal could be
worn out.
Have the cup seal
replaced.
Pump will not lower
completely.
Air-lock in system. Release air by removing
the filler plug.

11
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
SPECIFICATIONS
Capacity 10 Tonne Dimensions
Operating Pressure 10000 PSI A 110 mm
Ram Travel 183 mm B 340 mm
Ram Diameter 42 mm C 365 mm
Net Weight 55 kg D 180 mm
E 183 mm
F 600 mm (ex pump)
G 450 mm
H 1070 mm
L 80 mm

12
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or Servi[email protected]
FRAME PARTS DIAGRAM

13
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
PARTS LISTS
FRAME PARTS
NO DESCRIPTION NO DESCRIPTION
1 Pressure Gauge 14 Washer 8mm
2 Nylon Ring 15 Spring Washer M8
3RamAssembly 16Bed
4 Hydraulic Hose 17 Bed Support Pins
5 Pump Assembly 18 Bolt M6 x 25
6 Bolt M6x16 19 Nut M6
7 Spring Washer M6 20 Bolt M10 X 25
8 Washer M6 21 Washer M10
9 Upper Collar 22 Spring Washer M10
10 Welded Frame Assembly 23 Nut 10mm
11 Lower Collar 24 Mandrell /Adaptor Set Complete
12 Arbor Plate 25 Mandrell Mounting Bracket
(part of adaptor kit)
13 Bolt M8 x 16 socket head 26 Frame Foot
RAM PARTS
NO DESCRIPTION NO DESCRIPTION
R1 Bolt M20 x 25 R14 O-Ring
R2 Sealing Washer R15 Threaded End
R3 Connecting Insert R16 Spring
R4 Gauge Coupling R17 Nut M8
R5 Dust Cap R18 Ring 29.5 x 3.55
R6 Connector R19 Ram Piston
R7 Hex socket bolt M8 x 30 R20 Grub Screw
R8 Cylinder Body R21 Washer
R9 Circlip R22 Bolt M8 x 12
R10 O-Ring R23 End Cap
R11O-RingSeal R24ThreadedRing
R12 Sealing Ring R25 Upper Collar
R13 O-Ring 45x 2.65 R26 Lower Securing Collar

14
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or Servi[email protected]
RAM PARTS DIAGRAM

15
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
DECLARATION OF CONFORMITY
