Clarke CC15 User manual

PAGE 1
Pop-Up Canopy
10 x 15 ft. / 3 x 4.6m
DESCRIPTION MODEL
Pop-Up Canopy 10' x 15'
Straight Leg - Chequer design
CC15
3503524
Please read instructions COMPLETELY before assembly. This shelter MUST be securely anchored.
WARNING – Keep all ame and heat sources away from fabric. The fabric may burn if left in continuous
contact with any ame source. The application of any foreign substance to the fabric may render
the ame-resistant properties ineffective. It is not reproof.
Before you start: 2 or more individuals recommended for assembly.
RECOMMENDED TOOLS
Clarke International
Hemnall Street
Epping
Essex CM16 4LG
ENGLAND
www.clarkeinternational.com
PARTS & SERVICE: 0208 988 7400
E-mail: [email protected] or
[email protected]
SALES: UK 01992 565333 or
EXPORT: 00 44 (0)1992 565335

PAGE 2
ATTENTION:
The canopy product is classied as a temporary fabric covered shelter designed primarily
for seasonal shade. It is NOT snow, ice, or wind load rated and is not recommended as a
permanent structure. This canopy must be properly and securely anchored.
CAUTION:
Use CAUTION when erecting the frame.
WARNING:
Choose the location of your canopy carefully. Check for overhead utility lines, tree
branches or other structures. DO NOT hang objects from the roof. DO NOT smoke
or use open ame devices in or around the canopy. DO NOT store ammable liquids
(gasoline, kerosene, propane, etc.) under your canopy. DO NOT expose top or legs of
the canopy to open re or other ame source. DO NOT use BBQ's, re pits, deep fryers
or smokers under the canopy.
Before you start: 2 or more individuals recommended for assembly.
NOTE: Please read instructions COMPLETELY before assembly
CARE AND CLEANING:
PROPER ANCHORING AND INSTALLATION OF FRAME:
PROPER ANCHORING OF THE FRAME IS THE RESPONSIBILITY
OF THE CONSUMER.
A tight cover will ensure longer life and performance. Always maintain a tight cover. Loose fabric can accelerate
deterioration of cover fabric. Immediately remove any accumulated debris from the cover with a broom, mop or other
soft-sided instrument. Use extreme caution when removing debris from cover. Always remove from outside the structure.
DO NOT use hard-edged tools or instruments like rakes or shovels to remove debris. This could result in punctures to
the cover. DO NOT use "Protect and Shine", bleach or harsh abrasive products to clean the fabric cover. Cover is easily
cleaned with mild soap and water.
Clarke®International is not responsible for damage to the unit or the contents from acts
of nature. Any canopy that is not anchored securely has the potential to y away causing
damage. Periodically check the anchors to ensure stability of the canopy.
Clarke®International cannot be responsible for any shelter that blows away.
NOTE: Your shelter's cover can be quickly removed and stored prior to severe weather
conditions. If strong winds or severe weather is forecast in your area, we recommend
removal of cover.

PAGE 3
CAUTION: Temporary spike anchors are
NOT designed for permanent installation.
Never leave canopy unattended.
NOTE: Replacement anchors are available
from our spare parts department.
Please quote Part No. 18166
1
3
5
7
4
6
2
1
/
2
CLICK!
CLICK!

Replacement Parts
CC15
PAGE 4
Part
Pièce
Parte
Part Number
Numéro de Pièce
Número de Parte
Description / Désignation / Descripción
1SHLCC1515381 Leg Tube Assembly
2SHLCC1515370 Gemel Assembly, side 1
3SHLCC1515398 Gemel Assembly, side 2
4SHLCC1515373 Gemel Assembly, supports
5SHLCC1515399 Gemel Assembly, middle
6SHLCC1515376 Top Tube Kit
7SHLCC1522606 Sliding Connector Kit
8SHLCC1515557 Replacement Roller Bag
9SHLCC15800812 Replacement Cover - Chequered Flag
9
8
7
1
4
32
2
7
3
5
6
4
4
4
