Clarke CIS788 User manual

ASSEMBLY INSTRUCTIONS
ORIGINAL INSTRUCTIONS
INSTANT GARAGE
MODEL NO: CIS788
PART NO: 3503582
GC0918

2
Parts & Service: 020 8988 7400 / E-mail: Parts@clarkein ternational.com or [email protected]
INTRODUCTION
Thank you for purchasing this CLARKE Instant Garage. When erected, the
CIS788 garage will be of the dimensions show below. Weight is 34 kg
packed (32 kg unpacked).
Before attempting to use this product, please read this manual thoroughly and
follow the instructions carefully. In doing so you will ensure the safety of yourself
and that of others around you, and you can look forward to your purchase
giving you long and satisfactory service.
SAFETY INSTRUCTIONS
This garage is a temporary structure and is not recommended as a permanent
building.
Choose your garages location carefully. Check for overhead utility lines,
branches, etc. DO NOT install near roofs or other structures that may shed snow,
ice or excessive run-off onto your garage. Keep away from power cables.
WARNING: READ ALL SAFETY INSTRUCTIONS TO REDUCE THE RISK OF
INJURY. RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE.
2.4m
8'
2.4m
8'
2.1m
7'
1.63m
5'5"
1.65m
5'6"

3
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [email protected]
Erect your garage on a level surface.
Have an overview of all parts before attempting installation. Make sure all
components are available.
DO NOT use this product in environments for which it is not Intended (i.e.
extreme cold, high winds, extreme heat, heavy rainfall, etc).
Always wear safety glasses when assembling this product. Wear gloves when
working with tubing to prevent cuts or abrasions.
Proper anchoring and keeping the cover tight and free of snow and debris is
the responsibility of the user.
Damage caused by improper anchoring are not covered under warranty.
Keep all flame and heat sources away from the garage fabric. The fabric will
burn if left in continuous contact with a naked flame.
DO NOT use open flames or cooking or heating devices inside or in close
proximity to the garage, including all types of stoves, gas heaters, gas lanterns,
torches, fly killers, etc.
In order to reduce risk of burning and avoid damage, DO NOT- cook, smoke,
refuel or use any open flame devices in or around the garage.
DO NOT store flammable liquids (petrol, kerosene, propane, etc.) in the
garage, operate gas powered vehicles/equipment in or around the garage.
Keep open flames a safe distance away from the garage.
DO NOT use hard-edged tools or instruments, such as rakes or shovels, to
remove snow. These can cause punctures to the cover.
NEVER start the engine of any vehicle or machine inside a closed garage.
Ensure that there is adequate ventilation for engines and for any work with
paints, cleaners. etc.
This garage is NOT designed to support heavy snow, Snow or ice
accumulation may cause your garage to collapse. To avoid overload, brush
snow and ice off the roof top with a broom or mop.
To prevent collapse, damage to property or personal injury, NEVER clear the
roof of snow or debris from inside the garage.
DO NOT use bleach, alkaline or harsh detergents for cleaning. Doing so will
damage the material. Soap and warm water are recommended.
This temporary garage is designed to offer protection from damage caused
by the sun, light rain, light snow, tree sap and bird droppings. It is not designed
to shelter equipment from high winds, heavy rain or snow.

4
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [email protected]
COMPONENT PARTS LIST
No Description Illustration Qty
1Upright Pole with Dimples 6
2Corner Extension Tube 4
3Bent Corner Leg 4
4Shoulder Cross Rail 6
5Rafter Pole 6
6Bottom Cross Rail 4
7Center Extension Tube 2
83-Way Side Connector - Left 2
93-Way Side Connector - Right 2
10 4-Way Side Connector 2
11 3-Way Peak Connector 2
12 4-Way Peak Connector 1
13 4-Way Cross Rail Clamp 4
14 3-Way Cross Rail Clamp 8
15 Ratchet Tie Down 8
16 M6x45 Bolt 8
17 M6 Nut 8
18 M6 Washer 8
19 Roof Tarp 1
20 Front Door Panel (with zipper) 1
21 Back Panel 1
22 Anchor 4
23 Cable (1' / 30 cm) 4
24 Cable Clamp 4

5
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [email protected]
ASSEMBLY
1. Place all parts from the packaging in a clear area and arrange them on
the ground in front of you.
2. Remove all packaging materials and place them back in the box. Do not
dispose of the packaging materials until assembly is complete.
3. Check for completeness and for any transport damage.
Diagram A

6
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [email protected]
STEP 1: PREPARING THE ROOF PARTS
Select a suitable location for the garage. The layout of the roof parts is shown in
Diagram B.
Note the differences between
the connectors shown in
Diagram C. (connectors are
also individually numbered).
Note: When installed, the
welded socket for the cross rail
must be below the bend.
Parts #8, #9 & #10are side
(shoulder) connectors.
Parts #11 & #12 are top (apex)
connectors.
Diagram B 9511 8
89
10 10
12
5
5
5
5
5
4 4 4
444
11
89
10
11 12
Diagram C

7
Parts & Service: 020 8988 7400 / E-mail: Parts@clarkein ternational.com or [email protected]
STEP 2: ASSEMBLING THE ROOF
1.
Diagram D 11 12 11
4
4
Attach the shoulder cross rails (4) to the 3-way side connectors (8, 9) and
4-way side connectors (10). Insert the connectors (8, 9, 10) into the rafter
poles (5) to complete the assembly of the roof (Diagram D).
94
4
8
10
8
4
49
10
55
5
5
5
5
NOTE:
●Be sure that all tubes are fully inserted. Use a rubber
mallet if necessary.
●When using the connectors, be sure to remove the
protective caps first.

8
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [email protected]
STEP 3: ATTACHING THE LEGS
There are 6 legs for the whole shelter.
1. Follow Diagram E. Connect the tubes #1,2 & #3 to create the 4 corner
legs.
2. Connect tubes #1 & #7 to create the 2 center legs.
3. Insert the centre legs and corner legs into the side connectors as in
Diagram E.
4. Repeat to assemble the other side as shown in Diagram E.
Diagram E
1 1
7
2
3
9
2
1
8
2
1
3
3

9
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [email protected]
STEP 4: SQUARE AND ANCHOR THE FRAMES
1. Check that the width measurements of the frame are 8' at both the front
and back corners, as well as across the center.
2. Take a diagonal measurement as shown in Diagram F. When these two
measures are equal the frame is square. Adjust the frame until they are
equal to within 1".
3. Once equal, check the width measurement again to ensure all widths are
equal at 8'.
4. Next, install the anchors
(Parts #22, #23 & #24) at the
4 corner legs by screwing
the removable anchor
(#22) into the ground on
the inside of the structure.
5. Secure with cable (#23)
and cable clamp (#24) (as
shown in Diagram G).
Diagram F
8'
8'
22
3
24
23
Diagram G

10
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [email protected]
STEP 5: INSTALLING THE FRONT AND BACK COVERS
The front cover has a zippered door to allow entry to the garage. Be sure to
locate this cover at the desired end and ensure the zipper is in the closed
position while installing.
The back cover is a solid piece of fabric.
The covers are installed in the same fashion.
1. Thread the strap through the spindle of the ratchet to make sure the strap
will stay in the sleeve when assembled, Raise and lower the handle two or
three times to wind the strap onto the spindle (as shown in Diagram I1&I2).
2. Begin with the front cover and first locate the webbed strap that runs
around the perimeter at the cover.
The webbing is exposed at the peak, the shoulders and the feet of
the cover.
Diagram H
20
Diagram I
I 1 I 2

11
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [email protected]
4. Wrap the door panel around the tube. Slip the webbing strap between the
tubes and then re-connect.
5. Hook the pre-assembled ratchet tie down to the frameand tighten until the
front cover is reasonably tight. Repeat (Diagram J3) to install the rear panel.
Diagram J2) (
Diagram J
Diagram J1
J1
J2
J3
3. Following Diagram J1,disconnect the tube (#4) from the connector
(#8,#9,＆
#11）
Diagram J2 Diagram J3
49
4
11
3

12
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [email protected]
STEP 6: INSTALLING THE MAIN COVER
1. Lay the cover on the ground next to the frame with the inside of the cover
(the side with the pockets) facing down and the strap on the front and rear
of the frame.
2. Tie a rope to the eyelets on the cover, one each side. Another rope in the
middle helps if another person is available.
3. Pull the cover over the frame using the rope as in Diagram K, making sure
to centre the cover on the frame. There should be an equal overhang on
each corner.
4. Assemble the ratchet tie-down
(#15) to the strap ends on the four
corners of the cover. Ratchet a
few times to draw the strap onto
the spool.
5. Insert the hook on the ratchet into
the hole on the bent corner leg.
Wind the ratchet so that the
webbing overlaps itself.
6. Slide the bottom cross rails
through the fabric pockets at each leg and re-attach with clamps at each
leg. Repeat this on the other side. Push down on the cover rails to tighten
the cover before tightening all bolts completely.
Diagram K
19

13
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [email protected]
7. When the cover rails are all secured, proceed to the four corners and
tighten the end covers to the end frames using the ratchet action.
Note: Over-tightening can cause damage to straps and/or the anchor point.
Do not over-tighten!
The garage is now ready for use.
24
25
Diagram M
13
16
18
17
14
16
17
18
Diagram L

14
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [email protected]
Note: Check periodically (two to three times in the first week) and tighten
ratchet tie-downs and all hardware as needed. Monthly inspection is
recommended throughout usage.
DISASSEMBLY
When disassembling the garage, depress the spring-loaded bar to disengage
the ratchet and open the ratchet handle completely to allow the webbing
strap to pull through.
PLEASE RE-READ ALL WARNINGS CONTAINED ON PAGE 2/3 OF THESE
INSTRUCTIONS. SAVE THESE INSTRUCTIONS FOR FUTURE USE.
To dismantle, execute all instructions in reverse order.
Store your garage in a cool, dry location between seasons to prolong the
usable life of all components.
Components are not equally durable and will require replacement over time
at differing intervals.

15
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [email protected]
GUARANTEE
This product is guaranteed against faulty manufacture for a period of 12
months from the date of purchase. Please keep your receipt which will be
required as proof of purchase.
This guarantee is invalid if the product is found to have been abused or
tampered with in any way, or not used for the purpose for which it was
intended.
Faulty goods should be returned to their place of purchase, no product can
be returned to us without prior permission.
This guarantee does not effect your statutory rights.
