COMAC Optima 90 User manual

SCRUBBING MACHINES
ORIGINAL INSTRUCTION DOC. 10081741 - Ver. AA - 07-2018
USE AND MAINTENANCE MANUAL

CONTENTS
CONTENTS...............................................................................................................3
GENERAL SAFETY REGULATIONS.......................................................................4
RECHARGING THE BATTERIES................................................................................................ 4
USING THE MACHINE................................................................................................................ 5
DEACTIVATION OF THE MACHINE ........................................................................................... 7
MAINTENANCE........................................................................................................................... 7
TRANSPORT............................................................................................................................... 9
SYMBOLS USED ON THE MACHINE ...................................................................10
SYMBOLS PRESENT ON THE REGISTRATION PLATE ......................................................... 10
SYMBOLS PRINTED ON THE MACHINE................................................................................. 10
LABELS ON THE MACHINE ..................................................................................................... 10
SYMBOLS PRESENT ON THE COMMAND PANEL..................................................................11
SYMBOLS PRESENT ON THE CONTROL PANEL...................................................................11
SYMBOLS USED IN THE MANUAL ......................................................................12
PURPOSE AND CONTENT OF THE MANUAL..................................................... 12
TARGET GROUP....................................................................................................12
STORING THE USE AND MAINTENANCE MANUAL........................................... 12
ON CONSIGNMENT OF THE MACHINE ............................................................... 12
INTRODUCTORY COMMENT ................................................................................12
IDENTIFICATION DATA..........................................................................................12
TECHNICAL DESCRIPTION ..................................................................................12
INTENDED USE......................................................................................................12
SAFETY ..................................................................................................................12
REGULATIONS.......................................................................................................12
SPECIAL EQUIPMENT........................................................................................... 13
SERIAL NUMBER PLATE ...................................................................................... 13
TECHNICAL DATA (INTERNATIONAL SYSTEM) .................................................13
TECHNICAL DATA (IMPERIAL SYSTEM) .............................................................14
BRUSH TYPE ......................................................................................................... 14
PREPARATION OF MACHINE ...............................................................................15
HANDLING THE PACKAGED MACHINE.................................................................................. 15
HOW TO UNPACK THE MACHINE........................................................................................... 15
HOW TO MOVE THE MACHINE............................................................................................... 15
MACHINE SAFETY ................................................................................................................... 15
TYPE OF BATTERY TO BE USED............................................................................................ 15
BATTERY MAINTENANCE AND DISPOSAL ............................................................................ 15
RECHARGING THE BATTERIES.............................................................................................. 16
FILLING THE SOLUTION TANK WITH WATER........................................................................ 16
DETERGENT SOLUTION ......................................................................................................... 17
ASSEMBLING THE SQUEEGEE BODY ................................................................................... 17
USER SEAT ADJUSTMENT...................................................................................................... 18
PREPARING TO WORK ......................................................................................... 18
STARTING WORK ..................................................................................................19
WATER FLOW ADJUSTMENT FUNCTION .............................................................................. 20
DETERGENT SOLUTION FLOW ADJUSTMENT FUNCTION (CDS VERSION) ..................... 20
ECO-MODE FUNCTION............................................................................................................ 20
BUZZER..................................................................................................................................... 20
MOVEMENT SPEED ADJUSTMENT ........................................................................................ 20
EXTRA-PRESSURE FUNCTION EXERTED ON THE BRUSHES ........................................... 20
DIPPED HEADLIGHTS.............................................................................................................. 20
HOUR METER........................................................................................................................... 20
BATTERY CHARGE LEVEL INDICATOR.................................................................................. 21
EMERGENCY BUTTON ............................................................................................................ 21
ALARM SCREEN....................................................................................................................... 21
SERVICE BRAKE ...................................................................................................................... 21
OVERFLOW DEVICE ................................................................................................................ 21
AT THE END OF THE WORK.................................................................................22
ROUTINE MAINTENANCE.....................................................................................22
DRAINING THE RECOVERY TANK.......................................................................................... 22
EMPTYING THE DEBRIS HOPPER ......................................................................................... 23
CLEANING THE SQUEEGEE BODY ........................................................................................ 23
CLEANING THE RECOVERY TANK FILTER-FLOAT ............................................................... 23
CLEANING THE BRUSH HEAD BODY BRUSHES .................................................................. 24
CLEANING THE RECOVERY TANK ......................................................................................... 24
EMPTYING THE SOLUTION TANK .......................................................................................... 24
CLEANING THE WATER SYSTEM FILTER.............................................................................. 25
CLEANING THE VACUUM TUBE ............................................................................................. 25
CLEANING THE DETERGENT TANK (CDS VERSIONS) ........................................................ 25
EXTRAORDINARY MAINTENANCE WORK ......................................................... 26
REPLACING THE SQUEEGEE BODY RUBBER BLADES ...................................................... 26
REPLACING THE BRUSH HEAD BODY BRUSHES................................................................ 26
REPLACING THE BRUSH HEAD BODY SPLASH GUARD ..................................................... 26
ADJUSTMENT INTERVENTIONS..........................................................................27
ADJUSTING THE SQUEEGEE BODY'S RUBBER BLADES.................................................... 27
ADJUSTING THE SQUEEGEE BODY'S RUBBER BLADES.................................................... 27
DISPOSAL ..............................................................................................................27
EC DECLARATION OF CONFORMITY.................................................................. 28
TROUBLESHOOTING............................................................................................28
BROWSING THE COMMAND DISPLAY MENU .................................................... 29
3

GENERAL SAFETY REGULATIONS
The following symbols are used to indicate any potentially hazardous situations. Always read this
information carefully and take the necessary precautions to protect any people and/or objects that
may be present.
Operator cooperation is paramount for accident prevention. No accident prevention programme
can be e󰀨ective without the full cooperation of the person directly responsible for the machine's
operation. Most accidents that occur at the workplace, during work activities, or while in transit, are
caused by the failure to respect the most basic safety regulations. An attentive, careful operator is
most e󰀨ective guarantee against accidents and is fundamental in order to implement any prevention
programme.
DANGER: Indicates an imminent danger that could cause serious injury or death.
WARNING: Indicates a probable dangerous situation that could cause serious injury or death.
CAUTION: Indicates a probable dangerous situation that could cause minor injuries.
ATTENTION: Indicates a probable dangerous situation that could damage objects.
RECHARGING THE BATTERIES
DANGER:
• If the battery charger power cable is damaged or broken, it must be replaced by the battery
charger manufacturer; by an authorized Service Centre personnel or a qualied person in order
to avoid hazards.
• The socket for the battery charger cable must have a prescribed earth connection.
• Keep sparks, ames, and incandescent materials at a safe distance from the batteries. Explosive
gases are emitted during normal use.
• highly explosive hydrogen gas is generated while charging the batteries. Keep the seat mounting
plate in the maintenance position during the entire battery recharging cycle, and only carry out
the procedure in well-ventilated areas and at a safe distance from any open ames.
• Before charging check that the electric cable that connects the battery charger to the batteries
is not damaged, and if it is damaged do not use it and contact technical assistance.
• Before charging check that the electric cable that connects the battery charger to the mains is
not damaged, and if it is damaged do not use it and contact technical assistance.
• Do not disconnect the direct current cable of the battery charger from the socket of the machine
when the battery charger is operating. This is necessary to prevent electric arcs forming. To
disconnect the battery charger when it is charging, rst disconnect the alternating current power
cable.
WARNING:
• Do not use incompatible battery chargers since they could damage the batteries and potentially
cause a re.
• Before using the battery charger, make sure that the frequency and the voltage values indicated
on the machine's data plate coincide with the network's values.
4

• Keep the battery charger's cable at a safe distance from any hot surfaces.
• Never smoke in the machine's vicinity while the batteries are charging.
• Before starting the charging operation, carefully read the use and maintenance manual of the
batteries and the battery charger that you want to use.
USING THE MACHINE
DANGER:
• In the event of danger, quickly press the emergency button on the instrument panel.
• Never collect gases, explosive/inammable liquids or powders, nor acids and solvents! These
include gasoline, paint thinners and fuel oil (which, when mixed with the vacuum air, can form
explosive vapours or mixtures), and also non-diluted acids and solvents, acetones, aluminium
and magnesium powders. These substances may also corrode the materials used to construct
the machine.
• If the machine is used in dangerous areas (e.g. petrol stations), the relative safety standards
must be observed. It is forbidden to use the machine in environments with a potentially explosive
atmosphere.
WARNING:
• The machine must be exclusively used by authorised, trained personnel.
• Do not use the machine on surfaces with a slope greater than the one indicated on the serial
number plate.
• The machine is not suitable for cleaning rough or uneven oors. Do not use the machine on
slopes.
• In the event of a re, use a powder extinguisher. Do not use water.
• Adapt the speed to the adhesion conditions.
• In order to prevent the unauthorised use of the machine, the power supply must be disconnected:
switch the machine o󰀨 using the main switch (by removing the key from the block) and disconnect
the battery's connector from the electrical system's connector.
• Do not use the machine if you do not have the requisite knowledge or authorisation.
• Do not use the machine if you have not read and understood the following user manual.
• Do not use the machine under the inuence of alcohol or drugs.
• Do not use the machine when using a mobile phone or other types of electronic devices.
• Do not use the machine if it is not working correctly.
• Do not use the machine in areas where there are inammable vapours or liquids or combustible
powders.
• Do not use the machine in areas that are too dark to see the controls or operate the machine
safely, unless the work lights or the front headlights are on.
• Do not use the machine in areas where there is a risk of falling objects, unless the machine is
equipped with an overhead guard (optional).
CAUTION:
• Children must be supervised to ensure they do not play with the machine.
• During the working of the machine, pay attention to other people and especially to children.
5

• The machine must only be powered with a voltage equal to that shown on the serial number
plate.
• Read the labels on the machine carefully. Do not cover them for any reason, and replace them
immediately if they become damaged.
• The machine must only be used and stored in an enclosed or covered environment.
• The machine must not be used or stored outdoors in damp conditions or directly exposed to
rain.
• Use the machine only in the way described in this manual.
• Do not pick up anything that is burning or smouldering, like cigarettes, matches or glowing
embers.
• Reduce speed on slopes and dangerous corners.
• Reduce speed before making a turn.
• Keep all parts of your body inside when the machine is moving.
• Be careful when reversing.
• Do not transport passengers. Do not use the machine as a means of transport.
• Always follow the instructions for mixing, use and disposal on the containers of the chemical
substances.
ATTENTION:
• The appliance should not be used by people (including children) with reduced physical,
sensory or mental capabilities or who do not have the necessary experience or knowledge
of the appliance.
• If the machine is to be used in the presence of other individuals, aside from the operator, the
beacon light (optional) must be utilized.
• Always take appropriate measures to protect any individuals and/or objects that may be present
while using this machine.
• Be careful to avoid collisions with shelving or sca󰀨olding, above all if there is a risk of objects
falling from heights.
• Do not place any liquid containers on the machine.
• The machine must only be used under temperature conditions ranging from 0 °C to +40 or
+32 °F to 104 °F.
• When using detergents to clean the ooring, always follow the instructions and respect the
warnings indicated on the containers' labels.
• Always use appropriate gloves and protective equipment when handling the detergents used
to clean the oor.
• Avoid working with the brushes when the machine is standing still, so as not to damage the
oor.
• In the event of a re, use a powder re extinguisher if possible, and avoid the use of water.
• Do not allow any objects to penetrate into the machine's openings. Do not use the machine is
the openings are obstructed.
• Keep the machine's openings free of any dust, lint, hairs, or any other foreign materials that
could reduce the airow.
• Do not remove or alter any labels a󰀩xed to the machine.
• This machine has not been approved for use on public streets or roadways.
• This machine has not been made for external use but internal locations only.
• Only use the brushes and pad holders that have been supplied along with the machine or those
specied in the Operator's Manual. The use of other brushes or felt pads could compromise the
machine's safety conditions.
• Before starting to work check that there are no leaks.
6

• Before starting to work check that all the safety devices have been installed and are working
correctly.
• Before starting work check that the brakes and steering are working correctly.
• Before starting work adjust the seat and steering wheel, and also the seat belt if there is one.
DEACTIVATION OF THE MACHINE
WARNING:
• Always protect the machine against sunlight, rain, and other atmospheric agents, both while it
is stationary and while it is in function. Store the machine in a dry, sheltered place: this machine
is only designed for use under dry conditions, and must not be used or stored outdoors under
humid conditions.
• Do not park the machine near combustible materials, powders, gases or liquids.
• Stop the machine on a at surface.
• If the machine is left unattended, it must be protected from any accidental movements
ATTENTION:
• The machine must only be stored under temperature conditions ranging from 0 °C to +40 or
+32 °F to 104 °F. The humidity level must be between 30% and 95%.
MAINTENANCE
DANGER:
• In order to avoid short-circuits when working in the vicinity of electrical components, do the
following: avoid the use of non-insulated tools; do not place or allow metallic objects to fall upon
the electrically powered components; remove any rings, watches and/or clothing with metallic
parts that might come into contact with the electrically powered components.
• do not work underneath the raised machine without adequate xed safety supports.
WARNING:
• Read all the relevant instructions carefully before performing any maintenance/repair operations.
• If the machine does not work properly, check this is not caused by failure to carry out routine
maintenance. Otherwise, ask for intervention of the authorised technical assistance centre.
• Restore all electrical connections after any maintenance interventions.
CAUTION:
• When doing maintenance work, switch o󰀨 the machine using the main switch. Remove the
key from the instrument panel and remove the battery connector from the electrical system
connector.
• Avoid contact with moving parts. Do not wear loose clothing or jewellery and tie long hair back.
• Block the wheels before lifting the machine.
• Lift the machine with equipment that can sustain the weight to be lifted.
ATTENTION:
• All maintenance operations on the machine must be carried out under su󰀩cient visibility and
lighting conditions.
7

• Ensure that the area used for the maintenance of the machine is well ventilated.
• Avoid contact with moving parts during machine maintenance. Do not wear loose clothing or
jewellery and tie long hair back.
• Block the wheels before lifting the machine with the jack.
• Raise the machine with the jack only at the points indicated. Support the machine using the
stands.
• Wear personal protective equipment as required and as suggested in the manual.
• Never tamper with the machine's protection devices for any reason; always follow the supplied
routine maintenance instructions scrupulously.
• If the machine needs to be pushed for maintenance purposes (batteries absent; discharged
batteries; etc.), never exceed 4 km/h or 2.49 mph.
• If any issues are encountered while using the machine, check to make sure that these are
not due to a lack of proper maintenance. Otherwise, request the intervention of authorized
personnel or an Authorized service centre.
• If any parts need to be replaced, always request ORIGINAL spare parts from an authorized
Dealer or Retailer.
• In order to ensure the machine's safety and proper functionality, always have the scheduled
maintenance interventions (specied in the appropriate section of this Manual) performed by
authorized personnel or by an authorized Service Centre.
• Do not clean the machine with direct or pressurized jets of water, or with corrosive substances.
• Disconnect the battery connection and the battery charger cable before working on the machine.
• If lead batteries (WET) have been installed on the machine, avoid tilting the machine beyond
30° with respect to the horizontal plane, as this could cause the highly corrosive liquid to leak
out of the batteries.
• Avoid contact with the battery acid.
• Keep all metal objects away from the batteries.
• Use a non-conductive device for removing the battery.
• Use a hoist and suitable equipment when lifting the batteries.
• The battery must be installed by qualied personnel.
• Always observe the safety measures of the site regarding removing the battery.
• Remove the batteries if the machine needs to be tilted in order to perform maintenance
procedures.
• Have the machine checked by an authorised technical assistance centre every year.
• When disposing of consumable materials, observe the laws and regulations in force. Once
the machine has reached the end of its service life, the materials contained within it must be
disposed of in an appropriate manner, keeping in mind that the machine itself has been built
using fully recyclable materials.
• Do not push or tow the machine without an operator on the seat who can control the machine.
• Do not wash the machine with pressurised water or wet the machine near electrical components.
• All repairs must be carried out by qualied personnel.
• Do not physically change the design characteristics of the machine.
• Use spare parts supplied by Comac or by Comac service centres.
• Wear personal protective equipment as required and as suggested in the manual.
8

TRANSPORT
WARNING:
• Use hoists or jacks capable of supporting the weight of the machine.
• Do not push or tow the machine without an operator on the seat who can control the machine.
• The ramp gradient must not be such as to cause damage to the machine as it moves up onto
the vehicle or from the vehicle to the ground.
• Do not load / unload the machine from a truck or trailer unless the load height is 380 mm or
14.96 inches or less from the ground.
• Block the wheels of the machine.
• Secure the machine to the truck or trailer.
• Drain both tanks before transport.
• Bring both the squeegee and the brushes to a working position before securing the machine to
the transport vehicle.
• Use a ramp, a truck or a trailer that can support the weight of the machine and the operator.
ATTENTION:
• The machine must only be stored under temperature conditions ranging from 0 °C to +40 or
+32 °F to 104 °F. The humidity level must be between 30% and 95%.
9

SYMBOLS USED ON THE MACHINE
SYMBOLS PRESENT ON THE REGISTRATION PLATE
SYMBOLS PRINTED ON THE MACHINE
Direct current symbol:
Used on the appliance's registration plate to indicate that the appliance is powered by a DC power supply.
Battery symbol:
Used on the appliance's registration plates to indicate the mass of the batteries used to power the appliance (expressed in Kg). The value refers to the batteries that the manufacturer o󰀨ers.
X% Maximum gradient symbol:
Used on the registration plate of the device, to indicate the maximum gradient that can be safely handled by the device in work mode.
Solution tank drain pipe symbol:
Located on the rear part of the machine, to identify the solution tank drainage tube.
Recovery tank drainage hose symbol:
Located on the rear part of the machine, to identify the recovery tank drainage tube.
Cap/lter position symbol:
Used on the rear of the device to indicate the position of the solution tank cap/lter.
Symbol of maximum temperature for lling the solution tank:
Used on the side of the device, to indicate the maximum temperature of the water for lling the solution tank safely.
LABELS ON THE MACHINE
Label for detergent ow solution tap control.
This is used near the driver's seat to indicate how to position the lever if you want to activate or deactivate the ow of detergent solution within the circuit of the machine's water system.
Label indicating that the reading of the use and maintenance manual is compulsory:
This is used in the rear part of the steering column to warn the user to read the use and maintenance manual (the present document) before using the machine for the rst time.
Label prohibiting the vacuuming of ammable or incandescent substances:
This is used in the rear part of the steering column to warn the user that there is an absolute obligation not to vacuum ammable or incandescent substances..
Gas leakage warning label during battery charging:
This is used in the rear part of the steering column to warn the user to keep harmful and ammable gases from generating during the battery charge cycle.
Solution tank lter daily care warning label:
This is used in the front left side of the machine to warn the user to clean the solution tank lter after each use of the machine.
Daily care and battery recharge warning label:
This is used in the rear part of the steering column to warn the user on how to recharge the batteries, and the daily care of the machine is explained in the lower part.
Detergent solution ow rate value label:
Used on the rear part of the steering column to indicate the variation of the “detergent solution quantity level” symbols in the machine's water circuit.
Label warning about the risk of crushed hands:
Indicates danger to hands due to crushing between two surfaces.
pH label (versions with on-board automatic detergent dosing system):
A󰀩xed above the detergent tank to indicate the pH range of the chemical product to be utilized.
Detergent tank correct positioning label (versions with on-board automatic detergent dosing system):
Positioned inside the solution tank, near the compartment containing the detergent canister, to indicate the correct positioning of the detergent canister or the distribution pipe.
Water system use warning label with on-board automatic detergent dosing system:
This is used on the machine to warn the user on which chemical products to use.
Detergent solution ow-rate value label (versions with on-board automatic detergent dosing system):
Used on the rear part of the steering column to indicate, on the top line, the variation of the “detergent percentage value” symbols in the machine's water circuit. While the bottom line indicates the
variation of the “detergent solution quantity level” symbols present in the machine's water circuit.
10

SYMBOLS PRESENT ON THE COMMAND PANEL
SYMBOLS PRESENT ON THE CONTROL PANEL
Main switch symbol:
Used on the command panel to indicate in which direction to turn the key to activate or deactivate the machine's general switch.
i-drive selector symbol:
Indicates the command knob for the i-drive program selector.
Open book caution symbol:
Used in the control panel to tell the operator to read the manual before using the machine.
Machine movement direction symbol:
Used on the control panel to indicate the direction of the machine.
ECO-MODE symbol:
Used on the control panel to indicate the button that activates or deactivates the ECO-MODE of the machine.
Buzzer symbol:
Indicates the buzzer command button.
Detergent solution quantity regulation symbol:
Used on the control panel to indicate the button regarding the regulation of the detergent solution level within the machine's water circuit.
Front headlights control symbol:
Used on the control panel to indicate the button that regulates the machine's front headlights.
Regulation symbol denoting pressure applied to the brushes:
Used on the control panel to indicate the button that regulates the weight exerted by the brushes on the oor.
Detergent percentage regulation symbol (versions with on-board automatic detergent dosing system):
Used on the control panel to indicate the button regarding the regulation of the detergent percentage within the machine's water circuit.
Forward speed level regulator symbol:
Used on the control panel, to indicate the button that allows you to regulate the movement speed of the machine.
Braking system oil level check label:
Located near the braking system oil basin, to remind the operator to check the level of oil in the basin.
The bottom part of the label shows the recommended oil for the braking system.
11

The descriptions contained in this document are not binding. The company therefore reserves the right to make any modications at any time to elements, details, or accessory supply, as considered necessary for
reasons of improvement or manufacturing/commercial requirements. The reproduction, even partial, of the text and drawings contained in this document is prohibited by law.
The company reserves the right to make any technical and/or supply modications. The images are shown as reference only and are not binding as to the actual design and/or equipment.
SYMBOLS USED IN THE MANUAL
Symbol of the open book with i:
Indicates the need to consult the instruction manual.
Symbol of the open book:
Tells the operator to read the user manual before using the device.
Covered place symbol:
The operations preceded by this symbol must always be carried out in a dry, covered
area.
Information symbol:
Indicates additional information for the operator, to improve the use of the device.
Warning symbol:
Carefully read the sections preceded by this symbol meticulously following the instructions
indicated for the safety of the operator and the device.
Danger symbol (corrosive substances):
The operator should always wear protective gloves to avoid the risk of serious injury to the
hands caused by corrosive substances.
Danger symbol (battery acid leakage):
Indicates the danger of leaking acid or acid fumes from the batteries while they are being
recharged.
PURPOSE AND CONTENT OF THE MANUAL
The aim of this manual is to provide customers with all the information needed to use the machine in the safest, most appropriate and most autonomous way. This includes information concerning technical
aspects, safety, operation, downtime, maintenance, spare parts and scrapping. The operators and qualied technicians must carefully read the instructions in this manual before carrying out any operations on the
machine. If in doubt about the correct interpretation of instructions, contact your nearest Customer Service Centre to obtain the necessary clarications.
Danger symbol (moving carriages):
Indicates that the packed product should be handled with suitable carriages that conform
to legal requirements.
Mandatory room ventilation symbol:
Informs the operator that the room must be ventilated while the batteries are being
recharged.
Symbol indicating the compulsory use of protective gloves:
Indicates that the operator should always wear protective gloves, to avoid the risk of
serious injury to his hands from sharp objects.
Symbol indicating the compulsory use of tools:
Informs the operator of the need to use tools not included with the machine.
Symbol indicating a treading ban:
Informs the operator that it is forbidden to tread on machine components, as this could
lead to serious injury.
Recycling symbol:
Tells the operator to carry out the operations in compliance with environmental regulations
in force in the place where the appliance is being used.
Disposal symbol:
Carefully read the sections marked with this symbol for disposing of the appliance.
TARGET GROUP
This manual is written both for operators and for qualied machine maintenance technicians. Operators must not perform operations that should be carried out by qualied technicians. The manufacturer is not
liable for damages resulting from failure to comply with this veto.
STORING THE USE AND MAINTENANCE MANUAL
The Use and Maintenance Manual must be stored in its special pouch close to the machine, protected from liquids and anything else that could compromise its legibility.
ON CONSIGNMENT OF THE MACHINE
When the machine is consigned to the customer, an immediate check must be performed to ensure all the material mentioned in the shipping documents has been received, and also to check the machine has not
su󰀨ered damage during transportation. If this is the case, the carrier must ascertain the extent of the damage at once, informing our customer service o󰀩ce. It is only by prompt action of this type that the missing
material can be obtained, and compensation for damage successfully claimed.
INTRODUCTORY COMMENT
Any oor scrubbing machine can only work properly and e󰀨ectively if used correctly and kept in full working order by performing the maintenance operations described in the attached documentation. We therefore
suggest you read this instruction booklet carefully and read it again whenever di󰀩culties arise while using the machine. If necessary, remember that our assistance service (organised in collaboration with our
dealers) is always available for advice or direct intervention.
IDENTIFICATION DATA
For technical assistance or to request replacement parts, always give the model, the version and the serial number (written on the relevant plate).
TECHNICAL DESCRIPTION
The Optima is a oor scrubbing machine that can handle a wide variety of oors and types of dirt by using the mechanical action of two cylindrical brushes and the chemical action of a water-detergent solution. As
it advances, it collects the dirt that has been removed and the detergent solution not absorbed by the oor.
The machine must only be used for this purpose.
INTENDED USE
This scrubbing machine was designed and built for the cleaning (scrubbing and drying) of smooth, compact ooring in the commercial, residential and industrial sectors by a qualied operator in proven safety
conditions. The scrubbing machine is not suitable for cleaning rugs or carpet oors. It is only suitable for use in closed (or at least covered) places.
ATTENTION: The machine is not suitable for use in the rain, or under water jets.
IT IS FORBIDDEN to use the machine for picking up dangerous dusts or inammable liquids in places with an explosive atmosphere. In addition, it is not suitable as a means of transport for people
or objects.
SAFETY
Operator cooperation is paramount for accident prevention. No accident prevention programme can be e󰀨ective without the full cooperation of the person directly responsible for machine operation. The majority of
occupational accidents that happen either in the workplace or whilst moving are caused by failure to respect the most basic safety rules. An attentive, careful operator is most e󰀨ective guarantee against accidents
and is fundamental in order to implement any prevention programme.
REGULATIONS
All references to forwards and backwards, front and rear, right and left indicated in this manual should be understood as referring to the operator in a driving position with his hands on the steering wheel.
12

SERIAL NUMBER PLATE
The serial number plate is located at the rear of the steering column, and indicates the machine's general characteristics, including its serial number. The serial number is a very important piece of information and
should always be provided together with any request for assistance or when purchasing spare parts. The serial number plate contains the following:
1. The weight of the batteries used to power the appliance (expressed in Kg).
2. The IP protection rating of the appliance.
3. The gross weight of the appliance (expressed in Kg).
4. The identication code of the appliance.
5. The serial number of the appliance.
6. The name of the appliance.
7. The nominal power consumed by the appliance (expressed in W).
8. The maximum grade that the appliance can handle during work activities (expressed in %).
9. The year in which the appliance was manufactured.
10. The nominal voltage of the appliance (expressed in V).
11. The commercial name of the appliance and the manufacturer's address.
11
10
9
8
7
6
1
2
3
4
5
TECHNICAL DATA (INTERNATIONAL SYSTEM) U/M OPTIMA 90BS
Rated power W 3340
Working width mm 870
Squeegee width mm 1120
Working capacity, up to m2/h 6960
Diameter and width of front brush Ø mm x mm 150 x 855
Diameter and width of rear brush Ø mm x mm 210 x 865
Front brush rotations rpm 810
Rear brush rotations rpm 590
Electrical characteristics of the brush motor V/W 24 / 1500
Maximum weight of the brushes kg 86
Electrical characteristics of the traction motor V/W 24 / 1000
Maximum forward speed Km/h 8
Maximum gradient with full load % 10
Electrical characteristics of the vacuum motor V/W 24 / 420
Suction vacuum (hole Ø0) mbar 85
Solution tank volume l 156
Recovery tank volume l 138
Detergent tank volume (version with dosing system only) l 5
Debris hopper volume l 10
Turning circle mm 1010
Maximum machine length (without bumper kit) mm 1796
Maximum machine height (without roof) mm 1005
Maximum machine width (without squeegee) mm 900
Battery Compartment Dimensions (Length x Width x Height) mm 430x630x470
Rated battery voltage V 24
Battery hopper weight kg 238
Machine weight kg 363
Transported machine weight kg 620
Machine weight in running order kg 895
Sound pressure level (ISO 11201) dB (A) 65.4
Uncertainty KpAdB (A) 1.5
Body vibration level m/s2< 0.5
SPECIAL EQUIPMENT
Each design is created with the aim of giving the customer a new reason to choose Comac spa products, this type of scrubbing machines in particular can be equipped with the following devices:
• ECO-MODE: a device that decreases the noise level and lowers energy consumption.
The paragraphs in the document that talk about the following equipment will have the wording “ECO-MODE”.
• COMAC DOSING SYSTEM: this is the dosing system for the separate management of water and detergent, and allows you to increase or reduce the delivery depending on the dirt to be treated.
The paragraphs in the document that talk about the following equipment will have the wording “CDS”.
• PRESSURE MONITORING: a system that monitors the power dispensed by the brush motors in order to guarantee maximum e󰀨ectiveness on any type of oor.
The paragraphs in the document that talk about the following equipment will have the wording “PM”.
• COMAC FLEET CARE: system that allows the remote control of machines status: if, when and where each machine is operating or if maintenance is needed, to let you promptly intervene avoiding machine
downtimes and unexpected costs for extraordinary maintenance.
13

BRUSH TYPE
MACHINE CODE QTY ØEXTERNAL TYPE OF
BRISTLE NOTES
OPTIMA 90BS
439098 1 150 mm PPL 0.7 WHITE FRONT BRUSH
439099 1 150 mm PPL 1 BLACK FRONT BRUSH
404628 1 210 mm PPL 0.7 WHITE REAR BRUSH
404630 1 210 mm PPL 1 BLACK REAR BRUSH
404631 1 210 mm ABRASIVE REAR BRUSH
TECHNICAL DATA (IMPERIAL SYSTEM) U/M OPTIMA 90BS
Rated power W 3340
Working width in 34.25
Squeegee width in 44.09
Working capacity, up to sq.ft/h 74916.81
Diameter and width of front brush Ø in x in 5.91 x 33.66
Diameter and width of rear brush Ø in x in 8.27 x 34.06
Front brush rotations rpm 810
Rear brush rotations rpm 590
Electrical characteristics of the brush motor V/W 24 / 1500
Maximum weight of the brushes lb 189.6
Electrical characteristics of the traction motor V/W 24 / 1000
Maximum forward speed mph 4,97
Maximum gradient with full load % 10
Electrical characteristics of the vacuum motor V/W 24 / 420
Suction vacuum (hole Ø0) mbar 85
Solution tank volume gal 34.32
Recovery tank volume gal 30.36
Detergent tank volume (version with dosing system only) gal 1.1
Debris hopper volume gal 2.2
Turning circle in 39.76
Maximum machine length (without bumper kit) in 70.71
Maximum machine height (without roof) in 39.57
Maximum machine width (without squeegee) in 35.43
Battery Compartment Dimensions (Length x Width x Height) in 16.93x24.8x18.5
Rated battery voltage V 24
Battery hopper weight lb 524.7
Machine weight lb 800.28
Transported machine weight lb 1366.87
Machine weight in running order lb 1973.14
Sound pressure level (ISO 11201) dB (A) 65.4
Uncertainty KpAdB (A) 1.5
Body vibration level m/s2< 0.5
14

PREPARATION OF MACHINE
HANDLING THE PACKAGED MACHINE
Gross weight of machine with packaging is:
• Optima 90BS= 410 Kg or else 904 lb
The overall dimensions of the package are:
• A= 1130 mm or 44.49 in
• B= 1880 mm or 74.02 in
• C= 1627 mm or 64.06 in
ATTENTION: It is recommended that all the packaging components be kept for any future machine transportation.
ATTENTION: Move the packaged product with handling equipment that complies with legal requirements regarding size and mass of the packaging.
HOW TO UNPACK THE MACHINE
The machine is shipped in specic packaging. To remove it, proceed as follows:
1. Place the lower part of the outer packaging in contact with the oor.
N.B.: Use the pictograms printed on the box as a reference.
2. Remove the outer package.
WARNING: The machine is contained in specic packaging materials, whose elements (plastic bags, staples, etc.) can pose potential hazards, and must not be left within reach of children, disabled persons, etc.
CAUTION:These operations must be carried out using protective gloves to avoid any possible contact with the edges or tips of metal objects.
3. Insert a ramp in the rear part of the machine.
ATTENTION: The ramp gradient must not be such as to cause damage to the machine as it comes down.
4. The machine is fastened to the platform with wedges, remove these wedges.
5. Take the machine o󰀨 the pallet via the ramp.
CAUTION: During this operation, check there are no people or objects near the machine.
HOW TO MOVE THE MACHINE
To transport the machine safely, proceed as follows:
1. Check to make sure that the solution tank and the recovery tank are empty. If this is not the case, empty them (see the sections titled “EMPTYING THE SOLUTION TANK” and “EMPTYING THE
RECOVERY TANK”).
2. Place the machine on the transport vehicle.
WARNING: Secure the device according to the directives in force in the country of use (ex. 2014/47/EU), so that it cannot slide or tip over.
MACHINE SAFETY
The procedure for securing the machine, thus allowing the operations to be performed under conditions of complete safety, is as follows:
1. Check that the recovery tank is empty, otherwise read paragraph “EMPTYING THE RECOVERY TANK”.
2. Sit on the driver’s seat.
3. Insert the key (1) into the main switch (2) on the control panel. Bring the main switch (2) to position “I” by turning the key a quarter turn clockwise (Fig. 1).
4. Use the i-drive command knob (3) (Fig. 2) to select the “transfer” program (A) (Fig. 3).
N.B.: In this way, both the brush head body and the squeegee body will move to their idle position.
5. Bring the main switch to its “0” position by turning the key (1) a quarter turn anti-clockwise (Fig. 4). Remove the key from the main switch.
6. Unhook the tank rotation latch (4) (Fig. 5) and turn the recovery tank into the maintenance position (Fig. 6).
7. Disconnect the battery connector from the machine's main system connector (Fig. 7).
8. Rotate the recovery tank into the working position (Fig. 8). Block the rotation with the latch (4) (Fig. 5).
1 4 5 62 3
1 1
2 2
4
3 A
ON OFF
7 8
TYPE OF BATTERY TO BE USED
The batteries must meet the requirements laid out in the norms: DIN/EN 60254-2 and IEC 254-2-2 (L range).
To carry out the work well the machine must have a 24V power supply, we recommend using a 24V 320Ah/C5 traction battery box.
BATTERY MAINTENANCE AND DISPOSAL
For battery maintenance and recharging, respect the instructions provided by the battery manufacturer.
When the batteries reach the end of their working life, they must be disconnected by expert, trained personnel then removed from the battery compartment with the aid of suitable lifting devices.
N.B.: Dead batteries are classied as dangerous waste and as such must be delivered to an authorised body for disposal.
15

RECHARGING THE BATTERIES
The batteries must be charged prior to the rst use, and when they don't provide enough power for tasks that could formerly be performed without di󰀩culty.
ATTENTION: To avoid any permanent damage to the batteries, it is essential to avoid their complete discharge; begin recharging them within a few minutes of noting the “discharged batteries” signal.
ATTENTION: Never leave the batteries completely run down, even if the machine is not being used.
To recharge the batteries, proceed as follows:
1. Bring the machine to the battery recharging area.
N.B.: Park the machine in an enclosed place, on a at and level surface; near the machine there must be no objects that could either damage it, or be damaged through contact with it.
WARNING: The battery recharging area must comply with the requisites of Standard CEI EN 50272-3, or those currently in force in the country of use.
2. Check that the recovery tank is empty, otherwise read paragraph “EMPTYING THE RECOVERY TANK”.
3. Sit on the driver’s seat.
4. Insert the key (1) into the main switch (2) on the control panel. Bring the main switch (2) to position “I” by turning the key a quarter turn clockwise (Fig. 1).
5. Use the i-drive command knob (3) (Fig. 2) to select the “transfer” program (A) (Fig. 3).
N.B.: In this way, both the brush head body and the squeegee body will move to their idle position.
6. Bring the main switch to its “0” position by turning the key (1) a quarter turn anti-clockwise (Fig. 4). Remove the key from the main switch.
7. Unhook the tank rotation latch (4) (Fig. 5) and turn the recovery tank into the maintenance position (Fig. 6).
8. Disconnect the battery connector from the machine's main system connector (Fig. 7).
ATTENTION: The following operations must be carried out by qualied personnel. An incorrect connection of the connector may cause problems with machine functioning.
9. Connect the external battery charger cable to the battery connector.
N.B.: The coupling connector of the battery charger is consigned inside the bag containing this instruction booklet, and must be assembled on the cables of the battery charger as indicated in the instructions.
CAUTION: Before connecting the batteries to the battery charger, make sure it is suitable for the batteries used.
CAUTION: Carefully read the Use and Maintenance Manual of the battery charger used for recharging.
CAUTION: Keep the battery inspection carter open for the duration of the battery recharging cycle to allow gas fumes to escape.
10. When the recharge cycle is complete, disconnect the external battery charger cable from the battery connector.
11. Connect the battery connector to the machine's main system connector.
12. Rotate the recovery tank into the working position (Fig. 8). Block the rotation with the latch (4) (Fig. 5).
1 4 5 62 3
1 1
2 2
4
3 A
ON OFF
7 8
FILLING THE SOLUTION TANK WITH WATER
Before lling the solution tank, carry out the following steps:
1. Take the machine to the usual place for lling the solution tank.
2. Perform the procedure for securing the machine (see the section titled “SECURING THE MACHINE”).
3. Check to make sure that the solution tank drainage cap (1) is closed. If this is not the case, close it (Fig. 1).
4. Check to make sure that the water system's lter cap (2), located on the front left-hand side of the machine, is closed, and close it if necessary (Fig. 2).
5. Fill with clean water, at a temperature no higher than 50°C (122°F) and no lower than 10°C (50°F).
6. Check the water level through the tube (3) located under the operator's seat (Fig. 3).
The tank can be lled with water in the following ways:
A) lling through the side inlet:
• Remove the cap (4) on the side of the machine (Fig. 4), ll the solution tank using a hose or a bucket.
• Before lling the tank, check that the lter (5) is correctly positioned above the inlet (Fig. 4).
B) lling through the quick lling pipe:
• Remove the ller pipe (6) from its housing (Fig. 5), remove the closure cap (7) and insert inside the water ller pipe.
• Remember to remove the cap (4) so the air can be properly vented.
N.B.: The ller pipe (6) supports the water ller pipe.
C) lling through the optional quick lling kit:
• Remove the cap (8) positioned above the quick coupling (9) (Fig. 6), insert the water ller pipe into the quick coupling.
• Remember to remove the cap (4) so the air can be properly vented.
1 5 62 3 4
17 9
6 8
2
3 4
5
16

DETERGENT SOLUTION
After lling the solution tank with clean water add the liquid detergent to the tank in the concentration and manner indicated on the detergent manufacturer's label.
To prevent the formation of an excessive amount of foam that could damage the vacuum motor, use the minimum percentage of detergent required.
CAUTION: Protective gloves should always be worn when handling detergents or acidic or alkaline solutions, to avoid serious injury to the hands.
ATTENTION: Always use detergents whose manufacturer's label indicates their suitability for scrubbing machines. Do not use acid or alkaline products or solvents without this indication.
N.B.: Always use low-foam detergent. To avoid the production of foam, put a minimum quantity of antifoam liquid in the recovery tank before starting to clean. Do not use pure acids.
For versions with automatic management system of chemical products, ll the solution tank with clean water and then proceed as follows:
1. Bring the machine to the area designated for relling the solution tank.
2. Make sure the machine has been secured (see the section titled “SECURING THE MACHINE”).
3. Unhook the tank rotation latch (1) (Fig. 1) and turn the recovery tank into the maintenance position (Fig. 2).
4. Disconnect the male insert (2) from the female insert (3) present on the cap (4) for the detergent tank (5) (Fig. 3).
NOTE: Before pulling on the male insert, push the lever on the female insert.
5. Gripping the handle (6) on the detergent canister (5), remove the canister from the compartment in the solution tank (Fig. 4).
6. Remove the cap (4) from the detergent canister (5) Fig. 5).
7. Fill the canister with the desired detergent, as shown on the label supplied with the appliance.
CAUTION: Protective gloves should always be worn before handling detergents or acidic or alkaline solutions, to avoid serious injury to the hands.
N.B.: Always use low-foam detergent. To avoid the production of foam, put a minimum quantity of antifoam liquid in the recovery tank before starting to clean. Do not use pure acids.
ATTENTION: Always use detergents whose manufacturer's label indicates their suitability for scrubbing machines. Do not use acid or alkaline products or solvents without this indication.
ATTENTION: The dosing system is suitable for frequent maintenance cleaning. Acid or alkaline maintenance detergent tank be used with pH values between 4 and 10 and that do not contain: oxidising agents,
chlorine or bromine, formaldehyde, mineral solvents. The detergents used must be suitable for use with scrubbing machines. Wash the circuit with water after use if the system is not used daily. The system
can be excluded. In case of sporadic use of detergents with pH between 1-3 or 11-14, use the oor scrubbing machine in the traditional way by adding the detergent in the clean water tank and excluding the
dosing circuit.
8. Make sure you tighten the cap (4) properly to avoid any leakage of liquid while working. Make sure the detergent suction lter (7) is correctly positioned on the bottom of the canister (Fig. 6).
9. Gripping the canister handle (6), place the canister (5) back in its compartment inside the solution tank (Fig. 7).
ATTENTION: Position the detergent canister (8) as shown in gure (Fig. 7). To help, refer to the label located near the water system pumps support box.
10. Connect the male insert (2) to the female insert (3) in the cap (4) of the detergent canister (5) (Fig. 8).
11. Turn the recovery tank until it is closed in the working position (Fig. 9), tighten the tank rotation latch (1) in order to prevent accidental rotation.
1 3 4 5 62
1
2 3
5 4 6 5
4 7
87 9
2 3
5 4
6
ASSEMBLING THE SQUEEGEE BODY
For packaging reasons, the squeegee body comes disassembled from the machine. To assemble it on the squeegee body support, proceed as follows:
1. Perform the procedure for securing the machine (see the section titled “SECURING THE MACHINE”).
CAUTION: These operations must be carried out using protective gloves to avoid any possible contact with the edges or tips of metal objects.
2. Unscrew the knobs (1) in the squeegee body pre-assembly (Fig. 1).
3. Insert the right pin (2) on the squeegee body into the right slit (3) in the squeegee support (Fig. 2), making sure that the washer and spring adhere to the top of the squeegee support.
4. Repeat the same operation for the left knob.
5. Tighten the knobs (1), ensuring that the washer and spring adhere to the top part of the squeegee support (Fig. 3).
6. Insert the vacuum tube (4) in the sleeve (5) in the squeegee body (Fig. 4).
N.B.: Although the squeegee comes pre-adjusted, it is nevertheless recommended to read the section titled “ADJUSTING THE SQUEEGEE BODY'S RUBBER BLADES”.
1 3 42
1 1 4
5
3
2
17

USER SEAT ADJUSTMENT
The proper adjustment of the driving position provides a greater sense of comfort when using the machine.
Seat backrest adjustment: Make sure you sit upright and that your back and that your lower back and spine are at 90°. Use the lever (1) located on the left side of the seat (Fig. 1) to adjust the backrest of the
seat.
Driving position adjustment: The seat should always be positioned using the pedals as a reference. Act on the lever (2) located on the lower part of the seat (Fig. 2) to adjust the seat sitting.
N.B.: The distance should be adjusted so that with the pedals fully pressed to the oor the knees are slightly bent (about 120°).
N.B.: Adjust the distance of the seat so that when pressing the brake pedal it goes as far as it can. This operation should be done with the machine running so as to pressurise the braking system.
N.B.: If the knee is not bent enough, it is too far from the steering wheel, if however the knee is bent almost 90°then it is too close to the steering wheel.
N.B.: The feet should be positioned keeping the heels on the footrest, the sole of the foot directly below the ngers should push the pedals.
N.B.: The ideal driving position is that which allows you to grip the steering wheel correctly with the palms slightly lower than the shoulders. With a good grip on the steering wheel, the elbows should be
bent by about 120°. They should be at least 30 cm or 11.81 in between the middle of the steering wheel and our breastbone. In any case, this distance should be no more than 45 cm or 17.72 in.
Adjusting the armrests (optional): The armrests should be inclined to make using the machine comfortable.
N.B.: To adjust the armrest use the runner (3) under it (Fig. 3).
N.B.: Taking the right armrest as a reference, if the wheel is turned outwards the inclination of the armrest is increased. Taking the left armrest as a reference, if the wheel is turned inwards the inclination of
the armrest is increased.
Wear the seatbelt correctly (optional): The machine has a sub-abdominal safety device that allows the operator to be anchored to the driver's seat. To secure the safety belt, rst of all you need to be sitting in the
drier's seat, take the mobile part (4) of the belt, wrap it round the abdomen and insert the mobile part () in the slit in the xed part (5) (Fig. 4).
N.B.: Adjust the horizontal part of the belt so it is as tight as possible on the pelvis. The belt should be pulled and put as low as possible on the pelvis bone, and not on the belly.
1 2 3 4
1
2
3 4
5
PREPARING TO WORK
Before beginning to work, it is necessary to:
1. Make sure the recovery tank is empty. If this is not the case, empty it (read “EMPTYING THE RECOVERY TANK”).
2. Check that the amount of detergent solution in the solution tank is su󰀩cient for the type of work to be performed. If it isn't, top up the solution tank (see “FILLING THE SOLUTION TANK WITH WATER”
and “DETERGENT SOLUTION”). Check the level tube (1) located near the operator's seat (Fig. 1).
3. Check the rubber squeegee blades are in good working condition. If they aren't, replace them (see “REPLACING THE SQUEEGEE BODY RUBBER BLADES”).
4. Check the brush is in good working condition. If it isn't, replace it (see “REPLACING THE BRUSH HEAD BODY BRUSHES”).
5. Check that the machine is o󰀨, otherwise set the main switch (2) to “0” by turning the key a quarter turn anti-clockwise (Fig. 2). Remove the key from the instrument panel.
6. Unhook the tank rotation latch (3) (Fig. 3) and turn the recovery tank into the maintenance position.
7. Connect the battery connector to the machine's main system connector.
ATTENTION: This process must be carried out by qualied personnel.
8. Rotate the recovery tank into the work position. Block the rotation with the latch (3).
9. Check that the solution tank drainage pipe cap (4) is closed. If this is not the case, close it (Fig. 4).
10. Make sure the cap of the recovery tank drainage tube (5) is closed. If it isn't, close it (Fig. 5).
11. Make sure the water system lter cap (6) is closed. If it isn't, close it (Fig. 6).
2 3
2
3
OFF
4 5 6 1
4
56
1
12. Make sure the vacuum tube (7) is correctly connected to the sleeve (8) in the squeegee body. If it isn't, connect it (Fig. 7).
13. Check that the recovery tank cover is correctly positioned, otherwise position it correctly in the upper part of the recovery tank.
7
7
8
18

STARTING WORK
To start working, do as follows:
1. Make all the checks listed in “PREPARING TO WORK”.
2. Sit in the driver's seat, to adjust the driving position read paragraph “USER SEAT ADJUSTMENT”.
3. Move the main switch (1) to position “I” and turn the key a quarter turn clockwise (Fig. 1).
4. When the display comes on, three screens appear in sequence:
• The rst screen displayed indicates the logo of the manufacturer of the machine.
• The second screen displayed indicates the name of the machine.
• The third screen displayed (Fig. 2) indicates the characteristics of the machine's programming.
• The forth screen displays (Fig. 3) identies the work panel.
5. Select the movement direction using the selector switch (2) (Fig. 4).
6. Select one of the following work functions (Fig. 6) by means of the knob (3) (Fig. 5):
A. Transfer
B. Drying
C. Scrubbing with drying
D. Scrubbing without drying
7. Press the forward movement pedal (4) (Fig. 7) to begin moving the machine.
1
7
2
3
1
4
ON
4 5 6
2
3
D
C
B
A
Transfer function:
The machine can be moved from one work area to another with the selector switch in transfer mode. The only main actuator active is that of the traction hub
motor.
Drying function:
With the selector in drying mode it is possible to dry the previously washed portion of the oor. The main actuators active are those of the traction hub motor
and the vacuum motor. When the drive pedal is pressed, the squeegee is brought into working position (in contact with the oor) and the vacuum motor will
start working in full working order. If the machine is stopped and the drive pedal is released during the operation, the squeegee body will remain in contact
with the oor for a few seconds, after which it will raise up from the ground to go back to its rest position. For all these phases the vacuum motor will continue
to operate, only after a few seconds that it has returned to its work position will it switch o󰀨, this is to allow the motor to collect all the liquid in the vacuum
hose. During these phases, the symbol of the vacuum motor on the instrument panel display will blink, and it will only stop when the squeegee is in its rest
position and the vacuum motor is o󰀨. If reverse is carried out with this program active, the squeegee will move to the rest position, the vacuum motor will
keep working for a pre-set time and then it will switch o󰀨.
Scrubbing with Drying function:
With the selector in the scrubbing with drying mode it is possible to both scrub and dry the oor at the same time. The main actuators active are those of
the traction hub motor brush head gearmotors and vacuum motor. When the drive pedal is pressed, both the brush head and the squeegee will move to the
working position, and as soon as it is in contact with the ground the brush head gearmotors and the vacuum motor start working in full working order. If the
machine stops and the foot pedal is released during the operation, the brush head body will start to rise to return to the rest position, and after a period of
time the gearmotors will switch o󰀨. The squeegee body will stay in contact with the oor for a few seconds, after which it will raise up from the ground and
return to its rest position. For all these phases the vacuum motor will continue to operate, only after a few seconds that it has returned to its rest position will
it switch o󰀨, this is to allow the motor to collect all the liquid in the vacuum hose. During these phases, the symbol of the vacuum motor on the instrument
panel display will blink, and it will only stop when the squeegee is in its rest position and the vacuum motor is o󰀨. If reverse is carried out with this program
active, the squeegee will move to the rest position, the vacuum motor will keep working for a pre-set time and then it will switch o󰀨.
Scrubbing without drying function:
With the selector in scrubbing without drying mode, it is possible to scrub the oor without vacuuming the detergent solution applied. The main actuators
active are those of the traction hub motor and the brush head gearmotors. When the drive pedal is pressed, the brush head will move to the working position,
and as soon as it is in contact with the ground the brush head gearmotors start working in full working order. If the machine stops and the foot pedal is
released during the operation, the brush head body will start to rise to return to the rest position, and after a period of time the gearmotors will switch o󰀨.
The drying without scrubbing operation should only be carried out if the machine was previously used to carry out a
scrubbing without drying operation.
19

WATER FLOW ADJUSTMENT FUNCTION
The water ow function in the machine's water system is regulated by the button (1) on the control panel (Fig. 1).
By pressing the button (1) for the rst time, you can display in the control display the status of the water ow set in the machine
at that precise moment (Fig. 2), each time the button (1) is pressed, the water level increases, and the ow rate will be
zeroed once the maximum level is reached. The water ow rate changes by pressing the button again, there are 8 selectable
levels (also counting the zero level). If the button (1) is kept pressed for more than three seconds, the water ow rate in the
machine's water system is reset.
The water ow rate level refers to the ow delivered at maximum machine speed, at intermediate speeds, the ow is reduced
and is proportional to the value set.
1
2
1
DETERGENT SOLUTION FLOW ADJUSTMENT FUNCTION (CDS VERSION)
The detergent solution ow function in the machine's water system is regulated by the button (1) on the control panel (Fig. 1).
By pressing the button (1) for the rst time, you can display in the control display the status of the detergent solution ow set
in the machine at that precise moment (Fig. 2), each time the button (1) is pressed, the detergent percentage increases, and
the ow will be zeroed once the maximum percentage is reached. The detergent solution percentage changes by pressing the
button again, there are 8 selectable levels (also counting the zero level). If the button (1) is kept pressed for more than three
seconds, the ow of detergent solution in the machine's water system is reset.
3
4
2
ECO-MODE FUNCTION
When the “ECO MODE” function is activated, by means of the appropriate key (3) on the control panel (Fig. 5), the speed of
the brushes' gearmotor and of the vacuum motor is reduced, in this way the energy consumption is reduced.
The Eco-mode function can only be used with working programs: drying; scrubbing with drying and scrubbing without drying.
When the eco-mode function is active the symbols of the vacuum motor (4) or the brush (5) or both, depending on the working
program selected, will be shown on the control display as shown in the gure (Fig. 6).
5
6
3 4
5
BUZZER
When button (6) on the control panel (Fig. 7) is pressed continuously it activates the buzzer on the machine.
If the button (6) is pressed during the reverse movement, as a signal priority, only the intermittent buzzer connected to the reverse will be heard.
7
6
DIPPED HEADLIGHTS
The default machine has two sidelights at the front of the nose that are activated when the machine is turned on.
Pressing the button (10) on the control panel (Fig. 12) activates the machine's dipped beam headlights, pressing the button again, the headlights will switch o󰀨.
12
10
MOVEMENT SPEED ADJUSTMENT
When the button (7) on the control panel (Fig. 8) is pressed it allows to adjust the speed of machine's movement, the level
selected can be viewed by looking at the symbol (8) on the control display (Fig. 9).
Each time the button (7) is pressed, the speed level of the machine's movement is increased, once the maximum level has
been reached, the speed will start again from the rst level. Pressing the button subsequently changes the movement speed of
the machine, there are 3 selectable levels (50% - 75% - 100%).
the reverse speed is lower than the forward speed to comply with current health and safety standards.
8
9
7
8
EXTRA-PRESSURE FUNCTION EXERTED ON THE BRUSHES
The extra-pressure function applied to the brushes is adjusted by means of the button (9) on the control panel (Fig. 10).
By pressing the button (9) for the rst time, you can display in the control display the level of extra-pressure exerted on the
brushes at that precise moment (Fig. 11), each time the button (9) is pressed, the extra-pressure level increases, and the
extra-pressure will be zeroed once the maximum level is reached. The extra-pressure changes by pressing the button again,
there are three selectable levels (also counting the zero level). If the button (9) is kept pressed for more than three seconds,
the extra-pressure is reset.
The set level is displayed with the weight symbol above the brush symbol in the control display.
10
11
9
HOUR METER
Through the control display, in the screen after switching on, it is possible to view the hours of work performed by the machine in the central part of the
screen (Fig. 13).
The rst line shows the total time the machine (11) has been used and the second line indicates the partial time of the use of the machine (12).
N.B.: The numbers followed by the letter “h” identify the hours, while the numbers followed by the letter “m” identify the tenths of an hour (a tenth of
an hour corresponds to six minutes).
13
11
12
20
