COLLABORATE® Versa™ Room CT 160
Quick-Start Guide

COLLABORATE® Versa™ Room CT 160
1QSG-0169-001v1.0 May 2023
Quick-Start Guide
Notices
© 2023 ClearOne, Inc. All rights reserved.
Information in this document is subject to change without notice.
Document: QSG-0169-001v1.0, May 2023
1. Read, follow, and keep all instructions.
2. Do not use these devices near water.
3. Clean only with dry cloth.
4. Do not block any ventilation openings. Install in accordance with manufacturer instructions.
5. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that
produce heat.
6. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the
other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your
safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.
7. Protect the PoE injector’s power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the
point where they exit from the apparatus.
8. Only use attachments/accessories specified by the manufacturer.
9. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.
10. Unplug this apparatus during lightning storms or when unused for long periods of time.
11. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as
power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate normally, or has been dropped.
12. Disconnect the apparatus from the AC mains with the mains plug. This plug shall remain readily operable.
13. Never push objects of any kind into this product through cabinet slots as they may touch dangerous voltage points or short out
parts that could result in fire or electric shock.
14. This product can interfere with electrical equipment such as tape recorders, TV sets, radios, computers and microwave ovens if
placed in close proximity.
15. Class 2 Wiring IS REQUIRED. Only qualified personnel should wire and install.
16. Underwriters Laboratories (UL) requires these safety notifications:
Important Safety Information
ClearOne®Contacts
Headquarters Headquarters
5225 Wiley Post Way Suite 500 Tel: +1.801.975-7200
Salt Lake City, UT 84116
Sales Technical Support
Tel: [phone] Tel: [phone]
[email protected] [email protected]

COLLABORATE® Versa™ Room CT 160
2QSG-0169-001v1.0 May 2023
Quick-Start Guide
Operating Requirements
System Power and Thermal
• Power Type: PoE/PoE+
• Port Type: RJ-45
• PoE In/P-Link In: 802.3af or 802.3at PoE/PoE+
• Power Source: PoE Injector or equivalent
• PoE: IEEE 802.3at compliant devices providing 56V and 640 mA (36 W).
• P-Link In - Mode B
Power Consumption
• 100-240VAC, 50/60Hz, 3 Watts Typical
• 38W at max power 1kHz (2 x 10W)
• Thermal: 130 BTU/Hr at max power
• Operating Temperature: 14° F/-10° C to 104° F/40° C ambient temperature
System Part Number
• 930-3200-020-U - COLLABORATE Versa Room CT
• 930-3200-020-I - COLLABORATE Versa Room CT INTL
Packing List
Verify that you have received all parts associated with each of the following components:
Inspect your shipment carefully.
If the shipment shows obvious signs of damage, retain original boxes and packing material for inspection by the carrier,
and contact the carrier immediately.
ClearOne is not responsible for product damage incurred during shipment.
1. BMA CTH
2. Versa USB
3. PoE (Injector) Kit
4. CONVERGE®Versa Hub
5. UNITE 160 4K Camera
6. Ceiling Loudspeakers
7. Cables
WARNING: TO
PREVENT FIRE
OR
ELECTRICAL
SHOCK
HAZARD, DO
NOT EXPOSE
THIS
PRODUCT TO
RAIN OR
MOISTURE
THE LIGHTING FLASH
AND ARROWHEAD
WITHIN THE TRIANGE IS
A WARNING SIGN
ALERTING YOU OF
DANGEROUS VOLTAGE
INSIDE THE PRODUCT.
THE EXCLAMATION POINT
WITHIN THE TRIANGLE IS A
WARNING SIGN ALERTING
YOU OF IMPORTANT
INSTRUCTIONS
ACCOMPANYING THE
PRODUCT.
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER (OR BACK)
NO USER SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
SEE MARKING ON BOTTOM/BACK OF PRODUCT
RISK OF ELECTRIC SHOCK DO
NOT OPEN
AVIS RISQUE DU CHOC ELECTRIQUE
- NE PAS OUVRIR
Use only in
non-tropical
locations.
Use only at
altitudes of
2000 meters
or less.
CAUTION

COLLABORATE® Versa™ Room CT 160
3QSG-0169-001v1.0 May 2023
Quick-Start Guide
3. PoE (Injector) Kit
CAT6 cable,
Black, 25 ft. (1)
CAT6 cable,
Blue, 25 ft. (1)
Power
cord, 6 ft.
Power
supply
4. COLLABORATE Versa Hub
Versa Hub
Power
supply
DVI-VGA
adapter USB 3.0 Cable Type
B to Type A, 3ft
Does not require a Quick-Start Guide
5. UNITE 160 4K Camera
USB 3.0 Cable Type
C to Type A, 5ft
Power Supply
Includes UNITE 160 Camera Quick-Start Guide
6. Ceiling Loudspeakers (2)
7. Cables
CAT6 cable,
50 ft. (1)
USB extender
cable, 33 ft.
Includes installation
instructions and ceiling tile
cutout template
1. BMA CTH
BMA CTH Plenum
shield (1)
2. Versa USB
Versa USB USB Cable
600-to-625
mm adapter
(4)
Camera

COLLABORATE® Versa™ Room CT 160
4QSG-0169-001v1.0 May 2023
Quick-Start Guide
Basic Versa Room CT 160 Connections
The steps listed below and the accompanying illustration describe how to connect your Versa Lite.
1. Connect the PoE injector to the
Versa USB PoE In port.
2. On the Versa USB, move the
Power Select switch to the PoE
In position.
3. Connect the Versa USB P-Link
Out port to the BMA CTH P-Link
In port.
4. On the BMA CTH, move the
Power Select switch to the
P-Link In position.
5. Connect the Versa USB Audio
port to a Versa Hub USB port.
6. Connect the Versa Hub’s USB
In port to your PC’s USB port.
Mount the Components
BMA - CTH
1. On the BMA CTH back panel, do the following:
• With speaker wire (not included), connect the two loudspeakers to the Phoenix Euroblock connectors (a)
• Move the Power Select sliding switch (b) to the right, towards the P-Link In connector (c)
2. Complete the steps indicated in the BMA Surface Mount Kit Installation Guide
adc
b

COLLABORATE® Versa™ Room CT 160
5QSG-0169-001v1.0 May 2023
Quick-Start Guide
Required Tools
Bottom Side of a Table Top Mount
Select your hardware based on your specific installation needs.
1. Determine the location for the Versa Hub.
2. Use a pencil to mark on the table the location of four mounting holes
that align with the mounting holes on the Versa USB mounting ears.
3. Determine the proper depth and diameter for the holes.
4. Drill four pilot holes for #6 or M3.5 screws.
5. Align the mounting holes on the Versa USB mounting ears with the
pilot holes.
6. Use four #6 or M3.5 screws to attach the Versa Hub to the table.
• No. 1 Phillips screwdriver
• T15 Torx screwdriver
• Level (to level the Versa USB)
• Drill bits appropriate for anchors
• Electric drill
• Drywall saw (for cutting hole in wall or ceiling)
Wall Mount
Select your hardware based on your specific installation needs.
1. Determine location for the Versa USB.
2. Use a pencil to mark on the table the location of four mounting holes that align with the mounting holes on the
Versa USB mounting ears. If needed, use a level.
3. With the proper size drill bits, drill four pilot holes for fasteners/anchors.
4. Install the fasteners/anchors in the wall.
5. Align the mounting holes on the Versa USB mounting ears with the pilot holes.
6. Use four #6 or M3.5 screws to attach the Versa Hub to the wall.
Note: Anchors and screws to mount the Versa USB are not provided. The installer must select them for the wall
material that supports the unit. Exercise care when you drill and install anchors so wall material does not tear out
and weaken the attachment.
Versa USB
You can mount the Versa USB in the following ways:
Note: Mounting hardware such as screws and anchors are not included with the Versa USB.
Standard Equipment Rack Mount
ClearOne offers a standard 1U rack shelf with 20 lb (9kg) weight capacity.
1. Determine location for rack shelf.
2. Align mounting holes on rack shelf mounting ears with holes on the rack (at determined location).
3. Insert the four #10-32 screws included with the ClearOne 1U rack shelf (or proper screws for your third-party
mount) and tighten.
Note: Remove pre-installed mounting ears on expander to fit up to 3 Versa USB units side-by-side on a single
ClearOne 1U rack shelf.
4. Torx drive screws secure the pre-installed mounting ears to the main body of
the Versa USB. Remove them with a Torx T15 screwdriver. (optional)
5. Secure the Versa USB to the rack shelf. You must supply your own hardware
(four #6 or M3.5 screws) for securing the Versa USB.
• Standard equipment rack
• Bottom side of a table top
• On a wall
• Above the ceiling

COLLABORATE® Versa™ Room CT 160
6QSG-0169-001v1.0 May 2023
Quick-Start Guide
Mount the Versa Hub, UNITE 160 4K Camera, and Ceiling Loudspeakers
Follow the instructions in the respective Quick-Start or Installation Guide (included).
Above the Ceiling Mount
Select hardware based on your specific installation needs.
Note: It is the installer’s responsibility to ensure that the installation and cable routing complies with local safety
codes.
1. Determine location for the mount, and where to route cables.
Mark location where you want to route cables through with a pencil (on finished side of ceiling tile) if you need to
cut a hole.
2. Remove affected ceiling tile and adjacent tiles required for access.
3. Install fasteners/anchors.
4. Install the Versa USB at determined location.
5. Use a drywall saw to cut a hole into finished side of ceiling tile at marked location.
6. Route the cables through the hole.
Note the following:
• Carefully run connected cables so they do not block the cooling vents or put strain on the connectors.
• Anchors and screws used to mount the Versa USB are not provided and must be selected by installer for the
type of ceiling material supporting the unit. Take care while drilling and installing anchors so ceiling material
does not tear out and weaken attachment.
Connect the Components
Warning:
Power over Ethernet (PoE) equipment used with Xceed BMA Room must meet the IEEE 802.3af or 802.3at
standards.
You should use the PoE Power Injector provided with Xceed BMA Room. Other power source equipment may
immediately apply power and could damage the Xceed BMA Room components.
Complete step 1 NOW if you did not when you installed the BMA CTH with the surface mount kit.
1. On the BMA CTH back panel, do the following:
• With speaker wire (not included), connect the two loudspeakers to the Phoenix Euroblock connectors (a)
• Move the Power Select sliding switch (b) to the right, towards the P-Link In connector (c)
2. On the Versa USB, set the Power select switch (h) towards PoE In.
adc
b
ef
g
h
i

COLLABORATE® Versa™ Room CT 160
7QSG-0169-001v1.0 May 2023
Quick-Start Guide
3. With a 50’ CAT6 cable (provided), connect the BMA CTH P-Link In connector (c) to the Versa USB P-Link Out
connector (g).
4. Optional
If your system includes a Bluetooth expander (available separately), complete this step.
If not, skip this step and proceed to step 5.
With a CAT6 cable (not included):
Connect the BMA CTH P-Link Out connector (d) to the Bluetooth Expander.
5. With one of the included 25 ft. CAT6 cables, connect
the Versa USB PoE In connecter (i) to the PoE injector
connector (j).
6. With the provided USB cable, connect the Versa USB Audio connector (e) to the Versa Hub USB connector (m)
(any one of the four).
7. As needed, use the provided 33 ft. USB extender cable to connect the UNITE camera to the Versa Hub connector
(l) (either of the two).
8. Connect the Versa Hub 12 VDC power connector (k) to a standard power outlet.
9. Caution: Complete this connection step only after you confirm that you correctly completed the previous steps!
With the PoE Injector:
• Attach the power cord to the power supply.
• Connect the power cord to a standard power outlet.
j
klm
