QUICK-START GUIDE
1
COLLABORATE ROOM PRO AND
THE COLLABORATE MICROPHONE
The COLLABORATE Microphone is a three microphone device that
provides high-quality audio to a COLLABORATE Room Pro.
The COLLABORATE Microphone connects to the COLLABORATE Room
Pro with a USB cable to a standard USB port.
The latest version of the COLLABORATE Pro firmware and the
COLLABORATE Room Pro Installation and Setup Guide can be found on
the ClearOne website at:
http://www.clearone.com/resources#media_collaboration

COLLABORATE ROOM PRO AND
THE COLLABORATE MICROPHONE
2
COMPONENTS INCLUDED
The COLLABORATE Room Pro with COLLABORATE Microphone bundle.
COLLABORATE Room Pro 510/610
930-401-862 (510) or
930-401-872 (610)
COLLABORATE Room
Pro 510 or 610 codec
with power supply and
remote control
910-2100-001
UNITE™100 PTZ
camera, power supply,
DVI-I to HDMI cable
and RS232 cable
910-401-205
COLLABORATE
Microphone
910-0002-004
IR Receiver with 6
ft. cable

QUICK-START GUIDE
3
MAKING THE CONNECTIONS
Connect the COLLABORATE microphone to the COLLABORATE Room
Pro with a USB connection.
ConneCtion Diagram

COLLABORATE ROOM PRO AND
THE COLLABORATE MICROPHONE
4
auDio output ConneCtion options
There are three audio output options, accessed from the back of the
COLLABORATE Room Pro, for connecting the audio.
1. Balanced Audio output to an amplifier that is connected to speakers
2. Line output to powered speakers
3. HDMI output to the monitor receiving the signal
Balanced Audio Output
HDMI Combined Video
and Audio Output
Line Audio Output
Audio optimization procedures to for each of the output options is
detailed later in this guide.

QUICK-START GUIDE
5
USING THE COLLABORATE MICROPHONE WITH
THE COLLABORATE ROOM PRO
When connected, the COLLABORATE Microphone will appear as an audio
source within the COLLABORATE Room Pro user interface.
Volume & mute
Volume is controlled through the volume up/down buttons on the
COLLABORATE Microphone unit or from COLLABORATE Room Pro user
interface.
Mute is controller by pressing on the microphone mute button on the
COLLABORATE Microphone unit or through your COLLABORATE Room
Pro. When muted, the microphone LED’s will change from blue to red.

COLLABORATE ROOM PRO AND
THE COLLABORATE MICROPHONE
6
