Clevertronics CleverEVAC L10 UltraBlade Pro Dynamic Red Installation and operating instructions

1942417
V1.5
16 February 2023
Testing:
Once connected to the 240V mains supply, the unit must be allowed to charge the battery for at least 24
hours. Conduct the following tests:
•For the first test, the emergency lamp must remain illuminated for at least 2 hours (4hrs for -4HR
fittings) after disconnection from the mains supply.
•Subsequent tests require the unit to illuminate for at least 90 minutes. The results of all tests are
required to be recorded in a service logbook, which is to be kept on-site at all times. If the unit fails to
remain illuminated for the requisite time, remedial action must be taken to repair the situation and
once completed, the unit must pass a subsequent test. For more specific information, please refer to
the current edition of the AS/NZS 2293.2 and AS/NZS 60598.2.22 Standards.
•Press and hold Test Button, the product will go into Dynamic Red mode for the initial 60 seconds of
the test button being pressed and then switch to Dynamic Green.
NOTE: Initiating a Function or Duration test using the Zoneworks Software will trigger the Dynamic Red
Mode for 60 seconds then Dynamic Green for completion of the test.
Networking:
When installing the product on a monitored network, (ZONEWORKS, HIVE, DATA, DALI) simply insert the
relevant Smart Node PCA.
Trouble Shooting:
Below are a list of common problems and their possible causes.
Fault: The Green LED Test Switch indicator is not illuminated.
Check: A.C. is connected and is turned on.
Battery is connected
Test Switch for damage.
Fault: Lamp does not illuminate in emergency mode.
Check: A.C. is connected.
Lamp is correctly inserted.
Battery is connected
Fault: Lamp illuminates in emergency mode, but only stays on for a short period.
Check: Battery has been allowed to charge for at least 24 hours.
Battery for damage.
Fault: The Dynamic Green is not sequencing.
Check: The 24 Volt/VF control is connected and turned on.
Polarity of 24V control.
Check that the correct interface control is selected.
Fault: The Dynamic Red is not illuminated.
Check: The 24 Volt/VF control is connected and turned on.
Polarity of 24V control.
Check that the correct interface control is selected.
Check that the Dynamic Red is activated on the dip switches.
Rated Emergency Lumen Output in accordance with AS2293.1 (refer to
spacing tables for installation positions):
Please refer to the technical label on the product for classification.
Warranty:
For Product Warranty information and Terms and Conditions of Sales please refer to our website
http://clevertronics.com.au/terms-conditions-sale-australia-nz
L10™UltraBlade Pro Dynamic Red
Installation & Maintenance Instruction Leaflet
Victoria (Head Office &
Manufacturing)
Website: www.clevertronics.com.au
Email: [e-mail]
Phone: [phone]
Fax: [phone]
New South Wales
Phone: [phone]
Fax: [phone]
Queensland
Phone: [phone]
Fax: [phone]
South Australia/Northern Territory
Phone: [phone]
Fax: [phone]
Western Australia
Phone: [phone]
Fax: [phone]
New Zealand
Phone: [phone]
Designed in Australia to comply with the requirements of
AS2293.3:2005(when not activated in the dynamic green or red
cross mode) and AS/NZS CISPR22: 2009
Note: AS2293.3 Compliance not applicable to -RU and -RD
Products
Models:
DYRL-xUP-uu-vv-ww-xx-yy-zz
Testing:
Options:
Zoneworks
xx = ZW
Running man
yy=R
Z/W DATA
xx = DATA
Running man with right arrow
yy=RR
Zoneworks HIVE
xx = HV/HVG
Running man with left arrow
yy=RL
Running man with Up arrow
yy=RU
Normally Open
xx=NO
Running man with down arrow
yy=RD
Normally Closed
xx=NC
Dynamic Green Disabled
uu=DDG
Activated Only by Fire
Panel
xx=AOFP
Theater Mask
vv=TH
Weatherproof
x=W
SoundEscape module
ww=SND
4 Hour run time
zz = 4HR
Spare Parts:
1530050
Replacement Battery (Extra for -4HR)
1530250
Replacement Battery
AUM01570070001
Replacement Emergency Driver
AUM01970160001
Replacement Emergency Driver (-HVG)
Important:
It is illegal for anyone, except for a licensed electrician to install or maintain this product. Before installation, ensure
that the electricity supply has been switched off and isolated. Installation must be carried out in accordance with
the relevant Australian and International Standards.
Clevertronics Pty Ltd is a vendor of CleverEVAC products. It is not a fire engineer or designer. It does not
purport to recommend its products for use in any particular application or to achieve any particular outcome.
Purchasers and users of its products must take their own steps to ensure compliance with statutory
requirements, safe practice and suitable application of the products

1942417
V1.5
16 February 2023
Installation:
The L10 UltraBlade Pro Dynamic Red is a recessed ceiling mount fitting. The UltraBlade Pro Dynamic Red
can be attached directly to any solid surface, or to a ceiling tile. The Fitting comes with an attached Flex
and Plug. Please follow the steps below to install the Exit:
•Create a cut-out (350mm x 70mm) in the mounting surface.
•Remove the Fire Panel Input terminal block by disengaging the clip. Refer to Image below.
•Route the power cord to the mains connection and connect the 240VAC supply.
•Route 24/VF control cables through the access hole and connect to the terminal block as per next
step.
•Connect positive signal of RED activation to I2and negative signal to C (Common).
•Connect positive signal of GREEN activation to I1and negative signal to C (Common).
•Reinstall the terminal block.
•Insert the Fitting into the ceiling cavity tighten the (4) clamping screws.
•Alternately, fix the Fitting to a solid surface using (4) screws through the surface material.
•Install the cover plate, Apply power to the fitting and test.
•To disable the Dynamic Green mode coming on in Emergency mode Set dipswitch 1 to OFF
position.
NOTE: For the Dip Switch setting to take effect the power and battery will need to be
disconnected and reconnected.
Dynamic Red 24 Volt (24V)/Volt Free (VF) Operation and Testing
Activation of the Dynamic Red/Green is controlled via 24V/VF control interface. The fitting comes pre-set
as normally OFF. This is switched via an intelligent circuit inside the fitting. This is controlled by the
24V/VF input from a fire panel or other source. If you would like to change the activation of the Dynamic
Red/Green from Normally OFF to Normally ON change the Dip Switch no.2 (RED)/ no.3 (GREEN) found
next to the fire Panel Input terminal block
Selecting the Type of the Interface
The fitting comes pre-set to the Volt Free(VF) control interface, to change this to 24V you will have to
change the switch from VF to 24V found next to Fire Panel Input Terminal Block. Please see image
below.
Zoneworks, HIVE (HV/HVG) and DATA Monitored Options
Luminaires with part numbers having -ZW, -HV, -HVG, -DATA are fitted with Zoneworks communications
modules (nodes). These fittings are monitored using either Powerline Carrier Technology that utilises the
power cable to provide data communication or a dedicated data cable to/from data routers installed on a
dedicated data trunk connected to a central Server (can also be connected via Ethernet/Internet/Fibre).
Zoneworks software on the server is used to monitor, coordinate testing and collate test data from each
fitting and can be commissioned by scanning of the supplied barcode. The LED Test Switch indicator
provides a multifunction indication of the status of the luminaire during testing and normal operation:
Option
State
LED Operation
ZW, HV, HVG,
DATA
Commissioned
LED on Solid (Green)
ZW, DATA
Un-commissioned
Batt plugged-in: Amber 1s, green 1s
Batt unplugged: red 1s, off 1s
HV, HVG
Un-commissioned
With network connectivity
Batt plugged-in: Amber 1s, green 1s
Batt unplugged: red 1s, off 1s
HV, HVG
Un-commissioned
Without network connectivity
Batt plugged-in: Amber 250mS, green
250mS,Amber 250mS, green 250mS,
green 1s
Batt unplugged: red 250mS, off
250mS, red 250mS,off 250mS, off 1s
ZW, DATA
Emergency Light Test In Progress
LED flashes at Amber 5s ,0ff 1s
HV, HVG
Emergency Light Test In Progress
LED flashes at Amber 1s , 0ff 1s
In the case of the DATA version a 2-way “figure 8” cable and terminal block facilitates the connection to
the DATA network via a multi-drop bus (daisy chain connection). For further information of installation of
a Zoneworks system, please refer to the Zoneworks Users Guide and Commissioning Guide (incl. DATA
version)
Caution:
On many building sites, power circuits may be cut off in an uncontrolled and repetitive basis during
construction. As a result, any Exit & Emergency Units, on these circuits, will have their batteries
discharged or “cycled”. The Li-ion battery in this fitting has been selected to give excellent long life
performance in a controlled AS/NZS 60598.2.22 testing environment. Excessive battery cycling will
reduce through-life performance and may lead to premature battery failure. Battery warranty claims, as a
result of such abuse, are specifically EXCLUDED from Clevertronics warranty terms.
