Clevertronics L10 LUBPRO Series Installation and operating instructions

1943039
V1.1
21 March 2019
Zoneworks and DATA Monitored Options
Ultrablades with part numbers LUBPRO-ZW, LUBPRO-DATA are fitted with Zoneworks communications
modules (nodes).These fittings are monitored using either Powerline Carrier Technology that utilises the
power cable to provide data communication or a dedicated data cable to/from data routers installed on a
dedicated data trunk connected to a central Server (can also be connected via Ethernet/Internet/Fibre).
Zoneworks software on the server is used to monitor, coordinate testing and collate test data from each
Ultrablade and can be commissioned by a single push of the test switch, or scanning of the supplied
barcode. The LED Test Switch indicator provides a multifunction indication of the status of the Ultrablade
during testing and normal operation:
State LED Operation
Commissioned LED on Solid (Green)
Un-commissioned LED flashes at 0.5Hz (0.5s Green, 0.5s Yellow)
Emergency Light Test In Progress LED flashes at 3s On (Yellow) & 0.5s Off
In the case of the DATA version a 2-way “figure 8” cable and terminal block facilitates the connection to
the DATA network via a multi-drop bus (daisy chain connection). For further information of installation of
a Zoneworks XT system, please refer to the Zoneworks Users Guide and Commissioning Guide (incl.
DATA version)
DALI EM Option
Ultrablades with part numbers LUBPRO-DALI are fitted with DALI modules (nodes) that facilitate
connection and integration to 3rd Party Lighting Control Systems. Before installing the LUBPRO-DALI
please confirm that the Lighting Control System has the capability to monitor DALI Emergency Luminaires.
The LUBPRO-DALI will be addressed and configured into the control system by the Lighting Control
System Commissioning Technicians and not Clevertronics.
State
LED Operation
Commissioned/ Un-commissioned LED on Solid (Green)
Emergency Light Test in progress LED flashes at 1s On (Yellow) & 1s Off
“IDENTIFY COMMAND” Fitting goes into emergency mode for 10 seconds
A 2-way “figure 8” cable and terminal block facilitates the connection to the DALI network. DALI
connections are marked as Da Da.
Clevertest and Clevertest Plus
Refer to the supplementary operation guide supplied with the Product.
After Power ON, the Status LED on a Clevertest Plus enabled fitting will display a rapid Green or Red
flashing for a period up to 2 minutes.
Caution:
On many building sites, power circuits may be cut off in an uncontrolled and repetitive basis during
construction. As a result, any Ultrablade Units, on these circuits, will have their batteries discharged or
“cycled”. The Li-ion battery in the Ultrablade has been selected to give excellent long life performance in
a controlled IEC 60598-2-22 testing environment. Excessive battery cycling will reduce through-life
performance and may lead to premature battery failure. Battery warranty claims, as a result of such
abuse, are specifically EXCLUDED from Clevertronics warranty terms.
L10™ Ultrablade Pro Recessed LED Exit
Installation & Maintenance Instruction Leaflet
NOTE: Standard product codes with this symbol
are enabled with Clevertest Plus capability. Please refer to the
operation guide supplied with the product for details.
Australia (Head Office)
195 Chesterville Rd
Moorabbin VIC 3189
Phone: [phone]
E-Mail: [e-mail]
IP20
UK OFFICE
362 Stockley cl
West Drayton UB7 9BL
Models:
LUBPRO-xx
Testing Options:
Manual Test
xx = Blank
Zoneworks
xx = ZW
Z/W DATA
xx = DATA
DALI Comp.
xx = DALI
Clevertest
xx = CT
(NOTE: -CT Products supplied with the Clevertest Plus Symbol are activated with Clevertest PLUS
capability. Please refer to the operation guide supplied with the product for details).
Spare Parts:
1530050
BATT: L10 3.3V 2500mAh 70mm lead, no BRKT.
8002178
PCA: UBP LED strip PCB Assy (CT10602-D3)
UKM01370030001
LUBPRO-CKIT-70, Ultrablade Pro, Control Only, L10
Important:
It is illegal for anyone, except for a licensed electrician to install or maintain this product. Before installation,
ensure that the electricity supply has been switched off and isolated. Installation must be carried out in
accordance with the relevant British Standards.

1943039
V1.1
21 March 2019
Installation:
The L10 Ultrablade Pro LED Exit (LUBPRO) is a recessed ceiling mount fitting. The LUBPRO can be
attached directly to any solid surface, or to a ceiling tile with the integrated clamping mechanisms. The
LUBPRO comes with an attached Flex. Please follow the steps below to install the LUBPRO Exit:
•Create a cut-out (350mm x 48mm) in the mounting surface.
•Route the power cord to the mains connection and connect the 240VAC supply.
•Insert the LUBPRO into the ceiling cavity tighten the (4) clamping screws.
•Alternately, fix the LUBPRO to a solid surface using (4) screws through the surface material.
•Install the cover plate.
•Apply power to the fitting and test.
•If the external flexible cable or cord of this luminaire is damaged, it shall be exclusively replaced by
the manufacturer or his service agent or a similar qualified person to avoid a hazard.
•This luminaire contains non-user replaceable light source and battery.
•Terminal block not included. Installation may require advice from a qualified person.
•Recommended specifications of terminal block for connecting leads:
−Type of Terminal: Screw Terminal
−Number of Terminals: 2-Pin
−Rated Voltage: 250 V
−Rated Connecting Capacity: 10A
•If the CTP capabilities are activated, please affix the CTP Status Label to a visible surface.
Networking:
When installing the product on a monitored network, (ZONEWORKS, DATA, DALI) simply insert the
relevant Smart Node PCA.
Dimensions:
Luminaire Dimensions: 380mm x 220mm
Cover Plate: 385mm x 67mm
Ceiling Cut-out: 350mm x 48mm
Minimum Depth 80mm
Changing EXIT Legend Inserts
:
The Ultrablade Pro Exit comes with an assortment of standard legends.
1. To remove the legend, grasp the centre of the bottom trim piece and pull down slightly to expose the legend
edge. See photo.
2. Grasp the bottom edge of the legend and slide the existing legend out of the blade, while working the edges out
along the sides.
3. Slide the new legend into the blade, ensuring to fit the edges into the sides then slide the legend to the top of the
blade. Insert one bottom corner then the other. Slide the legend down into the bottom trim.
Testing Procedure:
When the unit is connected to the un-switched active, it must be allowed to charge the battery for at
least 24 hours. Conduct the following tests:
•The emergency lamp must illuminate for at least 180 min after disconnection from the mains. The
results of all tests are required to be recorded in a service logbook, which is to be kept on-site at all
times. If the unit fails to illuminate for the requisite time, remedial action must be taken to repair the
situation and once completed, the unit must pass a subsequent test.
•Press and hold Test Button or switch Off Mains Supply, check that the emergency lamp is On.
•Release the Test Button or Switch On Mains Supply, check that the emergency lamp is Off (Non-
maintained operation).
Ultrablade Maintenance:
LED Lamp Replacement:
•Use only the LED Strip recommended in the
Spares Parts list of this instruction.
•Disconnect battery from LED driver pack and
cut cable tie to remove.
•Disconnect the signal cable from LED strip,
loosen screw and remove the mains driver
pack.
•Remove 4 self-tapping screws and unclip the
LED strip.
•Install the new LED strip following the above
procedure in reverse.
Battery Replacement:
•Use only the battery recommended in the
Spares List on this instruction.
•Remove the cable ties holding the battery,
un-plug the lead from the battery connector
remove the old battery.
•Plug the new battery into the battery
connector.
•Secure the battery using suitable cable ties
Trouble Shooting:
Below are a list of common problems and their
possible causes.
Fault: The Green LED Test Switch indicator
is not illuminated.
Check: A.C. is connected and is turned on.
Battery is connected
Test Switch for damage.
Fault: Lamp does not illuminate in
emergency mode.
Check: A.C. is connected.
Lamp is correctly inserted.
Battery is connected
Fault: Lamp illuminates in emergency
mode, but only stays on for a short
period.
Check: Battery has been allowed to charge for
at least 24 hours.
Battery for damage.
Warranty:
For Product Warranty information and Terms and Conditions of Sales please refer to our website
https://clevertronics.com.au/warranty-statement/
