Clevertronics LP Argonaut PLUS Installation and operating instructions

1948874
V1.6
14 June 2022
Instruction Sheet Template - V1.3 –Updated 20/01/2022
Clevertest and Clevertest Plus
Refer to the supplementary operation guide supplied with the Product.
4HR: CTP will only test for the 2 hours (first test) and 90 minutes duration. 4 hours testing would only be
facilitated as a Manual Discharge Test.
Zoneworks, HIVE (HV/HVG) and DATA Monitored Options
Fittings with part numbers -ZW, -HV, -HVG, -DATA are fitted with Zoneworks communications modules
(nodes). These fittings are monitored using either Powerline Carrier Technology that utilize the power
cable to provide data communication, RF transceiver modules operating in the ISM band or a dedicated
data cable to/from data routers installed on a dedicated data trunk connected to a central Server (can also
be connected via Ethernet/Internet/Fibre). Zoneworks software on the server is used to monitor,
coordinate testing and collate test data from each fitting. Zoneworks Fittings can be commissioned by a
single push of the test switch or by scanning the supplied barcode. The LED Test Switch indicator provides
a multifunction indication of the status of the fitting during testing and normal operation:
Option
State
LED Operation
ZW, DATA,
HVG, HV
Commissioned
LED on Solid (Green)
ZW, DATA
Un-commissioned
Batt plugged-in: yellow 1s, green 1s
Batt unplugged: red 1s, off 1s
HV, HVG
Un-commissioned
With network connectivity
Batt plugged-in: yellow 1s, green 1s
Batt unplugged: red 1s, off 1s
HV, HVG
Un-commissioned
Without network connectivity
Batt plugged-in: yellow 250mS, green 250mS,
yellow 250mS, green 250mS, green 1s
Batt unplugged: red 250mS, off 250mS, red
250mS,off 250mS, off 1s
ZW, DATA
Emergency Light Test In Progress
LED flashes at yellow 5s , 0ff 1s
HV, HVG
Emergency Light Test In Progress
LED flashes at yellow 1s , 0ff 1s
In the case of the DATA version a 2-way “figure 8” cable and terminal block facilitates the connection to
the DATA network via a multi-drop bus (daisy chain connection). For further information of installation of
a Zoneworks system, please refer to the Zoneworks Users Guide and Commissioning Guide (incl. DATA
version)
DALI EM Option
Luminaires with part numbers having -DALI are fitted with DALI modules (nodes) that facilitate connection
and integration to 3rd Party Lighting Control Systems. Before installing the -DALI luminaire, please confirm
that the Lighting Control System has the capability to monitor DALI Emergency Luminaires. The -DALI
fitting will be addressed and configured into the control system by the Lighting Control System
Commissioning Technicians and not Clevertronics.
State
LED Operation
Commissioned/ Un-commissioned
LED on Solid (Green)
Emergency Light Test in progress
LED flashes at 1s On (Yellow) & 1s Off
“IDENTIFY COMMAND”
Lamp and Status LED Flash for 30 seconds
A 2-way “figure 8” cable and terminal block facilitates the connection to the DALI network. DALI
connections are marked as Da Da.
Caution:
On many building sites, power circuits may be cut off in an uncontrolled and repetitive basis during
construction. As a result, any Exit & Emergency Units, on these circuits, will have their batteries
discharged or “cycled”. The battery in this fitting has been selected to give excellent long-life
performance in a controlled AS2293 testing environment. Excessive battery cycling will reduce through-
life performance and may lead to premature battery failure. Battery warranty claims, as a result of such
abuse, are specifically EXCLUDED from Clevertronics warranty terms.
Argonaut PLUS Weatherproof Emergency LED Batten
Installation & Maintenance Instruction Leaflet
Victoria (Head Office & Manufacturing)
Website: www.clevertronics.com.au
Email: [e-mail]
Phone: [phone]
Fax: [phone]
New South Wales
Phone: [phone]
Fax: [phone]
Queensland
Phone: [phone]
Fax: [phone]
South Australia/Northern Territory
Phone: [phone]
Fax: [phone]
Western Australia
Phone: [phone]
Fax: [phone]
New Zealand
Phone: [phone]
Designed in Australia to comply with the
requirements of AS2293.3: 2018, AS CISPR15:
2017
Models:
ARGOPLUS-1200-xx-yy-zz-uu
Testing:
Options:
Manual Test
zz = Blank
Microwave Sensor (HI/LO)
xx = SEN
DALI Registered
zz = DALI
DALI Driver
xx = DD
Zoneworks
zz = ZW
Integrated Battery (non-POD)
yy = LP
Zoneworks HIVE
zz = HV/HVG
Emergency POD
yy = LPPOD
4 Hours run time
uu = 4HR
(NOTE: -CT Products supplied with the Clevertest Plus Symbol are activated with Clevertest PLUS
capability. Please refer to the operation guide supplied with the product for details).
Spare Parts:
1550050
Replacement Battery (POD only)
1550230
Replacement Battery (Non-POD only)
8003110
Replacement Emergency LED Board
8002752
Replacement 240V LED Strip
AUM02370050001
Replacement Emergency Driver
AUM02870450001
Replacement Emergency Driver (-SEN, -HV only)
AUM02970010001
Replacement Emergency Driver (-HVG)
AUM02870060001
Replacement Emergency Driver (-HV, -4HR)
1330092
Replacement 240V Driver
1330093
Replacement 240V Driver (-SEN)
1330151
Replacement 240V Driver (-DD)
Important:
It is illegal for anyone, exceptfor a licensed electrician toinstall or maintain this product. Before installation,
ensure that the electricity supply has been switched off and isolated. Installation must be carried out in
accordance with the relevant Australian and International Standards.
Note: This luminaire (with reinforced insulation between control/LED terminal and AC Supply) contains
non-user replaceable light source and battery –to be replaced (if required, refer installation instructions
for battery replacement) by the manufacturer or his service agent or a similar qualified person.

1948874
V1.6
14 June 2022
Instruction Sheet Template - V1.3 –Updated 20/01/2022
Installation:
The product can be mounted/suspended from any solid surface. Follow the below installation steps:
•Determine the installation and power entry method.
•Undo the Diffuser Clips, remove the Diffuser and Gear Tray. Position the batten base in the desired
location and Mark out the fixing points on the mounting surface.
•If the cable entry is to be via the rear of the body –Drill out a suitable entry-hole in the rear of the
batten body (must be suitably sealed after cable entry using a sealant). If the cable entry is via the
end of the batten - Install the provided cable gland, or bring in conduit, to the base as required for
the intended power access.
Note: Only round cables are to be used with the cable gland for an IP65 seal. Keep cable entry
straight and tension free. Ensure all seals are tight.
min. wire diameter 7mm, max. 12mm.
•For surface mounting -, there are 3 extrusions/posts at each end of the base. Drill out the desired
number of fixing points at each end. Fixings must only be through the extrusions/mounting
posts.
oPosition the fitting to the mounting surface and mark the mounting holes.
oCable/Gland entry to be down if mounting vertically.
oDrill the mounting holes.
oFix the base to the surface with appropriate fixings.
oSeal any penetrations/fixing points with appropriate sealant.
•For Surface Mount Clip mounting, measure/mark spacing (see Dimensions image), install
stainless steel clips to surface (use appropriate fixings), then snap batten into clips.
•For Suspension Mounting, measure/mark spacing (see Dimensions image), install suspension
device, E.G chain, and connect chain to batten base.
•Wire mains power cable, 240V 50Hz, to terminals marked Lsw (Switched Active), Lem
(Emergency/Unswitched Active), N & (and DALI Cables to terminals Da Da as applicable)
•Set Colour Switch to the desired colour (3000K / 4000K / 5700K, 4000K set as default)
•Attach Gear Tray to lanyards.
•Re-Install the Diffuser, close all the Diffuser Clips and secure with screws
•The Pod version of the luminaire should be positioned so that prolonged staring into the luminaire
at a distance closer than 330mm is not expected
Wiring:
Sensor Version:
Dimensions:
Driver Setting:. Colour Setting:
For non -SEN/-DD products For -DD products
Recommended currents are 350mA & 650mA for this product. Using settings outside of the recommended will void
warranty.
Battery Replacement (non-POD)
1. Prior to any work, isolate power to any Batten
that requires battery replacement
2. Open the Diffuser by releasing the Batten
Diffuser Clips
3. Remove Gear Tray by unclipping the Gear Tray
Clips on each side (ensure the Gear Tray is
supported while unlocking clips)
4. Remove Battery connector from the Emergency
Driver
5. Remove Battery by removing the
Screw/Washer/Nuts
6. Install replacement Battery/Screw/Washer/Nuts
and connect into Emergency Driver
7. Re-Install the Gear Tray onto the Gear Tray
Clips
8. Re-Install the Diffuser, close all the Diffuser
Clips and secure with screws
NOTE: For POD products refer to Instruction Sheet
for LP POD’s provided with product (1948146)
Testing:
Once connected to the 240V mains supply, the unit must be
allowed to charge the battery for at least 24 hours. Conduct
the following tests:
•For the first test, the emergency lamp must remain
illuminated for at least 2 hours (4 hours for -4HR
fittings), after disconnection from the mains supply.
•Subsequent tests require the unit to illuminate for at
least 90 minutes. The results of all tests are required to
be recorded in a service logbook, which is to be kept on-
site at all times. If the unit fails to remain illuminated for
the requisite time, remedial action must be taken to
repair the situation and once completed, the unit must
pass a subsequent test. For more specific information,
please refer to the current edition of the AS 2293.3
Standard.
•Press and hold Test Button or switch Off Mains Supply,
check that the emergency lamp is On.
•Release the Test Button or Switch On Mains Supply,
check that the emergency lamp is Off (Non-maintained
operation).
Trouble Shooting:
Below are a list of common problems and their possible causes.
Fault: The Green LED Test Switch indicator is not illuminated.
Check: A.C. is connected and is turned on.
Battery is connected
Test Switch for damage.
Fault: Lamp does not illuminate in emergency mode.
Check: A.C. is connected.
Lamp is correctly inserted.
Battery is connected
Fault: Lamp illuminates in emergency mode, but only stays on for a short period.
Check: Battery has been allowed to charge for at least 24 hours.
Battery for damage.
Rated Emergency Lumen Output in accordance with AS2293.1 (refer to spacing tables for
installation positions):
Refer to the Technical Label for classification information.
Warranty:
For Product Warranty information and Terms and Conditions of Sales please refer to our website
http://clevertronics.com.au/terms-conditions-sale-australia-nz/
