Clevertronics TS Trade Series Installation and operating instructions

1945028
V1.1
12 January 2022
Instruction Sheet Template - V1.2 –Updated 06/10/2021
THIS PAGE HAS BEEN INTENTIONALLY LEFT BLANK
Trade Series LIFELIGHT Surface Mount Emergency
Luminaire
Installation & Maintenance Instruction Leaflet
Victoria (Head Office & Manufacturing)
Website: www.clevertronics.com.au
Email: [e-mail]
Phone: [phone]
Fax: [phone]
New South Wales
Phone: [phone]
Fax: [phone]
Queensland
Phone: [phone]
Fax: [phone]
South Australia/Northern Territory
Phone: [phone]
Fax: [phone]
Western Australia
Phone: [phone]
Fax: [phone]
New Zealand
Phone: [phone]
Designed in Australia to comply with the requirements
of AS2293.3: 2005 and AS/NZS CISPR15: 2017
Models:
ELIFE-X-I-SM
Spare Parts:
1560160
BATT:EcoLith 3.2V 3.0Ah 170mm lead,NoBKT
8050176
HWSUB: CT10696-D1
8002986
PCA: ELIFE-X-SM-LI CT10614-L2
Important:
It is illegal for anyone, except for a licensed electrician to install or maintain this product. Before installation,
ensure that the electricity supply has been switched off and isolated. Installation must be carried out in
accordance with the relevant Australian and International Standards.

1945028
V1.1
12 January 2022
Instruction Sheet Template - V1.2 –Updated 06/10/2021
Installation:
The ELIFE-X-LI-SM is a Non-Maintained Surface Mount (SM) fitting that can be attached directly to any
solid surface (use appropriate fixings to suit the mounting surface). Please follow the steps below to install
the ELIFE- X-LI-SM:
•Remove the Lid from the Base by using a flat screwdriver to release the snap fits (see below)
•Cut/Drill out Cable Entry points (see image below)
•Drill out the required fixing holes on the Base (see image below)
•Mark holes on mounting surface (use drilled out holes on the Base as a template)
•Mount Base using appropriate fixings to ensure a secure installation (pre-drill holes if required)
•Insert Mains Cables through Cable Entry
•Terminate the Mains Cables into terminal block. Ensure Active, A & Neutral, N wires are connected
as per Terminal Block Label.
•Re-attach Lid Assembly, ensuring to align Mains Connector Pins into Terminal Block
Networking:
When installing the product on a monitored network, (ZONEWORKS, DATA, DALI) simply insert the
relevant Smart Node PCA.
Dimensions:
Lid Removal:
Testing:
When the unit is connected to the un-switched active, it must be allowed to charge the battery for at
least 24hours. The emergency lamp only illuminates during a power fail. Conduct the following tests:
•The emergency lamp must illuminate for at least 2 hours after disconnection from the mains. The
results of all tests are required to be recorded in a service logbook, which is to be kept on-site at all
times. If the unit fails to illuminate for the requisite time, remedial action must be taken to repair the
situation and once completed, the unit must pass a subsequent test.
•Press and hold Test Button or switch Off Mains Supply, check that the emergency lamp is On.
•Release the Test Button or Switch On Mains Supply, check that the emergency lamp is Off (Non
maintained operation)
Trouble Shooting:
Below are a list of common problems and their possible causes.
Fault: The Green LED Test Switch indicator is not illuminated.
Check: A.C. is connected and is turned on.
Battery is connected
Test Switch for damage.
Fault: Lamp does not illuminate in emergency mode.
Check: A.C. is connected.
Lamp is correctly inserted.
Battery is connected
Fault: Lamp illuminates in emergency mode, but only stays on for a short period.
Check: Battery has been allowed to charge for at least 24 hours.
Battery for damage.
Fault: Green LED flashes once every 5 seconds-Battery is disconnected
Check: Battery is connected
Fault: Green LED blinks off once every 5 seconds-Charging very flat battery
Check: Allow 20min to recover battery then re-check
Fault: Green LED flashes at 2Hz (Fast Flash)-Faulty Battery
Check: Replace battery
Rated Emergency Lumen Output in accordance with AS2293.1, not applicable
for –TH (theatre) version (refer to spacing tables for installation positions):
Refer to the Technical Label for classification information.
Caution:
On many building sites, power circuits may be cut off in an uncontrolled and repetitive basis during
construction. As a result, any Exit & Emergency Units, on these circuits, will have their batteries
discharged or “cycled”. The battery in this fitting has been selected to give excellent long-life
performance in a controlled AS2293 testing environment. Excessive battery cycling will reduce through-
life performance and may lead to premature battery failure. Battery warranty claims, as a result of such
abuse, are specifically EXCLUDED from Clevertronics warranty terms.
Warranty:
For Product Warranty information and Terms and Conditions of Sales please refer to our website
http://clevertronics.com.au/terms-conditions-sale-australia-nz/
