HDML-Cloner Box Turbo User Manual
This documentation describes how to use HDML-Cloner Box Turbo (Model: CA-988BT) device.
Copyright Notice
Copyright © ClonerAlliance Inc. All rights reserved
Documentation Version 1.10
No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system,
or translated into any language or computer language, in any form or by any means, electronic,
mechanical, magnetic, optical, chemical, manual, or otherwise, without the prior written permission
of ClonerAlliance Inc.
Trademarks
HDML® is a registered trademark of ClonerAlliance Inc.

Safety Notices
Before using HDML-Cloner Box Turbo, please ensure that
you read and understand the safety precautions below:
1. Do not attempt to open the case of HDML-Cloner Box Turbo or modify it
in any way, as this will void the warranty.
2. Keep HDML-Cloner Box Turbo away from water and other liquids, as
this may cause the unit to malfunction.
3. HDML-Cloner Box Turbo may become warm during use. This does not
indicate malfunction.
4. Do not place heavy objects on HDML-Cloner Box Turbo, as this may
cause the unit to overheat and malfunction.
5. If the exterior of HDML-Cloner Box Turbo requires cleaning, wipe it with
a soft dry cloth.
6. Do not dispose of the unit via conventional domestic waste.

Table of Contents
12
14
15
15
15
17
19
20
22
24
28
29
30
30
31
Getting Started
Box Contents
Product Layout
How to record videos to the USB storage device
Connect
Record/Capture
How to record videos to PC
System Requirements
Install HDML-Cloner Pro Helper
Connect
Register HDML-Cloner Pro Helper
Record/Capture
Schedule Recording
How to live stream videos with HDML-Cloner Box Turbo
Frequently Asked Questions
Supported Resolutions
Product Specifications
Microphone Function
Contact Us
Disclaimer
Index
1
1
2
7
7
8

a b c
de
Getting Started
Box Contents
a. HDML-Cloner Box Turbo b. HDMI Cable
c. Micro-USB to USB Cable d. Power Adapter
e. Quick Start Guide

Product Layout
1

8
2

ON/OFF: Press this button to switch on/switch off HDML-Cloner Box Turbo.
5V/2A: Plug the power adapter into this socket and power on HDML-Cloner Box Turbo.
3. IN: Connect an HDMI cable between the HDMI source device and HDML-Cloner Box Turbo.
OUT: Connect an HDMI cable between HDML-Cloner Box Turbo and TV.4.
5. Storage: Insert the USB flash drive or mobile hard disk and record videos to this
storage medium.
6. REC/STOP and 1080p/720p: Press this button to start or stop recording. If you press
and hold this button for a few seconds, it will work as a switch between 720p and 1080p.
7. MIC: Insert the microphone plug into this jack to input voice.
8. TO PC: Connect the Micro-USB to USB cable between PC and HDML-Cloner Box Turbo
1.
2.
for recording videos to PC. This function must be realized together with HDML-Cloner Pro
Helper.
3

How to record videos to the USB
storage device?
4
Connect
1. Connect the source video player to the "IN" port on HDML-Cloner Box Turbo via an HDMI
cable.
2. Connect HDML-Cloner Box Turbo from the "OUT" port to TV via an HDMI cable.
3. Connect the USB flash drive or mobile hard disk to the "Storage" port of HDML-Cloner Box
Turbo.
4. Plug the power adapter into the "5V/2A" port of HDML-Cloner Box Turbo and plug the other
end into the power socket.

*The USB flash drive is not included in the product box. You need to purchase it independently.
HDML-Cloner Box Turbo
②
③
POWER
④
①
STORAGE

Tips on selecting a proper USB flash drive:
1. Recommended brands: Toshiba, SanDisk, Kingston
2. Interface specifications: USB 2.0, USB 3.0
3. Connector type: Type A
4. Make sure the actual reading speed is not less than 30Mbps, and the writing speed is not less
than 10Mbps.
5. It is recommended that you format the USB flash drive or erase data before connecting it to our
product.
6. It is recommended that you use a USB flash drive with the LED indicator, so that you can
easily understand the working status of the USB flash drive. Don't unplug the USB flash drive in
the process of reading and writing, otherwise your data will be damaged.
7. FAT32 format is recommended. Due to the special properties of FAT32, the single video file
will be 2GB at most, and the recorded video will be split into multiple files but more stable (You
can use our bonus software MP4-Cloner from https://www.cloner-alliance.com/download.html to
combine them into one file easily). For NTFS, the recorded video will be stored as a single large
file, but will be more prone to error than FAT32, resulting in unsuccessful storage or file
corruption. Please contact our customer service for help when you encounter such problems.
Therefore, it is strongly recommended that you format the USB flash drive to FAT32 in order to
get a better experience.
8. After formatting the USB flash drive using PC, please make sure to safely remove the USB
device instead of unplugging it directly, otherwise the USB flash drive will be damaged and not
work properly.
9. If the recorded video is 0KB or cannot play back normally, please reformat your USB flash
drive.
14

1. Switch on HDML-Cloner Box Turbo. The LED light will illuminate solid Blue or Green.
2. Prior to gameplay or video playback, press the REC/STOP button. Start playing
game or video, then recording will start simultaneously. The LED light will blink Blue
or Green.
3. When gameplay or video playback is completed, press the REC/STOP button
again to stop recording.
4. The LED light will blink blue/green alternately several times. DO NOT remove the
USB device as the file is being saved. The LED light will illuminate Blue or Green
after the file is saved.
Record/Capture
11

IndicationLED Status
Solid Green
Solid Blue
Blink Blue/Blink Green
Blink Blue/Green alternately
The current video is 720p/others.
The current video is 1080p.
Recording
Buffering, please wait.
The LED light of HDML-Cloner Box Turbo will illuminate different colors/ways to indicate functions.
12

How to record videos to PC
System Requirements
Prior to installing HDML-Cloner Pro Helper, please make sure you are using Windows 7 or
later versions and your PC is equipped with USB 2.0 or USB 3.0 port.
Install HDML-Cloner Pro Helper
HDML-Cloner Pro Helper is a smart program to record video discs, game videos, homemade
videos or anything from any video source under Windows OS working together with HDML-
Cloner Box Turbo.
Please download the latest version of HDML-Cloner Pro Helper from our official website:
https://www.cloner-alliance.com/download.html
Note: Please don't connect HDML-Cloner Box Turbo to PC before installing the software, or
there will be a prompt "Unknown USB Device".
15

If the following window appears during the installation process, please select "Install", otherwise
HDML-Cloner Pro Helper will not work properly.
16

Connect
1. Connect the source video player to the "IN" port of HDML-Cloner Box Turbo via an HDMI cable..
2. Connect the Micro-USB to USB cable between the "To PC" port of HDML-Cloner Box Turbo and the
USB port of PC.
3. Plug the power adapter into the "5V/2A" port of HDML-Cloner Box Turbo and plug the other end
17
into the power socket.
STORAGE
PC
POWER
HDML-Cloner Box Turbo
Video
Player

After all devices have been connected properly, please power on all connected devices. The
Windows operating system will prompt "Found a new hardware" and install the driver
automatically. Please make sure "Full HD Capture Device" is installed successfully and appears
in the Device Manager (Right click My Computer – Manage – System Tools - Device Manager).
If "Full HD Capture Device" doesn't appear in the list, please reinstall HDML-Cloner Pro Helper
and try again.
18

Register HDML-Cloner Pro Helper
Please register HDML-Cloner Pro Helper first before using. With the trial version, you can only
use it for 7 days. Run HDML-Cloner Pro Helper. Click in the main interface and then click
the "Register" button. Click the "Input registration code" button to open the "Register" window.
Fill in your proper Email address, name and registration code. Then click "OK" to finish the
registration.

How to get the registration code of HDML-Cloner Pro Helper?
For more details about registering HDML-Cloner Pro Helper, visit the link below to read
step by step instructions.
https://www.cloner-alliance.com/hdmicloner-box-pro-faq/purchase-and-register-faq/how-
to-register-hdml-cloner-pro-helper.html
https://goo.gl/vHQelH
19
Scan the QR code below to register HDML-Cloner Box Turbo and get the registration code of HDML-
Cloner Pro Helper.
Scan QR code to register and
get FREE bundled softwares.
CEXXXXXXXX
