ClonerAlliance Flint D4P User Manual

ClonerAlliance Flint D4P User Manual
This documentation describes how to use ClonerAlliance Flint D4P (Model: CA-1480FPP) device.
Copyright Notice
Copyright © ClonerAlliance Inc. All rights reserved.
Documentation Version 1.0.0
No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any
language or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual,
or otherwise, without the prior written permission of ClonerAlliance Inc.
Trademarks
”ClonerAlliance” is a registered trademark of ClonerAlliance Inc.

Safety Notices
Before using ClonerAlliance Flint D4P, please ensure that you read and under-
stand the safety precautions below:
1. Do not attempt to open the case of ClonerAlliance Flint D4P or modify it in any
way, as this will void the warranty.
2. Keep ClonerAlliance Flint D4P away from water and other liquids, as this may
cause the unit to malfunction.
3. ClonerAlliance Flint D4P may become warm during use. This does not indicate
malfunction.
4. Do not place heavy objects on ClonerAlliance Flint D4P, as this may cause the unit
to overheat and malfunction.
5. If the exterior of ClonerAlliance Flint D4P requires cleaning, wipe it with a soft
dry cloth.
6. Do not dispose of the unit via conventional domestic waste.

CONTENTS
1Getting Started 1
1.1 Box Contents ...............................................................................1
1.2 Product Diagram.............................................................................2
2Software Installation 5
2.1 Install and register HDML-Cloner Pro Helper (Windows Users) .......................................5
2.2 Install OBS Studio (Windows, Mac, and Linux Users) ...............................................8
3OSD Status Information 10
3.1 Show up the OSD ............................................................................10
3.2 OSD Structure...............................................................................11
4Switching Display Mode 16
4.1 PIP Mode ..................................................................................17
4.2 POP Mode..................................................................................21
4.3 PMP Mode .................................................................................23
5Adjust and Mix Audio channels 25
6Record/capture videos to PC. 30
6.1 Connect ....................................................................................30
6.2 Record/Capture for Windows users ..............................................................35
6.3 Record/Capture for Mac OS users ...............................................................42
6.4 Record/Capture for Linux users .................................................................43
7Record/capture game console with PC. 50
7.1 Connect ....................................................................................50
i

7.2 Record/capture game console videos to PC ........................................................55
8Play game console on PC without TV 56
8.1 Connect ....................................................................................56
8.2 Play game console for Windows users ............................................................57
8.3 Play game console for Mac OS users .............................................................60
8.4 Play game console for Linux users...............................................................61
9Record/capture videos to mobile. 68
9.1 Connect ....................................................................................68
9.2 Record/Capture with ClonerAlliance App .........................................................70
10 Preview videos for live streaming. 74
10.1 Connect ....................................................................................74
10.2 Install software ..............................................................................75
10.3 Setting for preview video ......................................................................76
11 Frequently Asked Questions 81
12 Product Specifications 93
13 After Sales Warranty 94
14 Contact Us 95
15 Disclaimer 96

GETTING STARTED
1.1 Box Contents
a.
d.
e.
b. c.
• a. Remote Control
• b. ClonerAlliance Flint D4P
• c. User Manual
• d. HDMI cable
• e. Male Type-C to male USB 3.0 cable
1

ClonerAlliance Flint D4P User Manual
1.2 Product Diagram
1 2 3 4
1. LINE OUT: Insert the headphone plug into this jack to output the video sound.
2. MIC: Insert the microphone plug into this jack to input voice.
3. LINE IN: Stereo audio inputs.
4. IR Window: Receives the IR signal from the remote control.
1.2. Product Diagram 2

ClonerAlliance Flint D4P User Manual
65 7 8 9 10
5. HD2 IN 4K/30: Connect an HDMI cable with the input video up to 4K@30fps.
6. HD1 IN 4K/60: Connect an HDMI cable with the input video up to 4K@60fps.
7. EXT.AUDIO IN: Connect an audio cable between an external input audio source and ClonerAlliance Flint D4P if
needed. It’s an optional port.
8. OUT: Connect an HDMI cable between ClonerAlliance Flint D4P and TV.
9. TO PC: Connect a Type-C to USB cable between PC and ClonerAlliance Flint D4P for capturing videos to PC.
10. |O|O|: Receive serial control signal from PC. The port is only for the debug mode of ClonerAlliance Flint D4P. It’s an
optional port.
1.2. Product Diagram 3

ClonerAlliance Flint D4P User Manual
Power on/Power off.
Quick screen switching(HD1 and HD2).
Select HD1 as the input signal.
Select HD2 as the input signal.
PIP mode.
POP mode.
PMP mode.
Select HD1 audio for sound.
Select HD2 audio for sound.
Select EXT. audio for sound.
Switch output resolution settings(Only works when not connected to PC).
Switch screen size in PIP mode.
OK button.
Left button: moving left for PIP mode.
Right button: moving right for PIP mode.
Up button: moving up for PIP mode.
Down button: moving down for PIP mode.
Show Input and Output signal information.
Back button.
Volume down for main audio.
Volume up for main audio.
Mute or unmute for main audio.
Volume down for mic.
Volume up for mic.
Mute or unmute for mic.
Volume down for line in.
Volume up for line in.
Mute or unmute for line in.
Volume down for line out.
Volume up for line out.
Mute or unmute for line out.
Tips: The remote control is powered by 2 AAA batteries which are not included and need to be purchased independently.
1.2. Product Diagram 4

SOFTWARE INSTALLATION
2.1 Install and register HDML-Cloner Pro Helper (Windows
Users)
Tips:
For Windows users, HDML-Cloner Pro Helper or third party software like OBS, VLC, etc can be used with Flint D4P.
For Mac or Linux users, please download third party software like OBS Mac/Linux version accordingly to work with Flint
D4P.
1. Install HDML-Cloner Pro Helper
HDML-Cloner Pro Helper is a smart program to record video discs, game videos, homemade videos or anything from any
video source under Windows OS working together with ClonerAlliance products.
• Download HDML-Cloner Pro Helper software from https://static.cloner-alliance.com/download/hdml-cloner-pro.exe
• Double click the installation file and the setup wizard window will pop up. Follow the installation wizard to complete
the installation process. You do not have to restart your computer after the installation is complete.
5

ClonerAlliance Flint D4P User Manual
Note: Prior to installing HDML-Cloner Pro Helper, please make sure you are using Windows 7 or later versions and your
PC is equipped with USB 2.0 or 3.0 port.
2. Register HDML-Cloner Pro Helper
Please register HDML-Cloner Pro Helper first before using, otherwise it can only be used for 7 days. Launch HDML-Cloner
Pro Helper. Click ”Input registration code” button in the auto pop-up Register window. Fill in your proper Email address,
2.1. Install and register HDML-Cloner Pro Helper (Windows Users) 6

ClonerAlliance Flint D4P User Manual
real name and code. Then click ”OK” to finish the registration.
• Obtain the registration code of HDML-Cloner Pro Helper.
Scan the QR code below to get the code directly. Or visit https://www.cloner-alliance.com/register, fill in your product S/N.
You will get a registration code directly. It is advised that you input your correct email address to receive the registration
code at the same time. You may use the registration code, name and your email address to register HDML-Cloner Pro Helper.
MP4-Cloner will be registered automatically.
If you get trouble in the process, don’t be discouraged, just send us a message to [email protected] with your
S/N and your order ID. Our support will send you the code directly.
2.1. Install and register HDML-Cloner Pro Helper (Windows Users) 7

ClonerAlliance Flint D4P User Manual
(a)
Click.Here
FHXXXXXXXX
For more details about registering HDML-Cloner Pro Helper, visit here to read step by step instructions.
2.2 Install OBS Studio (Windows, Mac, and Linux Users)
Open Broadcaster Software is a Free and open source software for video recording and live streaming. Download and start
streaming quickly and easily on Windows, Mac or Linux.
Please install Open Broadcaster Software (OBS Studio) and run it on your computer.
Tip: You can click here to download Open Broadcaster Software (OBS Studio).
2.2. Install OBS Studio (Windows, Mac, and Linux Users) 8

ClonerAlliance Flint D4P User Manual
2.2. Install OBS Studio (Windows, Mac, and Linux Users) 9

OSD STATUS INFORMATION
3.1 Show up the OSD
Please press button on remote to display OSD. Please observe the color of ”HD1/HD2”, if it shows grey and the message
”In case of Black Screen” at the bottom, please press and hold ”OK” button on remote for a while until Flint D4P reboot.
Then confirm the color of ”HD1/HD2” on OSD turns to Green. It indicates the Flint D4P device is ready for work.
10

ClonerAlliance Flint D4P User Manual
3.2 OSD Structure
1. INPUT: Here shows the resolution of inputs which connected to D4P device
2. Overlay Position: It will show the overlay mode currently use
1. HD1 or HD2 as Display mode:
3.2. OSD Structure 11

ClonerAlliance Flint D4P User Manual
2. PIP as Display mode:
3.2. OSD Structure 12

ClonerAlliance Flint D4P User Manual
3. POP as Display mode:
3.2. OSD Structure 13

ClonerAlliance Flint D4P User Manual
4. PMP as Display mode:
3.2. OSD Structure 14

ClonerAlliance Flint D4P User Manual
Output for The Display Mode: It shows which Audio and Video Source you’re choosing for displaying. It will update after
you select Video and Audio channel on remote, please refresh the OSD menu by pressing button on remote.
3.2. OSD Structure 15
