Cloner Alliance HDMI Cloner Box User manual

SAFETY PRECAUTIONS
Before using HDMI-Cloner Box, please ensure that youreadandunderstandthe
safety precautions below.
Do not attempt to openthe case of HDMI-Cloner Box or modifyit in anyway, as
this will voidthe warranty.
Keep HDMI-Cloner Box away from water and other liquids, as this may
cause the unit to malfunction.
HDMI-Cloner Box maybecomewarm duringuse. This does not indicate
malfunction.
Do notplace heavyobjects on HDMI-Cloner Box ,as this maycause the unit to
overheat andmalfunction.
If the exterior of HDMI-Cloner Box requirescleaning, wipe it with asoft
drycloth.
Do notdispose of the unit via conventional domesticwaste.
14
12

PRODUCT DIAGRAM PRODUCT DIAGRAM
1
2
3
4
5
6
7
PowerON/OFF
DC input5V/2A
HDMI In*
HDMI Out*
USB 2.0 port(compatible with USB 3.0)
REC/STOPand720p/1080p button
MIC input
*Not all gamesare 1080p
34

CONNECTION GUIDES CONNECTION GUIDES
PlayStation 3and PlayStation 4
PS3 PS4
HDMI
HDMI
TV
1.
2.
3.
4.
5.
Make surethe PS3/PS4video/audiooutputsettings areset up correctly beforeyou
begin.
Connect the other endof the HDMI cable into HDMI-Cloner Box.
Connect HDMI-Cloner Box to TV via an HDMI cable.
Make sure gameplay is visible on TV screen.
Connect the HDD or USB stick to the USBporton HDMI-Cloner Box.
HDMI-Cloner Box
56

English
English
CONNECTION GUIDES CONNECTION GUIDES
Xbox 360 and Xbox One 1.
2.
Connect HDMI-Cloner Box from HDMI out to TV via an HDMI cable.
Connect Xbox 360/Xbox One to HDMI in on HDMI-Cloner Box via an HDMI cable.
3. Make sure gameplay is visible on TV screen.
XBOX TV 4. Connectthe
HDD or USB stick to the USBporton HDMI-Cloner Box .
HDMI HDMI
HDMI-Cloner Box
78

English
English
CONNECTION GUIDES CONNECTION GUIDES
Nintendo Wii 1.
2.
3.
Connect all devices by HDMI cables.
Make sure gameplayis visible on TV screen.
Connect the HDD or USB stick to the USBporton HDMI-Cloner Box.
Wii
TV
HDMI HDMI
HDMI-Cloner Box

910

English
English
CONNECTION GUIDES
Set-top box/DVD/Blu-ray player/PC HD video output devices
CONNECTION GUIDES
Your HDMI-Cloner Box cancapture any videofromanyvideosource/device and
all youneed is the right ports/connections!
HDMI HDMI
TV
1.
2.
3.
Connect HDMI-Cloner Box to TV via an HDMI cable.
Connect set-top box, DVD/Blu-ray player, PC or anyother device to HDMI-Cloner Box .
Connect the HDD or USB stick to the USBporton HDMI-Cloner Box.
HDMI-Cloner Box
11 12

English
English
The HDMI-Cloner Box LEDlightswillilluminatedifferentcolours/waysto indicatefunctions.
RECORDING/CAPTURE
How to:
1.
2.
3.
4.
5.
Switch On Power. The buttonLED will illuminate Blue or Green.
Connect aUSB storage device to the HDMI-Cloner Box USB port.
Prior to gameplay,press the REC button. Commencegameplay–
it is now recording.The RECbutton will illuminate.
When gameplayis completed,press theREC/STOPbutton to stop recording.
The REC LED will flash several times. DO NOT removethe USB device as the file
is being saved.The RECLEDwill turn off after the file is saved.
13 14
LED Status Chart
LEDred
POWER ON
LEDgreen
1080p/1080i
LEDblue
720p/others
LEDflashing
Recording/buffering

English
English
Supported resolutions
HDMI-ClonerBox
File saving
SAVING FILES
-
-
-
HDMI-Cloner Box will recordanew file when the previous file reaches acapacity
of 2GB.
When the HDD or USB storage is full, HDMI-Cloner Box stops recordingand theRECLED
will turn off.
HDMI-Cloner Box saves files in MPEG-4format.
Resolution
The resolution canbe set at either 720p or 1080p for capture. Please notethat not
all gamesare producedat 1080p.
Switch between 720p and 1080p
If you press the ON/OFF button once, it works as ON/OFF.
If you press (hold it for a few seconds, about 3-5 seconds), it works as a switch between 720p and 1080p.
Recording time
HDMI-Cloner Box will recordapproximately1GB per10mins at either 720p and
1080p.
16
Input/output
1920 x1080 (50p), 1920 x1080 (60p)
1920 x1080 (24p), 1920 x1080 (25p), 1920 x1080 (30p)
1920 x1080 (50i), 1920 x1080 (60i), 1280 x1024 (60p)
1280 x720p (60p), 1280 x768 (60p), 1280 x800 (60p)
720 x480 (60i), 720 x480 (50i)
640 x480 (60p), 720 x480 (60p), 720 x576 (50p)
Recording
1920 x1080 (24p), 1920 x1080 (25p), 1920 x1080 (30p)
1280 x720 (50p), 1280 x720 (60p)
640 x480 (60p), 720 x480 (60p), 720 x576 (50p)

English
English
PRODUCT SPECIFICATIONS
Microphone Function
For best quality voice recording, please use good quality microphone.
To control voice recording, please adjust the volume of HDMI input source.
18
Captureformat
MP4(H.264)
Video format (input)
NTSC,PAL,PAL-60
Supported recording format
FAT,FAT32, NTFS
Input signals
HDMI
Output signals
HDMI (pass-through)
USB 2.0
Bitrate
Max:16Mbps
Recordingcapacity
2GB maximumperfile
Note:
HDMI-Cloner Box will record several2GBfilesto
capturegreatercapacityin onesession.
Maximum storage capacity
2TB
Powersupply
DC 5V,2A
Weight
150g
Dimensions
112x112x25mm
